KlikAanKlikUit Trust SMART Home ZTHS-100 User manual
SMART Home
By:
USER MANUAL
Item 71247 Version 1.0
Visit www.trust.com/71247 for the latest instructions
TEMPERATURE AND
HUMIDITY SENSOR
ZTHS-100
5441
www.trust.com/zigbee
32
LED
indicator
A B
A
4 5
ZTSH-100 TEMPERATURE AND HUMIDITY SENSOR ENEN ZTSH-100 TEMPERATURE AND HUMIDITY SENSOR
COMPATIBILITY
The Temperature and Humidity sensor works with the Z1 ZigBee
Bridge and the ICS-2000. NOTE: For receiving push notifications, a
fully working internet connection is required.
1. (RE)PLACE THE BATTERIES
ARemove the backplate by sliding it from the sensor.
BHold the battery cover tightly and remove the battery pull strip
by pulling it from the sensor.
2. INDICATORS
The sensor contains a LED indicator to show the status of the
sensor. Please see below the meaning of the dierent LED
indications.
LED FUNCTION TABLE
Connection mode LED will flash fast for 1 min.
Connected successfully LED will light up for 3 sec (The App will also
indicate when the connection is successful)
Sensor reset LED will flash 6x
3. DOWNLOAD APP
To connect the sensor with a Z1
ZigBee bridge or ICS-2000, first
get the App by scanning the QR
code or go to trust.com/zigbee
and install it.
4. CONNECT SENSOR
AIn the App, select a room,
press the + button and choose
Zigbee (Trust Smart Home)/
Temperature and Humidity
sensor and follow the
instructions. For manual set up
of push-notifications go to the
rules tab, press the + button
and select notification wizard.
5. MOUNT THE SENSOR
ARemove the plastic layer
from the double sided-tape
on the back of the sensor
and place it on a flat service.
RESET SENSOR AND
ACTIVATE CONNECT MODE
Warning: This step will
disconnect the sensor from
the Z1 Zigbee Bridge or the ICS-
2000. To reset the sensor press
the button in the hole (with
the included pin) at the side for
approximately 5 sec with the
included pin. The LED will flash
6x to confirm the reset.
Activate connect mode: After
resetting the sensor you can
activate the connect mode by
pressing the button in the
hole on the side for approx.
2 sec. The LED will flash fast
for 1 minute to indicate the
connection mode.
www.trust.com/zigbee
