KLOCK WERKS Flare User manual

5. Use a plastic putty knife
or similar non-abrasive
tool, gently lift the nose of
the fairing off of the four
grommets in the lower
fairing.
6. Carefully remove front fairing
and set aside.
7. Use an 8mm wrench to loosen
the windshield mounting
screws and remove the stock
windshield.
3. Place a rag underneath
the mounting bolts to help
prevent them from falling
into the fairing.
8. Install your new Flare™
Windshield with the hardware
removed in step 7 and
torque fasteners to factory
specifications.
1. Remove mirror boots from
outer fairing.
2. Gently fold the mirrors
forward to expose the 6mm
fairing mount bolts.
4. Using a 10mm wrench,
remove the two mounting
bolts.
Reference your service manual for
proper windshield torque specs.
Over-tightening may crack windshield
material.
SEE PAGE 2 FOR VENT REPLACEMENT
FLARE™ WINDSHIELD FOR HONDA F6B
CUSTOMER COPY
- 10mm box end wrench
- 8mm nut driver or 8mm socket and ratchet
- plastic putty knife
TOOLS NEEDED FOR INSTALLATION:
Klock Werks Flare™ Windshield uses all of the
stock mounting hardware. Instructions lead you
through removing the stock shield and hardware,
and re-installing the Flare™.
NOTE:
KLOCK WERKS // GETKLOCKED.COM
Klock Werks cannot be held responsible for any damage resulting from improper installation performed by any consumer or their dealer.
QUESTIONS?
CALL: [phone]
[e-mail]
EMAIL:

1. Remove the two button head fasteners holding the vent
halves together
a. The vent shown uses a 3mm allen wrench and an
8mm socket
2. Disconnect the small plastic tab at the bottom of the vent
3. Rock the inner half up and off of the lip of the outer half and
the two pieces should release from the windshield
4. Install the vent in reverse order into your new Klock Werks
vented Flare™ windshield.
VENT REPLACEMENT
We tested many products, and found a company that would combine what we like and remove what we didn’t like to create a
complete Kleaning product line-up.
KLOCK WERKS KLEANING PRODUCTS
2312-F6B01R2 ©2016 KLOCK WERKS
