Knape&Vogt 8805 User manual

QD
LENGTH
10"
[254]
10"
[254]
10"
[254]
12"
[305]
12"
[305]
14"
[356]
14"
[356]
17"
[432]
17"
[432]
Product: Heavy-Duty Over-Travel Drawer Slide
Mounting: Side - Unhanded Slide and QD Rail
Clearance: .89" (+.030, -.000)
Load Rating: 200-Pound Class
Height: 2-9/32". Slide with QD 2-25/32".
Finish: Zinc Plated
Travel: 1" Over-Travel
Action: Telescopic
Hardware: Customer supplied mounting hardware
# 8 Panhead Wood Screws [Customer to determine length
of mounting hardware based on application.]
Sizes: 12", 14", 16", 18", 20", 22", 24", 26", 28"
Packaging: Bulk pack (8805B):
All Sizes .................................4 pair per box
Mounting hardware not included.
One set of installation instructions.
PATENT PENDING
(+ 0.03", - 0.00")
QD LENGTH
CROSS SECTION
KV 8805 Major Dimensions and Mounting Hole Locations
FRONT
REAR
8805
Heavy-Duty, Over-Travel Drawer Slide
Dimensions in [ ] are in millimeters
QD
LENGTH
10"
[254]
10"
[254]
10"
[254]
12"
[305]
12"
[305]
14"
[356]
14"
[356]
17"
[432]
17"
[432]
300960 0617
NOTE: This slide must never be used as a pullout step, platform or any other application supporting human weight as injury may result.
33.693
5
16
Figure A
Figure B
For Best Results, Read Instructions First!
These instructions show how to install the KV 8805 Drawer
Slide. Please note that improper installation may void the Knape
& Vogt Limited Lifetime Warranty.
To install the slides correctly, follow these instructions, use only
KV hardware, and make no modifications.
Mounting Instructions
1. Refer to Figure A for cabinet mounting hole locations. Use #8
panhead screws (not included) to secure slide to cabinet. Use
horizontal mounting holes first to allow for slide adjustments.
2. Refer to Figure B for drawer mounting hole locations. Use #8
panhead screws (not included) to QD rail to drawer. Use verti-
cal-mounting holes first to allow for adjustments.
3. Extend slides fully and insert drawer by lowering the rear of
the QD rail into “bayonet” tab (Figure C) and lower the front of
the drawer into the “belt-loop” pocket. The lock tab will snap
into place when drawer is properly inserted. Cycle slides to
determine if any adjustments are needed before securing the
slide to the cabinet and the disconnect rail to the drawer. Note:
A minimum of 4 screws must be used to secure each slide to
cabinet and each disconnect bracket to drawer (minimum of
16 screws).
4. To remove drawer extend slides fully and press in lock tab
from the outside and lift drawer from the front. Note: Make
sure the contents of the drawer are emptied before removing
the drawer.
Installation Instructions for:
8805 Heavy-Duty, Over-Travel Drawer Slide
Knape & Vogt Manufacturing Company • 2700 Oak Industrial Drive NE • Grand Rapids, MI 49505 USA • 800.253.1561 • www.kv.com
© 2017 Knape & Vogt Manufacturing Company • Made in Taiwan
KV 8805 QD Rail (unhanded)
300960 0617
Figure C
Belt Loop
Bayonet
Lock Tab
1-27/32
[46.8mm]
1-1/2"
[38.1mm]
INSTALL SCREWS
INTO VERTICAL
SLOTS FIRST
1-5/32
[29.4mm]
D
G - 2"
[G - 50.8mm]
SLIDE
C
L
(+ 0.03", - 0.00")
QD LENGTH
