These instructions should be read carefully and retained after installation by the end user for future
reference and maintenance.
These instructions should be used to aid installation of the following product:
OS0016
GENERAL INSTRUCTIONS
SAFETY
INSTALLATION
• Installation of this sensor should only be carried out by a qualified electrician or competent person
to the latest Building and current IEE Wiring Regulations (BS7671)
• Please isolate mains prior to installation/maintenance
• Check the total load on the circuit does not exceed the rating of the circuit cable, fuse or circuit
breaker
• Please note the IP (Ingress of Protection) rating of this sensor when deciding the location for
installation
• This product is Class II double insulated
• This product is IP20 rated
• Provide power to the required point of installation. Suitable IP rated junction boxes should be
used where required
• We recommend an installation height of between 2.2m and 4m
• Remove clear cable connections cover (see Fig 1)
• Cut an 80mm cut-out ensuring not to infringe with any joists, gas or water pipes or electrical
cables
• Connect the sensor to the luminaire and mains supply (via terminal connector) ensuring the
correct polarity is observed. See Fig 2 for the wiring diagram (Live (brown), Neutral (blue) and
Switched Live (A)
Fig 1
OS0016
Theseinstructionsshouldbereadcarefullyandretainedafterinstallationbytheenduserforfuturereferenceand
maintenance.
Theseinstructionsshouldbeusedtoaidinstallationofthefollowingproduct:
OS0016
SAFETY
• Installationofthissensorshouldonlybecarriedoutbyaqualifiedelectricianorcompetentpersontothe
latestBuildingandcurrentIEEWiringRegulations(BS7671)
• Pleaseisolatemainspriortoinstallation/maintenance
• Checkthetotalloadonthecircuit(includingwhenthisluminaireisfitted)doesnotexceedtheratingofthe
circuitcable,fuseorcircuitbreaker
• PleasenotetheIP(IngressofProtection)ratingofthisluminairewhendecidingthelocationforinstallation
• ThisproductisClassIIdoubleinsulated
• ThisproductisIP20rated
INSTALLATION
• Providepowertotherequiredpointofinstallation.SuitableIPratedjunctionboxesshouldbeusedwhere
required
• Werecommendaninstallationheightofbetween2.2mand4m
• Removeclearcableconnectionscover,seeFig1
Fig1
• Usingthesensorasatemplatemarkthelocationofthefixingholes,anddrilltheholesensuringnottoinfringe
withanyjoists,gasorwaterpipesorelectricalcables
• Connectthesensortotheluminaireandmainssupply(viaterminalconnector)ensuringthecorrectpolarityis
observed.SeeFig2forthewiringdiagram(Live(brown),Neutral(blue)andSwitchedLive(A))
Fig2
ANL
2
