Knightsbridge AC65 T8 HF Series Instruction Manual

1
52
INSTALLATION & MAINTENANCE MANUAL
AC65 T8 HF SERIES
230V
50Hz
IP
65
110V

2
These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following products:
AC65118 / AC65136 / AC65158 / AC651581 / AC65170 / AC65218 / AC65236 / AC65258 /AC652581
/ AC65270
GENERAL INSTRUCTIONS
SAFETY
INSTALLATION
• Installation of this luminaire should only be carried out by a qualified electrician or competent
person to the current Building and IEE Wiring Regulations (BS7671)
• Please isolate mains prior to installation/maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the
rating of the circuit cable, fuse or circuit breaker
• Please note the IP (Ingress of Protection) rating of this luminaire when deciding the location for
installation
• This product is Class I and requires an earth
• This product is IP65 rated
• Provide power to the point of installation
• Unfasten clips either side of the fitting (see Fig 1)
Part code LED tube size Length (ft) Length (mm)
AC65118 T8 2 653
AC65136 T8 4 1263
AC65158 / AC651581 T8 5 1563
AC65170 T8 6 1828
AC65218 T8X2 2 653
AC65236 T8X2 4 1263
AC65258 / AC652581 T8X2 5 1563
AC65270 T8X2 6 1828
AC65 T8 HF series
These instructions should be read carefully and retained after installation by the end user for future reference and
maintenance.
These instructions should be used to aid installation of the following products:
AC65118 / AC65136 / AC65158 / AC651581 / AC65170 / AC65218 / AC65236 / AC65258 / AC652581 / AC65270
Part code
LED tube size
Length (ft)
Length (mm)
AC65118
T8
2
653
AC65136
T8
4
1263
AC65158 / AC651581
T8
5
1563
AC65170
T8
6
1828
AC65218
T8 x2
2
653
AC65236
T8 x2
4
1263
AC65258 / AC652581
T8 x2
5
1563
AC65270
T8 x2
6
1828
SAFETY
•Installation of this luminaire should only be carried out by a qualified electrician or competent person to the
current Building and IEE Wiring Regulations (BS7671)
•Please isolate mains prior to installation/maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
•Please note the IP (Ingress of Protection) rating of this luminaire when deciding the location for installation
•This product is Class I and requires an earth
•This product is IP65 rated
INSTALLATION
•Provide power to the point of installation
•Unfasten clips either side of the fitting (see Fig 1)
Fig 1 (single fitting shown)
•Remove the diffuser
•Remove the baseplate by pinching the clips at two locations (see Fig 2)
Fig 2
Pinch at these points
Unfasten clips on both sides
Fig 1 (single fitting shown)

• Remove the diffuser
• Remove the baseplate by pinching the clips at two locations (see Fig 2)
• Referring to Fig 3, mark the location of the fixing holes and drill the holes ensuring not to
infringe with any joists, gas / water pipes or electrical cables
• Connect the Live (brown), Neutral (blue) and Earth (yellow and green) via the three-way terminal
connector (see Fig 4)
• Fit an appropriate T8 fluorescent tube
• Switch on power supply and check for correct operation
3
AC65 T8 HF series
These instructions should be read carefully and retained after installation by the end user for future reference and
maintenance.
These instructions should be used to aid installation of the following products:
AC65118 / AC65136 / AC65158 / AC651581 / AC65170 / AC65218 / AC65236 / AC65258 / AC652581 / AC65270
Part code
LED tube size
Length (ft)
Length (mm)
AC65118
T8
2
653
AC65136
T8
4
1263
AC65158 / AC651581
T8
5
1563
AC65170
T8
6
1828
AC65218
T8 x2
2
653
AC65236
T8 x2
4
1263
AC65258 / AC652581
T8 x2
5
1563
AC65270
T8 x2
6
1828
SAFETY
•Installation of this luminaire should only be carried out by a qualified electrician or competent person to the
current Building and IEE Wiring Regulations (BS7671)
•Please isolate mains prior to installation/maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
•Please note the IP (Ingress of Protection) rating of this luminaire when deciding the location for installation
•This product is Class I and requires an earth
•This product is IP65 rated
INSTALLATION
•Provide power to the point of installation
•Unfasten clips either side of the fitting (see Fig 1)
Fig 1 (single fitting shown)
•Remove the diffuser
•Remove the baseplate by pinching the clips at two locations (see Fig 2)
Fig 2
Pinch at these points
Unfasten clips on both sides
Fig 2
Fig 3
Fig 4
•Referring to Fig 3, mark the location of the fixing holes and drill the holes ensuring not to infringe with any
joists, gas / water pipes or electrical cables
Part code
L (mm)
L (ft)
A1 (mm)
AC65118 / AC65218
653
8
390
AC65136 / AC65236
1263
4
900
AC65158 / AC65258 / AC651581 / AC652581
1563
5
1000
AC65170 / AC65270
1828
6
1000
Fig 3
•Connect the Live (brown), Neutral (blue) and Earth (yellow and green) via the three-way terminal connector (see
Fig 4)
Fig 4
•Fit an appropriate T8 fluorescent tube
•Switch on power supply and check for correct operation
GENERAL
The unit should be recycled in the correct manner when it reaches the end of its life. Check local authorities for where
facilities exist
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the fitting
WARRANTY
This product has a warranty of 3 years from date of purchase. Failure to install this product in accordance with the current
edition of the IEE Wiring Regulations, improper use, or removal of the batch codes will invalidate the warranty. If this
product should fail within its warranty period it should be returned to the place of purchase for a free of charge
replacement. ML Accessories does not accept responsibility for any installation costs associated with the replacement
product. Your statutory rights are not affected. ML Accessories reserve the right to alter product specification without prior
notice.
Neutral (blue)
N
L
Live (brown)
E
Earth (green/yellow)
•Referring to Fig 3, mark the location of the fixing holes and drill the holes ensuring not to infringe with any
joists, gas / water pipes or electrical cables
Part code
L (mm)
L (ft)
A1 (mm)
AC65118 / AC65218
653
8
390
AC65136 / AC65236
1263
4
900
AC65158 / AC65258 / AC651581 / AC652581
1563
5
1000
AC65170 / AC65270
1828
6
1000
Fig 3
•Connect the Live (brown), Neutral (blue) and Earth (yellow and green) via the three-way terminal connector (see
Fig 4)
Fig 4
•Fit an appropriate T8 fluorescent tube
•Switch on power supply and check for correct operation
GENERAL
The unit should be recycled in the correct manner when it reaches the end of its life. Check local authorities for where
facilities exist
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the fitting
WARRANTY
This product has a warranty of 3 years from date of purchase. Failure to install this product in accordance with the current
edition of the IEE Wiring Regulations, improper use, or removal of the batch codes will invalidate the warranty. If this
product should fail within its warranty period it should be returned to the place of purchase for a free of charge
replacement. ML Accessories does not accept responsibility for any installation costs associated with the replacement
product. Your statutory rights are not affected. ML Accessories reserve the right to alter product specification without prior
notice.
Neutral (blue)
N
L
Live (brown)
E
Earth (green/yellow)
Part code L (mm) L (ft) A1 (mm)
AC65118 / AC65218 653 8 390
AC65136 / AC65236 1263 4 900
AC65158 / AC65258 / AC651581 / AC652581 1563 5 1000
AC65170 / AC65270 1828 6 1000

4
ML Accessories Limited
LU5 4LT
www.mlaccessories.co.uk SBAUG18_V1
GENERAL
WARRANTY
The unit should be recycled in the correct manner when it reaches the end of its life. Check local
authorities for where facilities exist
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may
damage the fitting
This product has a warranty of 3 years from date of purchase. Failure to install this product in
accordance with the current edition of the IEE Wiring Regulations, improper use, or removal of
the batch codes will invalidate the warranty. If this product should fail within its warranty period it
should be returned to the place of purchase for a free of charge replacement. ML Accessories does
not accept responsibility for any installation costs associated with the replacement product. Your
statutory rights are not affected. ML Accessories reserve the right to alter product specification
without prior notice.
