Knightsbridge LDGL Series Instruction Manual

1
INSTALLATION & MAINTENANCE MANUAL
LDGLxx
ACCESSORIES LTD ACCESSORIES LTD
ACCESSORIES LTD
ACCESSORIES LTD
02

2
These instructions should be read carefully and retained after installation by the end-user for
future reference and maintenance.
These instructions should be used to aid the installation of the following products:
LDGL5 / LDGL6 / LDGL9
GENERAL INSTRUCTIONS
SAFETY
INSTALLATION
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for installation
• This product is Class I and must be earthed
• This product series is IP65 rated
Note - If this luminaire is being used in conjunction with an external PIR or sensor, please confirm with the
manufacturer of the sensors that they are compatible with LED luminaires.
• Provide power to the required point of installation (refer to BS7671 for correct cabling methods). Suitable
IP rated junction boxes should be used where required
• The power source connections should be local and accessible via a suitable IP rated enclosure
• Cut a suitable hole in the mounting surface as per the cut-out details (see Fig. 1 and Tab. 1) ensuring not
to infringe with any joists, gas/water pipes or electrical cables
• Connect the luminaire to the mains supply ensuring that correct polarity is observed (see Fig. 2):
Live (Brown), Earth (Green/Yellow), Neutral (Blue)
Fig. 1 Tab. 1
LDGLxx INSTRUCTIONS
These instructions should be read carefully and retained after installation by the end-user for future reference and
maintenance.
These instructions should be used to aid the installation of the following products:
LDGL5 / LDGL6 / LDGL9
SAFETY
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
•Please isolate mains prior to installation or maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating
of the circuit cable, fuse or circuit breaker
•Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for
installation
•This product is Class I and must be earthed
•This product series is IP65 rated
INSTALLATION
Note - If this luminaire is being used in conjunction with an external PIR or sensor, please confirm with
the manufacturer of the sensors that they are compatible with LED luminaires.
•Provide power to the required point of installation (refer to BS7671 for correct
cabling methods). Suitable IP rated junction boxes should be used where required
•The power source connections should be local and accessible via a suitable IP rated enclosure
•Cut a suitable hole in the mounting surface as per the cut-out details (see Fig. 1 and Tab. 1)
ensuring not to infringe with any joists, gas/water pipes or electrical cables
Fig. 1
Tab. 1
Part Code
Cut-out "A"
With mounting sleeve
(mm)
Without mounting sleeve
(mm)
LDGL5
60
55
LDGL6
114
108
LDGL9
144
138
A
LDGLxx INSTRUCTIONS
These instructions should be read carefully and retained after installation by the end-user for future reference and
maintenance.
These instructions should be used to aid the installation of the following products:
LDGL5 / LDGL6 / LDGL9
SAFETY
•This product must be installed in accordance with the latest edition of the IEE Wiring Regulations
(BS7671) and current Building Regulations. If in any doubt, consult a qualified electrician
•Please isolate mains prior to installation or maintenance
•Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating
of the circuit cable, fuse or circuit breaker
•Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for
installation
•This product is Class I and must be earthed
•This product series is IP65 rated
INSTALLATION
Note - If this luminaire is being used in conjunction with an external PIR or sensor, please confirm with
the manufacturer of the sensors that they are compatible with LED luminaires.
•Provide power to the required point of installation (refer to BS7671 for correct
cabling methods). Suitable IP rated junction boxes should be used where required
•The power source connections should be local and accessible via a suitable IP rated enclosure
•Cut a suitable hole in the mounting surface as per the cut-out details (see Fig. 1 and Tab. 1)
ensuring not to infringe with any joists, gas/water pipes or electrical cables
Fig. 1
Tab. 1
Part Code
Cut-out "A"
With mounting sleeve
(mm)
Without mounting sleeve
(mm)
LDGL5
60
55
LDGL6
114
108
LDGL9
144
138
A

• We recommend not installing in areas where there is a high risk of flooding or areas where water may sit
on top of the fitting (see Fig. 3)
• Ensure a minimum of 300mm of drainage is put below the luminaire (see Fig. 4) and there must be
enough cable below the luminaire in order to carry out maintenance work (see Fig. 4 and Fig. 5)
• Switch on and check for correct operation
3
•Connect the luminaire to the mains supply ensuring that correct polarity is observed (see Fig. 2):
Live (Brown), Earth (Green/Yellow), Neutral (Blue)
Fig. 2 (LEDGL5 without mounting sleeve shown in image)
•We recommend not installing in areas where there is a high risk of flooding or areas where water
may sit on top of the fitting (see Fig. 3)
•Ensure a minimum of 300mm of drainage is put below the luminaire (see Fig. 4) and there must be
enough cable below the luminaire in order to carry out maintenance work (see Fig. 4 and Fig. 5)
•Switch on and check for correct operation
Live (Brown)
Earth (Green/Yellow)
Neutral (Blue)
Fig. 5
Fig. 4
Fig. 3
•Connect the luminaire to the mains supply ensuring that correct polarity is observed (see Fig. 2):
Live (Brown), Earth (Green/Yellow), Neutral (Blue)
Fig. 2 (LEDGL5 without mounting sleeve shown in image)
•We recommend not installing in areas where there is a high risk of flooding or areas where water
may sit on top of the fitting (see Fig. 3)
•Ensure a minimum of 300mm of drainage is put below the luminaire (see Fig. 4) and there must be
enough cable below the luminaire in order to carry out maintenance work (see Fig. 4 and Fig. 5)
•Switch on and check for correct operation
Live (Brown)
Earth (Green/Yellow)
Neutral (Blue)
Fig. 5
Fig. 4
Fig. 3
•Connect the luminaire to the mains supply ensuring that correct polarity is observed (see Fig. 2):
Live (Brown), Earth (Green/Yellow), Neutral (Blue)
Fig. 2 (LEDGL5 without mounting sleeve shown in image)
•We recommend not installing in areas where there is a high risk of flooding or areas where water
may sit on top of the fitting (see Fig. 3)
•Ensure a minimum of 300mm of drainage is put below the luminaire (see Fig. 4) and there must be
enough cable below the luminaire in order to carry out maintenance work (see Fig. 4 and Fig. 5)
•Switch on and check for correct operation
Live (Brown)
Earth (Green/Yellow)
Neutral (Blue)
Fig. 5
Fig. 4
Fig. 3
•Connect the luminaire to the mains supply ensuring that correct polarity is observed (see Fig. 2):
Live (Brown), Earth (Green/Yellow), Neutral (Blue)
Fig. 2 (LEDGL5 without mounting sleeve shown in image)
•We recommend not installing in areas where there is a high risk of flooding or areas where water
may sit on top of the fitting (see Fig. 3)
•Ensure a minimum of 300mm of drainage is put below the luminaire (see Fig. 4) and there must be
enough cable below the luminaire in order to carry out maintenance work (see Fig. 4 and Fig. 5)
•Switch on and check for correct operation
Live (Brown)
Earth (Green/Yellow)
Neutral (Blue)
Fig. 5
Fig. 4
Fig. 3
Fig. 2 (LEDGL5 without mounting sleeve shown in image)
Fig. 3 Fig. 4
Fig. 5

4
WARRANTY
This product has a warranty of 2 years from date of purchase. Failure to install this product in accordance
with the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch
code will invalidate the warranty. If this product should fail within its warranty period it should be returned
to the place of purchase for a free of charge replacement. ML Accessories does not accept responsibility for
any installation costs associated with the replacement product. Your statutory rights are not affected. ML
Accessories reserve the right to alter product specification without prior notice.
ML Accessories Limited
LU5 4LT
www.mlaccessories.co.uk AVAUG19_V3
ACCESSORIES LTD ACCESSORIES LTD
ACCESSORIES LTD
ACCESSORIES LTD
WARNING
GENERAL
This luminaire must be disconnected from the circuit if subjected to any high voltage or insulation resistance
testing. Irreparable damage will occur if this instruction is not followed.
The LED lamps fitted in this product are non-replaceable. The product should be recycled in the correct
manner when it reaches the end of its life. Check local authorities for where facilities exist.
Clean with a soft dry cloth only, do not use aggressive cleaning products or solvents which may damage the
product.
Do not use any source of high-pressure washers to maintain or clean this product.
This product is not suitable for installation in or near a coastal or marine environment.
A light film of acid-free oil is recommended after installation and maintained periodically (2-3 times a year) to
aid corrosion prevention.
This product is non-dimmable.
