Koala JOEY WOMBAT Manual

WOMBAT CHEST OF DRAWERS INSTRUCTION GUIDE














 









Scan the QR
code to watch the
assembly video
Configuration

What’s in the box
Drawer Side
Panel x6
Drawer Base
Panel x3
Base
Support x3
Drawer Rear
Panel x3
Drawer Front
Panel x3
Rear Panel x1 Cross Brace x1Top Panel x1Side Panel x2
Gumnut x4 Fasteners x8
Dowel x4
Wall Mounting
Lanyard x2
Wall Mounting
Gumnut x2

Lay out the parts in the desired orientation for the room.
A. Frame
Step 1A: Align side panel hooks with the back panel slots. Push the back
panel down to ensure they are locked in. Repeat steps for the other side.
x2
x1

A. Frame
Step 2A: Attach the cross brace to the side panels by aligning the
brackets on the ends and pushing down.
A. Frame
Step 3A: Insert dowels into the side panel.
x1
x4

A. Frame
Step 4A: Lower the top panel carefully into position.
Note: Make sure the wall lanyard hole threads are facing the back.
A. Frame
Step 5A: Using the gumnuts provided, secure the top panel to the side panels.
x4
x1

A. Chest of Drawers - Frame
B. Drawer
Step 6B: Attach the side panel to the drawer front panel. Repeat for other side.
Ensure base panel
slot are aligned
x2
x1

B. Drawer
Step 7B: Insert the base support panel into the front panel.
B. Drawer
Step 8B: Slide the base panel into the pre-cut grooves as one person holds
the side panels in place.
x1
Ensure the board is sitting
flush in the groove
x1
Note: This is a two-person assembly.

B. Drawer
Step 9B: Attach the rear panel by aligning the side panel first and then sliding
the base support dowels to the real panel. Ensure the base panel is also in the
pre-cut grooves.
B. Drawer
Step 10B: Push the side joints into the back panel joints and ensure the edges
are flush. Repeat for the other side.
x1

B. Drawer
Step 11B: Complete the drawer assembly by inserting the fasteners into the
drawer panels.
Repeat steps 6-11 for other two drawers.
B. Chest of Drawers - Drawer
x8

Drawer configuration - Stickers indicate drawer position.
B. Drawer
Step 12B: Extend the bottom drawer sliders out of the main frame.
Top
Middle
Bottom

B. Drawer
Step 13B: Insert the drawer runners into the extended drawer sliders. Push the
drawer into the frame untill you hear a click.
B. Drawer
Step 14B: Repeat steps 12 & 13 for the middle drawer.
Note: Gently open and shut the drawer a
few times to make sure the drawer runners
are fitted properly.

B. Drawer
Step 15B: Repeat steps 12 & 13 for the top drawer.
B. Drawer
Step 16B: Secure the wall mounting lanyards to the back of the chest of drawers
using the gumnuts provided.
x2
x2
Note: Attach the wall mounting lanyards to the wall.
To avoid damage to yourself, your property, or your landlords, please seek advice
from a qualified tradesperson on how to attach the restraints to your wall.

Chest of Drawers

Manufactured for Koala Sleep Pty Ltd
Website: koala.com
Phone: [phone]
Address: Unit 12 37-41 O’Riordan Street, Alexandria,
NSW 2015, Australia
Date of launch - 03/2023
SKU-109-0003
REV1.1
