Koala KIRRIBILLI User manual

Kirribilli Console
Clickthe button
to watch the
assembly video

top panel
x1
shelf
x2 drawer
x1 gumnut
x8
dowel
x4
leg
x2
back panel
x1
gumnut
x2 wall mount lanyard
x2
What’s in the box*:
*Not to scale
Clickthe button
to watch the
assembly video

1.
2.
lay the top of the console on a soft surface
to avoid damaging the finish
push the dowels into the holes
!
NOTE - Make sure lip is
facing down
Clickthe button
to watch the
assembly video

3.
4. slide in the back panel using the slots in the leg and top panel
fix one leg into position using the dowels.
ensure the top panel slot and leg slot align
Clickthe button
to watch the
assembly video

5.
6.
x4
fasten the leg down using the
gumnuts provided
Clickthe button
to watch the
assembly video

7.
8. flip console into the upright position
x4
fasten the leg down using the
remaining gumnuts provided
Clickthe button
to watch the
assembly video

9.
10.
attach bottom shelf using the brackets.
repeat for top shelf
extend the drawer railings out. take note of the rear hooks and the
dowel on the drawer runners
extend the tabs
on both runners
Clickthe button
to watch the
assembly video

11.
12.
carefully place the drawer onto the
drawer runner at an angle.
ensure drawer is securely fitted by gently
opening and closing the drawer
to mount console to the wall, fasten the lanyards using the
gumnuts provided
ensure the rear hook
of the runner goes
into the hole of the
back drawer align hole at front of
drawer with dowel
on runner
Clickthe button
to watch the
assembly video

don’t forget to recycle.
