OPER ATOR’S MANUAL
KOBE
ORDER CODE KBE-828-0120K
2kW FLAT FAN HEATER
© The Kennedy Group Ltd. 06/09
AVAILABLE FROM YOUR DISTRIBUTOR
QUALITY GUARANTEE & WARRANTY
KOBE ELECTRICAL GOODS carry one years manufacturers warranty.
KOBE ELECTRICAL GOODS are designed & manufactured
to the highest standards & specifications
Assuring the quality and performance required by all sectors of industry.
KOBE ELECTRICAL GOODS are fully guaranteed against
faulty materials & workmanship
Should they be found to be defective, they will either be repaired or replaced free of charge
(fair wear and tear and/or misuse excepted).
Please retain supplier invoice as proof of purchase.
Read all of this manual before using your heater and
retain for future reference
•2 heat settings - 1000W & 2000W
•Variable heat thermostat with frost protection
•Cooling fan setting
•Safety overheat cutout
•Power Indicator light
KOBE
ELECTRICAL
APPLIANCES
SPECIFICATION
Manufactured For:
KENNEDY TOOLS
Wigston Works, Leicester, England.
ISO 9001 REGISTERED COMPANY
The Declaration of Conformity and Technical File
for this product is held by The Kennedy Group
Ltd. The Technical File may be inspected by a
national authority upon request.
POWER CONSUMPTION ................................................................................... 1000W & 2000W
FREQUENCY ................................................................................................................. 50~60Hz
VOLTAGE .............................................................................................................. 220 - 240V AC
KBE-828-0090K
KBE-828-0050K
MODEL FFH202
KBE-828-0070K
KBE-828-0080K
KBE-828-0120K_Instructions.qxd 25/06/2009 10:38 Page 1

Parts description
1. Air inlet Grill
2. Thermostat Control Switch
3. Heat Select Switch
4. Air Outlet Grill
KOBE
ELECTRICAL
APPLIANCES
KOBE
ELECTRICAL
APPLIANCES
SAFETY INSTRUCTIONS OPERATION OF YOUR HEATER
You have purchased a quality product that is designed for high
performance and long service life. If correct use, safety and maintenance
procedures are observed this product will last for many years.
Thankyou for choosing our KOBE Fan Heater. Your new heater has been designed using the
latest technology. With normal maintenance, your heater will provide years of satisfactory
performance. Please read this Owner's Manual carefully before using and
save it for future reference.
GENERAL SAFETY
When using electrical appliances, basic precautions
should always be followed to reduce the risk of fire,
electric shock and injury to persons, including the
following:
The heater is only intended for private domestic
non-commercial use, as described below. Any other
uses not recommended by the manufacturer may
cause fire, electric shock or injury to persons and
void warranty.
Remove the heater from its packaging and check to
make sure it is in good condition before using.
Keep the packaging for storage/transportation.
Do not let children play with parts of the packing
(such as plastic bags).
Ensure the power supply to the socket into which
the heater is plugged is in accordance with the
rating label on the heater and that the socket is
earthed.
Do not use the heater if the power cord is damaged.
If the power cord is damaged it must be replaced
by a recognized service agent or other qualified
person. If the plug is damaged, see Plug Fitting
details below.
Do not run the cord under carpeting. Do not cover
the cord with throw rugs, runners or the like.
Arrange the cord away from traffic area where it
may be tripped over.
Keep the mains lead away from the heat outlet grill
of the heater.
Always place the heater on a firm level surface to
avoid it falling over blocking the air inlet/outlet. Do
not place the heater on carpets having a very deep
pile.
Always turn off the power before unplugging the
heater and make sure your hands are dry to
prevent electric shock.
Do not use the heater in areas where flammable
liquids are stored or where flammable fumes may
be present.
The heater is not intended for use in bathrooms,
laundry areas or similar indoor locations. Never
place the heater where it may fall into a bathtub or
other water container.
Do not use outdoors.
Do not use near or point the heater at furniture,
curtains or other flammable objects. Keep the back
of the fan heater a minimum of 15cm away from
walls or objects to allow free airflow.
Do not block air inlet or outlet in any manner to
prevent possible fire.
Always unplug the heater when not in use.
Do not insert any object through the heat outlet or
air intake grills of the heater.
Particular care should be taken when the heater is
situated in areas occupied by children or invalids.
KOBE
ELECTRICAL
APPLIANCES
CARE OF YOUR HEATER
Flat Fan Heater with thermostat FFH202
Choose a suitable location for the heater, taking
into account the safety instructions opposite.
Insert the plug of the heater into a suitable
socket.
Turn the thermostat knob fully in a clockwise
direction to the maximum setting.
Turn on the heating element using the rotational
switch (3) to select either 1kw or 2kw. When
the heater is on, the indicator light will be
illuminated.
When the desired room temperature has been
reached, the thermostat knob should be turned
slowly anti-clockwise until the thermostat is
heard to click off and the indicator light is seen
to go out. After this the heater will keep the air
temperature in the room at the set temperature
by switching on and off automatically.
In it’s minimum (fully anti-clockwise) position,
the thermostat provides a frost guard position.
In this position (depending on the size of the
room) the heater will maintain the temperature
above freezing.
CLEANING THE HEATER
Always unplug the heater from the wall
socket and allow it to cool down before
cleaning.
Clean the outside of the heater by wiping
with a damp cloth and buff with a dry cloth.
Do not use any detergents or abrasives
and do not allow any water to enter the
heater.
STORING THE HEATER
When the heater is not used for long
periods of time it is best stored in it’s
original box or should be protected from
dust and stored in a clean dry place.
Note: It is normal when the heater is turned on for the first time or when it has been turned on
after having not been used for a long period of time that it may emit some smell and fumes. This
will disappear when the heater has been on a short while.
Yellow & Green = Earth wire
Cable restraint
BS4343 3 Pin Plug
13A
Brown = Live wire
Blue = Neutral wire
PLUG FITTING
A moulded UK 3 pin plug with ASTA/BS approval is already fitted for your safety.
If it becomes damaged, and needs replacing, cut off the plug and prepare the wires.
Use the following instructions:
a) The power cord and/or the plug should only be replaced by a qualified electrician or
professional technician.
b) Connect the BROWN live wire to the live terminal marked ‘ L’ or coloured black or
blue.
c) Connect the BLUE neutral wire to the neutral terminal marked ‘ N’ or coloured red or
brown.
d)
GREEN/YELLOW earth wire is normally connected to the earth terminal marked either
‘ E’ or with the earth symbol‘ ’. This is not required as this product is double insulated.
d) After wiring, check there are no bare wires, that all wires have been correctly
connected, that the cable external insulation extends beyond the cable restraint
and that the restraint is tight.
1 2
4 3
Heat Setting (Parts description 3.)
The fan heater incorporates a rotation
switch to select either:
O = OFF
= Cool Air
= Warm Air (1000W)
= Hot Air (2000W)
