KOBE KLF010 User manual

© The Kennedy Group Ltd. 11/19
QUALITY GUARANTEE & WARRANTY
KOBE ELECTRICAL APPLIANCES carry a one year manufacturer’s warranty.
KOBE ELECTRICAL APPLIANCES are designed & manufactured
to the highest standards & specifications
Assuring the quality and performance required by all sectors of industry.
KOBE ELECTRICAL APPLIANCES are fully guaranteed against
faulty materials & workmanship
Should they be found to be defective, they will either be repaired or replaced free of charge (fair wear and
tear and/or misuse excepted).
Please retain supplier invoice as proof of purchase.
KOBE TOOLS OFFICIAL AGENT: THE KENNEDY GROUP LTD, P.O. BOX 14, WIGSTON, LEICESTER, ENGLAND, LE18 1AT.
KOBE
ELECTRICAL
APPLIANCES
THE ENVIRONMENT
Always dispose of unwanted tools, accessories and packaging materials in an environmentally
friendly manner.
In observance of the European Directive on Waste Electrical and Electronic Equipment (WEEE) and
its implementation in accordance with national law, electrical goods that have reached the end
of their life must be collected separately and returned to an environmentally compatible recycling
facility.
Do not dispose of electrical goods with domestic waste materials as inappropriate disposal may
cause potential hazards to the environment and human health.
For further information, please contact your local authority or the retailer from whom you purchased
the product.
This product does not contain any restricted substances in concentrations and applications which
are banned by the European RoHS2 Directive.
DECLARATION OF CONFORMITY
We hereby certify that RECHARGEABLE COB LED PORTABLE WORKLIGHT
(ORDER CODE: KBE-282-5500K)
complies with all the relevant provisions of the
Low Voltage Directive 2014/35/EU
Standards Applied:
EN 60598-2-5:1998, EN 60598-1:2015, EN 62493:2015, EN 60598-2-4:1997,
EN 62031:2008+A1:2013+A2:2015, EN 62471:2008
EMC Directive 2014/30/EU
Standards Applied:
EN 55015:2013, EN 61547:2009, EN 61000-3-3:2013,
EN 61000-3-2:2014
Restriction of the use of certain hazardous substances (RoHS2) 2011/65/EU
Standards Applied:
EN 50581-1:2012
RECHARGEABLE COB LED 10W
PORTABLE WORKLIGHT
Read all of this manual before using your site light and
retain for future reference
KOBE
OPERATOR’S MANUAL
WARNING: THE SAFETY INFORMATION GIVEN INSIDE MUST BE
READ AND UNDERSTOOD BY ANY PERSON USING, INSTALLING,
REPAIRING OR MAINTAINING THESE PRODUCTS.
ORDER CODE
KBE-282-5500K
l Eco-friendly COB LED with low consumption,
90% energy saving when compared with
ordinary floodlights
l700Lms delivers purer white light than halogen
l2 chargers included (12V & 240V) along with
4 types of universal international plug adapters
l 5 hours charging time and 3 hours
working time
lSupplied with steel stand and has
an adjustable head to light up out of
reach areas
lBeamangleof120˚
lLight produces minimal heat and is ideal
for working in small spaces
lAluminium die-cast alloy body with
stainless steel external fixings and
toughened glass
lSuitable for outdoor use with IP65 rating
l10W COB LED is equivalent to 100W Halogen
MODEL
KLF010
Signed:
Date: 11 November 2019
Name: Toni Johnson
Position: Compliance Director
KOBE TOOLS
P.O. Box 14, Wigston, Leicester, England, LE18 1AT.

2 7
NOTES

6 3
KOBE
ELECTRICAL
APPLIANCES
SAFETY INSTRUCTIONS
KOBE ELECTRICAL APPLIANCES have been specifically designed to help you work SAFELY
and EFFICIENTLY. Your care and good judgement are the best protection against injury, but always ensure
that the appropriate safety equipment is worn. All possible hazards cannot be covered here, but the most
important ones have been highlighted.
You have purchased a quality product that is designed for high performance
and long service life. If correct use, safety and maintenance procedures are
observed this machine will last for many years.
lAlways adhere to the processes and safety
warnings, which are stated in the instruction
manual.
GENERAL OPERATING HAZARDS
lNever allow routine to lead to mistakes.
lNever operate if any parts are missing or
damaged.
lNever allow untrained persons to operate the
tool.
WORKPLACE HAZARDS
lAlways ensure your working area is clean and
well lit.
lWhen working at height make sure that the tool
is safely secured and be aware of objects falling
below. Make sure that no persons are working
directly below the working area.
lDo not operate in explosive atmosphere, for
instance extreme dust, gases and liquids.
lKeep children and bystanders away while
operating the tool. Distractions can cause you to
lose control.
l Never run the tool in areas exposed to water or
in damp conditions.
PERSONAL PROTECTION
lAlways wear approved eye protection during
operation. Use safety glasses or goggles which
conform to BSEN136 or CE equivalent that
provide protection from the front and side. The
operator of the power tool is responsible for
following accepted eye, face, respiratory, hearing
and body protection.
lAlways ensure that all long hair and loose clothing,
ties, scarves, jewellery, etc, are secured or
removed.
lAlways consult a doctor if numbness, tingling,
pain or whitening of the skin occurs. Repetitive
work motions, awkward positions and exposure
to vibration can cause “Repetitive Strain
Injuries”.
lWhen operating the tool stay alert and use
common sense, especially when it comes to
working at height. Be aware of what’s below you.
lDo not overreach. Keep a proper balance and
footing at all times.
lDo not use the tool if under the influence of
alcohol, drugs or medication.
SPECIFIC SAFETY INSTRUCTIONS
l Replace or repair damaged power cords
immediately.
l Replace or repair damaged or missing lenses
immediately.
lRefer all servicing of electrical parts to a qualified
electrician.
lProtect power cords from contact with sharp
objects, chemicals or hot surfaces.
lDo not operate light around standing water.
lDo not direct light at persons or look directly into
the light beam.
CAUTION
This product has been carefully designed for its
intended purpose. It must not be modified in
any way. Any alterations may invalidate product
approvals and your insurance.
NOTES

BEFORE OPERATING THE FLOODLIGHT, PLEASE ENSURE THAT ALL SAFETY INSTRUCTIONS HAVE BEEN
READ AND UNDERSTOOD, AND THE LIGHT HAS BEEN ASSEMBLED CORRECTLY FOLLOWING THE BELOW
GUIDELINES.
ASSEMBLY:
1. Fix the floodlight body (7) securely to the stand (3) by locating and tightening the thumb screw (4).
OPERATING:
1. Before first use, ensure the floodlight has been fully charged (See charging section below).
2. Direct the lens away from your eyes before switching on.
3. To turn the floodlight on press the rocker switch (5) into the “ ” position.
4. To turn off press the rocker switch (5) into the “0” position.
5. To adjust the floodlight head make sure the floodlight is off. Then loosen the thumb screws (4).
6. Tilt the floodlight head into required position then tighten the thumb screws (4) to secure position.
KOBE
ELECTRICAL
APPLIANCES
OPERATING
54
Time required to fully charge the battery is 5 hours.
Battery operation time, up to 3 hours
l Charge the battery before use, ensuring floodlight is turned off during charging.
l AC/DC ADAPTER: Connect the charger into the charge socket at the back of the floodlight (6), then
plug the mains plug into the power supply.
l CAR ADAPTER: Plug the charger into the charge socket at the back of the floodlight (6), and plug the
car charger into the cigarette lighter socket in your car (lorry or boat). Note: Charging the floodlight from a
12V vehicle socket will drain the vehicle’s battery unless the engine is running.
The red LED on the charger will illuminate to indicate that charging is taking place.
NB: When charging is complete (approx 5 hours), the charging indicator will turn green.
Disconnect the charger from the lamp when it has been sufficiently charged.
KOBE
ELECTRICAL
APPLIANCES
CHARGING
Use only a mild soap and a damp cloth to clean the floodlight. Never let any liquid get inside the floodlight.
Never immerse any part of the floodlight into water or a liquid. Make sure the floodlight is completely dry
before using it.
To assure product safety and reliability, repairs, maintenance and adjustment should be performed by a
qualified engineer, always using identical replacement parts.
KOBE
ELECTRICAL
APPLIANCES
MAINTENANCE
Order code . . . . . . . . . . . . . . . . . . KBE-282-5500K
Model number . . . . . . . . . . . . . . . . . . . . . KPW010
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10W
Lumen output . . . . . . . . . . . . . . . . . . . . . >700Lm
Charging time* . . . . . . . . . . . . . . . . . . . . . . . 5hrs
Operating time . . . . . . . . . . . . . . . . . . . . . . . 3hrs
Operating temperature . . . . . . . . . . . . -20˚C˜45˚C
Input voltage . . . . . . . . . . . . . . . . . . . . . . 8.4V DC
Adapter input . . . . . . . . . . . 100-240V AC 50/60HZ
Emitting colour . . . . . . . . . . . . . . . . White (6500K)
Moisture protection . . . . . . . . . . . . . . . . . . . . IP65
Beam angle . . . . . . . . . . . . . . . . . . . . . . . . . . 120˚
Net weight . . . . . . . . . . . . . . . . . . . . . . . . . 1.08kg
Dimensions . . . . . . . . . .250(H) x 145(W) x 165(D)mm
ELECTRICAL DATA
In the United Kingdom, the ELECTRICITY AT WORK ACT 1989 requires all portable electrical appliances, if
used on business premises, to be tested by a qualified electrician, using a Portable Appliance Tester (PAT),
at least once a year.
The HEALTH & SAFETY AT WORK ACT 1974 makes owners of electrical appliances responsible for the
safe condition of the appliance and the safety of its operator. If in any doubt about electrical safety, contact
a qualified electrician.
ELECTRICAL SAFETY
An RCCB (Residual Current Circuit Breaker) should be fitted in the mains electricity distribution board. If the
power supply is not protected by an RCCB, it is highly recommended that an RCD (Residual Current Device)
is used with all portable electrical products.
KOBE
ELECTRICAL
APPLIANCES
ELECTRICAL SAFETY
KOBE
ELECTRICAL
APPLIANCES
SPECIFICATIONS
It is recommended that you save the packaging material for future transportation of the Portable Floodlight
in the event of service or repair.
Packaging materials, especially bags, must be kept well away from babies and children.
KOBE
ELECTRICAL
APPLIANCES
UNPACKING
KOBE
ELECTRICAL
APPLIANCES
IDENTIFICATION
1. COB LED
2. Padded Handle
3. Stand
4. Angle adjustment
thumb screws
5. On/off button
6. Jack inlet
7. Floodlight body 6
1
4
5
4
4
2
3
7
