Kobold DAG-A4T Series User manual

Operating Instructions
for
Digital Indicating Unit
Thermocouple Type K, B, S, N, E, T, R, L, J
Model: DAG-A4T…, 96 x 48 mm

DAG-A4T
page 2 DAG-A4T K06/0523
We don’t accept warranty and liability claims neither upon this publication nor in
case of improper treatment of the described products.
The document may contain technical inaccuracies and typographical errors. The
content will be revised on a regular basis. These changes will be implemented in
later versions. The described products can be improved and changed at any time
without prior notice.
© Copyright
All rights reserved.
1. Contents
1.Contents ........................................................................................................ 2
2.Note .............................................................................................................. 3
3.Instrument Inspection .................................................................................... 4
4.Regulation Use ............................................................................................. 4
5.Assembly ...................................................................................................... 5
6.Electrical connection ..................................................................................... 6
7.Function and operation description ............................................................... 7
8.Setting up the device ..................................................................................... 8
8.1Switching on ........................................................................................ 8
8.2Standard parameterization ................................................................... 8
8.3Extended parameterization ................................................................ 10
9.Functional principle of the set points ........................................................... 12
10.Factory settings ........................................................................................... 13
10.1Default values .................................................................................... 13
10.2Reset to default values ...................................................................... 13
11.Technical Information .................................................................................. 14
12.Order Codes ............................................................................................... 14
13.Safety advice .............................................................................................. 15
14.Error elimination .......................................................................................... 16
15.Disposal ...................................................................................................... 17
16.EU Declaration of Conformance ................................................................. 18
17.UK Declaration of Conformity ...................................................................... 19
Manufactured and sold by:
Kobold Messring GmbH
Nordring 22-24
D-65719 Hofheim
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.kobold.com

DAG-A4T
DAG-A4T K06/0523 page 3
2. Note
Please read these operating instructions before unpacking and putting the unit into
operation. Follow the instructions precisely as described herein.
The instruction manuals on our website www.kobold.com are always for currently
manufactured version of our products. Due to technical changes, the instruction
manuals available online may not always correspond to the product version you
have purchased. If you need an instruction manual that corresponds to the
purchased product version, you can request it from us free of charge by email
([email protected]) in PDF format, specifying the relevant invoice number and
serial number. If you wish, the operating instructions can also be sent to you by
post in paper form against an applicable postage fee.
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
The devices are only to be used, maintained and serviced by persons familiar with
these operating instructions and in accordance with local regulations applying to
Health & Safety and prevention of accidents.
When used in machines, the measuring unit should be used only when the
machines fulfil the EC machinery directive.

DAG-A4T
page 4 DAG-A4T K06/0523
3. Instrument Inspection
Instruments are inspected before shipping and sent out in perfect condition.
Should damage to a device be visible, we recommend a thorough inspection of the
delivery packaging. In case of damage, please inform your parcel service /
forwarding agent immediately, since they are responsible for damages during
transit.
Scope of delivery:
The standard delivery includes:
 Digital Indicating Unit model: DAG-A4T
4. Regulation Use
Any use of the device, which exceeds the manufacturer’s specification, may
invalidate its warranty. Therefore, any resulting damage is not the responsibility of
the manufacturer. The user assumes all risk for such usage.

DAG-A4T
DAG-A4T K06/0523 page 5
5. Assembly
Please read the Safety advice on page 12 before installation and keep this user
manual for future reference.
1. After removing the fixing elements, insert the device.
2. Check the seal to make sure it fits securely.
3. Click the fixing elements back into place and tighten the clamping screws by
hand. Then use a screwdriver to tighten them another half a turn.
CAUTION! The torque should not exceed 0.1 Nm!
The dimension symbols can be exchanged before installation via a channel
on the side!

DAG-A4T
page 6 DAG-A4T K06/0523
6. Electrical connection
Advice:
The galvanic insulation in devices with temperature sensors that do not have a
galvanic connection to an extrinsic potential, can be cancelled by a bridge from
terminal 3 to 4 and this stabilize the device against external failures.
Devices with a VAC supply need a connection from terminal 3 to signal ground.
DAG-
A
4T0
DAG-A4T4
DAG-
A
4T2
with power supply 230 VAC
with power supply 115 VAC
with
p
ower su
pp
l
y
24 VAC
DAG-
A
4T3 with power suppl
y
24 VDC
Powe
r
Supply
230 VAC or
115 VAC or
24 VAC

DAG-A4T
DAG-A4T K06/0523 page 7
7. Function and operation description
Operation
The operation is divided into two different levels.
Menu-Level
Here it is possible to navigate between the individual menu items.
Parameterization-Level
The parameters stored in the menu item can be parameterized here. Functions
that can be adjusted or changed are always indicated with a flashing of the display.
Adjustments made at the parameterization level should be always confirmed by
pressing the [P] key to save them. However, the display automatically saves all
adjustments and then switches to operation mode if no further keys are pressed
within 10 seconds.

DAG-A4T
page 8 DAG-A4T K06/0523
8. Setting up the device
8.1 Switching on
Once the installation is complete, you can start the device by applying the current
loop. Check beforehand once again that all the electrical connections are correct.
Starting sequence
For 1 second during the switch-on process, the segment test (8 8 8 8) is displayed,
followed by an indication of the software type and, after that, also for 1 second, the
software version. Afte the start-up sequence, the device switches to operation /
display mode.
8.2 Standard parameterization
To be able to parameterize the display, press the [P] key in operating mode for 1
second. The display then changes to the menu level with the first menu item TYPE.

DAG-A4T
DAG-A4T K06/0523 page 9

DAG-A4T
page 10 DAG-A4T K06/0523
8.3 Extended parameterization
By pressing the [ ] & [ ] buttons during standard parameterization for 1 second,
the display switches to the extended parameterization mode. Operation is the
same as in standard parameterization.

DAG-A4T
DAG-A4T K06/0523 page 11

DAG-A4T
page 12 DAG-A4T K06/0523
9. Functional principle of the set points
Alarms / optical setpoint display
An activated set point can be optically indicated by flashing of the 7-segment
display.
Limit value exceedance
„High“
By limit value exceedance the
alarm S1-S2 is off below the
threshold and on on reaching
the threshold.
Limit value undercut
„Low“
By limit value undercut the
alarm S1-S2 is on below the
threshold and switched off on
reaching the threshold.

DAG-A4T
DAG-A4T K06/0523 page 13
10. Factory settings
10.1 Default values
10.2 Reset to default values
To return the unit to a defined basic state a reset can be carried out to the default
values.
The following procedure should be used:
 Switch off the power supply 

Press the button [P] 

Switch on voltage supply and press [P] button until “- - - -“ is shown in the
display. 
With reset, the default values of the program table are loaded and used for
subsequent operation. This puts the unit back to the state in which it was supplied.
Caution! All application-related data are lost.
Parameter Menu items Default
to
or
to
to
to
to
to
to
to
to

DAG-A4T
page 14 DAG-A4T K06/0523
11. Technical Information
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
12. Order Codes
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com

DAG-A4T
DAG-A4T K06/0523 page 15
13. Safety advice
Please read the following safety advice and the assembly chapter 5 before
installation and keep it for future reference.
Proper use
The DAG-A…-device is designed for the evaluation and display of sensor signals.
Danger! Careless use or improper operation can result in
personal injury and / or damage to the equipment.
Control of the device
The panel meters are checked before dispatch and sent out in perfect condition.
Should there be any visible damage, we recommend close examination of the
packaging. Please inform the supplier immediately of any damage.
Installation
The DAG-A…-device must be installed by a suitably qualified specialist (e.g.
with a qualification in industrial electronics).
Notes on installation
 There must be no magnetic or electric fields in the vicinity of the device, e.g. due
to transformers, mobile phones or electrostatic discharge.
 The fuse rating of the supply voltage should not exceed a value of 0.5 A N.B.
fuse.
 Do not install inductive consumers (relays, solenoid valves etc.) near the
device and suppress any interference with the aid of RC spark extinguishing
combinations or free-wheeling diodes.
 Keep input, output and supply lines separate from one another and do not lay
them parallel with each other. Position “go” and “return” lines next to one
another. Where possible use twisted pair. So, you receive best measuring
results.
 Screen off and twist sensor lines. Do not lay current-carrying lines in the vicinity.
Connect the screening on one side on a suitable potential equalizer (normally
signal ground).
 The device is not suitable for the installation in areas where there is a risk of
explosion.
 Any electrical connection deviating from the connection diagram can endanger
human life and / or can destroy the equipment.
 The terminal area of the devices is part of the service. Here electrostatic
discharge needs to be avoided. Attention! High voltages can cause dangerous
body currents.
 Galvanic insulated potentials within one complex need to be placed on a
appropriate point (normally earth or machines ground). So, a lower disturbance
sensibility against impacted energy can be reached and dangerous potentials,
that can occur on long lines or due to faulty wiring, can be avoided.

DAG-A4T
page 16 DAG-A4T K06/0523
14. Error elimination

DAG-A4T
DAG-A4T K06/0523 page 17
15. Disposal
Note!
 Avoid environmental damage caused by media-contaminated parts
 Dispose of the device and packaging in an environmentally friendly manner
 Comply with applicable national and international disposal regulations and
environmental regulations.
Batteries
Batteries containing pollutants are marked with a sign consisting of a crossed-out
garbage can and the chemical symbol (Cd, Hg, Li or Pb) of the heavy metal that
is decisive for the classification as containing pollutants:
Cd1 Hg2 Pb3 Li4
1. „Cd" stands for cadmium
2. „Hg" stands for mercury
3. „Pb" stands for lead
4. „Li" stands for lithium
Electrical and electronic equipment

DAG-A4T
page 18 DAG-A4T K06/0523
16. EU Declaration of Conformance
We, KOBOLD Messring GmbH, Hofheim-Ts, Germany, declare under our sole
responsibility that the product:
Digital Indicating Unit Model: DAG-A4T
to which this declaration relates is in conformity with the standards noted below:
EN 61010-1:2010+A1:2019+A1:2019/AC:2019
Safety requirements for electrical equipment for measurement, control and
laboratory use
EN 61326-1:2013
Electrical equipment for measurement, control and laboratory use - EMC
requirements - Part 1: General requirements
EN 63000:2018
Technical documentation for the assessment of electrical and electronic products
with respect to the restriction of hazardous substances
Also, the following EC guidelines are fulfilled:
2014/30/EU EMC Directive
2014/35/EU Low Voltage Directive
2011/65/EU RoHS (category 9)
2015/863/EU Delegated Directive (RoHS III)
Hofheim, 17 Jan. 2023
H. Volz M. Wenzel
General Manager Proxy Holder

DAG-A4T
DAG-A4T K06/0523 page 19
17. UK Declaration of Conformity
We, KOBOLD Messring GmbH, Hofheim-Ts, Germany, declare under our sole
responsibility that the product:
Digital Indicating Unit for Panel Mounting Model: DAG-A4T
to which this declaration relates is in conformity with the standards noted below:
BS EN 61010-1:2010+A1:2019
Safety requirements for electrical equipment for measurement, control, and
laboratory use. General requirements
BS EN 61326-1:2013
Electrical equipment for measurement, control and laboratory use. EMC
requirements. General requirements
BS EN IEC 63000:2018
Technical documentation for the assessment of electrical and electronic products
with respect to the restriction of hazardous substances.
Also, the following UK guidelines are fulfilled:
S.I. 2016/1091 Electromagnetic Compatibility Regulations 2016
S.I. 2016/1101 Electrical Equipment (Safety) Regulations 2016
S.I. 2012/3032 The Restriction of the Use of Certain Hazardous Substances
in Electrical and Electronic Equipment Regulations 2012
Hofheim, 04 May 2023
H. Volz M. Wenzel
General Manager Proxy Holder

