Kobold DUK User manual

Operating Instructions
for
Ultrasonic Flowmeter/ -Monitor/
-Counter/ -Dosing Unit
Model: DUK

DUK
page 2 DUK K14/1122
1. Contents
1.Contents ........................................................................................................ 2
2.Note .............................................................................................................. 4
3.Instrument Inspection .................................................................................... 4
4.Regulation Use ............................................................................................. 5
5.Operating Principle ........................................................................................ 5
5.1General ................................................................................................ 5
6.Mechanical Connection ................................................................................. 6
6.1Check operating conditions .................................................................. 6
6.2Installation ............................................................................................ 6
7.Electrical Connection .................................................................................... 8
7.1General ................................................................................................ 8
7.2DUK-...S300 ......................................................................................... 8
7.3DUK-...S30D ........................................................................................ 8
7.4DUK-...F3x0; DUK-...L3x3 .................................................................... 9
7.5DUK-...L443 ......................................................................................... 9
7.6DUK-...C3T0.. ...................................................................................... 9
8.Operation .................................................................................................... 10
8.1Switch point setting DUK-...S300, DUK-…S30D ................................ 10
8.2Use of media other than water (only option -C3T0) ........................... 10
9.Adjustment – Compact Electronics DUK-...C3T0 ........................................ 10
10.Device status - compact electronics DUK-...C3T0 ...................................... 11
11.Maintenance ............................................................................................... 11
12.Technical Information .................................................................................. 12
13.Order Codes ............................................................................................... 12
14.Dimensions ................................................................................................. 12
15.Disposal ...................................................................................................... 13
16.IO-Link – compact electronics DUK-...C3T0 ............................................... 14
16.1IO-Link function .................................................................................. 14
17.Appendix - Compact electronics DUK-...C3T0 ............................................ 15
17.1IO-Link process data structure ........................................................... 15
17.2IO-Link diagnostic information ........................................................... 16
17.3IO-Link system command table ......................................................... 18
17.4IO-Link ISDU parameter table ............................................................ 19
18.Manufacturer’s declaration .......................................................................... 28
19.EU Declaration of Conformance ................................................................. 30
20.UK Declaration of Conformity ...................................................................... 31

DUK
DUK K14/1122 page 3
Manufactured and sold by:
Kobold Messring GmbH
Nordring 22-24
D-65719 Hofheim
Tel.: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.kobold.com

DUK
page 4 DUK K14/1122
2. Note
Please read these operating instructions before unpacking and putting the unit
into operation. Follow the instructions precisely as described herein.
The instruction manuals on our website www.kobold.com are always for currently
manufactured version of our products. Due to technical changes, the instruction
manuals available online may not always correspond to the product version you
have purchased. If you need an instruction manual that corresponds to the
purchased product version, you can request it from us free of charge by email
([email protected]) in PDF format, specifying the relevant invoice number and
serial number. If you wish, the operating instructions can also be sent to you by
post in paper form against an applicable postage fee.
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
The devices are only to be used, maintained and serviced by persons familiar
with these operating instructions and in accordance with local regulations
applying to Health & Safety and prevention of accidents.
When used in machines, the measuring unit should be used only when the
machines fulfil the EC Machinery Directive.
as per PED 2014/68/EU
In acc. with Article 4, Paragraph (3), "Sound Engineering Practice", of the
PED 2014/68/EU no CE mark.
3. Instrument Inspection
Instruments are inspected before shipping and sent out in perfect condition.
Should damage to a device be visible, we recommend a thorough inspection of
the delivery packaging. In case of damage, please inform your parcel service /
forwarding agent immediately, since they are responsible for damages during
transit.
Scope of delivery:
The standard delivery includes:
 Ultrasonic Flowmeter/ -Monitor/ -Counter/ -Dosing Unit model: DUK

DUK
DUK K14/1122 page 5
4. Regulation Use
Any use of the device, which exceeds the manufacturer’s specifications, may
invalidate its warranty. Therefore, any resulting damage is not the responsibility of
the manufacturer. The user assumes all risk for such usage.
5. Operating Principle
5.1 General
The new KOBOLD type DUK flow meters are used for the measurement,
monitoring, metering and dosing of low viscosity aqueous fluids.
The devices work on the principle of the difference in running times.
This is based on the fact that ultrasonic waves in a medium are influenced by the
speed of flow.
Two sensors mounted opposite one another in the pipeline function
simultaneously as transmitter and receiver of ultrasound signals.
If there is no flow, then the running times of both signals are identical. If the
medium is flowing, then the running time of the signal against the flow is longer
than that with the flow.
The running time difference, which is determined by a microprocessor, is
proportional to the speed of flow.
The devices can be equipped with a switching output, a frequency output or an
analogue output. A universal compact electronics model C3T0 is also available,
which contains two outputs that can be configured as required by the customer.

DUK
page 6 DUK K14/1122
6. Mechanical Connection
6.1 Check operating conditions
 flow rate
 max. operating pressure
 max. operating temperature
In general, the DUK is subjected to the same loads as the piping into which it is
installed. The DUK should therefore be kept free from extreme loads, such as
pressure surges with strong, dynamic pipe movements, vibrations in the proximity
of centrifugal pumps, high temperature media, flooding etc.
6.2 Installation
 Remove all packing materials and transport retainers and ensure that no such
materials remain in the device.
 It can be installed in vertical, horizontal or rising pipes. Flow in direction of the
arrow.
 Avoid pressure and tensile load.
 Mounting the inlet and outlet pipe in a distance of 50 mm from the connections.
 Avoid valves or large reduction on the inlet section (this increases the
inaccuracy of measurements).
 Check the leak tightness of the connections.
 Air bubbles in the flowing medium can disrupt the measuring function or
reduce measuring accuracy

DUK
DUK K14/1122 page 7
In-/Outlet Runs
Mounting from top to bottom avoid these installation areas
Gas bubbles
Particle
Free outlet

DUK
page 8 DUK K14/1122
7. Electrical Connection
7.1 General
Attention! Make sure that the voltage values of your system
correspond with the voltage values of the measuring unit.
 Make sure that the supply wires are de-energised.
 Connect the supply voltage and the output signal to the plug PIN´s as stated
below.
 We recommend the use of wires with cross sectional area of min. 0,25 mm².
7.2 DUK-...S300
7.3 DUK-...S30D
12
34
Output
N/C
Output
N/O
+Vs
GND
1
2
34
5
Output
N/O
Output
Common
Output
N/C
+Vs
GND

DUK
DUK K14/1122 page 9
7.4 DUK-...F3x0; DUK-...L3x3
Connection example DUK-...L3x3
1
2
34
+Vs
Signal
Out
n.c.
GND
7.5 DUK-...L443
7.6 DUK-...C3T0..
+Vs
Signal
Out
+Vs
GND
GND
1
2
34
+Vs
Signal
Out
n.c.
GND
+Vs
GND

DUK
page 10 DUK K14/1122
8. Operation
The units are preset and after electrical connection ready for operation.
8.1 Switch point setting DUK-...S300, DUK-…S30D
Switch setting Switch point
0 Switch function deactivated
1 10 % of f.s.
2 20 % of f.s.
3 30 % of f.s.
4 40 % of f.s.
5 50 % of f.s.
6 60 % of f.s.
7 70 % of f.s.
8 80 % of f.s.
9 90 % of f.s.
Flow above switch point: DUO-LED green
Flow below switch point: DUO-LED red
8.2 Use of media other than water (only option -C3T0)
The DUK-...C3T0 is able to measure viscous media up to a maximum viscosity of
68 mm2/s. However, this must be a homogeneous Newtonian liquid, but not
necessarily based on water. The DUK-...C3T0 is factory set with a data set for
water. If another medium is to be used, the KOFICOM-IFMU order option and the
free MEDIATOR Tool software are required to exchange the data set.
MEDIATOR Tool contains the data records of common media and is regularly
expanded with media data. Upon request, customer-specific data sets can be
created upon submission of the relevant data.
The MEDIATOR Tool software can be downloaded free of charge from the
Kobold homepage: www.kobold.com/qr/DUK
9. Adjustment – Compact Electronics DUK-...C3T0
The operation and setting of the electronics option -C3T0 is described in the
operating manual supplement for C3T0.

DUK
DUK K14/1122 page 11
10. Device status - compact electronics DUK-...C3T0
display text error type display color description debugging
Meas Error
functional limitation
orange
Measuring tube not or only
partially filled or stationary air
bubbles in front of the
transducers
Fill the measuring tube
completely with medium
or Flush out air bubbles
Temo
overrun
Limitation of
measurement
accuracy
yellow
The measuring range of the
temperature measurement has
been exceeded
If necessary, reduce
medium temperature
Temp
underrun
Limitation of
measurement accuracy
Yellow
The measuring range of the
temperature measurement is
undershot
Increase medium
temperature if
necessary
Temp
sensor
device error
Red
Defect in the temperature sensor
measuring circuit
Repair necessary at
the manufacturer
Medium
warning
Warning - qualitative
limitation of the flow
measurement
orange Large fluctuations in measured
values caused by poor flow
conditions in the inlet/outlet or
air bubbles in the medium
Adhere to inlet and
outlet distances,
avoid / eliminate air
bubbles in the
medium
MVM error device error red
Read error internal data memory Repair by the
manufacturer is
necessary if the
problem occurs
repeatedly
Signal
warning
Warning - qualitative
limitation of the flow
measurement
orange
Significant signal
attenuation by the medium
Use a suitable
medium or eliminate
sound-absorbing
components in the
medium
11. Maintenance
The measurement device requires no maintenance if the measurement medium
does not cause deposits. In order to avoid problems, we recommend the
installation of a filter, such as the magnetic filter, e.g. model MFR.
If it is necessary to clean the sensor, the sensor can be rinsed with a suitable
liquid. Fibre parts or large particles can be carefully removed with a cleaning cloth
or similar.
Work on the electronics can only be performed by the factory, or the warranty is
otherwise voided.

DUK
page 12 DUK K14/1122
12. Technical Information
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
13. Order Codes
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com
14. Dimensions
Operating instructions, data sheet, approvals and further information via the QR
code on the device or via www.kobold.com

DUK
DUK K14/1122 page 13
15. Disposal
Note!
 Avoid environmental damage caused by media-contaminated parts
 Dispose of the device and packaging in an environmentally friendly
manner
 Comply with applicable national and international disposal regulations and
environmental regulations.
Batteries
Batteries containing pollutants are marked with a sign consisting of a crossed-out
garbage can and the chemical symbol (Cd, Hg, Li or Pb) of the heavy metal that
is decisive for the classification as containing pollutants:
Cd1 Hg2 Pb3 Li4
1. „Cd" stands for cadmium
2. „Hg" stands for mercury
3. „Pb" stands for lead
4. „Li" stands for lithium
Electrical and electronic equipment

DUK
page 14 DUK K14/1122
16. IO-Link – compact electronics DUK-...C3T0
16.1 IO-Link function
The DUK-XXXXXC3T0 flow meter has an IO-Link communication interface as
standard. The process and diagnostic data can be accessed directly via this
interface and the device can be parameterized.
Output 1 is factory configured for IO-Link function. If the IO-Link communication
mode is active, the "IOLINK" symbol in the status display for the outputs is
displayed in green. The settings menu remains locked when the IOLINK mode is
active and is not accessible.
To ensure that the IO-Link device can be operated correctly on the connected IO-
Link master, it is necessary to install the device description file that matches the
device.
The device description files (IODD) are available in the IODDfinder database at
ioddfinder.io-link.com.
Product-Typ Device-ID
[hex]
Device-ID
[dec]
DUK-XXXXXC3T0 040200 262656
If the device is operated on an IO-Link master with port class A, only a maximum
output current of 50 mA may be drawn from output 2 (OUT2) (current or binary
output), otherwise the IO-Link master will be overloaded and it can malfunctions
occur.

DUK
DUK K14/1122 page 15
17. Appendix - Compact electronics DUK-...C3T0
17.1 IO-Link process data structure
Process data length: 10 bytes
Byte
number Data Bit counter Format Factor Range Value
0 - 3 Flow 32 Bit FloatT +/-1,4*10-45 ... +/- L/min
4 - 7 Volume 32 Bit FloatT +/-1,4*10-45 ... +/- L
8 - 9
Temperature 12 Bit IntegerT 1/10 +/-204,8 °C
reserved 1 Bit BooleanT
reserved 1 Bit BooleanT
Status OUT1 1 Bit BooleanT
Status OUT2 1 Bit BooleanT
Flow (32 Bit, FloatT)
0 1 2 3 4 5 6 7 0 1 2345670123456 7 0 1 2 3 4 5 6 7
Byte 0 Byte 1 Byte 2 Byte 3
Temperature (12 Bit, IntegerT)
0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7
B
y
te 8 B
y
te 9
Volume (32 Bit, FloatT)
0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7 0 1 2 3 4 5 6 7
Byte 4 Byte 5 Byte 6 Byte 7

DUK
page 16 DUK K14/1122
17.2 IO-Link diagnostic information
Event
Code
[hex]
Event
Code
[dec]
Name Device
Status Type Definition
0x7710 30480 Short Circuit Error check installation
0x8C10 35856 Process Variable
Range Overrun  Warning process data uncertain
0x8C20 35872 Measurement Range
Overrun  Error check application
0x8C30 35888 Process Variable
Range Underrun  Warning process data uncertain
0x1838 6200 1. Test Event For
Protocol Testing  Error first test event
0x1839 6201 2. Test Event For
Protocol Testing  Error second test event
0x183A 6202 NVM Error 4 Error
non-volatile
memory is
corrupt
0x183B 6203 Subslave Lost  Error
communication to
subslave
interrupted
0x183C 6204 Subslave Not Found 4 Error
cummunication to
subslave couldn`t
be astablished
0x183D 6205 Counter Overflow 2 Error
volume or
partvolume
counter
overflowed
0x183E 6206 Simulation Active  Warning
indicates that one
of the simulations
is running
0x183F 6207 Flow MRE Overrun Warning measuring range
overrun
0x1840 6208 Flow MRS Underrun Warning measuring range
underrun
0x1841 6209 Flow Overflow
Overrun 2 Warning overflow range overrun
0x1842 6210 Flow Underflow
Underrun 2 Warning underflow range underrun
0x1847 6215 Temperature MRE
Overrun Warning measuring range overrun
0x1848 6216 Temperature MRS
Underrun Warning measuring range underrun
0x1849 6217 Temperature
Overflow Overrun 2 Warning overflow range overrun

DUK
DUK K14/1122 page 17
Event
Code
[hex]
Event
Code
[dec]
Name Device
Status Type Definition
0x184A 6218 Temperature
Underflow Underrun 2 Warning underflow range underrun
0x185F 6239 Meas Error 3 Warning
ultrasonic
measurement out
of range
0x1860 6240 Temp Overrun 1 Warning
SOS
Temperature
over range
0x1861 6241 Temp Underrun 1 Warning
SOS
Temperature
under range
0x1862 6242 Temp Sensor 1 Warning
PT1000
Temperature
sensor broken
wire
0x1863 6243 Medium Warning 3 Warning
Too many jumps
in ultrasonic
measurement
0x1864 6244 NVM Error 1 Warning Checksum of
NVM is wrong
0x1865 6245 Signal Warning 3 Warning Ultrasonic signal
is very attenuated

DUK
page 18 DUK K14/1122
17.3 IO-Link system command table
Command
(hex)
Command
(hex) Command name
82 130 Restore factory settings
A0 160 Reset MinMax Flow
A1 161 unused
A2 162 Reset MinMax Temperature
A3 163 Reset Part Volume Counter
A4 164 unused
A5 165 unused
A6 166 unused
A7 167 unused
A8 168 Start Simulation Flow
A9 169 unused
AA 170 Start Simulation Temperature
AB 171 Start Simulation Part Volume
AC 172 unused
AD 173 unused
AE 174 unused
AF 175 unused
B0 176 Stop Simulation Flow
B1 177 unused
B2 178 Stop Simulation Temperature
B3 179 Stop Simulation Part Volume
B4 180 unused
B5 181 unused
B6 182 unused
B7 183 unused
B8 184 Events Handling ON
B9 185 Events Handling OFF

DUK
DUK K14/1122 page 19
17.4 IO-Link ISDU parameter table
Parameters that relate to the measured values of flow, temperature or volume
must be entered in the basic units and, if necessary, converted beforehand. The
basic units are:
Flow: L/min
Temperature: °C
Volume: Liter
Units conversion table
Category: Flow
Unit Description Conversion
L/m Liter per minute (basic unit) -
L/h Liter per hour 1 L/h = 0.0167 L/m
mL/m Milliliter per minute 1 mL/m = 0.001 L/m
m3/h Cubic meters per hour 1 m3/h = 16.667 L/m
gal/m US gallons per minute 1 gal/m = 3.7854 L/m
gal/h US gallons per hour 1 gal/h = 0.06309 L/m
galk/m UK gallons per minute 1 galk/m = 4.54609 L/m
galk/h UK gallons per hour 1 galk/h = 0.07577 L/m
L/s Liters per second 1 L/s = 60 L/m
mL/s Milliliters per second 1 mL/s = 0.0000167 L/m
USER User unit 1 user unit = USER * L/m
Category: Temperature
Unit Description Conversion
°C DegreeCelsius (basic unit) -
°F Degree Fahrenheit x
°
C = (32 + x *1,8) °F
USER User unit 1 user unit = USER * °C
Catego
r
y:
V
olume
Unit Description Conversion
L Liter (basic unit) -
mL Millilite
r
1 mL = 0.001 L
m3 Cubic meters 1 m3 = 1000 L
galUS US gallons 1 galUS = 3.7854 L
galU
K
UK gallons 1 gal
k
= 4.54609 L
barrel Barrel (US) 1 barrel = 158.99 L
USER User unit 1 user unit = USER * L

DUK
page 20 DUK K14/1122
Index
[hex] ObjectName Definition Defaultvalue MaxValue MinValue Length [Bytes]
Data
Type Access
System
0x0002 SystemCommand SeeTable"Comand
Codes"    1 UInteg erT W
ProductIdentification(Vendorspecificparameters)
0x0010 VendorName  Kobold
Messring   max. 20 StringT R
0x0011 VendorText  www.kobold.c
om   max. 32 StringT R
0x0012 ProductName  DUK‐
XXXXXC3T0   max. 16 StringT R
0x0013 ProductID  DUK‐
XXXXXC3T0   max. 16 StringT R
0x0014 ProductText  DUK‐C3T0   max.
32 StringT R
0x0015 Serialnumber onlyreadparameter onlyread
parameter   max.8 StringT R
0x0016 HardwareRevision     max.8 StringT R
0x0017 FirmwareRevision FirmwareRevisionis
constantinFW
Firmware
Revisionis
constantinFW
  max.8 StringT R
0x0018 ApplicationDeviceTag tagnameisfrom
userconfigurable
tagnameis
from user
configurable
  32 StringT R/W
0x0019 FunctionTag functiontagisfrom
userconfigurable
functiontagis
from user
configurable
  32 StringT R/W
0x0020 LocationTag locationtagisfrom
userconfigurable
locationtagis
from user
configurable
  32 StringT R/W
DeviceStatusInformation
0x0024 DeviceStatus
0‐DeviceOK
1‐Maintenance
required
2‐Outof
specification
3‐Functionalcheck
4‐Failure
   1 UInteg
erT R
0x0025 DetaildDeviceStatus     max.
20
ArrayT
of
OctetSt
ringT3
R
DisplayConfiguration
0x0100 DisplayOrientation Orientationof
display 1
(1)‐Landscape
(2)‐PortraitFlip
(3)‐LandscapeFlip
(4)‐Portrait
1 UInteg
erT R/W
0x0103 DisplayLayout Singleorduallayout 1 (1)‐single
(2)‐dual 1 UInteg erT R/W
0x0104 UpperDisplay Sourcefortheupper
display 0
(1)‐Flow
(2)‐Volume
(3)‐Temperature
(4)‐PartVolume
1 UInteg
erT R/W
