Kodak I250 - Document Scanner User manual

i200 Series Scanners
User’s
Guide
A-61167
P/N 3E9296

A-61167 September 2002 i
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Scanner Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Paper Transport Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Speed/Capacity (Throughput) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Image Quality Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Preparing Documents for Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Recommended Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Warning Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
User Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Safety and Regulatory Agency Approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Environmental Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
EMC Statements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
For the United States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
For Japan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
For Taiwan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
For the European Union (EU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Acoustic Emission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Power System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installing the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Site Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Unpacking the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Registering Your Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Removing the Foam Sheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Scanner Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Internal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Making Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Installing the IEEE-1394 (FireWire) Card in the Host Computer . . . . . . . 11
Installing the Kodak Driver Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Power Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

ii A-61167 September 2002
Input and Output Trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Attaching the Input Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Attaching the Output Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Tray Extenders and Side Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Adjusting the Output Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Closing the Input and Output Trays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Installing Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Using the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Starting and Stopping Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Automatic Feeding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Continuous Feeding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Manual Feeding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Damaged Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cleaning the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cleaning the Separator Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cleaning the Feed Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cleaning the Drive Rollers and Transport Area . . . . . . . . . . . . . . . . . . . . 22
Cleaning the Imaging Guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Cleaning the Paper Path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Replacing Wear Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Replacing the Separator Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Replacing the Feed Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Calibrating the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Indicator Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Lamps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Clearing Document Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Adjusting the Separator Module Tension . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
System Is Not Responding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Color Image Quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Problem Solving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Transporting the Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

A-61167 September 2002 iii
Appendix A Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Appendix B Supplies and Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Appendix C KODAK i200 Series Imprinter . . . . . . . . . . . . . . . . . . . . . . . . C-1
Contents of the Imprinter Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
Installing the Imprinter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
Removing the Circuit Board Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-2
Attaching the Imprinter Board and Cable . . . . . . . . . . . . . . . . . . . . . . . . C-3
Completing the Imprinter Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . C-8
Installing the Ink Blotter Strips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-10
Purging an Ink Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-11
Installing an Ink Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-12
Setting the Imprinter Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-13
Imprinter Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-14
Imprinting Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-14
Expected Life of Imprinter Components . . . . . . . . . . . . . . . . . . . . . . . . C-14
When the Imprinter Is Not in Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-14
Replacing an Ink Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-14
Replacing the Ink Blotter Strips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-15
Replacing the Ink Cartridge Carrier . . . . . . . . . . . . . . . . . . . . . . . . . . . C-16
Imprinting Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-17
Print Characters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-17
Imprinter Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-18
Appendix D KODAK i200 Series Dockable Flatbed . . . . . . . . . . . . . . . . . D-1
Contents of the Dockable Flatbed Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1
Flatbed Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1
Installing the Dockable Flatbed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1
Using the Flatbed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-3
Book Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-3
Calibrating the Flatbed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-4
Cleaning the Flatbed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-5
After a Power Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-5
Removing the Dockable Flatbed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-6
Appendix E Installing Optional Memory . . . . . . . . . . . . . . . . . . . . . . . . . . E-1

A-61167 September 2002 1
Introduction
Before you install and operate your KODAK i200 Series Scanner, take a few
minutes to read through this guide. It contains important information about
installing, using, and maintaining your scanner.
• KODAK i250 Scanner is a desktop simplex color scanner with an automatic
document feeder.
• KODAK i260 Scanner is a desktop duplex color scanner with an automatic
document feeder.
Optional Accessories • KODAK i200 Series Imprinter—prints a date, time, fixed string, and/or
sequential number on document backs. For information about this
accessory, refer to Appendix C, KODAK i200 Series Imprinter.
• KODAK i200 Series Dockable Flatbed—the A3 flatbed adds scanning
capability for exception documents. For information about this accessory,
refer to Appendix D, KODAK i200 Series Dockable Flatbed.
NOTE:For information about ordering the above accessories, refer to
Appendix B, Supplies and Accessories.
•Additional memory(SODIMM)—purchase a memorycardat a computer
supplyretailer near you. For information about installing a memorycard,
refer to Appendix E, Installing Optional Memory.
Scanner Features • Excellent paper handling, image quality, and reliability
• Color at the same speed as bitonal and grayscale
• Dual-stream output
• Easy to use and maintain
• Handles a broad range of paper weights and sizes
• Small footprint; fits easily on a desktop or table
• Low noise level
• Easy installation
• ISIS and TWAIN device drivers are included on a CD that is packed with
each scanner
• International language support
• Automatic overlap/multifeed detection
• All scanner models support multiple electrical power requirements for
use worldwide
• May be user-calibrated at any time
• Electronic red, green, and blue color dropout

2A-61167 September 2002
Paper Transport
Features • Automatic and manual feeding
• Multifeed detection by document length and/or document thickness
• Automatic feeder with operator-assisted “infinite” and single-sheet feeding
Speed/Capacity
(Throughput) The following speeds in pages per minute (ppm) are for color, grayscale, or
bitonal output.
Image Quality Features • Adaptive Threshold Processing (ATP), image compression, despeckle, and
dithering for bitonal scanning
• Image capture optical resolution: 300 dpi
• Image output resolution: 75/100/150/200/300/400/600 dpi for bitonal,
grayscale, and color scanning
NOTE:Throughput speed at 400 dpi and 600 dpi is dependent on your
PC configuration.
• Auto-color balancing (auto-white balancing) to ensure good color balance
after calibration
• Pixel and color correction for the best color image quality
• JPEG compression allows images to be viewed in many image viewers
Maintenance • Easily replaceable feed module and separator module
• Easy one-step paper jam clearance
• LED indicators for power, ready, paper jam, and operating conditions
Resolution Landscape A4 Portrait Letter
i250 Scanner i260 Scanner i250 Scanner i260 Scanner
150 dpi 67 ppm 67 ppm
(134 ipm) 53 ppm 53 ppm (106 ipm)
200 dpi 50 ppm 50 ppm
(100 ipm) 40 ppm 40 ppm (80 ipm)
300 dpi 33 ppm 33 ppm
(67 ipm) 26 ppm 26 ppm (53 ipm)

A-61167 September 2002 3
Preparing Documents
for Scanning • A batch of documents to be fed into the scanner must be arranged so that
the leading edges of all documents are aligned and centered under the
automatic paper feeder; this allows the feeder to introduce documents into
the scanner one at a time. Documents must be positioned face down
for scanning.
• Staples and paper clips in documents may damage the scanner. Remove all
staples and paper clips before scanning.
• Torn, damaged, or crushed pages can be transported successfully through
the scanner. However, no scanner can transport every possible type of
damaged paper. If in doubt about whether a specific damaged document
can be transported through the scanner, place the document in a clear
protective sleeve. Sleeves should be manually fed, one at a time, folded
edge first, while lifting the gap release lever.
NOTE:Use the optional dockable flatbed to scan damaged documents.
• When scanning documents in a clear protective sleeve, the input tray guides
must be adjusted to accommodate the width of the sleeve.
NOTE:Kodak scanners have been tested with a range of documents that
represent the broad spectrum of document types found in the most
common business applications. Optimal scanner performance is
achieved when scanning documents within the recommended
document specifications listed below. Scanning documents that are
outside of these specifications may lead to undesirable results in terms
of scanner reliability, image quality, and/or consumable life.
Recommended Documents The following chart lists the recommended document attributes.
Materials • Virgin and recycled papers
• Photographic papers • Clear protective sleeves meeting the size and
thickness requirements in this section
Paper Types • Bond
• Laser •Inkjet •Offset
Paper Weights The document feeder handles a broad range of paper weights from 50 to 200g
(13 to 110 lb.)
Minimum Document Size
(Width x Length) 8.9 x 6.4 cm (3.5 x 2.5 in.)
Maximum Document Size
(Width x Length) With standard memory: 29.7 x 43.2 cm (11.7 x 17 in.)
With extended memory: 29.7 x 66.0 cm (11.7 x 26.0 in.)
Dockable Flatbed: 29.7 x 43.2 cm (11.7 x 17 in.)
Paper Inks NOTE:All inks on the paper must be dry before scanning is started.
• Standard offset printing
• Inkjet printer • Thermal transfer • Handwriting inks
Correction Fluids NOTE:All correction fluids on the paper must be dry before scanning is started.
• Liquid Paper®
•Tipp-Ex
®• Wite-out®
• Other, similar correction fluids
Document Batch Height for
Automatic Feeding When feeding batched documents, the maximum height of the batched documents is 10.2 mm (0.4 in.) or approximately 100 sheets of 75g (20 lb.) paper.

4A-61167 September 2002
Safety Information • When placing the scanner, make sure that the electrical power outlet is
located within 1.52 metres (5 feet) of the scanner and is easily accessible.
CAUTION:The power supply must only be used indoors in a dry location.
Warning Labels
User Precautions Users and their employer need to observe the common sense precautions
applicable to the operation of any machinery. These include, but are not limited
to, the following:
• Do not wear loose clothing, unbuttoned sleeves, etc.
• Do not wear loose jewelry, bracelets, bulky rings, long necklaces, etc.
• Hair should be kept short, using a hair net if needed, or by tying long hair up
in a bun.
• Remove all loose objects from the area that could be drawn into
the machine.
• Take sufficient breaks to maintain mental alertness.
Supervisors should review their practices and make the compliance with
these precautions a part of the job description for the operator of the
KODAK i200 Series Scanners and any other mechanical devices.
CAUTION:High voltage. Avoid contact.
CAUTION:Hot surface. Avoid contact.
CAUTION:Moving parts. Avoid contact.
WARNING: The scanner front panel must be in place and
closed during scanner operation.
WARNING: The printer access door must be in place and
closed during scanner operation, except when
changing the printhead location or replacing the
ink cartridge.
When the printer access door is removed,
DO NOT allow loose clothing, jewelry, hair, or
other objects to enter the printer opening.

A-61167 September 2002 5
Safety and Regulatory
Agency Approvals The KODAK i200 Series Scanners conform to all applicable national and
international product safety and electronic emission regulatory requirements.
This includes, but is not limited to, the following:
• Underwriters Laboratories Inc. listing to UL 60950 Third Edition
• Underwriters Laboratories Inc. listing to CAN/CSA C22.2 No. 60950-00
Third Edition
• TUV Rheinland of North America approval to EN60950
• CFR 47 Part 15, Subpart B (FCC Class A)
• Canadian ICES003 Class A
• CE Mark (Europe)
• CISPR22 Class A
• EN55022:98 Class A
• EN55024
• EN61000-3-2
• EN61000-3-3
• C-Tick Mark (Australia)
•VCCIClassA(EMC)
Environmental
Information • The KODAK i200 Series Scanners are designed to meet worldwide
environmental requirements.
• The i200 Series Scanners’ power supply cord jacket and the solder on the
circuit boards contain lead. Disposal of lead may be regulated due to
environmental considerations. For disposal or recycling information, contact
your local authorities, or in the U.S.A., visit the Electronics Industry Alliance
web site at www.eiae.org.
• Based on a review of the available information, disposal of the ink cartridge
would not be regulated under U.S. EPA’s (RCRA), U.S. Clean Water Act
(CWA), or both. However, disposal may be subject to state or local landfill,
incineration, or recycling requirements.
• Guidelines are available for the disposal of consumable items that are
replaced during maintenance or service; follow local regulations or contact
Kodak locally for more information.
• The product packaging is recyclable.
• Parts are designed for reuse or recycling.
• The i200 Series Scanners are Energy Star compliant.
