Koden KDS-6000BB User manual

KDS-6000BB Revision History
0092660002-00 i
KDS-6000BB Installation Manual
Doc No: 0092660002
Document Revision History
No. Doc. No-Rev. No. Revised Date
(Y/M/D) Revised Content
0 0092660002-00 2014/09/29 First edition
1
2
3
4
5
6
7
8
9
10
Document No. Revised Version Norm
When part of the document needs to be revised, the document has advanced revision number.
The document No. is indicated at the lower right side on the cover and at the left or right side of the
footer region of each page.
© 2014 Koden Electronics Co., Ltd. All rights reserved.
No part of this publication may be reproduced, transmitted, translated in any form by any means
without the written permission of Koden Electronics Co., Ltd. The technical descriptions contained in
this publication are subject to change without notice. Koden assumes no responsibility for any errors,
incidentals or consequential damages caused by misinterpretation of the descriptions contained in this
publication.

Important Notice KDS-6000BB
ii 0092660002-00
Important Notice
• For copy and transcription of this Installation Manual (hereinafter referred to as this
manual), permission from Koden is needed. Koden prohibits the un-authorized copy and
transcription of this manual.
• If this manual is lost or damaged, consult a dealer of Koden or Koden.
• The specification of the products and the contents in this manual are subject to change
without notice.
• The contents displayed on the menu of product may be different from the expression of this
manual. The fonts and shapes of the keys and menus in the illustration may differ from the
actual ones, and some parts may be omitted.
• Koden is not liable for damages and troubles arisen from misunderstanding of the contents
in this manual.
• Koden is not liable for any damages caused by earthquake, lightning, wind and flood
damage and fire for which Koden is not responsible, and actions by third parties, other
accidents, customer’s unintended error/abuse and the use under other abnormal
conditions.
• Koden is not liable for damages of accompaniment (change/loss of memorized content,
loss of business profit, stop of business) arisen from use or failure of our products.
• If the stored data are changed or lost, irrespective of causes of troubles and damages,
Koden is not liable for them.
• Koden is not liable for any damages arisen from malfunction caused by combination of
software and connected equipment in which Koden is not engaged.

KDS-6000BB For Your Safe Operation
0092660002-00 iii
For Your Safe Operation
Symbol used in this Installation Manual
The following pictograms are used in this manual. The meaning of each symbols shall be well
understood and the maintenance and inspection shall be carried out.
Symbol Meaning
Mark for warning
This symbol denotes that there is a risk of death or serious injury when
not dealing with it correctly.
Mark for danger of high voltage
This symbol denotes that there is a risk of death or serious injury caused
by electric shock when not dealing with it correctly.
Mark for caution
This symbol denotes that there is a risk of slight injury or damage of
device when not dealing with it correctly.
Mark for prohibition
This symbol denotes prohibition of the specified conduct. Description of
the prohibition is displayed near the mark.
Caution items on equipment
Be careful of high voltage inside
A high voltage, which may risk your life, is used. This high voltage
remains in the circuit after you have powered off switch. To prevent
touching the high voltage circuit inadvertently, the hard cover is
provided to the high voltage circuit and the high voltage caution label is
affixed. Ensure to power off switch for your safety and discharge the
electricity remaining in the capacity before starting to check. An
engineer authorized by our company should inspect and maintain.
Be sure to power off in the boat
If the power switch is inadvertently powered on during work, you will be
electrified. To prevent such accident from occurring, ensure to power off
in the boat and the power of equipment. Furthermore, it is safer to hang
the caution tag described as [Under Work] near the power switch of
equipment.
Be careful of dust
Inhaling dust may cause A respiratory disease. When cleaning the
inside of equipment, be careful not to inhale dust. Wearing a safety
mask is recommended.
Warning
Warning
Caution
Warning

For Your Safe Operation KDS-6000BB
iv 0092660002-00
Caution on location of equipment
Do not install the equipment where it is excessively damp and suffers
from excessive water drops.
Measures against static electricity
The static electricity may be generated from the carpet on the floor in
the cabin or clothes made of synthetic fiber. The static electricity may
destroy the electronic parts on the circuit board. Handle the circuit
board, taking the measure of static electricity free.
Caution at installation of a transducers
Install the transducer at the location where it is not affected by bubble
and noise The bubble and noise seriously degrade the performance of
this unit.
Cautions on handling
Do not disassemble or modify. It may leads to trouble, fire, smoking or
electric shock. In case of trouble, contact our dealer or our company.
In case of smoke or fire, boat power off and the power of this unit. It may
cause fire, electric shock or damage.
Be cautious of remaining high voltage
A high voltage may remain in the capacitor for several minutes after you
have powered off. Before inspecting inside, wait at least 5 minutes after
powering off or discharge the remaining electricity in an appropriate
manner. Then, start the work.
The information displayed in this unit is not provided directly for your
navigation. For your navigation, be sure to see the specified material.
Use the specified fuse. If un-specified fuse is used, it may cause a fire,
smoke or damage.
Whenever transmitting, be sure to submerge the transducer in water
first. If transmitted without submerging the transducer, it may be
damaged.
Caution
Caution
Caution
Warning
Warning
Caution
Caution
Caution

KDS-6000BB Contents
0092660002-00 v
Contents
Document Revision History ............................................................................................................. i
Important Notices............................................................................................................................ ii
For Your Safe Operation................................................................................................................ iii
Contents ......................................................................................................................................... v
System Configuration ................................................................................................................... vii
Configuration of Equipment ......................................................................................................... viii
External View ............................................................................................................................. xiii
Specification ............................................................................................................................. xvi
Chapter 1 Installation.................................................................................................................. 1-1
1.1 Installation precautions ..........................................................................................................1-1
1.1.1 Unpacking of components ..........................................................................................1-1
1.1.2 Appearance verification of each unit and accessories ................................................1-1
1.1.3 Selection of location for installation.............................................................................1-1
1.1.4 Laying and connection of cables.................................................................................1-2
1.1.5 Confirmation after installation .....................................................................................1-2
1.2 Installation of KDS-6000BB Display unit................................................................................1-3
1.3 Installation of KDC-6000BB Processor unit ...........................................................................1-3
1.4 Installation of an Operation unit .............................................................................................1-4
1.4.1 Desk-top installation of Operation unit .......................................................................1-4
1.4.2 Flush-mount installation of Operation unit .................................................................1-6
1.4.3 Installation of TD position alarm device......................................................................1-7
1.5 Installation of Hull unit............................................................................................................1-8
1.5.1 Installation location of Hull unit...................................................................................1-8
1.5.2 Maintenance space for TD tank .................................................................................1-9
1.5.3 Installation conditions for a TD tank.........................................................................1-10
1.5.4 Example of installation of the TD tank .....................................................................1-11
1.5.5 Assembly of Hull unit ...............................................................................................1-13
1.6 Wiring ..................................................................................................................................1-22
1.6.1 Connection of cables to Processor unit ...................................................................1-22
1.7 List of input/output sentences ..............................................................................................1-35
1.7.1 Input sentences .......................................................................................................1-35
1.7.2 Output sentences.....................................................................................................1-35
Chapter 2 Adjustment ................................................................................................................. 2-1
2.1 Setup of frequency of Transducer unit...................................................................................2-1
2.1.1 Setting of frequency...................................................................................................2-1
2.2 Setting of gain of Transducer unit ..........................................................................................2-1
2.3 Setup of TX power .................................................................................................................2-2

Contents KDS-6000BB
vi 0092660002-00
2.3.1 Display of TX power menu....................................................................................... 2-2
2.4 Train correct........................................................................................................................2-3
Chapter 3 Maintenance ...............................................................................................................3-1
3.1 Inspection ..............................................................................................................................3-1
3.2 Cleaning ................................................................................................................................3-1
3.2.1 Display/Processor units ............................................................................................. 3-1
3.2.2 Hull unit......................................................................................................................3-2
3.3 Fuse replacement..................................................................................................................3-2
3.4 Diagnostics of troubles ..........................................................................................................3-2
3.4.1 Necessary information for requesting repair.............................................................. 3-2
3.4.2 System check ............................................................................................................3-3
3.4.3 Setting at factory........................................................................................................ 3-4
3.4.4 Other maintenance menu ..........................................................................................3-4
3.4.5 Update of programs................................................................................................... 3-6
3.5 If you suspect a trouble ....................................................................................................... 3-10

KDS-6000BB System Configuration
0092660002-00 vii
System Configuration
Connection Diagram
Standard configuration
Option
Owner supply
Legend
Onboard DC
power supply
10.8 to
31.2VDC
Cable for external
monitor
(CW-560-2M is
acceptable)
J8 (6P)
Remote controller
RCW-14
Display unit
17 inch LCD monitor
is acceptable
Echo sounder
GPS Compass
NMEA Converter
TD shaft
ESR-1504
Shaft guide
ESR-1510
ESR-1511
For ESR-1507
Hull unit
DHU-630
TD tank
ESR-1506
/30927C-2
/30927C-3
/ESR-1507
/FRP TD tunk set
_G16ELA0010
Gum packing
ESR-1512
ESR-1513
For ESR-1507
Transducer unit
DHU-6302
with 10m cable
Onboard AC
power supply
100/115VAC
200/230VAC
AC power cable
VV-2D8-3M CW-373-5M
CW-376-5M
POWER (3P)
J6 (8P) J2
(
12P
)
J1 (5P)
CW-259-2M
Hull unit
control cable
CW-589-20M
TD position
alarm device
JB-36
DOU-620
DOU-620R
(with RCW-14)
CW-576-0.5M
J5 (10P)
External monitor
D-sub15P
Cable for external
monitor
(CW-560-2M is
acceptable)
CW-273-10M
Transducer unit
extension cable
CW-590-15M
J6
(8P)
18P female
18P male
Processor unit
DPU-610
J7 (16P)
15P
J5
(3P)
Onboard DC
power supply
10.8 to
31.2VDC
Trigger In/Out
CW-413-5M
CW-412-5M
Hull unit
DHU-6301
Power rectifier
PS-010
Operation
unit

Configur
a
viii
Config
u
Standard
E
a. DPU-61
No
１Pr
o
2 Oper
a
3 TD p
o
4 DC p
o
5 Hull
u
contr
o
6 Tran
s
exten
7 Fuse
8 Oper
a
9 Quic
k
10 Instal
a
tion of Eq
u
u
ration o
f
E
quipment
C
0 (Process
o
Name of it
e
o
cessor unit
a
tion unit
o
sition alar
m
o
wer cable
u
nit
o
l cable
s
ducer unit
sion cable
a
tion manu
a
k
Reference
lation manu
u
ipment
f
Equip
m
C
onfigurati
o
o
r unit) / D
O
e
m
D
D
m
device
J
C
C
C
F
V
C
a
l
K
K
al
K
m
ent
o
n List
O
U-620 (O
p
Ty
p
D
PU-610
D
OU-620
J
B-36
C
W-259-2M
C
W-589-20
M
C
W-590-15
M
F
-7161-10A
/
V
C
ylinder (ø
6
K
DS-6000B
B
K
DS-6000B
B
K
DS-6000B
B
p
eration un
i
p
e
M
M
/
N30C-125
6
.4x30)
B
.OM.E
B
.QR.E
B
.IM.E
i
t)
R
e
No displa
y
VGA out
p
With mou
(CW-412
-
Processo
r
Operatio
n
With CW-
5P conne
c
end plain
)
With 3P
c
one end
p
With 8pin
resistant
c
both end
s
With a 18
and a 12
p
resistant
c
Normal fu
main po
w
English
English
English
e
mark
y
unit
ut
n
ting brack
e
5M,
r
unit -
n
unit)
4
13-5M (Wi
c
tor and on
e
)
onnector a
n
p
lain
water
c
onnecto
r
s
a
s
p
in connect
o
p
in water
c
onnecto
r
sion type fo
e
r
KDS-60
0092660
0
Weigh
t
Lengt
h
5.1kg
e
t 1.1kg/
5m
i
th
e
5m
n
d 2m
a
t
20m
or 15m
o
r
00BB
0
02-00
t
/
h
Qty
1
1
1
1
1
1
3
1
1
1

KDS-6000BB Configuration of Equipment
0092660002-00 ix
×８
×８
×８ ×８
b. TD tank / TD shaft
c. DHU-630 (Hull unit)
Package 1
No Name of item Type Remark Weight/
Length Qty
1 TD tank ESR-1506 (PVC) 1230mm
30927C-2 (PVC) 1500mm
30927C-3 (PVC) 1800mm
ESR-1507 (FRP) 1500mm
Select
according to
equipment.
*Refer to
Option list
9.0kg
11.0kg
13.0kg
12.0kg
1
2 TD shaft ESR-1504 1411mm 6.0kg 1
No Name of item Type Remark Weight/
Length Qty
1 Hull unit DHU-6301 17.0kg 1
2 Shaft guide ESR-1510 For TD trunk of
PVC
3
3 Bolt set SUS-M16-55-Assy
(M16x55L, 2W16U, SW16U,
N16U)
EACH
8
4 Gum packing for flange ESR-1512 Gum 1
5 DC power cable CW-273-10M With 3P
connector and
one end plain
10m 1
Caution: TD tank is option.

Configuration of Equipment KDS-6000BB
x 0092660002-00
4A
8A
Package 2
Package 3
No Name of item Type Remark Weight/
Length Qty
1 Crank handle OB-03 1
2 Grease 100g 1
3 Fuse F-7161-4A
F-7161-8A
At input of
12 V
At input of
24 V
EACH
3
4 ANP base ANP-1 2
5 Binding Band AB-100-1000 2
No Name of item Type Remark Weight/
Length Qty
1 Damper 34924D 1
2 Fixing collar 32681D 2
3 Pipe cap 34378D 1
4 Cap bolt CB4 x 10U 4
5 HEX rod wrench 1.5mm ×1
2.5mm ×1
3.0mm ×1
5.0mm ×1
EACH
1
1 SET

KD
S
0092
Pac
k
C
No
1
2
S
-6000BB
660002-00
k
age 4
C
aution: D
m
Na
m
Transduc
e
Bath cork
on’t carry
t
m
anner ma
y
m
e of item
e
r unit
t
he Trans
d
y
cause b
r
DH
U
Bath
d
ucer unit
(
r
eakage of
Typ
e
U
-6302
h
cork (Whit
e
(
DHU-6302
the equip
m
e
e
) 50g
Config
u
)
by holdi
n
m
ent.
Re
m
With 10
m
(With 18
P
resistant
end plain
u
ration of
E
n
g its cabl
e
m
ark
W
L
m
cable
P
water
and one
n
)
9
5
E
quipmen
t
x
i
e
. Such
W
eight/
L
ength Q
t
9
.0kg 1
5
0g 1
t
i
t
y

Configuration of Equipment KDS-6000BB
xii 0092660002-00
Option List
No Name of item Type Remark
1 Remote controller RCW-14 With 5m cable, (with Operation unit)
2 TD tank
(For *xxxx mm of TD
shaft)
*TD shaft length
ESR-1506 PVC, 1230mm (For 1411mm of TD shaft)
30927C-2 PVC, 1500mm (For 1681mm of TD shaft)
30927C-3 PVC, 1800mm (For 1981mm of TD shaft)
ESR-1507 FRP, 1500mm
FRP TD tank set
(With Shaft guide and
Gum packing)
ESR-1507(1), ESR-1513(1),
ESR-1510(2),ESR-1511(2)
3 Shaft guide ESR-1510 1pc ESR-1506 (TD tank of PVC)
ESR-1511 1pc ESR-1507 (TD tank of FRP)
4 Gum packing ESR-1513 1pc ESR-1507 (TD tank of FRP)
5 Power rectifier PS-010 With 2 pieces of 5A fuse
6 AC power cable VV-2D8-3M Both ends plain
7 Connecting cable CW-372-5M 5m With 5P water resistant connector and one
end plain
CW-373-5M 5m 6P water resistant connectors at both
ends
CW-376-5M 5m With 6P water resistant connector and one
end plain
Cable for external monitor CW-576-0.5M 0.5m With 10P water resistant connector and
D-Sub connector
CW-560-2M 2m D-Sub 15P connectors at both ends
8 Junction box JB-35 1 input, 3 outputs with CW-376-5M
9 TD shaft 32679C-2 ESR-160_1681mm
32679C-3 ESR-160_1981mm
40φ-4t-3000mm ESR-160_3000mm
10 Monitor 17inch LCD Monitor With power cable and signal cable

KD
S
0092
Ext
e
Pro
c
Op
e
S
-6000BB
660002-00
e
rnal Vi
e
c
esso
r
uni
t
e
ration uni
e
w
t
(DPU-610
)
t (DOU-62
0
)
0
)
Ext
e
Unit:
e
rnal Vie
w
xii
i
mm (inch)
w
i

External
V
xiv
TD positi
o
Remote c
o
V
iew
o
n alarm d
e
o
ntroller (
R
e
vice (JB-
3
R
CW-14) (
o
3
6)
o
ptional)
Installation dimensions
KDS-60
0092660
0
Unit: mm
(
00BB
0
02-00
(
inch)

KD
S
0092
Hull
S
-6000BB
660002-00
unit (DHU
-
-
630)
Ext
e
e
rnal Vie
w
x
v
Unit: mm (inch)
w
v

Specifica
t
xvi
Specifi
c
t
ion
c
ation
KDS-60
0092660
0
00BB
0
02-00

KDS-6000BB Chapter 1 Installation
0092660002-00 1-1
Chapter 1 Installation
1.1 Installation precautions
In order to obtain the maximum performance of the Digital Sonar, this Digital Sonar should be
installed by a qualified engineer in charge of installation and maintenance. Installation
procedures include the following:
(1) Unpacking of components
(2) Inspection of composition units, spare parts, accessories and installation materials.
(3) Checking of supply voltage and current capacity.
(4) Selection of location for installation.
(5) Installation of Display unit, Processor unit, Operation unit and Hull unit.
(6) Attachment of accessories.
(7) Planning and implementation of cable lying and connection.
(8) Coordination after installation.
1.1.1 Unpacking of components
Unpack the components and check that all the items correspond with the description of the
packing list. When a discrepancy or damage has been found, contact the dealer you
purchased of our sales company.
1.1.2 Appearance verification of each unit and accessories
Inspect the appearance of each components and accessories and check that no dents or
damages exist.
If any dents or damages exist and they are believed to be caused by accident during
transportation, contact the transportation and insurance company and consult our sales
company or our dealer nearest to you.
1.1.3 Selection of location for installation
In order to obtain the maximum performance of the unit, it is necessary to install in
consideration of matters described below:
(1) The Processor unit is not waterproof. Do not set it up in the place where water splashes.
(2) Keep enough space for maintenance for the Processor unit and the Hull unit. Especially,
secure enough space at the rear panel where many cables are connected.
(3) The operation unit shall be set up within the distance the connection cables are not too
stretched.
(4) The operation unit shall be set up within the distance the connection cables are not too
stretched.
(5) Keep the equipment as far away from wireless transmitter/receivers as possible.

Chapter 1 Installation KDS-6000BB
1-2 0092660002-00
1.1.4 Laying and connection of cables
(1) Keep the cables related with the Hull unit and the power cable as far away from the cables
of other electronic equipment as possible.
(2) The cabinet of the display unit and the Processor unit shall be securely grounded to the
hull, using the grounding terminal on the rear panel.
All chassis shall be securely grounded as a means of noise
suppression. The – (negative) output is isolated (floating) output.
(3) If you connect the power cable directly to the battery, interference from the other
electronics equipment is expected to be less. (See Fig. 1.1)
Fig. 1.1 KDS-6000BB Connection of power line
1.1.5Confirmationafterinstallation
Be sure to confirm the following points before starting. The confirmation is mandatory to
operate the equipment normally:
(1) Is the power voltage in the boat within the appropriate voltage range? Is the current
capacity enough?
(Voltage range: 10.8 VDC to 31.2 VDC measured at the power connector.)
(2) Is the electric current capacity sufficient?
(Power consumption: Processor unit (DPU-610)/70W, Hull unit (DHU-630) /70W）
(3) Is the cabling from the Hull unit correct? Is the wiring shorted?
Battery
Good
example
B
a
d
example
Battery
Display unit, Processor unit or
Hull unit
Display unit, Processor unit
or Hull unit
DPU-610
or
DHU-630
NoiseNoise
DPU-610
or
DHU-630
Caution

KDS-6000BB Chapter 1 Installation
0092660002-00 1-3
1.2 Installation of KDS-6000BB Display unit
The display unit should be prepared by customers and should be installed in accordance with
the installation manual attached to it. In addition, please be sure to carry out the following:
(1) Decide the location to install the Display unit and keep the space for the maintenance
works.
(2) Energizing shall be performed after confirmation of the installation of display unit, and
other components, and the completion of power cabling works for them.
1.3 Installation of KDC-6000BB Processor unit
The Processor unit can be installed on either on table or panel.
Install by the following procedure.
(1) Please determine the place where the Processor unit will be mounted with enough space
for the maintenance.
(2) Make 4 holes at the location to be installed (See Fig. 1.2)
(3) Install the Processor unit in the installing location (installation hole) and fix it with 4 tapping
screws (4mm) (M4 or pan-head). (Prepare 4mm screws suitable for thickness of installing
location.)
Fig. 1.2 Position of installation hole of Processor unit
308
(12 1/8)
308
(12 1/8)
308
(
12 1/8
)
308
(12 1/8)
4-φ4.5
Unit: mm (inch)
