Kogan KA21CBDISPA User manual

COMMERCIAL ICE CUBE MAKER
AND WATER DISPENSER
22KG
KA21CBDISPA

Ensure to read all instructions and warnings in this user guide prior to first use. Retain this
user guide for future reference.
•This appliance is intended to be used in households and similar applications such as:
oStaff kitchen areas in shops, offices, and other working environments.
oFarmhouses and by clients in hotels, motels, and other residential type
environments.
oBed and breakfast type environments.
oCatering and similar non-retail applications.
•When using electrical appliances, basic safety precautions should be followed to
reduce the risk of fire, electric shock, and injury to persons or property.
•Adult supervision is required at all times when children are around the appliance.
•This appliance supports voltages between 220–240V with a frequency of 50Hz.
Ensure the outlet used matches this.
•Do not place the appliance under direct sunlight or other heat sources.
•Do not use the appliance outdoors.
•Ensure there is at least a 10cm clearance on all sides of the appliance from any walls
or obstructions.
•Do not place this appliance on uneven surfaces.
•Ensure the appliance is only plugged into properly polarised outlets.
•Ensure no other appliance is plugged into the same outlet.
SAFETY & WARNINGS
WARNING:
•Risk of fire/flammable materials used. Due to its flammable
blowing gas, if disposing, ensure to follow local regulations.
•Keep ventilation openings of the appliance or the built-in
structure clear of obstructions.
•Do not damage the refrigerant circuit.
•Do not use mechanical devices or other means to accelerate the
defrosting process or ice collecting process, other than those
recommended by Kogan.com.
•Do not use other electrical appliances inside the appliance.

•Ensure the power cord is fitted securely into the outlet.
•Do not run the power cord over carpeting or other heat-insulating surfaces.
•Do not cover the power cord. Ensure it is visible at all times to prevent a tripping
hazard.
•Keep the power cord away from high traffic areas.
•Do not submerge the appliance in water or any other liquid.
•Do not use an extension cord with this appliance as it may cause overheating and a
risk of fire.
•Ensure the appliance is turned off and unplugged before cleaning and when not in
use.
•Do not tip the appliance over.
•Do not use any other liquid to make ice other than water.
•Do not store explosive substances (for example, aerosol cans) with a flammable
propellant in this appliance.
•Do not clean the appliance with flammable fluids as the fumes can create a fire
hazard or explosion.
DANGER:
Improper use of the grounded plug can result in the risk of electrical
shock. If the power cord is damaged, stop use immediately and
contact help.Kogan.com for assistance.
•This appliance must be earthed.
•This appliance must be properly grounded for user safety. The
power cord of this appliance is equipped with a three-prong plug
which mates with the standard three-prong wall outlets to
minimise the possibility of electric shock.

•Commercial ice maker and water dispenser
•Ice scoop
•User guide
Control panel
OVERVIEW
Air outlet
Cold water tap
Water drain cap
Bottle probe
Cold water tap button
Ice cube basket
Control panel
Water dispensing
button
Select button
ON/OFF button
Power indicator
Add water
indicator
Small ice cube
indicator
Medium ice cube
indicator
Large ice cube
indicator
Ice full
indicator
COMPONENTS LIST
Top cover

Unpacking
Remove the exterior and interior packaging, ensuring the ice cube basket is inside. If any
components are missing, contact help.Kogan.com for assistance.
1. Clean the interior with diluted detergent, lukewarm water, and a soft cloth.
2.Use the water to rinse the interior, then unplug the water drain cap to drain out the
water.
3.Clean the exterior with a solution of mild detergent and warm water.
4.Dry the interior and exterior with a soft cloth.
5.Remove the ice cube basket and clean with water.
Placement
Place the appliance on a flat, dry surface. Ensure there is at least a 10cm clearance around
all sides of the appliance, away from walls and other obstructions.
The power cord and outlet should be easily accessible.
Wait for one hour to allow the refrigerant liquid to settle before use.
BEFORE USE
Note:
During winter, allow the appliance a few hours to warm to room temperature before
plugging in.

Placing the water bottle
Ensure the water drain cap is securely fastened.
Hold the water bottle (not included) upside down vertically and place it into the bottle probe
on the appliance. Apply slight pressure to pierce the bottle cap onto the probe.
Notes:
•Ensure the cap on the bottle is compatible with the dimensions of the bottle
probe as seen above.
•This appliance is compatible with bottles between 7.5–19L in capacity that have
pierceable sealed caps.
•Ensure the water used is between 8–32°C.
19mm
69.5mm

Ensure there is at least a 10cm clearance around all sides of the appliance, away from walls
and other obstructions.
Powering
Plug the power cord into an exclusive grounded wall outlet, then turn on the outlet. The
appliance will then enter standby.
Making ice cubes
1. Press the ON/OFF button on the control panel to begin the ice-making cycle.
2.Press the select button to choose the size of the ice cubes (small, medium, large). The
relevant ice cube indicator will illuminate.
3.One ice-making cycle lasts between 6–15 minutes. This variability depends on the ice
cube size selected and the ambient temperature. Once complete, the ice cubes will
enter the ice cube basket and the ice-making cycle will automatically repeat.
4.Once you have the desired amount of ice cubes, pull out the ice cube basket and use
the ice scoop to collect the ice cubes.
5.Press the ON/OFF button to turn off the appliance.
Add water indicator
If the water pump is unable to pump sufficient water, the appliance will stop automatically.
The add water indicator will also illuminate.
1. Replace the water bottle with a new one filled with water.
2.Press the ON/OFF button to resume making ice.
OPERATION
Note:
Do not cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified electrician.
Note:
During extreme temperatures, the ice making cycle may differ significantly.

If a new bottle has been inserted but the add water indicator is still illuminated and the
water pump is not working properly, check on the water filters.
•Water filters in the tank:
1. Pull out the ice cube basket. The water filters are circular and are located at
the bottom of the water tank.
2. Remove the filters by hand and clean them with water. Once cleaned,
reattach the filters.
•Water filter connected to the pipe: A qualified professional will be required to remove
this water filter.
1. Open the top cover and locate the water pipe.
2. Release the hose clamp then unplug the water pipe to reveal the water filter.
3.Remove the water filter by hand and clean it with water.
4.Once cleaned, reattach the water filter. Secure the water pipe with the hose
clamp and replace the top cover.
After cleaning the water filters, wait for at least three minutes to allow the compressor to
settle before resuming use.
Ice full indicator
If the ice cube basket becomes full, the appliance will stop automatically. The ice full
indicator will illuminate to alert users.
Pull out the ice cube basket then use the ice scoop to collect ice.
To p cover
Hose clamp
Water filter
Water pipe
Note:
Do not attempt to clean the water filter connected to the pipe yourself.

Dispensing water
Water dispensed from the appliance will only be cold after the ice-making cycle has
operated for at least 30 minutes.
1. Press the cold water tap button to pop out the cold water tap.
2.Hold a cup under the tap.
3.Press and hold the water dispensing button to dispense cold water from the tap.
Release the button when the cup has been filled.

Ensure the appliance is turned off and unplugged before cleaning.
Cleaning should be done regularly to ensure proper hygiene.
1. Remove the ice basket.
2.Using a soft cloth, clean the interior with a solution of diluted detergent and lukewarm
water.
3.Use the water to rinse the interior, then unplug the water drain cap to drain out the
water.
4.Clean the exterior with a solution of mild detergent and warm water.
5.Dry the interior and exterior with a soft cloth.
6.Remove the ice cube basket and clean.
Storage
If the appliance will not be used for an extended period, open the water drain cap to drain
the water completely from the water reservoir. Dry thoroughly.
Store in a cool, dry place, away from children.
CLEANING & CARE

Problem Possible cause Solution
The add water
indicator is
illuminated.
There is not enough
water in the water
bottle.
1. Press the ON/OFF button to turn off the
appliance and replace the water bottle with
a new one full of water.
2. Press the ON/OFF button to resume making
ice.
One of the water
filters is blocked.
Check both water filters for obstructions and
clean if necessary.
The ice full
indicator is
illuminated.
The ice cube basket
is filled with ice
cubes.
Pull out the ice cube basket and remove ice
cubes using the ice scoop.
The ice cubes are
sticking together.
The ice-making cycle
has been operating
for too long.
1. Press the ON/OFF button to turn off the
appliance.
2. Wait for the ice cubes to melt, then press the
ON/OFF button to resume making ice.
Ensure to press the select button to choose
the small ice cube setting.
The temperature of
the water is too low. Ensure the water used is between 8–32°C.
The appliance is
operating but not
making ice.
The ambient
temperature or water
temperature is too
high.
•Ensure the ambient temperature is below
32°C.
•Ensure the water used is between 8–32°C.
There is a refrigerant
liquid leakage.
Stop use immediately and contact
help.Kogan.com for assistance.
The pipe in the
cooling system is
blocked.
Stop use immediately and contact
help.Kogan.com for assistance.
TROUBLESHOOTING

Protection type I
Climate class SN, N, ST, T
Power rating 220–240V, 50Hz
Ice making rated current 1.1A
Ice collecting rating current 1.3A
Refrigerant R290, 33g
Vesicant C5H10
Enclosure Stainless steel
Dimensions (W x D x H) 357 x 423 x 452mm
Net weight 15kg
SPECIFICATIONS

CIRCUIT DIAGRAM

NOTES
