Kogan KA19LICEMKA User manual

ICE CUBE MAKER
12KG
KA19LICEMKA

Ensure to read all instructions and warnings in this user guide prior to first use. Retain this
user guide for future reference.
•This ice cube maker is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities, or lack of experience and knowledge
unless they have been given supervision or instruction concerning the use of the ice
cube maker by a person responsible for their safety.
•This ice cube maker is made for indoor household use only.
•Do not use this ice cube maker outdoors.
•The internals of the ice cube maker should never exceed 45°C.
•The operating environment for this ice cube maker is between 5–35°C.
•Do not turn the ice cube maker upside down. This can cause the compressor or
refrigerating system to operate incorrectly.
•Do not use with an extension cord unless necessary. If using, ensure it is suitably rated
and it is handled safely as is the ice cube maker’s own power cord.
•Do not allow the power cord to be exposed to water, heat, or direct sunlight.
•Do not allow the power cord to overhang where it can be pulled or otherwise be
damaged or pose a hazard.
•This ice cube maker contains no user-serviceable parts. If it suffers any failure or
damage, consult the “Troubleshooting” section of this user guide. If the issue is not
resolved, stop use immediately and contact help.Kogan.com for assistance.
•Do not touch the evaporator while making ice to avoid frostbite.
•Ensure the power cord is unplugged when not in use.
•Never store or use gas and other flammable articles near the ice cube maker.
SAFETY & WARNINGS

Control panel
1 To p l i d
2 Evaporator
3 Air outlet
4 Viewing window
5 Ice tray
6 Ice shovel
7 Ice basket
8 Ice scoop
9 Control panel
10 Max level indicator
11 Water reservoir
12 Drain plug
13 Infrared LED
14 Infrared receiver
ADD WATER ICE FULL ICE ON/OFF
Illuminates
when the water
reservoir is
empty.
Illuminates when
the ice basket is full.
Blinks in standby
mode, solid when
operating.
Start or stop the ice
cube maker.
OVERVIEW

Unpacking
Unpack the ice cube maker, then check to ensure that all the components are included. If
components are missing, contact help.Kogan.com for assistance.
Cleaning
It is strongly recommended to clean the ice cube maker before first use.
•Remove the ice basket.
•Open the drain plug. Clean the interior with a soft cloth soaked with warm water and
vinegar. Rinse with fresh water and drain.
•Wash the ice basket and ice scoop in warm soapy water. Rinse and dry.
•Clean the exterior of the ice maker with a soft damp cloth. Use a mild dishwashing
soap if necessary.
Placement
Place the ice cube maker on a stable, level surface with at least a 25cm clearance from
heat sources (for example, ovens, heaters, and corrosive gases).
Before first use, wait for at least two hours to allow the fluids in the compressor to settle.
For subsequent uses, wait for at least 30 minutes to allow the fluids in the compressor to
settle after the ice cube maker is moved or transported.
Notes:
•Do not turn the ice cube maker upside down.
•During winter, allow the appliance a few hours to warm to room temperature
before plugging in.
BEFORE USE

Ensure that the drain plug at the bottom of the water reservoir is closed well.
Before first use, wait for at least two hours to allow the fluids in the compressor to settle.
1. Plug the ice cube maker into the wall outlet and turn the outlet on. The “ICE”
indicator will blink.
2.Open the top lid and remove the ice basket.
3.Fill the water reservoir with drinking water between 8–25°C.
4.Place the ice basket in and close the top lid.
5.Press the “ON/OFF” button and the “ICE” indicator will turn solid. One ice-making
cycle will take approximately 7–15 minutes, depending on the ambient temperature
and water temperature.
•The ice-making cycle starts with water being pumped into the ice tray
situated below the evaporator. Over the next 7–15 minutes, ice will form in
the evaporator.
•Once completed, the ice tray will tilt backwards and the remaining water in
the ice tray is drained back into the water reservoir.
•The ice cubes are then dropped from the evaporator and pushed forward
into the ice basket by the ice shovel.
•The ice tray will automatically move back into position under the evaporator
and start the next cycle.
6.When the desired amount of ice is made, press the “ON/OFF” button to stop the
ice-making process. Turn off the outlet then unplug the power cord. Open the top lid
and collect the ice using the ice scoop.
OPERATION
Note:
Do not fill the water reservoir with hot water. It is best to fill it with water that is
room temperature or colder.

Ice full indicator
The “ICE FULL” indicator will illuminate when the ice basket is full, and the ice-making cycle
will stop automatically.
Gently remove the ice from the ice basket with the ice scoop. About five seconds later, the
ice cube maker will resume making ice automatically.
Add water indicator
The “ADD WATER” indicator will illuminate when the water reservoir is out of water. The
ice-making cycle will stop automatically.
1. Remove the ice basket and add water into the reservoir.
2.Place the ice basket into the ice cube maker then press the “ON/OFF” button to
restart the ice-making cycle.

It is recommended to clean the ice maker and replace the water once a week.
Ensure the ice cube maker is turned off, unplugged, and at room temperature before
cleaning.
1. If there is residual water found in the ice tray, gently push the ice tray back so that all
water drains into the water reservoir.
2.Move the ice cube maker 75mm away from the surface it is used on and open the
drain plug to drain out excess water.
3.Remove the ice basket.
4.Clean the interior with a soft cloth soaked with warm water and vinegar, then rinse
with fresh water and drain.
5.Replace the drain plug firmly. Wash the ice basket and ice scoop in warm soapy
water. Rinse and dry.
6.Clean the exterior with a soft damp cloth. Use a mild dishwashing soap if necessary,
then wipe dry.
Storage
If the ice cube maker will not be used for an extended period, ensure the water reservoir is
empty, and all components are dry.
Store in a cool, dry place, away from direct sunlight.
CLEANING & CARE
Notes:
•Do not use organic solvents, boiled water, detergent, strong acid, or strong
alkali to clean this ice cube maker.
•Do not clean the evaporator.

Issue Possible cause Steps to resolve
The “ADD
WATER”
indicator is
illuminated.
There is insufficient
water in the ice cube
maker.
Refill the water reservoir and restart.
The screen at the
bottom of the water
reservoir is blocked.
Unplug the ice cube maker and clean.
The pump has
malfunctioned.
Stop use immediately and contact
help.Kogan.com for assistance.
The “ICE
FULL”
indicator is
illuminated.
The ice basket is full. Remove ice from the ice basket.
The infrared LED and
receiver are not
working.
Clean the infrared LED and receiver then
restart the ice cube maker.
The “ADD
WATER” and
“ICE FULL”
indicators are
illuminated.
The ice tray is not in
the correct position.
•Ensure the ice tray is unobstructed.
•Unplug, reconnect, and restart the ice
cube maker.
The ice cubes
are clumping
together.
The ice-making cycle
is too long.
1. Turn off the ice cube maker to stop making
ice.
2. Wait until the ice inside melts before
restarting.
The water
temperature is too
low.
Refill the water reservoir with water between
8–25°C.
The ice cube
maker is
operating but
not making
ice.
The ambient
temperature or water
temperature is too
high.
•Ensure the ambient temperature is
between 5–32°C.
•Refill the water reservoir with water
between 8–25°C.
The refrigeration
system is leaking.
Stop use immediately and contact
help.Kogan.com for assistance.
The refrigeration
system is blocked.
Stop use immediately and contact
help.Kogan.com for assistance.
TROUBLESHOOTING

Poor
icemaking
results
There is poor heat
dissipation.
Ensure there is at least a 25cm clearance on
all sides of the ice cube maker for proper
ventilation.
The water
temperature is too
high.
Refill the water reservoir with water between
8–25°C.
The ambient
temperature is too
high.
Ensure the ambient temperature is between
5–32°C.
Ice is getting
stuck.
Occasional
occurrence in low
temperatures.
The ice cube maker will automatically enter
standby after three instances of ice sticking
and run again automatically after 20
minutes.
If the above steps do not resolve an issue you are facing, contact help.Kogan.com for
assistance.

Power supported 220–240V, 50Hz
Rated current 0.8A
Refrigerant R600a/27g
Foaming agent C5H10
Net weight 9.03kg
Housing material ABS
Dimensions (D x W x H) 348 x 248 x 295mm
SPECIFICATIONS

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
