Kogan KA12KBICEMKA User manual

12KG ICE CUBE MAKER
KA12KBICEMKA

Ensure to read all instructions and warnings in this user guide prior to first use. Retain this
user guide for future reference.
• This ice cube maker is not intended for use by persons (including children) with reduced
physical, sensory, or mental capabilities, or lack of experience and knowledge unless
they have been given supervision or instruction concerning the use of the ice cube
maker by a person responsible for their safety.
• This ice cube maker is designed for indoor household use only.
• Do not use this ice cube maker outdoors.
• Ensure that the power supply corresponds to the one shown on the appliance rating
plate.
• Do not remove any safety, warning or product information labels from your ice maker.
• This appliance must be connected to a grounded power outlet. No other appliance
should be plugged into the same outlet. Be sure that the plug is fully inserted into the
power outlet.
• If the power cord is damaged, cease use immediately and contact help.Kogan.com for
assistance.
• The use of attachments or accessories not recommended by Kogan.com may cause
fire, electric shock or injury.
• Do not immerse any part of this product in water.
• Do not plug or unplug this product with wet hands.
• Unplug the product before cleaning, maintaining and when not in use.
• Do not clean your ice maker with any flammable fluids. The fumes may create a fire
hazard or explosion.
• If the ice maker is brought in from outside in wintertime, do not use for a few hours,
allowing the unit to warm up to the room temperature before operating.
• Unplug the ice maker before moving it to avoid damaging the refrigerating system.
• Do not attempt to disassemble, repair, modify or replace any part of your product.
• Cleaning and user maintenance shall not be made by children without supervision.
• Close supervision is necessary when any appliance is used by or near children.
• Do not use the appliance for anything other than intended use.
• This product must be disposed of in accordance with your local environmental
authority as it uses flammable blowing gas and refrigerants. The internals of the ice
cube maker should never exceed 45°C.
• The operating environment for this ice cube maker is between 5–35°C.
SAFETY & WARNINGS

• Do not turn the ice cube maker upside down. This can cause the compressor or
refrigerating system to operate incorrectly.
• Do not use with an extension cord unless necessary. If using, ensure it is suitably rated
and it is handled safely as is the ice cube maker’s own power cord.
• Do not allow the power cord to be exposed to water, heat, or direct sunlight.
• Do not allow the power cord to overhang where it can be pulled or otherwise be
damaged or pose a hazard.
• This ice cube maker contains no user-serviceable parts. If it suffers any failure or
damage, consult the “Troubleshooting” section of this user guide. If the issue is not
resolved, cease use immediately and contact help.Kogan.com for assistance.
• Do not touch the evaporator while making ice to avoid frostbite.
• Ensure the power cord is unplugged when not in use.
• Never store or use gas and other flammable articles near the ice cube maker.
Warnings
• Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear
of obstruction.
• Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food storage compartments of the
appliance, unless recommended by Kogan.com
• Do not store explosive substances such as aerosol cans with a flammable propellant in
this appliance.
• This appliance is intended to be used in household and similar applications such as
o staff kitchen areas in shops, offices and other working environments.
o farmhouses and by clients in hotels, motels and other residential type
environments.
o bed and breakfast type environments.
o catering and similar non-retail applications.

OVERVIEW
Control panel
Top cover
Viewing window
Air outlet
Front housing
Infrared receiver
Infrared LED
Filter
Drain plug
MAX level indicator

Evaporator
Ice shovel
Ice tray
Ice basket
Ice scoop

Control Panel
Key (with indicator)
Function
ON/OFF button
Start or stop the appliance
• Indicator flashing: Standby
• Indicator solid: Operational
Indicator on: Ice basket is full.
Indicator on: Water reservoir is low on water.
Indicator on: Small ice selected.
Indicator on: Large ice selected.
Indicator on: When ice maker is cleaning.
SELECT button
Select between small ice and large ice.

Unpacking
Unpack the ice cube maker, then check to ensure that all the components are included. If
components are missing, contact help.Kogan.com for assistance.
Cleaning
It is strongly recommended to clean the ice cube maker before first use.
• Remove the ice basket.
• Open the drain plug. Clean the interior with a soft cloth soaked with warm water and
vinegar. Rinse with fresh water and drain.
• Wash the ice basket and ice scoop in warm soapy water. Rinse and dry.
• Clean the exterior of the ice maker with a soft damp cloth. Use a mild dishwashing
soap if necessary.
Placement
Place the ice cube maker on a stable, level surface with at least a 25cm clearance from
heat sources (for example, ovens, heaters, and corrosive gases).
Before first use, wait for at least two hours to allow the fluids in the compressor to settle.
For subsequent uses, wait for at least 30 minutes to allow the fluids in the compressor to
settle after the ice cube maker is moved or transported.
BEFORE FIRST USE
Note:
• Do not turn the ice cube maker upside down.
• During winter, allow the appliance a few hours to warm to room temperature
before plugging in.

1. Ensure that the drain plug at the bottom of water reservoir is closed well.
2. Plug the ice maker into an electrical outlet, the “ ” indicator will blink.
3. Open the top lid and remove the ice basket.
4. Fill the water reservoir using potable water only.
5. Replace the ice basket and close the top lid.
6. Press the “SELECT” key to select the desired ice size.
o “” Small ice
o “ ” Large ice.
7. Press the “ON/OFF” key and the “ ” indicator lights solidly.
8. The ice-making cycle will last approximately 7-15 minutes, depending on the
ambient and water temperatures.
9. The ice-making cycle starts with water being pumped into the ice tray situated
below the evaporator. Over the next 7-15 minutes ice forms on the evaporator.
Once completed, the ice tray will tilt backwards and the remaining water in the ice
tray is drained back into the water reservoir. The ice cubes are then dropped from
the evaporator and pushed forward into the ice basket by the ice shovel. The ice
tray will automatically move back into position under the evaporator and start the
next cycle.
10. The “ ”indicator will light up when the ice basket is full and then the ice maker
will stop the ice-making cycle automatically. Gently remove the ice from the ice
basket with the ice scoop. About 5 seconds later, the ice maker will restart its ice
making function automatically.
OPERATION
Note:
if it has been moved, allow the ice maker to rest for 30 minutes before plugging it back
in.
Note:
Do not fill above the MAX water level mark.

11. The “ ” indicator will light up when the water reservoir is low on water and the
ice-making cycle will stop automatically. Remove the ice basket and refill the
water reservoir and then press “ON/OFF” key again to restart the ice-making
cycle.
12. When the desired amount of ice has been made, stop the ice making cycle by
pressing the “ON/OFF” key and unplug the unit from the electrical outlet.
13. Open the top lid and transfer the ice to a freezer.
Notes:
• Ice will last in the ice maker for up to an 18-hours, depending on the ambient
temperature.
• It is recommended to change the water at least once a week.
• Empty the water reservoir if the ice maker is not used for an extended period.

To ensure optimal performance, it is recommended to clean your ice maker at least once a
week.
1. Stop the ice-making cycle by pressing the “ON/OFF” key, unplug the ice maker
from the wall outlet and allow it to warm up to room temperature.
2. If residual water is found in the ice tray, gently push the ice tray back so that all
water drains into the water reservoir.
3. Move the ice maker so that it is over hangs approximately 60mm from the edge of
the working table and open the drain plug to drain out excess water (refer Fig.1,
Fig.2 and Fig.3).
4. Replace the drain plug and ensure it is closed well. Fill the water reservoir with
clean water, press “SELECT” until the “” indicator flashes, then press the
“ON/OFF” key, the pump will start to pump water and keep running for 6 minutes
and then will enter standby. Open the drain plug and empty the water.
5. Remove the ice basket.
6. Clean the ice maker interior with a soft cloth soaked with warm water and vinegar,
then rinse with clean water and then drain all the water.
7. Replace the drain plug and ensure it is closed well. Wash the ice basket and ice
scoop in warm soapy water. Rinse and dry.
8. Clean the exterior of the ice maker with a soft damp cloth. Use a mild dishwashing
soap, if necessary.
9. Please empty the water reservoir and dry it for storage if the ice maker is not used
for a long time.
CLEANING & CARE
Note:
Do not use solvents, boiling water, detergent, strong acid and strong alkali etc. for
cleaning.

Figure 1
Figure 2 Figure 3
Working table
60
Drain plug
Drain plug

Problem
Possible causes
Solution
“” indicator turns on
Low water level or lack of
water
Stop making ice, refill water
and then press “ON/OFF”
key to restart ice-making
cycle.
The water screen at the
bottom of water reservoir is
blocked.
Clean the water reservoir.
Pump malfunction.
Contact help.Kogan.com
for support.
“” indicator lights up
Ice basket is full and the
infrared light is blocked by
the ice.
Remove the ice from ice
basket.
Infrared light-emitting
diode & light-receiving
diode do not work
Wipe up the foreign objects
on the infrared LED & light-
receiving diode and restart
the ice maker.
If problem persists, contact
help.Kogan.com for
support.
The ice sticks together.
Making ice takes too much
time.
Stop making ice and restart
the ice-making cycle after
the ice melts.
The temperature of the
water in the water reservoir
is too low.
Fill the water reservoir with
water between 8°C and
25°C.
TROUBLESHOOTING

The ice-making cycle
seems normal, but no ice is
produced.
The ice-making cycle
seems normal, but no ice is
produced.
The ambient temperature
or water temperature is too
high.
Start the ice-making cycle
at an environment with an
ambient temperature less
than 32°C and fill the water
reservoir with some cold
water.
Refrigerating system leaks
Contact help.Kogan.com
for support.
The ambient temperature
or water temperature is too
high.
Start the ice-making cycle
at an environment with an
ambient temperature less
than 32°C and fill the water
reservoir with some cold
water.
Poor ice-making result
Poor heat dissipation.
Leave an 8-inch (20cm)
clearance on all sides of
the ice maker for proper
ventilation.
The water temperature is
too high.
Fill the water reservoir with
water between 8°C and
28°C.
The ambient temperature
is too high.
Operate the ice maker at
an environment with an
ambient temperature
between 10°C and 32°C.

Water pump does not work
or produces noise.
Water pump is damaged.
Contact the after-sales
department for replacing
the water pump.
The appliance has not
been cleaned for a long
time, which has resulted in
the formation of mucoid
substance at the water
inlet of the water pump, so
that the water-pumping is
not smooth. There is air in
the water pipe, so there will
be resonance noise
produced when pumping
water.
The appliance should be
cleaned in one to two
weeks and some neutral
cleaning agents (such as
detergent and soapy water
etc.) can be added if
necessary.
Disposal
This marking indicates that this appliance should not be disposed with
other household wastes. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources.

Applicable climate
ST/SN/N/T
Class
I
Power source
220-240V/50Hz
Rated power
150W
Refrigerant/Refrigerant amount
R600a / 20g
Net weight
6.2kg
Housing
PP
Dimensions (DxWxH)
292 x 238 x 282mm
SPECIFICATIONS

NOTES

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
