Kogan KA19LICEMKA User manual

Table of Contents
Safety & Warnings.......................................................................................................................................................... 1
Overview............................................................................................................................................................................ 1
Operation.......................................................................................................................................................................... 2
Cleaning & Care.............................................................................................................................................................. 3
Troubleshooting............................................................................................................................................................. 4
Safety & Warnings
• ead all instructions before using the appliance and retain for reference.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their
safety.
• Do not use outside of indoor household use as described in this manual.
• Do not use with an extension cord unless necessary, and if so, ensure it is suitably rated and it is
handled safely as is the product's own power cord:
• Do not allow the power cord to be exposed to water, heat, direct sunlight or overhang where it
can be pulled or otherwise be damaged or pose a hazard.
• This appliance contains no user-serviceable parts. If it suers any failure or damage, cease
usage and contact Kogan Support after consulting the Troubleshooting section of this manual.
• Do not touch the evaporator while making ice to avoid frostbite.
• Unplug while not in use.
• Never store or use gas and other flammable articles near the ice maker.
Overview
Main product
1) Top lid
2) Evaporator
3) Air outlet
4) Viewing window
5) Ice tray
6) Ice shovel
7) Ice basket
8) Ice scoop
9) Control panel
10) Max level indicator
11) Water reservoir
12) Drain plug
13) Infrared LED
14) Infrared receiver
1

Control panel
ON/OFF Start or stop appliance.
ICE Blinks in standby mode, solid in
working mode
ICE FULL Lights up when ice basket full
ADD WATE Lights up when water reservoir
empty
Specifications
Power source ated power efrigerant Foaming agent
220-240V/50Hz 105W 134a/68g C5H10
Net weight Housing Size (D x W xH)
9.03kg ABS 348*248*295mm
Operation
Before first use
1. Unpack the appliance, then check to ensure that all the accessories are
included. If not, contact Kogan Support.
2. Install the ice maker on stable, level surface with sucient ventilation (at least
25cm), far from heat sources such as ovens, heaters and corrosive gases to
ensure good operation.
3. The ice maker cabinet should never exceed 45°. Do not turn upside down. This
can cause the compressor or refrigerating system to operate incorrectly. Please
allow time for the fluids in the compressor to settle after the ice maker is moved
or transported (at least 30 minutes). Before using the ice maker for the first
time, please wait for 2 hours after installation.
NOTES:
• Clean before first use. (See “Cleaning & Care”)
• Do not fill the water reservoir with hot water. This may damage the ice maker. It
is best to fill the water reservoir with water of room temperature or lower.
• Do not use the appliance in very cold environments (lower than 5°C).
How to use
1. Ensure that the drain plug at the bottom of water reservoir is closed well.
2. Plug the ice maker into the wall outlet: the “Ice” indicator will blink.
3. Open the top lid and remove the ice basket.
4. Fill the water reservoir with drinking water.
5. eplace the ice basket and close the top lid.
6. Press “On/O” and the “Ice” indicator will become solid.
7. The ice-making cycle will last approximately 7-15 minutes, depending on the
ambient temperature and water temperature.
8. The ice-making cycle starts with water being pumped into the ice tray
situated below the evaporator. Over the next 7-15 minutes ice forms on the
evaporator. Once this has completed, the ice tray will tilt backwards and the

remaining water in the ice tray is drained back into the water reservoir. The ice
cubes are then dropped from the evaporator and pushed forward into the ice
basket by the ice shovel. The ice tray will automatically move back into position
under the evaporator and start the next cycle.
9. The “Ice Full” indicator will light up when the ice basket is full and the ice
maker will stop the ice-making cycle automatically. Gently remove the ice from
the ice basket with the ice scoop. About 5 seconds later, the ice maker will
restart its ice making function automatically.
10. The “Add Water” indicator will light up when the water reservoir is out of
water and the ice-making cycle will stop automatically. At that time, remove the
ice basket and add water to the water reservoir, and then press “On/O” again
to restart the ice-making cycle.
11. When the desired amount of ice has been made, stop the ice making cycle by
pressing “On/O” and unplug the unit from the wall outlet.
12. Open the top lid and transfer the ice to a freezer.
Note: The ice will last in the ice maker for up to 18 hours, depending on ambient
temperature.
13. Allow the ice maker to reach room temperature.
14. It is best to replace the water once a week. Empty the water reservoir if the
ice maker will not be used for a long time.
Cleaning & Care
To keep your ice tasting fresh and your ice maker looking great, it is
recommended to clean the ice maker once per week.
1. Stop the ice-making cycle by pressing “On/O”, unplug the ice maker from the
wall outlet and allow it to warm up to room temperature.
2. If residual water is found in the ice tray, gently push the ice tray back so that
all water drains into the water reservoir.
3. Move the appliance 75mm away from the working table and open the drain
plug to drain out excess water (see images below).
4. emove the ice basket.
5. Clean the ice maker interior with a soft cloth soaked with warm water and
vinegar, then rinse with clean water and then drain all the water.
6. eplace the drain plug firmly. Wash the ice basket and ice scoop in warm
soapy water. inse and dry.
7. Clean the exterior of the ice maker with a soft damp cloth. Use a mild
dishwashing soap, if necessary.
Note:
•Do not use organic solvent, boiled
water, detergent, strong acid and
strong alkali etc. for cleaning.
• Do not clean the evaporator.
• Please empty the water reservoir
and dry it for storage if the ice
maker is not used for a long time.
3

Troubleshooting
Issue Possible Cause Steps to esolve
“Add Water”
indicator lit
1. Insucient water
2. Water screen at the bottom
of water reservoir blocked.
3. Pump malfunction.
1. efill water reservoir and restart
2. Clean
3. Contact Kogan Support
“Ice Full” indicator
lit
1. Ice basket is full
2. Infrared LED and receiver not
working
1. emove ice from ice basket
2. Clean infrared LED and receiver and
restart ice maker
“Add Water” and
“Ice Full” indicators
lit
The ice tray is not in the right
position
1. Check if the ice tray is blocked by
something
2. Unplug, reconnect and restart
appliance
Ice collects together Making ice takes too much time Stop making ice and restart the ice-
making cycle after the ice melts
Water temperature too low efill, ensure water is between 8-25°C
Ice-making cycle
seems normal but
no ice produced
Ambient temperature or water
temperature too high
estart in environment with ambient
temperature less than 32°C and refill
with cold water
efrigerating system leaking Contact Kogan Support
efrigerating system blocked Contact Kogan Support
Poor ice-making
results
1. Poor heat dissipation.
2. Water temperature too high.
3. Ambient temperature too
high.
1. Leave at least 25cm clearance on all
sides for proper ventilation.
2. efill, ensure water is between 8-25°C
3. estart in environment with ambient
temperature less than 32°C
If the above steps do not resolve an issue you are facing, contact Kogan
Support.
User manual is subject to change without notice. For the latest version of your user manual,
please visit https://www.kogan.com/usermanuals/
4
