Kogan KASLJUICERA User manual

COLD PRESS SLOW JUICER
KASLJUICERA

Read all instructions and safety warnings in this user guide before using this appliance for
the first time. Retain this user guide for future reference.
• Ensure that the voltage power corresponds to the one indicated on the appliance
nameplate.
• Do not operate the appliance if the cord or plug is damaged, or if the appliance
malfunctions or has been damaged in any way. Cease use immediately and contact
help.Kogan.com for support.
• The use of attachments, including sieves, lids, food pushers, or jars that are not
recommended or sold by Kogan.com, may cause fire, electric shock, or injury.
• Do not place the appliance on or near a hot gas or electric burner, or in a heated oven.
• Do not allow the cord to hang over the edge of a table or counter.
• Never run the appliance without any food inside.
• Do not use the appliance if the rotating sieve is damaged.
• Avoid inserting your fingers or other objects into the juicer opening while it is in
operation. If food becomes stuck, use the food pusher or another piece of fruit or
vegetable to push it down. If this method is not possible, turn off the appliance,
disconnect the power and disassemble the juicer to remove the remaining food.
• Do not push food into the hopper with your hand, spoon, chopstick, clip, or any other
object besides the food pusher when the appliance is connected to a power source.
• Always ensure that the juicer cover is securely in place before turning on the motor. Do
not unfasten the clamps while the juicer is in operation.
• Avoid contact with moving parts.
• After each use, ensure the juicer switch is in the off position. Ensure that the motor has
completely stopped before disassembling.
• Do not immerse the motor unit in water or other liquids.
• After cleaning, ensure that all detachable parts are completely dry before reassembling
them for the next use.
• Close supervision is necessary when any appliance is used by or near children.
• Ensure all users are familiar with this user guide and warned about the potential for
injury from misuse.
• If the supply cord is damaged, cease use immediately and contact help.Kogan.com for
support.
SAFETY & WARNINGS

• Always disconnect the juicer from the power supply if it is left unattended, and before
assembling, disassembling, or cleaning.
• This appliance should not be used by children. Keep the appliance and its cord out of
the reach of children.
• Children should not play with the appliance.
• Do not use the appliance if the blade or filter cover is damaged or has visible cracks.
• Switch off the appliance and disconnect it from the power supply before changing
accessories or approaching parts that move during use.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• This appliance is NOT suitable for use outdoors.

OVERVIEW
Food pusher
Grinding Head
Filter
Grinding
Assembly
Blade
Small cleaning
brush
Juice outlet cover
Juice container
Juice outlet
Juicing bowl
Pulp container
Power switch
Motor unit
Pulp outlet
Hopper

1. Attach the jar to the motor unit and ensure the symbol “ ” on the juicing bowl aligns
with the symbol “ ” on the motor unit so that it can be locked in tightly.
2. Ensure the juicing bowl is correctly assembled with the buffer aligned with the inside of
the residue outlet.
ASSEMBLY
Buffer plate
Buffer plate

3. Place the filter into the blade and then place them both into the juicing bowl. Ensure
the symbol “ ”on the filter aligns with the symbol “ ” on the motor unit.
4. Insert the grinding head into the filter and ensure the grinding head is seated correctly
within the motor unit.

5. Attach the hopper onto the juicing bowl and use align the symbols “” on both pieces.
When the symbols are aligned, rotate the hopper clockwise to lock it into place.
Note:Ensure the hopper is correctly installed otherwise the appliance will not operate.
6. To disassemble the hopper from the motor unit, rotate it anticlockwise.
7. Place your juice container below the juice outlet and the pulp container below the pulp
outlet.
8. The juicer is ready for operating.

1. Remove the grinding assembly and the filter together and then separate them.
2. Immerse all the detachable parts and accessories in warm soapy water and rinse them
and dry everything thoroughly before assembly.
3. Prepare all the required ingredients according to the characteristics of them:
• Materials with hard fibres
o Cut into slices 3~5cm in length and 1.5~2cm in thickness.
• Leafy vegetables and materials with long & hard fibre (such as celery, wild celery herb
and collard etc.)
o Cut the stems of the materials into slices 3~5cm in length and then roll up the
leaves of the materials well.
• Fruit with hard cores must be pitted. Do not place the cores of peach, plum, mango,
apricot and other stone fruits into the hopper to avoid any malfunction.
• Ingredients with thick or hard peels must be peeled before being put into the juicer for
processing.
• Frozen ingredients must be defrosted before juicing.
• Do not process ingredients with high vegetable oil or animal oil with this juicer to avoid
the degradation and damage of the grinding head
• Do not juice sugarcane, coconut or cereals (e.g., bean, rice) without first being soaked in
water to soften.
• Ensure the buffer plate is correctly in position before operating the juicer.
BEFORE FIRST USE
WARNING: Do not immerse motor unit in water for cleaning to prevent
the risk of electric shock.

This juicer squeezes the fruit instead of grinding which allows the juice to maintain its pure
colour, natural taste, nutrients and vitamins. The juice will flow in your juice container from
the juice spout and the pulp will be ejected from pulp ejection spout and be collected by
pulp container. When using the juicer, the pulp container and juice container must be
assembled in position.
Power Switch
the power switch has three settings:
• “I” indicates “ON”, press the power switch to “I” position to activate the motor and start
making juice.
• “O” indicates “OFF” position, press the power switch to “O” position to turn off the
juicer.
• “R” means reverse rotation, which is only used when something is stuck and you need
to unclog.
Using the Juicer
1. Before connecting the power cord into the electrical outlet, ensure the power
switch is in the “O” position.
2. Ensure the juice container and the pulp container are placed in position.
3. Cut fruits and vegetables into smaller pieces (15x15x15mm) before placing them
into the juicer.
4. Place the ingredients into the hopper and use the pusher to feed them into the
grinding head.
5. Connect the appliance to the power source and then press the power switch to
the “I” position, the appliance starts to work. After few minutes, the juice flow out.
OPERATION
Notes:
• Do not turn the power switch from "I" to "R" or from "R" to "I" directly at any time
during operation. Always allow the appliance stop running completely and then
turn the power switch from "I" to "R" or from "R" to "I".
• Do not operate the unit before placing food into the hopper, to avoid damaging
the grinding assembly (include grinding head and strainer).
• Do not put your fingers or other foreign objects into the feeding opening during
operation.

6. When the juice container is full (the max capacity is 400ml) or the food has
finished extracting, turn the power switch to the “O” position and empty the juice
container and residue container before continuing extracting.
7. During operation, if the machine gets stuck, place the power switch to “O” position
and then press the reset button located on the bottom of the appliance
8. Press and hold the power switch in the “R” position for few seconds then try
resuming operating.
9. If the reverse function doesn’t work, remove the ingredients and disassemble the
juicer to clear any large pieces of food.
10. Reassemble the juicer and resume operation.
Notes:
• Do not use the juicer for more than 15 minutes at a time. Ensure a minimum 30 minutes
of rest between operating cycles.
• Do not overfill the juicer. Once the juice container is full, you must stop the appliance
and empty the pulp container before next cycle.
• During operation, if the interlock switch between the hopper and the motor unit is
disconnected, the motor will stop to prevent from danger.
Reset button
reset
Notes:
• Remove any hard seeds before juicing.
• It is not recommended to process coconuts or similar hard ingredients, since this
may damage the motor.
• It is not recommended to process hard fruits or vegetables rich in fibre and
starch, such as sugarcane.
• The peel and pips should be removed from oranges, lemons, grapefruits and
melons.

• Unplug the appliance and wait for it to completely cool down before cleaning.
• After extracting juice, pour some water into the hopper to clean it so that it will be
easier to be detached.
1. Unlock the hopper by turning it in anti-clockwise and then remove it.
2. Detach the blade, filter and grinding head.
3. Rotate the juicing bowl anticlockwise and then remove it.
4. Empty the pulp container and then clean the hopper, grinding head, filter, blade,
juicing bowl and pulp container under running water.
5. To clean the pulp outlet, remove the buffer plate and clean it using a small
cleaning brush.
6. Wipe the outside of motor unit with damp cloth. Do not immerse the motor unit in
water.
7. Dry all parts and assemble all parts and then store the appliance in a dry place.
8. The juice container can be stored in the pulp container.
Disposal
This marking indicates that this appliance should not be disposed with
other household wastes. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources.
CLEANING & CARE
Note:
• The blade is sharp, so handle carefully during cleaning.
• Do not use metal scourer to clean, this will damage the machine.

NOTES

Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
