Introduction
Thank you for selecting the Kogan Smart Bluetooth Body Fat Scale. The scale
measures eight and uses bio-electrical impedance analysis (BIA) technology to
estimate body fat, total body ater percentage, bone mass and muscle mass in
generally healthy children from 14-17 years old and healthy adults.
Safety Information
The symbols belo may appear in the user manual, labelling or other
components. Please follo all instructions.
Symbol for “Guide must be read” Symbol for “manufacturer”
The Bluetooth compatible symbol Symbol for “Environment Protection –
aste electrical products should not
be disposed of ith the household
aste.
Please recycle here facilities exist.
Check ith your local council or
authorities for recycling advice.”
Symbol for “manufacture date”
Symbol for “serial number”
Symbol for “Complies ith EU
requirements”
Caution
•The scales offer you a seamless ay to manage your health. Please be
a are that this product is designed for healthy people over 14 years old,
self measuring and self monitoring their body compositions. Any
information provided by this device is in no ay meant to treat, cure or
prevent any disease or illness from happening.
•If in doubt, contact your doctor.
•DO NOT use this device if pregnant or if you suspect you may be pregnant.
The effects of this device on a fetus is unkno n and untested.
•DO NOT use this device if you have a earable or implanted electronic
device such as a defibrillator or pacemaker.
•This device should not be used by someone ho is acutely or chronically ill
or suffering from a disease or taking medications that ill affect your ater
levels. The accuracy of the readings for these patients cannot be verified.
Specific medical information should be obtained from a doctor.
•The scales are equipped ith data transmission functions, therefore it ill
emit electromagnetic energy to perform its intended function. Nearby
portable and mobile RF communications equipment can affect the
performance.
•No modifications of this equipment are allo ed.
•Please only use the device as described in this user manual. Any misuse
may cause electric shock, burns, fire or other unexpected hazards.
•Do not expose the scales to extreme temperatures, direct sunlight,
moisture or a corrosive environment.
•Do not step on the scale hen your body or feet are et, especially after
bathing or sho ering.
2

Usage Tips
•To ensure the accuracy of measurements, please follo the instructions
belo hen starting measurement.
•Place the scale on a flat, hard surface. Soft surfaces such as carpet ill
affect the performance of the scale.
•Step onto the platform ith bare feet. Stand still and keep full contact ith
the electrodes until the measurement is complete.
•Perform measurement at least t o hours after aking up or dining.
•Avoid measurements immediately after strenuous exercise, a sauna, a bath,
drinking or dining.
•Try to perform measurements at the same time of day in the same location
on the same surface.
•The condition of the skin on the bottom of your feet can affect the reading.
The natural effects of aging or activity can make this skin hard. Take the
reading ith clean, slightly damp feet for best accuracy. If you are having
trouble operating the scales, please contact the Kogan customer service
team.
•Body fat percentage estimates ill vary ith the amount of ater in the
body, and can be affected by dehydration or over-hydration due to such
factors as alcohol consumption, menstruation, illness, intense exercise etc...
Product Overview
Device Components
3
LCD Display
Electrode Electrode
UNIT Button
Battery Compartment

Contents List
1 x Body scale
4 x AAA batteries
1 x User manual
LCD Display
st lb Stone Successful Bluetooth Connection
lb Pound Data transmitting/pending
Kg Kilogram Lo Battery
Initial Start Up
General Instructions
The Kogan smart scale applies BIA (Bio-impedance Analysis) technology. A small
amount of eak current flo s through the human body so as to detect the bio-
impedence and estimate body fat. The electric current is so small as to not be felt
by the user.
BIA technology is safe, non-invasive, toxin-free and harmless. The current used is
less than 1mA, ho ever anyone earing any form of electronic medical implant
such as a pacemaker must avoid using this device.
Inserting the Batteries
•Open the battery door in the back of the scale.
•Insert the batteries (4 x 1.5V AAA) into the battery compartment,
making note of the polarity indicators marked inside the
compartment.
The digits “8888” ill be sho n on the LCD.
•Close the battery door and ait until the digits “0.0lb” are sho n on
the LCD.
Caution
•When the symbol appears, the device ill po er off. You should then
replace the batteries ith a ne set of batteries. Please replace all four
batteries at the same time. Do NOT mix old batteries ith ne ones.
•Worn out batteries are classified as hazardous aste. Do NOT dispose of
them in the household garbage.
•If you do not intend to use the scales for a prolonged period of time, please
remove the batteries before storing.
Installing the App and Pairing Up
1. With Bluetooth 4.0 technology applied, mobile or portable equipment is
capable of receiving your personal health data.
2. Simply install the App from the App store.
3. Turn on Bluetooth and start the App up, and ensure the scale is turned on
before pairing.
4

4. Press and hold the UNIT button on the back of the scale to pair up. A
symbol of t o small circles spinning around each other ill display to
indicate that pairing is proceeding.
•If successful, a linked square icon ill sho on the LCD.
•If the pairing fails, an E1 error symbol ill sho on the LCD.
Selecting Measurement Unit
With the batteries installed, press the UNIT button in the back of the
scale to select your preferred measurement unit. The default
measurement unit is lbs (pounds). You may press UNIT to choose
bet een pounds, kilograms or stone.
Measuring
Daily Measurement
The scale ill turn on as soon as you step onto the
platform in bare feet.
Stand still and keep full contact ith the electrodes.
The eight unit ill flash, then the eight
measurement ill be locked. When the moving “o”
animation stops, the LCD ill display the eight and
body fat measurement.
When the scale is successfully paired ith the
smartphone and the Bluetooth is turned on, the data
transfer ill begin automatically.
(Please refer to 'Data Transmission' belo for more
details)
Data Management
Data Transmission
With the scales successfully paired up ith
your smartphone, measurement data ill be
automatically transmitted to your mobile via
Bluetooth.
The symbol ill disappear once the data
transfer has complete successfully. You may then
check your health data on your phone.
Successful Bluetooth Connection
If the data transmission fails, the symbol ill
remain on the screen. The pending data ill be
stored in the scale and transmitted to your
smartphone hen the next measurement is
taken.
Data transmitting to the ireless
device.
•If successful, icon ill
disappear.
•If failed, icon ill remain.
5

Caution
•Interference may occur in the vicinity of equipment marked ith the
symbol.
•To enable the data transmission function, the product should be paired to a
Bluetooth 4.0 device.
How to avoid possible interference?
1. The range bet een the scales and the Bluetooth device should be
reasonably close, any here bet een 1 and 10 metres. Please ensure that
there are no objects bet een the scale and the Bluetooth device.
2. To avoid interference, other ireless/Bluetooth enabled devices should be
kept a ay from the scales hile transmission is taking place.
Troubleshooting
Error Prompts
Error Description Solution
Overload – Device ill
po er off.
Stop using the scale for
measurement.
Lo battery – Device
ill po er off.
Replace all four batteries
at the same time.
Pairing failure Please check:
•Bluetooth is ON
•The App is ON
•Both devices are
ithin
transmitting
distance.
During Measurement
Problem Cause Solution
Abnormal results such as
•Too high
•Too lo
•Huge differences
bet een consecutive
measurements
Incorrect posture Please step onto platform
in bare feet and stand still.
Scale is on soft carpet
or unstable surface
Place the device on a hard,
flat surface.
Cold body that may
result in bad blood
circulation
Warm your hands and feet
to improve blood
circulation then measure
again.
Cold electrodes Place the device in a arm
room for a hile, then try
again.
Hands or feet are too
dry
Wipe your feet ith a
damp cloth, making them
slightly damp.
No display on LCD hen
device po ers on.
Batteries not installed Install the batteries into
the unit.
Worn or flat batteries Replace all four batteries
at the same time.
6

Problem Cause Solution
Cannot proceed to analyse
body fat.
Stepping onto scale
earing socks or
shoes
Stay in bare feet during
measurement, keeping full
contact ith the
electrodes at all times.
Device po ers off
automatically
Lo battery Replace all four batteries
at the same time.
During Data Transmission
Problem Cause Solution
Data transmission failed
Bluetooth is OFF Turn on Bluetooth via the
settings.
App is not running Press the icon to run the
App.
Devices are out of
range
Place your smartphone
closer to the scale.
Specifications
Product K
Dimension 320 x 330 x 27.2mm (approximately)
Net eight Approximately 1.75kg (excluding
batteries)
Display Digital LCD ith hite backlight
Measurement units Kilograms/Pounds/Stone
Measurement range 5kg ~ 180kg/0st 11lb ~ 28st 5lb / 11lb ~
397lb
Division 0.1kg / 0.2lb
Accuracy 0-50kg: ±0.3kg; 50-100kg: ±0.4kg;
100-150kg: ±0.5kg; 150-180kg: ±0.7kg
Working environment Temp: 5~40°C Humidity: <90% RH
Storage environment Temp: -20~60°C Humidity: <93% RH
Po er source 6V (4 x AAA batteries)
Turn on method Sense on Technology
Auto-OFF Scale ill shut do n after 10 seconds of
no operations.
Accessories 4 x AAA batteries
1 x user manual
Mode of operation Continuous operation
Bluetooth module no. AW8001
About the accuracy of this product
•This product passes strict inspections before delivery and therefore its
accuracy is guaranteed by Kogan.com.
•This product is specifically designed for body fat analysis as ell as eight
measurement. It should NOT be used by anyone during the process of
transaction verification of goods' eight.
7

Maintenance
When carrying out usual maintenance, please ensure you follo these do's and
don'ts:
•Do use a soft cloth to ipe off dust
•Do use a damp soft cloth, dipped into ater and rung out, to ipe up any
extra dirt. Then use a soft dry cloth to dry the device.
•Don't ash the device ith ater, or immerse it in any liquids.
•Don't use propellant or any abrasive chemicals to ipe off dirt as this may
cause discolouration or malfunctions.
•Don't disassemble this device. If you have any problems, please contact the
Kogan customer service team for advice. (See follo ing 'Warranty' section
for information)
Warranty
Kogan.com arrants this scale to be free of defects and orkmanship under
normal use for a period of ONE year from the date of purchase.
The arranty does not cover damage caused by misuse or abuse, including, but
not limited to:
•Failure caused by unauthorized repairs or modifications;
•Damage caused by shock, or dropping hile transporting;
•Failure caused by improper operation, inconsistent ith the instructions
stated in this user manual;
•Malfunction or damage from failure to provide the recommended
maintenance;
•Damage caused by improper use of a po er supply.
Should this device require any maintenance or repairs, please contact the
Kogan.com customer support team.
Appendix
Table of Body Fat Level (Unit: %)
Age
Man / Sportsman Woman / Sportswoman
Low Normal High V. High Low Normal High V. High
20 ~ 29 <13 13.1 – 20 20.1 – 23 >23 <19 19.1 – 28 28.1 – 31 >31
30 ~ 39 <14 14.1 – 21 21.1 – 24 >24 <20 20.1 – 29 29.1 – 32 >32
40 ~ 49 <16 16.1 – 23 23.1 – 26 >26 <22 22.1 – 30 30.1 – 33 >33
50 ~ 59 <17 17.1 – 24 24.1 – 27 >27 <23 23.1 – 31 31.1 – 34 >34
60+ <18 18.1 – 25 25.1 – 28 >28 <24 24.1 – 32 32.1 – 35 >35
8

Table of Body Water Level (Unit: %)
Gender Body Fat Percentage
Range
Optimal Total Body
Water Percentage Range
Male
4-14 70-63
15-21 63-57
22-25 57-55
>25.1 55-37
Female
4-20 70-58
21-29 58-52
30-33 52-49
>33 49-37
Source: derived from Wang & Deurenberg: “Hydration of fat-free body mass”. American Journal Clin Nutr 1999, 69833-841
Health Tips – About Body Fat
Fat is essential to the human body. It not only stores energy and protects viscera,
but it also regulates body temperature and maintains the normal physiological
function of the human body. Ho ever, too much body fat is harmful to the human
body, as it can lead to fatty liver, diabetes, coronary heart disease etc...
Self-measuring and self-monitoring your body fat levels is beneficial to your
health. Body fat levels cannot be judged simply by eight.
EMC Guidance
Table 1 – Guidance and manufacturer's declaration – electromagnetic emissions
for all ME equipment and ME systems.
Guidance and manufacturer's declaration – electromagnetic emissions
The device is intended for use in the electromagnetic environment as specified belo . The
customer or the user of the device should ensure that it is used in such an environment.
Emissions test Compliance Electromagnetic environment guidance
RF emissions
CISPR 11
Group 2 The device must emit electromagnetic energy
in order to perform its intended function.
Nearby electronic equipment may be affected.
RF emissions
CISPR 11
Class B
Harmonic emissions
IEC 61000-3-2
Not applicable
Voltage
fluctuations/flicker
emissions
IEC 61000-3-3
Not applicable
9

Table 2 – Guidance and manufacturer's declaration – electromagnetic immunity
for all ME equipment and ME systems.
Guidance and manufacturer's declaration – electromagnetic immunity
The device is intended for use in the electromagnetic environment as specified belo . The
customer or the user of the device should ensure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±6 kV contact
±8 kV air
±6 kV contact
±8 kV air
Floors should be ood, concrete or ceramic
tile. If floors are covered ith synthetic
material, the relative humidity should be at
least 30%.
Electrical fast
transient/burst
IEC 61000-4-4
±2 kV for po er supply
lines
±1 kV for input/output
lines
Not applicable Mains po er quality should be that of a
typical commercial or hospital environment.
Surge
IEC 61000-4-5 ±1 kV line(s) to line(s)
±2 kV line(s) to earth
Not applicable Mains po er quality should be that of a
typical commercial or hospital environment.
Voltage dips, short
interruptions and
voltage variations
on po er supply
input lines
IEC 61000-4-11
<5% UT
(>95% dip in UT)
for 0,5 cycle
40% UT
(60% dip in UT)
for 5 cycles
70% UT
(30% dip in UT)
for 25 cycles
<5% UT
(>95% dip in UT)
for 5 s
Not applicable Mains po er quality should be that of a
typical commercial or hospital environment. If
the user of the device requires continued
operation during po er mains interruptions, it
is recommended that the device be po ered
from a non-interruptible po er supply or
battery.
Po er frequency
(50/60Hz)
magnetic field
IEC 61000-4-8
3 A/m 3 A/m Po er frequency magnetic fields should be at
levels characteristic of a typical location in a
typical commercial or hospital environment.
Note: UT is the a.c. mains voltage prior to application of the test level.
Table 4 – Guidance and manufacturer's declaration – electromagnetic immunity
for all ME equipment and ME systems that are NOT life supporting.
Guidance and manufacturer's declaration – electromagnetic immunity
The device is intended for use in the electromagnetic environment as specified belo . The
customer or the user of the device should ensure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 6100-4-3
3 Vrms
150 kHz to 80 MHz
3 V/m
80 MHz to 2,5 GHz
Not applicable
3 V/m
Portable and mobile RF communications
equipment should be used no closer to any part
of the device, including cables, that the
recommended separation distance calculated
from the equation applicable to the frequency of
the transmitter.
Recommended separation distance
Where P is the maximum output po er rating of
the transmitter in atts (W), according to the
transmitter manufacturer and d is the
recommended separation distance in metres (m).
10

Field strengths from fixed RF transmitters, as
determined by an electromagnetic site surveya,
should be less than the compliance level in each
frequency rangeb.
Interference may occur in the vicinity of
equipment marked ith the follo ing symbol.
Note 1: At 80MHz and 800MHz, the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflection from structures, objects and people.
a) Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land
mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically
ith accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site
survey should be considered. If the measured field strength in the location in hich the device is used exceeds
the applicable RF compliance level above, the device should be observed to verify normal operation. If
abnormal operations are observed, additional measures may be necessary, such as re-orienting or relocating the
device.
b) Over the frequency range 150kHz to 80MHz, field strengths should be less than [V1] V/m.
Table 6 – Recommended separation distances bet een portable and mobile RF
communications equipment and the ME equipment or ME system - for ME
equipment and ME systems that are NOT life supporting.
Recommended separation distances between portable and mobile RF
communications equipment and the device
The device is intended for use in an electromagnetic environment in hich radiated RF disturbances are controlled. The
customer or the user of the device can help prevent electromagnetic interference by maintaining a minimum distance
bet een portable and mobile RF communications equipment (transmitters) and the device as recommended belo ,
according to the maximum output po er of the communications equipment.
Rated maximum
output power of
transmitter
W
Separation distance according to frequency of transmitter
m
150kHz to 80MHz 80MHz to 800MHz 800MHz to 2,5GHz
0.01 Not applicable 0.117 0.233
0.1 Not applicable 0.369 0.738
1 Not applicable 1.167 2.333
10 Not applicable 3.690 7.378
100 Not applicable 11.67 23.33
For transmitters rated at a maximum output po er not listen above, the recommended separation distance d in metres
(m) can be estimated using the equation applicable to the frequency of the transmitter, here P is the maximum output
po er rating of the transmitter in atts (W) according to the transmitter manufacturer.
Note 1: At 80MHz and 800MHz, the separation distance of the higher frequency range applies.
Note 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
reflections from structures, objects and people.
11
