1014767-1-A2002 Kohler Co.
    
Roughing-In Guide
USA: 1-800-4-KOHLER
Mexico: 001-877-680-1310
Canada: 1-800-964-5590
kohler.com
K-1248
Español, Página 3
Français, Page 4
1014767-1-A2Kohler Co.
Roughing-In
          
  
  
    
   
  
Product Information
    
     
     
   
   

  
      
     
    
    
 
  
Required Electrical Service
       
 
    
           

Notes
       
          
     
           
        
          
      
        

11”
(27.9cm)
36-5/8” (93cm)
4”
(10.2cm)
3-1/2” (8.9cm)
1-3/16” (3cm) 1-1/2” O.D.
PUMP/ CONTROL ACCESS
FRONT OR END
8-5/16”
(21.1cm)
CUT-OUT DETAIL
25-3/4”
(65.4cm)
SYMMETRICAL ABOUT C’s
L
35-1/4” (89.5cm)
14-5/8”
(37.1cm)
32-9/16” (82.7cm)
17-1/16”
(43.3cm) 17-3/4”
(45.1cm)
19-1/2”
(49.5cm)
DROP-IN RIM
DETAIL
1-1/2”
(3.8cm)
36” (91.4 cm)
72” (182.9cm)
42” (106.7cm)
2-7/8” (7.3cm)
3” (7.6cm)
21”
(53.3cm)
20-1/4”
(51.4cm)
K-1248
1014767-1-A
3
Kohler Co.
Diagrama de instalación
       
            
    
   
     
  
  

    
Información sobre el producto
     
  
       
  
    
   
   
 
 
 
       
     
      
     
 
   
Servicio eléctrico requerido
         
          

        
           
     
Notas
         
            
     
            
           
            
          
    
           
  
11”
(27,9cm)
36-5/8” (93cm)
4”
(10,2cm)
3-1/2” (8,9cm)
1-3/16” (3cm) 1-1/2” DIÁM. EXT.
ACCESO FRONTAL
O POSTERIOR A LA
BOMBA/CONTROL
8-5/16”
(21,1cm)
DETALLE DE LA ABERTURA
25-3/4”
(65,4cm)
SIMÉTRICO RESPECTO A LA LÍNEA CENTRAL
35-1/4” (89,5cm)
14-5/8”
(37,1cm)
32-9/16” (82,7cm)
17-1/16”
(43,3cm) 17-3/4”
(45,1cm)
19-1/2”
(49,5cm)
DETALLE
DEL BORDE
EMPOTRADO
1-1/2”
(3,8cm)
36” (91,4cm)
72” (182,9cm)
42” (106,7cm)
2-7/8” (7,3cm)
3” (7,6cm)
21”
(53,3cm)
20-1/4”
(51,4cm)
K-1248
1014767-1-A4Kohler Co.
Diagramme de raccordement
     
         
      
  
      
   
  

   
Renseignements du produit
      
  
       
 
     
        
     
 
 
   
   
     
     
     
     
  
 
Branchement électrique requis
            
  
        
       
          
Remarques
      
           
      
           
          
           
           
    
         
      
11 po
(27,9 cm)
36-5/8 po (93 cm)
4 po
(10,2 cm)
3-1/2 po (8,9 cm)
1-3/16 po
(3 cm) 1-1/2 po DIA. EXT.
ACCÈS AVANT OU
ARRIÈRE À LA POMPE /
COMMANDES
8-5/16 po
(21,1 cm)
DÉTAIL DE L’ÉVIDEMENT
25-3/4 po
(65,4 cm)
SYMÉTRIQUE PAR RAPPORT À L’AXE
35-1/4 po (89,5 cm)
14-5/8 po
(37,1 cm)
32-9/16 po (82,7 cm)
17-1/16 po
(43,3 cm) 17-3/4 po
(45,1 cm)
19-1/2 po
(49,5 cm)
DÉTAIL DE
REBORD POUR
INSTALLATIONS
SURBAISSÉES
1-1/2 po
(3,8 cm)
36 po (91,4 cm)
72 po (182,9 cm)
42 po (106,7 cm)
2-7/8 po (7,3 cm)
3 po
(7,6 cm)
21 po
(53,3 cm)
20-1/4 po
(51,4 cm)
K-1248
