Kohler 4CKM Specification sheet

RV/Mobile Generator Sets
Models:
4CKM
4CFKM
5CKM
4CKMR
4CFKMR
5CKMR
TP-5393 9/93
Operation and
Installation Manual

Engine exhaust fromthisproductcontains
chemicals knowntotheState ofCaliforniatocause
cancer,birth defects,orother reproductive harm.
WARNING
CaliforniaProposition 65

TP-5393 9/93 Table ofContents
Table of Contents
SUBJECTPAGE SUBJECTPAGE
SafetyPrecautions and InstructionsI......
Routine ServicePartsVIII.....................
Section 1.Specifications 1-1................
GeneralSpecifications1-1....................
Engine 1-3.................................
Generator1-4..............................
GlossaryofAbbreviations 1-5...............
Controller1-7...............................
Section 2. Operation 2-1....................
PrestartChecklist2-1........................
Start-Stop Procedure 2-1.....................
AutomaticDe-Icing (ForGasoline ModelsOnly)2-1
CircuitProtection 2-2.........................
Section 3.ScheduledMaintenance 3-1.......
Lubrication System3-2.......................
LowOil PressureShutdown 3-2...............
Oil Check 3-2...............................
Oil Change 3-3.............................
Oil Type 3-3................................
Cooling System3-4..........................
Ignition System3-5..........................
ElectronicMagnetoIgnition System3-5........
Operation 3-5...............................
SparkPlugs3-6.............................
Gasoline FuelSystem3-6.....................
Specification—Gasoline 3-6..................
FuelFilter—Gasoline Only3-7................
Gasoline CarburetorAdjustments3-8...........
MainAnd IdleFuelMixture 3-8................
LPGasFuelSystem3-9......................
Specification—LPLiquid 3-9..................
FuelFilter—LP Vapor3-9....................
LPCarburetorAdjustments3-10................
MainFuelMixture 3-10.......................
IdleFuelMixture 3-10.........................
FuelValve and Filter—LPLiquid 3-10...........
ChokeAdjustments3-11.......................
ProcedureForOperation
above 10°F(-12.2°C)3-11...................
ProcedureForOperation
below10°F(-12.2°C)3-11...................
ElectronicGovernor3-12......................
AirCleaner3-12..............................
Battery3-13..................................
BatteryCharging (ifequipped)3-13.............
Cleaning 3-14................................
Checking Electrolyte Level3-14................
Checking SpecificGravity3-14.................
CylinderHead Service 3-15....................
ValveService 3-15............................
Wattage Requirements3-16....................
GeneratorService 3-17........................
General3-17................................
Storage Procedure 3-17.......................
Section 4.Troubleshooting 4-1..............
Engine 4-1..................................
Generator4-2...............................
Section 5.Wiring Diagrams 5-1..............
Four-Lead Reconnectable(Single-Phase)5-2...
Section 6. Installation 6-1...................
Introduction 6-1..............................
GeneralInformation 6-1......................
GeneratorSelection And Wattage
Requirements6-2..........................
Installation Factors6-2.......................
ElectricalLoad 6-2..........................
Lighting Load 6-2...........................
MotorLoads6-3............................
Appliance Loads6-3.........................
Kilowatt Derating 6-4........................
4/5CKM-RVGeneratorSetMounting 6-5........
CompartmentSize 6-5.......................
AirRequirements6-6........................
Mounting 6-8...............................
4/5CKMR-MobileGeneratorSetMounting 6-9...
CompartmentMount6-10.....................
Below-floorMount6-11.......................
Vehicle-floorMount6-12......................
Extended Shaft Option 6-12...................
AirRequirements6-13........................
FuelSystem6-16.............................
Gasoline 6-16...............................
LPGasFuelSystem6-17.....................
ExhaustSystems6-18.........................
ElectricalSystems6-22........................
BatteryAnd Connections6-23.................
ACLoad Lead Connections6-24...............
RemoteSwitchConnection 6-25...............
Section 7. Installation Drawings 7-1..........
Section 8.Service Ordering Instructions 8-1. .
ServiceManualProcurement8-1..............
Section 9. Operating HourService Log 9-1...

SafetyPrecautionsand InstructionsITP-5393 9/93
Safety Precautions and Instructions
Ageneratorset, like anyotherelectro-mechanical
device,can pose potentialdangerstolife and limbif
improperlymaintained orimprudentlyoperated.The
bestwayto preventaccidentsisto be aware of the
potentialdangersand to always use good common
sense. Inthe interestofsafety,some general
precautionsrelating tothe operation ofa generatorset
follow.Keep theseinmind.Thismanualcontains
severaltypesofsafetyprecautionswhich are explained
below.
DANGER
Dangerisusedtoindicatethepresenceofahazardthat
will causeseverepersonal injury,death,orsubstantial
propertydamage if the warning isignored.
WARNING
Warning isused toindicatethe presence ofa hazard
thatcan causeseverepersonal injury,death,or
substantialpropertydamage if the warning isignored.
CAUTION
Cautionisusedtoindicatethepresenceofahazardthat
will orcan causeminorpersonal injuryorproperty
damage if the warning isignored.
NOTE
Noteisusedtonotifypeople ofinstallation,operation,or
maintenanceinformation thatisimportantbutnot
hazard-related.
Safetydecalsare affixed tothe generatorsetin
prominentplacesto advisethe operatororservice
technician ofpotentiallyhazardous situations.The
decalsarereproduced heretoimprove operator
recognition and therebyincrease decaleffectiveness.
Forafurtherexplanationofdecalinformation,reference
theaccompanying safetyprecautions.Beforeoperating
orservicing the generatorset, be sureyou understand
the message of these decals.Replace decalsifmissing
ordamaged.

TP-5393 9/93II SafetyPrecautionsand Instructions
EXHAUSTSYSTEM
WARNING
Carbon monoxide.
Cancause severenausea,fainting,ordeath.
The exhaustsystem mustbe leakproofand
routinelyinspected.
Carbon monoxide cancause severenausea,
fainting,ordeath.Install exhaustsystemtail pipe so
discharged exhaustgaseswill notbe drawnintovehicle
interiorthrough windows,doors,airconditioners,etc.
Do notuseflexibletail piping sincethistype couldcrack
and allowlethalexhaust fumesto enterthe vehicle.
Carbon monoxide cancause severenausea,
fainting,ordeath.Neveroperatethe generatorset
inside a building unless the exhaustgasispiped safely
outside.Neveroperatein anyarea where exhaustgas
could accumulate and seep back inside an occupied
buildingorvehicle.Becarefulwhenparkingyourvehicle
to avoid obstructing the exhaustoutlet. The exhaust
gasesmustdischarge freely,otherwisecarbon
monoxide maydeflectintothe vehicle.Avoid breathing
exhaust fumeswhen working on ornearthe generator
set. Carbon monoxide isparticularlydangerous
becauseitisan odorless,colorless, tasteless,
nonirritatinggasthatcancausedeathifinhaledforeven
ashortperiod of time.
ACCIDENTALSTARTING
WARNING
Accidentalstarting.
Cancause severeinjuryordeath.
Disconnectbattery cablesbeforeworking on
generatorset(negativelead firstand reconnectit
last).
Accidentalstarting cancause severeinjuryor
death.Turn generatormasterswitchtoOFF position,
disconnectpowerto battery charger,and remove
battery cables(remove negativelead firstand
reconnectitlast)todisablegeneratorsetbeforeworking
on anyequipmentconnected to generator.The
generatorsetcan be started byautomatictransfer
switch or remotestart/stop switch unless these
precautionsarefollowed.

SafetyPrecautionsand InstructionsIIITP-5393 9/93
MOVINGPARTS
WARNING
Hazardous voltage.
Do notoperate generatorsetwithoutall guards
and electricalenclosuresin place.
Moving rotor.
Cancause severeinjuryordeath.
WARNING
Rotating parts.
Cancause severeinjuryordeath.
Do notoperate generatorsetwithoutall guards,
screens,orcoversin place.
Exposedmoving parts cancause severeinjuryor
death.Keep hands, feet, hair,and clothing awayfrom
beltsand pulleys when unitisrunning.Replace guards,
covers,and screensbefore operating generatorset.
Flying projectiles cancause severeinjuryordeath.
Retorque all crankshaft and rotorhardware after
servicing.When making adjustmentsorservicing
generatorset, do notloosen crankshaft hardware or
rotorthru-bolt. If rotating crankshaft manually,direction
shouldbeclockwise only.Turning crankshaft boltor
rotorthru-boltcounterclockwisecan loosen hardware
and resultinseriouspersonal injuryfromhardware or
pulleyflying off engine while unitisrunning.
ENGINEBACKFIRE/FLASHFIRE
WARNING
Fire.
Cancause severeinjuryordeath.
Do notsmoke orpermit flame orsparkto occur
nearfuelorfuelsystem.
Aflashfire cancause severeinjuryordeath.Donot
smokeorpermitflameorsparktooccurnearcarburetor,
fuel line, fuelfilter, fuelpump,orotherpotentialsources
ofspilled fuelorfuelvapors.When removingfuel lineor
carburetor,useapropercontainertocatch all fuel.
Asuddenbackfire cancause severeinjuryordeath.
Do notoperatewith backfireflame arrestor removed.

TP-5393 9/93IV SafetyPrecautionsand Instructions
HAZARDOUS VOLTAGE/
ELECTRICALSHOCK
WARNING
Hazardous voltage.
Do notoperate generatorsetwithoutall guards
and electricalenclosuresin place.
Moving rotor.
Cancause severeinjuryordeath.
Do notconnect to anybuilding electricalsystem
withoutconnecting through an approved device
and afterbuilding mainswitchisopen.
WARNING
Hazardous voltage.
Backfeedto utility systemcancause severe
injury,death,orpropertydamage.
Hazardous voltage cancause severeinjuryor
death.The heatsinkof the voltage regulatorcontains
high voltage.Do not touchvoltage regulatorheatsink
when testing orelectricalshock will occur.
Hazardous voltage cancause severeinjuryor
death.Performelectricalservice onlyasprescribed in
equipmentmanual.Besurethatgeneratorisproperly
grounded.Nevertouch electrical leadsorappliances
withwethands,when standing inwater,oron wet
ground asthe chance ofelectrocution isespecially
prevalentundersuchconditions.Wiring should be
inspected at the intervalrecommended inthe service
schedule—replaceleadsthatarefrayed orin poor
condition.The function ofa generatorsetisto produce
electricityand whereverelectricityispresent, thereis
the hazard ofelectrocution.
Hazardous“backfeed”voltage cancause severe
injuryordeath.The generatormustnotbe used to
“backfeed”by connecting it to building/campground
circuits. Install atransferswitchinstandbypower
installationstopreventconnectionofstandbyandother
sourcesofpower.Electricalbackfeed into a utility
electricalsystemcan causeseriousinjuryordeathto
utilitypersonnelworking on transmission lines.
Hazardous voltage cancause severeinjuryor
death.Shortcircuits can cause bodilyinjuryand/or
equipmentdamage.Do notcontactelectrical
connectionswithtoolsorjewelrywhile adjustmentsare
made.Removewristwatch,rings,and jewelrythatcan
causeshortcircuits.

SafetyPrecautionsand InstructionsVTP-5393 9/93
FUELSYSTEM
WARNING
Explosive fuelvapors.
Cancause severeinjuryordeath.
Useextremecarewhenhandling,storing,
and using fuels.
Explosive fuelvapors cancause severeinjuryor
death.All fuelsare highlyexplosivein a vaporstate.
Use extremecarewhen handling,storing,and using
fuels.Storefuel in a well-ventilated area awayfrom
spark-producing equipmentand outof the reach of
children.Neveradd fueltothe tankwhilethe engine is
running sincespilled fuelmayignite on contactwith hot
partsorfromignition spark.Do notsmoke orpermit
flame orsparkto occurnearpotentialsourcesofspilled
fuelorfuelvapors.Keepfuel linesandconnectionstight
and in good condition—don’treplaceflexiblefuel lines
withrigidlines.Flexiblesectionsare used to avoid
breakageduetovibration.Should anyfuelleakage,fuel
accumulation,orelectricalsparks be noted,DONOT
OPERATEGENERATORSET.Havesystemsrepaired
beforeresuming generatoroperation.
Explosive fuelvapors cancause severeinjuryor
death.Additionalprecautionsmustbe taken when
using the following fuels:
Gasoline—Store gasoline onlyin approved red
containers clearlymarked GASOLINE.Do notstore
gasoline in anyoccupied building.
Propane(LP)—Adequateventilation ismandatory.
Propane isheavierthan air;install gasdetectorslowin
room. Inspectdetectorsoften.
Explosive fuelvapors cancause severeinjuryor
death.Spilled fuelcan cause an explosion.Use a
containertocatchfuelwhen draining fuelsystem.Wipe
up all spilled fuelafterdraining system.
Explosive fuelvapors cancause severeinjuryor
death.Fuelleakagecan causeanexplosion.CheckLP
vaporgasfuelsystemforleakage using a soap-water
solution withfuelsystemtestpressurized to 6-8 ounces
persquareinch(10-14 incheswatercolumn).Do not
usetestsolutionsthatcontain ammonia orchlorine,
sincethe soap will notbubbleforan accurateleakage
test.
Explosive fuelvapors cancause severeinjuryor
death.Fuelleakagecan causeanexplosion.CheckLP
liquidwithdrawalgasfuelsystemforleakage using a
soap-watersolution withfuelsystemtestpressurized
notlessthan90psi(621kPa).Donotusetestsolutions
thatcontainammoniaorchlorine,sincethesoapwillnot
bubbleforan accurateleakage test.

TP-5393 9/93VISafetyPrecautionsand Instructions
BATTERY
WARNING
Sulfuric acidin batteries.
Cancause severeinjuryordeath.
Use protective gogglesand clothes.Can cause
permanentdamage to eyes,burnskin,and eatholes
inclothing.
Sulfuric acidin batteries cancause severeinjuryor
death.Sulfuricacidin battery can cause permanent
damage to eyes,burnskin,and eatholesinclothing.
Alwayswearsplash-proofsafetygoggleswhenworking
around the battery. If batteryelectrolyteis splashed in
the eyesoron skin,immediatelyflushthe affected area
for15minuteswithlargequantitiesofcleanwater. Inthe
caseofeyecontact,seekimmediatemedicalaid.Never
addacidtoabatteryoncethebatteryhasbeenplacedin
service.Doing somayresultin hazardous spattering of
electrolyte.
Explosion cancause severeinjuryordeath.Battery
gases can cause an explosion.Do notsmoke orpermit
flame orsparkto occurneara batteryatanytime,
particularlywhen itisbeing charged.Avoidcontacting
terminalswithtools,etc.topreventburnsandtoprevent
sparks thatcouldcause an explosion.Remove
wristwatch,rings,andanyotherjewelrybeforehandling
battery.Neverconnectnegative(--) battery cableto
positive(+)connection terminalofstartersolenoid.Do
not testbattery condition by shorting terminalstogether
orsparks couldignite batterygasesorfuelvapors.Any
compartmentcontaining batteriesmustbe well
ventilated to preventaccumulation ofexplosive gases.
To avoidsparks,do notdisturb battery charger
connectionswhile batteryisbeing charged and always
turnchargeroff before disconnecting battery
connections.When disconnecting battery,remove
negativelead firstand reconnectitlast.
HAZARDOUSNOISE
CAUTION
Hazardousnoise.
Cancause loss ofhearing.
Neveroperate generatorwithoutamufflerorwith
faultyexhaustsystem.

SafetyPrecautionsand InstructionsVIITP-5393 9/93
HOTPARTS
WARNING
Hotengine and exhaustsystem.
Cancause severeinjuryordeath.
Donotworkongeneratorsetuntilunitisallowedto
cool.
Fire cancause severeinjuryordeath.Hotexhaust
systemcan ignite adjacentcombustiblematerials.Do
notlocate electricalwiring, fuel lines,orcombustible
materialabovethe exhaustmuffler.Becarefulwhen
parking yourvehicleto preventgrass fires started by
exhaustsystemand hotexhaustgases.
Fire cancause severeinjuryordeath.Hotgenerator
can ignite debrisincompartment. Keep the
compartmentandgeneratorsetclean and free ofdebris
and combustiblematerialstominimizechancesof fire.
Do notblock fuel/oil drain opening in generator
mounting tray. If sub-flooring isused,cuta
correspondingholeinthe sub-flooringfordrainopening.
Hotparts cancause severeinjuryordeath.Do not
touchhotengineparts.Anenginegetshotwhilerunning
and exhaustsystemcomponentsgetextremelyhot.
NOTES NOTE
Thisgeneratorsetdoes notcomplywithUnited
States CoastGuard(U.S.C.G.)requirements and
mustnotbeusedformarine applications.Use only
generatorsets specified formarine useinmarine
installations.U.S.C.G.Regulation 33CFR183 requires
a generatorset to be “ignitionprotected” whenused ina
gasoline-fueled environment.
NOTE
Do not“tee”intofuel injected fuelsystems.Use a two
diptube arrangement forfuelsupply.Consultan
AuthorizedKohlerServiceDealerforfurtherfuelsystem
installation information.
NOTE
Generatorsetsequipped with optional”swing down”
tray should notbe left inthe tilted position forany
extended period (one hourormore)otherwise,
hydrostaticlock can occur.Always place unitinthe
normalmounting position when serviceisnotactually
being performed.

TP-5393 9/93VIII SafetyPrecautionsand Instructions
RoutineService Parts
ContactyourKohlergeneratordealer/distributorfora
completelisting ofservice partsforyourgeneratorset.
PartDescription KohlerPartNo.
Engine:
AirFilter278612
Oil Filter52 050 02
FuelFilter:1/4in.inlet228269
FuelFilter:5/16 in.inlet227647
Ignition System:
SparkPlug 51 132 02
Black SprayPaint221292

TP-5393 9/93 Specifications1-1
Section 1. Specifications
Introduction
Yourvehicleisequipped with a dependableKohler
alternating-currentgeneratorset. Service
requirementsof the generatorsetareminimalbutitis
important that the required servicesbe performed at
theprescribedintervals.Pleasetakeafewmomentsto
read through thismanualthen carefullyfollowall
servicerecommendationstokeep yoursetintop
conditions. Inthe space provided,recordthe MODEL,
SPECIFICATION,SERIAL and ENGINE SPEC.
numbersasfound on the nameplate attached tothe
controllerof the generator (see “Section 8.Service
Ordering Instructions”).Thisinformation will enable
yourKohlergeneratorservice dealer/distributorto
supplythe correctpartordataforyourparticular
version.Keep thismanual inyourvehicleforfuture
reference.
Specifications
GeneralSpecifications
4CKM/CKMR(60Hz)5CKM/CKMR(60Hz)
Dimensions—LxWxH—in.(mm)24.83 x18.46 x13.98
(631 x469 x355)24.83 x18.46 x13.98 (631 x469 x355)
Weight—lbs.(kg)258 (117)268 (121.5)
AirRequirements:
Combustion—cfm20 20
Cooling—cfm340 340
Free AirOpening 85 sq.in.(548 sq.cm)85 sq.in.(548 sq.cm)
4CFKM/CFKMR(50Hz)
Dimensions—LxWxH—in.(mm)24.83 x18.46 x13.98 (631 x469 x355)
Weight—lbs.(kg)258 (117)
AirRequirements:
Combustion—cfm20
Cooling—cfm340
Free AirOpening 85 sq.in.(548 sq.cm)

TP-5393 9/931-2Specifications
FuelConsumption Gasoline—gph (Lph)
Load 25%50%75%100%
4CKM/CKMR(60 Hz)0.48 (1.8)0.58 (2.2)0.70 (2.6)0.89 (3.4)
4CFKM/CFKMR(50 Hz)0.39 (1.5)0.48 (1.8)0.59 (2.2)0.75 (2.8)
5CKM/CKMR(60 Hz)0.45 (1.7)0.58 (2.2)0.75 (2.8)1.04 (3.9)
FuelConsumption LPGas—gph (Lph)
Load 25%50%75%100%
4CKM/CKMR(60 Hz)0.46(1.7)0.69 (2.6)0.77(2.9)0.99 (3.8)
4CFKM/CFKMR(50 Hz)0.39 (1.5)0.58 (2.2)0.65 (2.5)0.82 (3.1)
5CKM/CKMR(60 Hz)0.54 (2.0)0.80 (3.0)0.90 (3.4)1.15 (4.4)

TP-5393 9/93 Specifications1-3
Engine
Some generalengine specificationsarelisted below.Refertothe appropriateservicesection and the engine service
manualforspecific service details.
4CKM/CFKM/
4CKMR/CFKMR5CKM/ 5CKMR
ManufacturerKohler
ModelM18 M20
Cycle 4
NumberCylinders2
Compression Ratio 6.0:1 6.6:1
Displacement—cu.in.(L)42.18 (0.69)46.98 (0.77)
Rated Horsepower:
60 Hz8.9 9.5
50 Hz7.4 7.9
RPM:
60 Hz1800
50 Hz1500
Bore—in.(mm)3.12 (79.25)3.12 (79.25)
Stroke—in.(mm)2.75 (69.85)3.06 (77.72)
ValveMaterialStelliteâ
ValveClearance—in.(mm):
Intake 0.003-0.006 (0.076-0.152)
Exhaust0.011-0.014 (0.279-0.355)
CylinderBlock MaterialAluminumcrankcasewithcastiron cylinders
CylinderHead Tightening Torque—ft. lbs(Nm)15-20 (20-27)
CylinderHead MaterialAluminum
Piston Rings2Compression/1Oil
Crankshaft MaterialHeat treated ductileiron casting
Bearings,Number&Type 2,ReplaceableSleeve
GovernorElectronic
Lubrication SystemFull Pressure
Oil Capacity(withfilter)—qts.(L)1.5(1.4)2.5(2.36)
Oil Type (API)SF
Oil Pressure—psi(kPa)30-40 (207-276)
FuelType:
Gasoline 87 Octane Unleaded
LP VaporGas(InletPressure)4-6 oz.persq.in.
LPLiquidWithdrawal50 psi
BatteryVoltage 12
BatteryGround Negative
BatteryRecommendation (min.)290 ColdCranking Amps/90 AmpHr.
SparkPlug Type ChampionâRV17YC
SparkPlug Gap:
Gasoline—in.(mm)0.025 (0.64)
LPGas—in.(mm)0.018 (0.46)
SparkPlug Tightening Torque—ft. lbs(Nm)10-15 (13.6-20)
Ignition SystemElectronic
Ignition ModuletoMagnetAirGap 0.008-0.012
StarterMotorBendix-drive electric startermotor
Cranking currentat70° F.100 Amps
Cooling SystemAir-Cooled
IntakeManifoldBoltTorque—ft. lbs.(Nm)12.5(17)

TP-5393 9/931-4Specifications
Generator
4CKM/CKMR5CKM/CKMR
Rated kW4 5
Rated kW(LPLiquidWithdrawal)4 4.6
Rated kW(LPLiquidWithdrawalwithBattery
Charging)3.7 4.3
Frequency—Hz60
Rated Voltage 120/240 Volt, 3wire,
single phase
120 Volt, 2wire,
single phase
Rated Amps(120 Volt)33.3 41.7
Rated Amps(240 Volt)16.7 20.8
Rated Amps12 VoltBatteryCharging System0-15 Amps—Regulated
StatorResistance(ohms)** Leads:
1-2,3-4,33-44 0.34
55-33 2.8
B1-B2 0.15
C1-CP,C2-CP0.14
4CFKM/CFKMR
Rated kW3.3
Frequency—Hz50
Rated Voltage 110 Volt, 2wire,single phase 110/220 Volt, 3wire,single phase
Rated Amps(110 Volt)30.0
Rated Amps(220 Volt)15.0
StatorResistance(ohms)** Leads:
1-2,3-4,33-44
5
5
-
3
3
0.40
1
-
2
,
3
-
4
,
3
3
-
4
4
55-33
B
1
-
B
2
2.8
5
5
-
3
3
B1-B2
C
1
-
C
P
,
C
2
-
C
P
0.15
C1-CP,C2-CP0.14
RotorResistance(ohms)3.5-5.5
Excitation Method SolidStateBrush
Coupling Type Direct
OverboltTorque—in.lbs.(Nm)60 (7)
Voltage RegulatorType (Single-PhaseModels)PowerBoostäIII
Voltage RegulatorType (Three-PhaseModels)PowerBoostäV
Insulation (Rotorand Stator) Class 155,Epoxy Varnish,VacuumImpregnated
Winding MaterialCopper
Bearing,Numberand Type 1,ReplaceableBall
CircuitProtection:
Controller15 AmpFuse
Voltage Regulator5AmpFuse
BatteryCharging (ifequipped)25 AmpCircuitBreaker
De-Icing Module(ifequipped)5AmpFuse
** Mostohmmeterswill notgive accuratereadingswhen measuring less than 1 ohm.The statorcan be considered good ifalowresistance
reading (continuity)isobtained and thereisno evidence ofshorted windings(discoloration).Do notconfusealowresistancereading witha
reading indicatingashorted winding.
DERATION:All unitsarerated 1.0 powerfactor.
Derateapproximately3.5%per1000ft.(300m)above500 ft (150 m)abovesea leveland 1 %foreach 10°F (5.5°C)increaseintemperature above 85°F(29°C).

TP-5393 9/93 Specifications1-5
Glossary of Abbreviations
Abbreviationsare used throughout thismanual.
Normallyinthe text theywill appearincompleteform
withthe abbreviation following in parenthesisthe first
timetheyare used.Afterthat theywill appearinthe
abbreviated form.The commonlyused abbreviations
areshown below.
ACalternating current
AHWTanticipatoryhigh watertemp.
ALOPanticipatorylowoil pressure
AMamplitude modulation
Amp ampere
Ampsamperes
ANSIAmerican NationalStandardInstitute
APIAmerican PetroleumInstitute
approx.approximate,approximately
A/Rasrequired,asrequested
A/Sas supplied,as stated,as suggested
ASA American StandardsAssociation
assy.assembly
ASTMAmerican SocietyforTesting Materials
ATDC aftertop dead center
ATSautomatictransferswitch
aux.auxiliary
AWGAmerican WireGauge
AWMappliancewiring material
BHPbrake horsepower
bmep brakemean effective power
BtuBritishthermalunit
°C Celsiusdegree
cc cubic centimeter
CCAcoldcranking Amps.
CEC Canadian ElectricalCode
cfhcubicfeetperhour
cfmcubicfeetperminute
CIDcubicinch displacement
cmcentimeter,centimeters
cmm cubicmetersperminute
co.company
cont’d.continued
C.S.A.Canadian StandardsAssociation
cu.in.cubicinch,cubicinches
cyl.cylinder
dBA decibels
DC directcurrent
DCR directcurrentresistance
deg.degree
dept. department
dia.diameter
e.g.example given
EMIelectromagneticinterference
etc.etcetera,(and soforth)
ext. external
°F Fahrenheitdegree
fl.oz. fluid ounce, fluid ounces
FMfrequency modulation
fsfull scale
ft. foot, feet
ft. lbs. footpound, footpounds
ga.gauge
gal., gals.gallon,gallons
gal./hr.gallonsperhour
GPHgallonsperhour
GPMgallonsperminute
gr.grade
grd.ground
HCHThigh cylinderhead temperature
HEThigh exhaust temperature
Hgmercury(element)
H2Owater
HPhorsepower
hr,hrshour
HWThigh watertemperature
Hzhertz(cyclespersecond)
IDinside diameter
in.inch(es)
inc.incorporated
in.lbs.inch pounds
int. internal
int.-ext. internal-external
ISOInternationalStandardsOrganization
Jjoule,joules
JISJapaneseIndustryStandard
kgkilogram,kilograms
kg/cm2kilogramspersquarecentimeter
kgmkilogram meter(s)
kmkilometer,kilometers
kPakiloPascal,kiloPascals
kph kilometersperhour
kVkilovolt
kVA kilovoltamperes
kWkilowatt, kilowatts
kWHkilowatt hour
Lliter,liters
LxWxHlengthxwidthxheight
LED,LEDslightemitting diode
lb., lbs.pound,pounds
L/hr.literperhour,litersperhour
L/min.liter(s)perminutes,
LOPlowoil pressure
LPliquefied petroleum
LWTlow watertemperature

TP-5393 9/931-6Specifications
m meter,meters
m3cubicmeter,cubicmeters
max.maximum
MCMone thousand circularmils.
mi.mile,miles
mil one one-thousandth ofan inch
min.minimum
mJmillijoule,millijoules
MJmega joule,mega joules
mm millimeter,millimeters
m3/mincubicmetersperminute
MPamegaPascal
mph milesperhour
MSmilitary standard
mWmilliwatt, milliwatts
MWmegawatt, megawatts
N/Anotavailable
NEC NationalElectricalCode
NEMANationalElectrical
ManufacturersAssociation
NFPA NationalFireProtection Association
NmNewton meter,Newton meters
no., nos.number,numbers
NPTNationalStandardtaperpipe
thread pergeneraluse
N/Rnotrequired
OCovercrank
ODoutside diameter
OEMoriginalequipmentmanufacturer
OSoverspeed,oversize
OVovervoltage
oz.ounce,ounces
PFpowerfactor
pot. potentiometer
ppmpartspermillion
psipoundspersquareinch
pt., pts.pint, pints
qt., qts.quart, quarts
qty.quantity
ref. reference
RFIradiofrequency interference
rmsrootmean square
rpmrevolutionsperinch
SAE SocietyofAutomotiveEngineers
sec.second,seconds
SCR silicon controlled rectifier
spec,specs specification
sq.square
sq.cmsquarecentimeters
sq.in.squareinch,squareinches
tachtachometer
TDC top dead center
temp. temperature
TIFtelephone influencefactor
turbo turbocharger
UNC Unified coarsethread (wasNC)
UNFUnified fine thread (wasNF)
ULUnderwriter’sLaboratories, Inc.
USundersize
Vvolt, volts
vacVoltsalternating current
vdc voltsdirectcurrent
Wwatt, watts

TP-5393 9/93 Specifications1-7
Controller
The Kohler relay controllerhasarocker-type
momentarycontactSTART-STOPswitchforoperating
the setat the controller.Alsoincluded isaconnector
forattaching a remotestart/stop switchlocated inside
thevehicle.SeeFigure1-1.The greenGENERATOR
ONlamp on the optionalremotecontrolpanelwill light
wheneverthe generatorisrunning. If the generator
sethasautomatically stopped due tolowoil pressure,
3 1/2 psi±1 1/2 psi(24.1kPa)orless,the causemust
be eliminated beforethe setcan be restarted.
1-905
Figure 1-1.Controller

TP-5393 9/931-8Specifications
1.ChokeAdjustment
2.Carburetor
3.Oil Fill/Oil Check
4.AirCleaner
5.Nameplate
6.15-AmpControllerFuse
7.5-AmpVoltage RegulatorFuse
8.Line CircuitBreakers
9.FuelPump
10.Oil Drain
11.Start-Stop Switch
12.BatteryPositiveConnection
13.Oil Filter
14.SparkPlugs
15.Voltage Regulator
16.Oil Sump(5CKMonly)
17.Load Leads
18.FuelFilter
19.RemoteControlConnector
ADV-5728-F
1234
15
18
5
8
10
11
12
13
14
16
17
19
7
6
9
Figure 1-2.Service View4/5CKM-RV

TP-5393 9/93 Specifications1-9
1.ChokeAdjustment
2.Carburetor
3.Oil Fill/Oil Check
4.AirCleaner
5.Nameplate
6.Extended Shaft (Option)
7.15-AmpControllerFuse
8.5-AmpVoltage RegulatorFuse
9.Line CircuitBreakers
10.FuelPump
11.Oil Drain
12.Start-Stop Switch
13.BatteryPositiveConnection
14.Oil Filter
15.SparkPlugs
16.25-AmpBatteryCharging CircuitBreaker (Option)
17.Voltage Regulator
18.Load Leads
19.FuelFilter
20.RemoteControlConnector
ADV-5780-B
123 4
17
5
9
10
12 11
13
14
15
6
18
20
78
16
19
Figure 1-3.Service View4/5CKMR-Mobile
