Kohler 11679T User manual

所有的资料是按最新出版的产品资料编写而成。科
勒公司保留任何时候不经通知即可改变产品特性、
包装或产品可供类型的权利。
说明书包括重要的安装、保养及清洁方面的内容，
请把这些资料交给用户阅读。
注意事项：
1. 遵守当地管路安装条例。
2. 关闭主供水源。
3. 尽可能在安装面盆之前安装水龙头。
BEFORE YOU BEGIN
All information is based on the latest product
information available at the time of publication. Kohler
Co. reserves the right to make changes in product
characteristics, packaging, or availability at any time
without notice.
Please leave these instructions for the consumer. They
contain important information.
NOTES:
1. Observe local plumbing codes.
2. Shut off the main water supply.
3. If possible, install this drain before installing the
lavatory.
11679T 台面式提拉落水
安装之前
使用说明 HANDLE OPERATION
INSTALLATION INSTRUCTIONS
安装说明书
Deck-Mount Pop-Up Drain
安装尺寸 ROUGH-IN DIMENSIONS
按压提拉头，打开排水。
Press the button to open the drain.
1155382-2-A 1
Ø54
Ø36.5
176.5
97.5 108
Ø31.75
192
210
275 Max 65 48
Ø27
Ø20

1155382-2-A 2
1155382-2-A 3
安装步骤 INSTALLATION 清洗说明 CLEANING INSTRUCTIONS
零件图
SERVICE PARTS
适用于所有加工处理过的表面：以中性肥皂水清洗
镀层表面，再以干净的软布彻底擦干整个表面，许
多清洁剂，比如氨水、去污粉及洁厕灵等，会对电
镀表面造成伤害，切忌使用。
有磨损性的清洁用具或清洁剂也不可使用于科勒牌
的水龙头及其配件上。
All Finishes: Clean the finish with mild soap and warm
water. Wipe entire surface completely dry with clean
soft cloth. Many cleaners may contain chemicals, such
as ammonia, chlorine, toilet cleaner etc, which could
adversely affect the finish and are not recommended
for cleaning.
Do not use abrasive cleaners or solvents on Kohler
faucets and fittings.
1
2
3
4
5
16
将螺母(1)和垫片(2)从提拉杆组件(3)上
拆下。将O型圈(4)嵌入装饰盖(5)底部
凹槽，然后将提拉杆组件插入面盆安
装孔中。从台面下方重新装回垫片和
螺母，但不拧紧螺母。
将止水塞(6)、法兰盘(7)及垫片(8)从排
水本体(9)上取下，在法兰盘底面套上
垫片。将尾管(10)从排水本体上取下。
在尾管螺纹处缠绕足以密封的密封胶
带或涂合适的密封胶，将排水本体装
回。把排水本体带垫圈(11)、钢垫(12)
及锁紧螺母(13)从面盆下方插入，排水
杆洞口(14)朝后方。
注意：如果需要，可直接在排水器法
兰盘(7)底面沿周围涂一圈密封油灰，
而不使用垫片(8)。
把排水器法兰盘旋入排水本体中。从
下方用手拧紧锁紧螺母。把止水塞放
入排水本体中，调整以使止水塞末端
孔(15)靠近并对正排水杆的洞口。
将固定螺母(16)取下，把塑料垫圈(17)
及固定螺母装在球杆(18)上，再把球杆
组件插入排水杆的洞口中并穿过止水
塞，拧紧固定螺母。
确保球杆指向面盆后方，并拧紧排水
本体上的锁紧螺母，去除多余油灰。
注意：在锁紧螺母拧紧后，不可调整
排水本体的位置，否则会破坏油灰密
封。
用“V”形夹(19)将联杆(20)连接到球
杆组件上，将提拉杆(21)插入联杆孔，
使装饰盖(5)紧贴台面，提拉头(22)紧
贴限位器(23)。
将球杆下推到排水器全开的位置。拧
紧手捻螺丝(24)。拧紧螺母(1)。取下
限位器并丢掉。
Take off the nut(1) and the washer(2)
from the lift rod kit(3). Put the o-ring(4)
into the groove on the bottom of the
escutcheon(5). Insert the lift rod kit into
the installing hole of lavatory. Reinstall
the washer and the nut, but don’t
tighten the nut.
Take off the stopper(6), drain flange(7)
and washer(8) from drain body(9). Slide
washer onto the underside of the drain
flange. Take off the tailpiece(10) from
the drain body. Supply enough tape or
sealant to tailpiece thread. Reinstall the
tailpiece. With the gasket(11), steel
washer(12) and locknut(13) on the
drain body, insert it into the bidet from
underside with the drain lever hole(14)
facing the rear.
NOTE: If needed apply a ring of
plumbers putty around the underside of
the drain flange(7), instead of using
washer(8).
Thread the drain flange onto the drain
body. Tighten the locknut by hand from
the underside. Place stopper into drain
body aligning the flat side of stopper
hole(15) with the drain lever hole.
Remove the retaining nut(16). Fit the
plastic washer(17) and retaining nut
onto the ball lever(18). Insert the ball
lever assembly into the drain lever hole
and through the stopper hole. Tighten
the retaining nut.
Be sure that the ball lever rod points to
the back of the bidet, tighten the
locknut on the drain body. Remove any
excess putty.
NOTE: Do not reposition the drain after
the locknut is tightened, or you may
break the putty seal.
Connect the link(20) onto ball lever
rodwith "V"-clip(19). Insert the lift rod
(21) into the link of the drain. Keep the
escutcheon(5) against the lavatory
panel, and the lift knob(22) against the
stopper(23).
Push the ball lever rod down to the
open position. Tighten thumb screw
(24). Tighten the nut(1). Remove and
discard the stopper.
6
15
7
8
9
10
14 12
7
24
20
19
11
13
17
18
21
22
1
5
1080817
O-ring
O型圈
880406
Washer
垫片
880008**
Stopper
止水塞
880037
Link Kit
排水联动组件
863927
Nut
螺母
871568
O-ring
O型圈
3008174
Washer
垫片
**订购时请说明颜色编号
**Color code must be specified when ordering
1180600**
Lift Rod Kit
提拉杆组件
23
