BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
The slide bar 8524T must be used with slide bar escutcheon 349T, 421T or 974T.
INSTALLATION INSTRUCTIONS
8524T Slider Bar
349T 421T 974T Slider Bar Trim
ROUGH-IN DIMENSIONS
25
349T
8524T
57
57
57
421T
974T
57
68
64
762
712

1215002-2A-B 2 1215002-2A-B 3
INSTALLATION
Select a suitable location to drill two holes on the finished wall
according to the rough-in dimensions and diameter of the anchor(1),
their distance is 712mm. Press the anchors into the holes.
Customer could select and install the slide bar escutcheon(2): 349T,
421T or 974T.
Apply a ring of plumbers putty or sealant into the groove on the
backside of an escutcheon. Position an escutcheon and post(3) over
the mounting hole. Secure an escutcheon and post to the wall with a
screw(4). Loosely tighten the screw.
Hold the slide bar up against the posts. Adjust the position of the posts
until the slide bar fits snug against the curved cutout of the posts.
Remove the slide bar and tighten the screws to secure the posts.
Thread the pin(5) into the post; tighten with a flat blade screwdriver.
Line up the hole of each lock assembly(6) with the holes of the slide
bar. If needed, use a screwdriver to adjust the position of the lock
assemblies.
Align the pins with the holes in the slide bar and slide bar locks. Insert
the pins through the slidebar and lock assemblies.
Secure the slide bar by tightening the setscrews(7) into the lock
assemblies．
Press the cap(8) into each end of the slide bar.
SERVICE PARTS
**Color code must be specified when ordering
INSTALLATION CHECKOUT
Ensure that all coupling nuts are tightened.
The height of handshower holder can be adjusted by pressing the
pinch cock and sliding up and down.
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc, which could adversely
affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
8524T Slider Bar
349T 421T 974T Slider Bar Trim
Apply a ring of
plumbers putty
or sealant
5
4
4
5
6
7
8
3
3
712mm
2
2
1
1
7
8
1061576
1033803
1033800**
1033799**
1040644** 34300
34300
1033797**
1040645**
1276023**
Pinch cock
