Kohler 99859T User manual

1293805-2A-B 1
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co.
reserves the right to make changes in product characteristics, packaging, or availability at any time without
notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. Shut off the water supplies to the fitting.
3. Observe local plumbing codes.
4. Maximum working pressure for spout: 0.5Mpa(5 bar).
5. Do not use alcohol and other organic solvents to wipe the spout.
DANGER: Risk of personal injury.
This product can not be used as a shelf or support bar. The misoperation may damage the product, and even
cause personal injury.
1293805-2A-B 4
INSTALLATION INSTRUCTIONS
99859T Decorative Bath Spout99859T Decorative Bath Spout
BEITOUBEITOU
ROUGH-IN DIMENSIONS
SERVICE PARTS
**Color code must be specified when ordering.
99859T
87
Ø10
140 34
80
26
50
65
225
G1/2˝
1287336**
1281468
1281465**
1287337
1183881
1058705
833730
1230337
834404
3008523
834638
3013706
1223568
20960
1293421
20960
1293418
1293420
1293417
1293422
1293419
1082904
1082902

1293805-2A-B 2 1293805-2A-B 3
INSTALLATION CHECKOUT
CLEANING INSTRUCTIONS
CARE AND MAINTENANCE
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc, which could
adversely affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
INSTALLATION
To perform installation, installer must provide G1/2″
female supply fitting(1), keep proper position in the
wall. NOTE: The supply fitting should be below the
finished wall 6~18mm, and be vertical with finished
wall as well. The hole in the finished wall should be
not more than Ø40.
Screw the tube(3) and base(2) into the wall, tighten
them by hex wrench(4).
Drill two Ø10 holes according to the mark. The depth
of the holes are 52mm.
Press the anchors(6) into the hole. Apply tape or
thread sealant to threads of the tube(3). Install the
tube into the wall through the base(2). Install the
screws(7) to secure the base on the wall. Tighten
the tube by hex wrench(4).
Install the connector(8) into the tube(3). Turn on the
water supply, run the hot and cold water through the
connector for about one minute to remove any
debris. Shut off water supply.
Install the spout kit(9) onto the base(2). Tighten the
screws(10) to secure the spout kit by hex
wrench(11). Press the plugs(12) into the hole.
Make sure the base(2) is horizontal by the attached
level(5). Mark the position of the hole on the wall
with a pencil.
Take out the screw(21) in the bottom of the spout by
hex wrench(14). Remove the escutcheon cover(18),
rectifier(19) and support ring(20).
Flush the filter of rectifier. Check the filter whether is
intact, if damaged replace it.
Reassemble the spout and body: put the support
ring(20), rectifier(19) and escutcheon cover(18) into
the spout. Tighten the screw(21) by hex wrench(14).
Put the O-ring(17) on the spout(13) bottom. Connect
the spout and body, fixed them by screw(15). Install
the spout kit to the base, fixed them by screw(10).
Clean Rectifier
If there is a lot of debris in the supply pipes or the
quality of water is bad, it will cause the flow in bad
condition. Please clean the filter as following steps:
Turn off the supply water. Take out the plugs(12),
remove the screws(10) by hex wrench(11). Remove
the spout kit(9).
Remove the screws(15) by hex wrench(14).
Uninstall the spout(13) from body(16).
Ensure that all connections are tightened.
Open the drain. Turn on the main water supply and check for leaks. Repair as required.
1
2
9
10
11
12
22
5
3
4① ②
③ ④
⑤ ⑥
2
8
3
16
15
14
13
2
① ②
③ ④
9
10
11
12
21
20
19
18
13
14
17
17
10
11
12
16
15
14
13
6
2
7
3
4
