Kohler EX28093K-8 User manual

INSTALLATION INSTRUCTIONS
1483415-H2-B 1
EX28093K-8 Single Control Lavatory Faucet - OylEX28093K-8 Single Control Lavatory Faucet - Oyl
COMPONENTS
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves the
right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. If possible, install this faucet before installing the lavatory.
3. Inspect the supply tubing for damage and leakage. Replace and maintain as necessary.
4. Observe local plumbing codes.
5. Shut off the water supplies to the fitting.
HANDLE OPERATION
When facing front of the faucet, gently push the handle forward to open the faucet, the direction of the red line is for
hot water and the blue line is for cold water.
ROUGH-IN DIMENSIONS
1483415-H2-B 4
SERVICE PARTS
COMPONENTS
**Color code must be specified when ordering.
1477827**
3002558
1477821**
1477819**
1477822
1477823**
1477824
1303142
1105733
3016093
1477825
1477826**
834704
1228834
3016159
1258880
1167318
1193625
870760
832940
1080817
3009021
837056**
136
15~24
53
193520
114
G3/8˝
21°
Ø42
Ø48
Ø32~Ø38
45 Max.
45 最大 67~86
35~55
Ø63
146
G1˝ 1/4
52

INSTALLATION CHECKOUT
CLEANING INSTRUCTIONS
All Finishes: Clean the finish with mild soap and warm water. Wipe entire surface completely dry with clean soft
cloth. Many cleaners may contain chemicals, such as ammonia, chlorine, toilet cleaner etc. which could adversely
affect the finish and are not recommended for cleaning.
Do not use abrasive cleaners or solvents on Kohler faucets and fittings.
Ensure all connections are tight.
Ensure the handle is in the off position.
Turn on the drain and main water supply,
and check for leaks. Repair as needed.
Remove the aerator(20) with tool(19).
Turn on the faucet. Run hot and cold
water through the spout for about one
minute to remove any debris. Check for
leaks. Remove any debris from the
aerator. Shut off the faucet. Reinstall the
aerator.
INSTALLATION
How to Install the Drain
Install the waste(9) with foam ring(10) into
the drain hole.
Install the seal(11), secure and tighten the
drain body(12) to the waste by hand.
Chamfer Side Up
Adjust the drain body to enable the ball
lever(13) and lift rod(8) to engage.
Insert the waste stopper kit(14) into the
waste.
Insert the ball lever into the drain body
and through the stopper hole(15).
Make sure that the ball lever engages
with the waste stopper kit and adjust the
waste stopper screw(16) if required.
Tighten the ball lever retaining nut(17)
by hand.
13
14
16
17
15
How to Install the Lift Rod Kit
Attach the connector(18) onto the ball
lever(13) and lift rod(8). Tighten the
connector retaining screw with a suitable
screwdriver.
Connect the drain body to the drain outlet.
18
13
8
1483415-H2-B 3 1483415-H2-B 2
How to Install the Faucet
If need to take off the hoses(1) to repair,
reinstall and tighten them by hand.
Install the mounting studs(2) into the
faucet(3) bottom. Slide the escutcheon(4)
over the hoses and mounting studs until
it is put into the faucet bottom.
Insert the faucet assembly into the hole
of the lavatory until the escutcheon
contacts the deck.
From underside of the lavatory, place the
washers(5, rubber washer is on the top)
onto the mounting studs. Position the
faucet．Tighten the nuts(7) with tool(6) to
secure the faucet.
Insert the lift rod(8) to the hole at the rear
of the faucet.
Attach the hoses to water supplies.
The hose with “COLD” label should be
connected to cold water.
9
9
11
12
10
20
19
3
4
6
8
2
7
5
1
