Kohler K-15246X-S Assembly instructions

1157542-X2-F


 




CAUTION: Turn on the water and allow
water to flow through the supply pipe to
flush the system of any debris before
connecting fill valve.
ข้อควรระวัง:


IMPORTANT NOTICE TO INSTALLERS!:
Please leave these instructions for the consumer.
Please retain for future reference.
NOTE: Some installation parts might not be
provided.
NOTE: The toilet pictured in the installation
steps may differ from the model being installed.
K-15246X-S, K-15246X-SP, K-18155K-NS,
K-18155VN, K-18155VN-S, K-18182MY-NS,
K-45462K-NS, K-45462R-NS,K-45462VN,
K-45462VN-S,
Position the template on the floor to
ensure the template against the wall.
Insert the anchors. Positions as
shown on the template and install.
Position the tank on the bowl. Slide the rubber washers
and washer onto bolts and insert into mounting bowl.
Tighten the nuts. Do not overtighten.
Connect the connector on the bowl. Caerfully tilt backward until connector and
waste pipe touch.
1 2 3
4








Align connector and carefully lower
over brackets.
5


7Apply silicone around base.
11 
Install the tank lid and the seat.
12

10 
Flush several times and ckeck
for leaks. Do not overtighen!
9


Tighten the nut to the push
buon from under tank cover.
8


Tape in place and drill holes.



Connector to Wall
Connector to Floor
Waste Pipe

Waste Pipe

Adjust the water level.
P-Trap

S-Trap

Turn here
to adjust
the water level.


Waterline

+
-
©2017 Kohler Co.
6
Loosen the nut from the new
push buon kit.


Roughing-in
Carefully thread the screws into the brackets, until toilet is secure. Alternately
tighten left and right sides to prevent pulling the toilet off center.






Screw Sleeve
Mounting Hole
Cap
Installation and Care Guide
ขอแนะนําการติดตั้งและการดูแลรักษา
3/8"
Tank/
Bolt/
Rubber washer/
Washer/
Nut/
Bowl/






1/2" 1/2"
200
mm/ 200
mm/
305
mm/
185
mm/
160
mm/
160
mm/

©2017 Kohler Co.
1157542-X2-F
1
2Note the position
of the colored
buons for
reinstallation.
Shut off the
water supply.
Remove the
tank cover. 3



Replace the Seal
For best results, keep the following in mind when caring for
your product:
• Carefully read the cleaner product label to ensure the cleaner
is safe for use on the material.
• Always test your cleaning solution on an inconspicuous
area before applying to the entire surface.
• Wipe surfaces clean and rinse completely with water
immediately after cleaner application. Rinse and dry any
overspray that lands on nearby surfaces.
• Do not allow cleaners to sit or soak on the surface.
• Use a soft, dampened sponge or cloth. Never use an abrasive
material such as a brush or scouring pad to clean surfaces.
• Be careful not to leave staining materials in contact with the
surface for extended periods of time.
• The ideal cleaning technique is to rinse thoroughly and blot
dry any water from the surface after each use.
WARNING: Risk of property or product damage. Do
not use in-tank cleaners in your toilet. Products contain-
ing chlorine (calcium hypochlorite) can seriously
damage fiings in the tank. This damage can cause
leakage and property damage.
Troubleshooting Care and Cleaning 
Symptoms Recommended Action
1. Poor flush. A. Adjust the tank water level to match the waterline.
B. Fully open the water supply shut-off valve.
C. Clear obstructions from the trapway, jet, or bowl
rim holes.
D Clear obstructions from the waste line.
2. No flush. A. Make sure the push buon rods are in place.
Adjust as needed.
4. Long tank
fill cycle. A. Fully open the water supply shut-off valve.
B. Clean the valve inlet, valve head, or supply line.
Flush the lines.
5. Noisy tank
fill cycle.
A. Partially close the water supply shut-off valve
if the water pressure to the toilet is too high.
Check the toilet performance following any such
adjustment.
B. Remove dirt or obstructions from the valve head.
Flush the lines.
3. The fill
valve
turns on/off
by itself or
it
runs,
allowing
water to
enter the
tank.
A. Adjust push buon rods for proper slack so the
flush valve seal isn’t held off the flush valve.
B. Clean or replace the flush valve seal if it is worn,
dirty, or misaligned with the valve seat or flush
valve seat is damaged.
C. Remove the tank and tighten the flush valve nut
if flush valve gasket is leaking. Do not overtighten.
If leakage continues replace the gasket.
D. Clean the fill valve seal of debris or replace the seal
assembly.
E. Replace the fill valve if the valve float sinks.
F. Adjust the tank water level if it is too high.
