Kohler K-2363X Assembly instructions

Installation and Care Guide
Pedestal Lavatory


1020683-X2-C ©2017 Kohler Co.
K-2363X/K-2364X

Thank you for choosing Kohler Company

Thank you for choosing the Bold Look of Kohler. Kohler craftsmanship oers
you a rare combination of proven performance and graceful sophistication
that will satisfy you for years to come. The dependability and beauty of your
Kohler product will surpass your highest expectations. We’re very proud of
our products here at Kohler and we know you will be too.
Please take a few minutes to review this manual before you start installation. If
you encounter any installation or performance problems, please don’t hesitate
to contact us. Our phone numbers and website are listed on back cover.
All information in this manual is based upon the latest product information
available at the time of publication. At Kohler, we constantly strive to improve
the quality of our products. We reserve the right to make changes in product
characteristics, packaging or availability at any time without notice.
Thank you for choosing Kohler Company.
  The Bold Look of Kohler 
 


 

  

 


 
1020683-X2-C 2 Kohler Co.

Before You Begin
CAUTION: Risk of personal injury or product damage. Handle with
care. Product can break, chip, or cause injury if handled carelessly. Get
help lifting the lavatory.

Important Information
IMPORTANT NOTICE TO INSTALLERS!: Please leave these instructions for
the consumer. They contain important information.
In addition to installation procedures, this manual contains important care and
cleaning. Please retain for future reference.
NOTE: Some installation parts might not be provided.
NOTE: The toilet pictured in the installation steps may dier from the model
being installed.
 
 

 
 

CAUTION: Risk of personal injury. This pedestal lavatory is heavy.
Do not aempt to lift or install the pedestal lavatory without assistance.
¨Observe all local plumbing and building codes.
¨Prior to installation, unpack the new lavatory and inspect it for damage.
Return the lavatory to its protective carton until you are ready to install it.
¨ This installation guide provides installation steps for aaching the lavatory
to concrete frame construction. For other installations, supply suitable
bracing and fastening devices of sucient size and strength.
¨ The walls and the oor must be square, plumb, and level.
¨Fixture dimensions are nominal and conform to tolerances established by
Standards TIS.
Kohler Co. 3 1020683-X2-C





 

¨ 
¨ 

¨  

 
¨ 
¨ 
Tools/
1020683-X2-C 4 Kohler Co.

 
¨ 
¨ 
Roughing-In/
Dimensions are approximate. Unit: mm.
 
1. Prepare the site

NOTE: The open position of the supply stop handles must not extend more
than 76 mm from the nished wall.
¨Install the 1/2” water supply lines and 1-1/2” drain piping according to
the roughing-in information.
¨ Install sucient backing behind the nish wall to provide a secure material
for the anchoring devices.
K-2363X-1/K-2364X-V K-2363X-8/K-2364X-V
876
578
527
102102
71
303
202
71
475
191
152
195
325 260
58
102
59
ø35
Ø35
ø44
ø10 Mounting Hole
In Pedestal/
รูยึดขารองอ่าง
ø10 Anchor Holes/รูพุก
1/2" Hot/นํ�าร้อน 1/2" Cold/นํ�าเย็น
1-1/2" OD
เส้นผ่าศูนย์กลาง
Finished Floor/พื �น
Finished Wall/ผนัง
Kohler Co. 5 1020683-X2-C

2. Install the Lavatory
¨Apply two self-adhesive pads to the underside of the lavatory basin.
¨ Mark the centerline of the pedestal on the oor with a pencil.
¨Align the center of the pedestal on the marked centerline.
¨Place the lavatory onto the pedestal.
¨ Verify the lavatory is level and ush against the nished wall. Adjust or add
self-adhesive pads as needed.
NOTE: If the boom of the lavatory contacts the pedestal, reposition the
self-adhesive pads.
¨ Mark the two lavatory anchoring hole locations on the nished wall with
a pencil.
¨ Mark the pedestal anchoring hole on the oor through the hole in the
pedestal boom.
¨ Carefully remove the lavatory from the pedestal. Set the lavatory and the
pedestal aside.
¨For concrete constructions, drill 13 mm holes at the marked locations on the
nished wall and the oor. Insert the anchors. For wood constructions, drill
6 mm.
Apply two self-adhesive pads
to the underside of the basin.
ติดแผนปรับระดับดานลางของอางลางหนา
Hanger Bolt
Washer
Cap Nuts
Lag Bolt
Washer Pedestal
โบลทแขวน
แหวนรอง
ฝาครอบนอต
แหวนรอง
โบลท
ขาตั้ง
Anchor
พุก
For Concrete Constructions
สำหรับผนังคอนกรีต
CAUTION: Risk of personal injury. This pedestal lavatory is heavy.
Do not aempt to lift or install the pedestal lavatory without assistance.
1020683-X2-C 6 Kohler Co.


¨ 
¨ 
¨ 
¨ 
¨ 
 


¨Install the hanger bolts to the wall.
¨Thread the cap nuts onto the hanger bolts.
¨ Thread the hanger bolts into the nished wall until each hanger bolt
is exposed 20 mm between the cap nut and the nished wall.
¨Remove the cap nuts.
¨Install the faucet and drain to the lavatory according to the manufacturer’s
instructions.
¨Move the pedestal back into position.
¨ Place the lavatory over the hanger bolts. Ensure the lavatory is ush against
the pedestal and the nished wall.
¨ Remove the lavatory from the pedestal. Set the lavatory aside.
¨Thread a washer and lag bolt through the hole in the pedestal and into the
oor until the washer contacts the pedestal. Do not overtighten.
¨Carefully set the lavatory on the pedestal so the hanger bolts extend through
the lavatory anchoring holes.
¨Verify the installation is level and properly positioned.
CAUTION: Risk of product damage. Do not overtighten the cap nuts.
Overtightening may damage the product.
CAUTION: Risk of product damage. Do not overtighten the cap nuts.
Overtightening may damage the product.
¨Thread a cap nut and washer over each hanger bolt until the washer and the
cap nut are tight against the lavatory.
¨ Secure the P-trap or S-trap to the drain.
¨Connect the water supply lines to the faucet according to the manufacturer’s
instructions.
Kohler Co. 7 1020683-X2-C

 

¨ 
¨ 
¨  

¨ 
 
¨ 
¨ 
¨ 
¨ 
¨ 
¨ 
¨ 
¨ 




¨ 
 
¨ 
¨ 
¨ 
 
¨ 
¨ 
1020683-X2-C 8 Kohler Co.

Care and Cleaning
For best results, keep the following in mind when caring for your product:
• Carefully read the cleaner product label to ensure the cleaner is safe for use
on the material.
• Always test your cleaning solution on an inconspicuous area before applying
to the entire surface.
• Wipe surfaces clean and rinse completely with water immediately after
cleaner application. Rinse and dry any overspray that lands on nearby
surfaces.
• Do not allow cleaners to sit or soak on the surface.
• Use a soft, dampened sponge or cloth. Never use an abrasive material such as
a brush or scouring pad to clean surfaces.
• Be careful not to leave staining materials in contact with the surface for
extended periods of time.
• The ideal cleaning technique is to rinse thoroughly and blot dry any water
from the surface after each use.

 

•   

• 

• 

• 
• 

• 
• 
 
Kohler Co. 9 1020683-X2-C

1020683-X2-C 10 Kohler Co.

Kohler Co. 11 1020683-X2-C
