Kohler K-4991X Assembly instructions

Installation and Care Guide
 ขอแนะนําการติดตั้งและการดูแลรักษา
©2014 Kohler Co.
1248245-X2-A
ขอสําคัญถึงผูติดตั้ง! 

ขอสังเกต: อุปกรณสําหรับการติดตั้งบางชิ้น

ขอสังเกต:


CAUTION: Turn on the water and allow water
to flow through the supply pipe to flush the
system of any debris before connecting fill valve.
ข้อควรระวัง:

IMPORTANT NOTICE TO INSTALLERS!:
Please leave these instructions for the
consumer. Please retain for future reference.
NOTE: Some installation parts might not be
provided.
NOTE: The toilet pictured in the installation
steps may differ from the model being installed.
K-4991X
Roughing-in/ระยะการติดตั้ง
Turn off the water. Drill 3 mounting holes
on the wall.
Fix hangers on the wall.
Apply thread sealant tape to the pipe
threads and install the females collar to
the waste pipe.
Install the adaptor
and water supply hose
to the spud.
Position the urinal on the hangers and
outlet. Tighten the screw.
1 2 3 4 5
  

 
  

Finished Wall
 Finished Wall

Wall Hangers

10 mm/
Gap 10 mm/  25 mm/ 
Waste pipe

For install back inlet
สําหรับการติดตั้งดานหลัง



152
2" NPT Tap

1029
to Floor


Outlet Detail
รายละเอียดขอตอนํ้าทิ้ง
464
305
514
681
484
84
618
361
534
2" NPT Tap

520
3/4" Spud
 Wall hangers

6
1029
to Floor


464
305
514
681
484
84
618
361
534
2" NPT Tap

Wall hangers

3/4" Spud

K-4991X-ER K-4991X-ET

©2014 Kohler Co.
1248245-X2-A
Install the flush valve following the manufacturer’s instructions. Turn on the water supply.
Flush several times and
check for leaks.
6 7



Slip nut is the optional part.
In case of flush valve is 1/2″or not included lock
nut, need to connect slip nut with outlet pipe.



For install top inlet
สําหรับการติดตั้งดานบน
ASIAN EMERGING MARKETS
Asia Customer Service Centre, Kohler Asia Pacific Limited
Tel: +(86) 21 2606 2572
KOHLER (THAILAND) PUBLIC COMPANY LIMITED
บริษัท โคหเลอร (ประเทศไทย) จํากัด (มหาชน)
ลูกคาสัมพันธ/Call Center 0 2204 6222
E-mail: [email protected]
For best results, keep the following in mind when caring for your
product:
• Carefully read the cleaner product label to ensure the cleaner is safe
for use on the material.
• Always test your cleaning solution on an inconspicuous area before
applying to the entire surface.
• Wipe surfaces clean and rinse completely with water immediately
after cleaner application. Rinse and dry any overspray that lands
on nearby surfaces.
• Do not allow cleaners to sit or soak on the surface.
• Use a soft, dampened sponge or cloth. Never use an abrasive
material such as a brush or scouring pad to clean surfaces.
• Be careful not to leave staining materials in contact with the surface
for extended periods of time.
• The ideal cleaning technique is to rinse thoroughly and blot dry any
water from the surface after each use.
WARNING: Risk of property or product damage. Do not use
in-tank cleaners in your toilet. Products containing chlorine
(calcium hypochlorite) can seriously damage fiings in the
tank. This damage can cause leakage and property damage.
Care and Cleaning การดูแลรักษาและการทําความสะอาด


• 

• 

• 

• 
• 

• 
• 

ขอควรระวัง ความเสี่ยงซึ่งอาจกอใหเกิดความเสียหายกับที่พัก
อาศัยและสุขภัณฑ 
  


