©2014 Kohler Co. 1 1217145-X2-B





 

• 


• 
• 
• 
• 
 
 
This document contains the latest product information
available at time of publication. Kohler reserves the right
to make changes in product characteristics, packaging or
availability at anytime without notice.
The product pictured in the installation steps may differ
from the model being installed.
IMPORTANT NOTICE TO INSTALLERS Please leave
these instructions for the consumer. They contain
important information.
•Flush the water supply pipes thoroughly to remove
debris.
•Shut off the water supplies.
•Recommended water pressure 1-5 bar.
• Femalewateroutlettobealignedwiththenishedwall.
• Refer to product specication sheet for ow curve.
If ow is less than stated, inspect system for other
restrictionssuchasowcontroller,instantaneoushot
water heater, clogged supply line, etc.
 BEFORE YOU BEGIN
 ROUGH-IN DIMENSION
K-R99252X-4CD
CUFF WALL-MOUNT SHOWER
VALVE-COLD WATER ONLY

INSTALLATION AND CARE GUIDE


 Dimensions are approximate.
Unit: mm
*Theinstallheightfromtheoortothevalvecentercanvarydependinguserpreference.
Recommended height: 1 to 1.2 meters.

 
ø130
93
158
Finished Wall/ผนัง
120
48
20
7
R1/2
G1/2
1217145-X2-B 2 ©2014 Kohler Co.
For best results, keep the following in mind when caring
for your product:
•Always test your cleaning solution on an inconspicuous
area before applying to the entire surface.
•Wipe surfaces clean and rinse completely with water
immediately after applying cleaner. Rinse and dry
any overspray that lands on nearby surfaces.
•Do not allow cleaners to soak on surfaces.
•Use a soft, dampened sponge or cloth. Never use
an abrasive material such as a brush or scouring pad
to clean surfaces.
•The ideal cleaning technique is to rinse thoroughly
and blot dry any water from the surface after each use.


• 

• 

• 
• 

• 

 INSTALL THE HANDLE AND VALVE
 CARE AND CLEANING
Water Inlet
ทางนํ�าเข้า
Water Outlet
ทางนํ�าออก
1. Apply sealant or thread seal.
 2. Put the valve into the washer and escutcheon base.

3. Thread the valve into the water inlet with the handle
down as shown. Adjust valve tightness position
using seal tape.


4. Run water through the valve and check for leaks.

Apply sealant or
thread seal tape.
ใช้กาวหรือเทปพันเกลียว
Escutcheon
ฝาครอบ
Washer
แหวนรอง
Notch Position
ตําแหน่งรอยบาก
Valve
วาล์ว
Check for leaks/
Do not overtighten.

©2014 Kohler Co. 3 1217145-X2-B
Kohler (Thailand) Public Company Limited warrants to the original
products, which are purchased from authorized distributors and dealers
within Kingdom of Thailand only, to be free of defects in material and
workmanship.
Within the below mentioned periods from the date of purchase, Kohler
(Thailand) Public Company Limited will at its election, repair, replace
or make appropriate adjustment where company’s inspection disclose
any such defect occurring in normal usage and maintenance but is not
responsible for labor charges, removal charges, installation, or other
incidental or consequential costs. In no event shall the liability of Kohler
(Thailand) Public Company Limited exceed the purchase price ofthe
product. This warranty applies only to Kohler Faucets installed in
Thailand.
• Ceramic Valve (leak/drip)
- Lifetime Limited Warranty* for residential use
- and Five (5) Years for commercial use
• Finish Five (5) Years
• Fitting Five (5) Years
• Automatic faucet One (1) Year
• Hygiene spray (leak/drip Five (5) Years for selected models
from hygiene spray body) only
• Shower Five (5) Years
• Bathroom Accessories Five (5) Years
This limited warranty DOES NOT COVER the defect or damage caused
byaccident,naturaldisasterssuchasre,ood,orearthquake,misuse
or abuse of products. Improper care and cleaning will avoid the warranty.
Consumers are responsible for the cost of service parts and service fee
for such cases.
To ensure continuous product quality and performance, as well as
product durability and lifetime, without any damage to the product,
consumers should purchase and use only genuine service parts and
after-sales services from Kohler (Thailand) Public Company Limited
or company’s authorized service centers, distributors, or dealers only.
*KOHLER®Faucet Lifetime Limited Warranty
Kohler (Thailand) warrants its faucets manufactured after January 1,
1997, to be leak and drip free during normal residential use for as long as
the original consumer purchaser owns his or her home. If the faucet
should leak or drip during normal use, Kohler (Thailand) will, free of
charge; replace
the new cartridge necessary to put the faucet in good
working condition.
Kohler (Thailand) also warrants all other aspects of the faucet or
accessories (“Faucet”)**to be free of defects in material and workman-
ship during normal residential use for as long as the original consumer
purchaser owns his or her home. If a defect is found in normal residential
use, Kohler (Thailand) will, at its election, repair, provide a replacement
part or product, or make appropriate adjustment. Damage to a product
caused by accident, misuse, or abuse is not covered by this warranty.
Improper care and cleaning will also void the warranty.
Proof of purchase (original sales receipt) must be provided to Kohler
(Thailand) with all warranty claims. Kohler (Thailand) is not responsible
for labor charges, installation, or other incidental or consequential costs.
In no event shall the liability of Kohler (Thailand) exceed the purchase
price of the Faucet.
Important: Never use cleaners containing abrasive cleansers, ammo-
nia, bleach, acids, waxes, alcohol, solvents or other products not
recommended for chrome. This will void the warranty.
To obtain warranty service, please contact your dealers or contact the
KOHLER (Thailand) Call Center, together with proof of purchase at;
Call Center
KOHLER (Thailand) Public Company Limited
16th Floor, Jasmine City Building
2 Soi Sukhumvit 23, Sukhumvit Road,
Wattana, Bangkok 10110
Tel: 02204-6222 Fax: 0-2204-6224
Email: [email protected]
COPYRIGHT ©2014 BY KOHLER (THAILAND) PUBLIC COMPANY
LIMITED.











  
   
   
   
   
   
  

  
   
   









































 LIMITED WARRANTY
1217145-X2-B 4 ©2014 Kohler Co.
Call Center: +(66) 2204 6222
e-mail: [email protected]
**Finish/color code must be specied when ordering.

SERVICE PARTS
 K-R99252X-4CD
CUFF WALL-MOUNT SHOWER
VALVE-COLD WATER ONLY

3018415**
Handle
มือบิด
1217875
Gasket
ประเก็น
1217880
Foam
Gasket
ประเก็นโฟม
1217876**
Escutcheon
ฝาครอบ
1186138
Valve
วาล์ว
834792
Nut
นอต
1093358**
Bonnet
ฝาครอบ
833438
Screw
สกรู
3008523
Plug
ป ุ่ ม ปิ ด
1217877
Washer
แหวนรอง
