IMPORTANT INSTRUCTIONS
WARNING: When using electrical products, basic precautions should always be followed,
including the following:
WARNING: Risk of electric shock. A licensed electrician should route all electrical wiring.
WARNING: Risk of electric shock. Disconnect power before servicing.
NOTICE: Follow all plumbing, electrical, and building codes.
IMPORTANT! The music server on your computer must be properly set-up in order to utilize music files
in your bath. Refer to the User Guide packed with your digital interface for information on configuring
your music server.
FCC and IC Compliance
The term ″IC:″before the certification/registration number only signifies that the Industry Canada
technical specifications were met.
Contains:
Kohler Company
Model #: 1070734
IC: 4554A-KOHLER004
FCC ID: N82-KOHLER004
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
NOTE:
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
FCC and IC Radiation Exposure Statement for Mobile Devices
This equipment complies with FCC and IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 7-7/8″(20 cm)
between the radiator and your body. The transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
Specifications
Ambient Temperature Max 104°F (40°C)
Maximum Relative Humidity 95% non-condensing
Electrical Service 100-240 VAC, 50-60 Hz, 4.4-1.83 A
Lighting 100-240 VAC, 50-60 Hz, 2.4-1.0 A
Media Module 100-240 VAC, 50-60 Hz, 2.0-0.83 A
Valve Cable Length (supplied) 30 ft (9.14 m)
Speaker Cable Length 25 ft (7.62 m)
Line-in Cable Length 5.6 ft (1.71 m)
Ethernet Cable Length 30 ft (9.14 m)
1069763-5-F 2 Kohler Co.

Thank You For Choosing Kohler Company
Thank you for choosing Kohler Co. Your Kohler Co. product reflects the true passion for design,
craftsmanship, artistry, and innovation Kohler Co. stands for. We are confident its dependability and beauty
will surpass your highest expectations, satisfying you for years to come.
All information in this guide is based upon the latest product information available at the time of
publication. At Kohler Co. we strive to fulfill our mission of improving the level of gracious living for each
person who is touched by our products and services. We reserve the right to make changes in product
characteristics, packaging, or availability at any time without notice.
Please take a few minutes to review this guide. Pay special attention to the care and cleaning instructions.
Warranty
KOHLER
®
Electronic Faucets, Valves and Controls
FIVE-YEAR LIMITED WARRANTY
Kohler Co. warrants that its electronic faucets, valves and controls will be free of defects in material and
workmanship during normal residential use for five years from the date the product is installed. This
warranty applies only to electronic faucets, valves and controls installed in the United States of America,
Canada and Mexico (″North America″).
If a defect is found in normal residential use, Kohler Co. will, at its election, repair, provide a replacement
part or product, or make appropriate adjustment where Kohler Co.’s inspection discloses any such defect.
Damage caused by accident, misuse, or abuse is not covered by this warranty. Improper care and cleaning
will void the warranty*. Proof of purchase (original sales receipt) must be provided to Kohler Co. with all
warranty claims. Kohler Co. is not responsible for labor charges, installation, or other incidental or
consequential costs other than those noted above. In no event shall the liability of Kohler Co. exceed the
purchase price of the faucet, valve or control.
If the electronic faucets, valves or controls are used commercially or are installed outside of North America,
Kohler Co. warrants that the faucet, valve or control will be free from defects in material and workmanship
for one (1) year from the date the product is installed, with all other terms of this warranty applying except
duration.
If you believe that you have a warranty claim, contact your Home Center, Dealer, Plumbing Contractor or
E-tailer. Please be sure to provide all pertinent information regarding your claim, including a complete
description of the problem, the product, model number, the date the product was purchased, from whom the
product was purchased and the installation date. Also include your original invoice. For other information,
or to obtain the name and address of the service and repair facility nearest you, write Kohler Co., Attn:
Customer Care Center, Kohler, Wisconsin 53044 USA, or by calling 1-800-4-KOHLER (1-800-456-4537) from
within the USA and Canada, and 001-800-456-4537 from within Mexico, or visit www.kohler.com within the
USA, www.ca.kohler.com from within Canada, or www.mx.kohler.com in Mexico.
THE FOREGOING WARRANTIES ARE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
KOHLER CO. AND/OR SELLER DISCLAIM ANY LIABILITY FOR SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES. Some states/provinces do not allow limitations on how long an implied
warranty lasts or the exclusion or limitation of such damages, so these limitations and exclusions may not
apply to you. This warranty gives the consumer specific legal rights. You may also have other rights that
vary from state/province to state/province. This warranty is to the original consumer purchaser only, and
excludes product damage due to installation error, product abuse, or product misuse, whether performed
by a contractor, service company, or the consumer.
This is Kohler Co.’s exclusive written warranty.
*Never use cleaners containing abrasive cleansers, ammonia, bleach, acids, waxes, alcohol, solvents or
other products not recommended for chrome. This will void the warranty.
Kohler Co. 3 1069763-5-F

Warranty
KOHLER CO.
It is recommended that at the time of purchase, you verify that all accessories and components are complete
in this package.
This Kohler product is warranted to be free of defects in material and workmanship for one (1) year from the
date of purchase as shown on the invoice or receipt.
1. Kohler Co. will only service its commercialized products through its authorized distributors.
2. To obtain warranty service, please present the invoice and corresponding warranty.
3. Through its authorized distributors, Kohler Co. promises to repair the defective product or provide a new
replacement or an equivalent model (in those cases that the model has been discontinued) when the product
is beyond repair, without any charge to the consumer.
4. The time of repair will not exceed six (6) weeks commencing on the date the product is received.
5. It is recommended that the consumer save the invoice or receipt as additional protection, as it may
substitute the warranty in the case that there is a discrepancy in the validity of the warranty.
EXCEPTIONS AND RESTRICTIONS
The Warranty will not be valid in the following cases:
1. When the product is not operated in accordance with the instructions concerning use and operation set
forth in the owner’s manual or installation instructions, and when the recommendations and warnings
included are not observed.
2. When the product has been modified or dismantled partially or totally; or has been used in a negligent
fashion and as a consequence has suffered damages attributable to the consumer, individual, or hardware not
authorized by Kohler Co.
3. This warranty does not cover the damages as a result of disaster such as fire or acts of God, including
flooding, earthquake, or electric storms, etc. To obtain a list of distributors in your area where you can
exercise your rights under this warranty, please call 001-800-456-4537.
KOHLER CO., KOHLER, WI 53044 U.S.A.
IMPORTER:
INTERNACIONAL DE CERÁMICA, S.A.B. DE C.V.
AV. CARLOS PACHECO NO. 7200
CHIHUAHUA, CHIH., MEXICO C.P. 31060
TEL: [phone]
1069763-5-F 4 Kohler Co.

Connection Key
Ethernet
Low Voltage
Access Cover
Audio Line In
Kohler Co. 5 1069763-5-F

Connect the Components
CAUTION: Risk of electric shock or product damage. Make sure the power cord is unplugged
before removing the access covers.
NOTE: If the power cord is damaged, it must be replaced by the manufacturer, its service agent, or a
similarly qualified person in order to avoid hazard.
Note: For wireless applications an Ethernet connection is not needed.
Remove the low voltage access cover.
Remove the grommets in the locations where the cables will be installed. Refer to the ″Connection
Key.″
Gently press each connection until it snaps together.
Slide the cable grommet into the slot with the male end up. Verify the grommet is properly seated.
Reinstall the access covers. Do not overtighten.
Plug the power supply into the outlet. Verify that the indicator light turns on and pulses.
Test each component to ensure proper functionality. Refer to the Installation and Homeowner
Guides packed with each of the individual components for additional information.
Make sure power cord is unplugged
before opening access covers.
Grommet
Slide grommet into slot with
male end up.
High Voltage
Access Cover
Low Voltage
Access Cover
Install grommets
flush with media box.
Male End
Indicator Light
1069763-5-F 6 Kohler Co.

Troubleshooting
This troubleshooting guide is for general aid only. For service and installation issues or concerns, call
1-800-4-KOHLER.
Interface Troubleshooting Table
Symptoms Probable Cause Recommended Action
1. Control panel is not lit. A. Power supply is not plugged
into the outlet. A. Plug the power supply into the outlet.
B. Power supply connection to the
media module may be loose or
disconnected.
B. Check power supply connections to
the media module and reconnect if
needed.
C. Interface cable connections may
be loose or disconnected. C. Check all interface cable connections, connect if needed.
D. Circuit breaker has been
tripped. D. Reset the circuit breaker.
E. The media module memory
may require resetting. E. Disconnect and reconnect the power supply from the media
module.
F. If none of the recommended
actions for the above issues
correct the symptom, the valve
or interface requires servicing.
F. Contact your Kohler Co.
Authorized Service Representative.
2. The interface power
indicator pulses but does
not turn on.
A. Interface cable connections may
be loose or disconnected. A. Check all interface cable connections, connect if needed.
B. If the above recommended
action does not correct the
symptom, the interface or valve
requires servicing.
B. Contact your Kohler Co.
Authorized Service Representative.
3. The interface functions
normally but no water
flows from the
components.
A. Inlet/outlet fittings may be
blocked. A. Check the inlets and outlets for blockage or debris. Clean the inlet
screens. Refer to the ″Clean the
Inlet Screens″section in the Valve
Homeowners Guide.
B. Hot and cold water supplies are
not turned on. B. Turn on the water supply to the valve.
C. The valve or media module
memory may require resetting. C. Disconnect and reconnect the power supply from the valve and
media module.
D. System error. D. Check the user interface for an
error code. Refer to the
″Diagnostics″section in the Digital
Interface Homeowners Guide.
E. If none of the recommended
actions for the above issues
correct the symptom, the media
module requires servicing.
E. Contact your Kohler Co.
Authorized Service Representative.
4. Continuous flow. A. System will not switch off. A. Turn off the water and power
supply and contact your Kohler Co.
Authorized Service Representative.
5. Primary and auxiliary
interface are lit, but
auxiliary interface does
not appear to function.
A. Lock-Out function is enabled. A. Disable in setup mode.
6. Display is difficult to read. A. Contrast is not optimized. A. Adjust contrast in the user interface
setting menu.
B. Brightness is not optimized. B. Adjust the brightness in the user
interface setting menu.
7. Massage and temperature
therapy does not work. A. Massage and temperature therapy functions are not
enabled.
A. Enable the massage and
temperature therapy functions
using the user interface.
Kohler Co. 7 1069763-5-F

Troubleshooting (cont.)
Valve Troubleshooting Table
Symptoms Probable Cause Recommended Action
1. Maximum blend
temperature too hot or
too cold.
A. Incorrect maximum temperature
setting. A. Refer to the ″Set the Maximum Temperature″section in the Digital
Interface User Guide.
B. If the above recommended
action does not correct the
symptom, the interface or valve
requires servicing.
B. Contact your Kohler Co.
Authorized Service Representative.
2. Continuous flow. A. System will not switch off. A. Turn off the water and power
supply and contact your Kohler Co.
Authorized Service Representative.
3. Massage mode shuts
down but water continues
to run from the
showerhead(s).
A. Unequal flow rates between
valve outlets. A. Verify the installation has one bodyspray per valve outlet and
uses bodysprays with the same
flow rate. If needed, contact the
installer to revise the installation.
B. Fluctuation of inlet pressure. B. Install pressure regulators in the
supply lines.
C. Pressure difference greater than
5 psi (34.5 kPa) between the hot
and cold supply lines.
C. Install pressure regulators to bring
the supplies within 5 psi (34.5 kPa)
of each other.
4. Only cold water flows
from the outlets. A. Hot water supply is either not turned on or not connected to
the valve inlet.
A. Check the hot water supply is
turned on and connected to the
valve inlet.
B. Hot water inlet is blocked. B. Check the hot water inlet screen for
blockage. Clean or replace the inlet
screen. Refer to the Valve
Homeowners Guide.
C. If none of the recommended
actions for the above issues
correct the symptom, the valve
requires servicing.
C. Contact your Kohler Co.
Authorized Service Representative.
5. Fluctuating or reduced
flow rate. Valve is
functioning properly.
A. Inlet/outlet fittings may be
blocked. A. Check the inlets and outlets for blockage or debris. Clean the inlet
screens. Refer to the ″Clean the
Inlet Screens″section in the Valve
Homeowners Guide.
B. Water outlet pressure is low.
C. Fluctuating flow. C. Verify that the dynamic inlet
pressures are within specifications.
Refer to ″Specifications″section in
the Valve Homeowners Guide.
D. If none of the recommended
actions for the above issues
correct the symptom, the valve
requires servicing.
D. Contact your Kohler Co.
Authorized Service Representative.
6. Blend temperature drift or
temperature cycling. A. Fluctuating water temperature. A. Check the inlet temperature differentials and verify they are
sufficient. Refer to ″Specifications″
section in the Valve Homeowners
Guide.
B. Hot water supply temperature
fluctuation. B. Check and make adjustments as needed.
C. Pressure difference greater than
5 psi (34.5 kPa) between the hot
and cold supply lines.
C. Install pressure regulators to bring
the supplies within 5 psi (34.5 kPa)
of each other.
1069763-5-F 8 Kohler Co.

Troubleshooting (cont.)
Valve Troubleshooting Table
Symptoms Probable Cause Recommended Action
D. If none of the recommended
actions for the above issues
correct the symptom, the valve
requires servicing.
D. Contact your Kohler Co.
Authorized Service Representative.
7. Water leaking from the
valve.
CAUTION: Risk of
personal injury or
product damage. Turn off
the main power and
water supply.
A. Connections are not secure. A. Check all connections. Make
adjustments as needed.
B. Seals are worn or damaged. B. Order a seal service pack and
replace all seals.
C. Internal leak. C. Unit requires overhaul. Contact
your Kohler Co. authorized service
representative.
8. Hot water only, the valve
shuts down. A. Hot and cold lines are reversed. A. Switch hot and cold water supply connections. Verify the hot water
supply is connected to the inlet
marked ″H″and the cold water
supply is connected to the inlet
marked ″C.″
Music Troubleshooting Table
Symptoms Probable Cause Recommended Action
1. Speakers do not produce
sound in a two speaker
setup.
A. Speaker cable is not plugged in
properly. A. Make sure the cables are properly installed into the Media Module
connections and to the left and
right speakers.
2. Speakers do not produce
sound in a four speaker
setup.
A. Damaged speaker or speaker
not plugged in. A. Make sure the working speakers are properly installed into the
Media Module connections and to
both sets of terminals on each left
and right cables.
3. After playing music
loudly, the music stops
even though a song is
properly selected.
A. Thermal shut down. A. Shut down the system for 1 hour to
allow the unit to cool. Make sure
the area where the unit is installed
does not exceed 104°F (40°C).
4. Library menu is not
available. A. The Roku agreement was declined. A. Enter the settings menu, select ″System,″select ″Music Software,″
select ″Roku Agreement″and select
″YES.″
5. Music server is not
available. A. Wireless network is not configured properly. A. Enter the settings menu, select ″System,″select ″WiFi Security,″
select ″Network Name,″select
″WEP/WPA Key″and enter the
security key.
B. The network cable is not
connected to the correct
router/switch input.
B. Connect the Media Module to the
router’s/switch’s ethernet ports.
C. A compatible media server is
not installed/running on your
home computer.
C. Install/open one of the supported
media servers such as iTunes
®
,
Microsoft
®
Windows
®
Media
Connect, RhapsodyTM or
Musicmatch
®
on your computer
and load your favorite music into
the server’s library.
D. The media server on your home
computer is not configured to
share files.
D. Reference the media server’s help
menu to properly configure file
sharing.
Kohler Co. 9 1069763-5-F

Troubleshooting (cont.)
Music Troubleshooting Table
Symptoms Probable Cause Recommended Action
E. The incorrect Wi-Fi region was
selected. E. Enter the settings menu, select ″System,″select ″Music Software,″
select ″Region″and select the
appropriate geographical region
that matches your Wi-Fi router.
6. I have a wireless network
but my Media Module is
unable to connect to the
network.
A. Ethernet cable is plugged in. A. Make sure an Ethernet cable is not
plugged into Media Module’s
ethernet jack.
B. Media Module is not within
Wi-Fi range. B. Make sure the Media Module is within range of your Wi-Fi
network.
C. A WEP key was not entered for
a secured network. C. Enter the settings menu, select ″System,″select ″WiFi Security,″
select ″Network Name,″select
″WEP Key″and enter the security
key.
D. The router is not set up for
802.11b. D. Make sure the access point/router is configured to allow 802.11b
clients.
7. The Media Module can
not connect to an iTunes
server with firewall
software running.
A. The firewall is not configured
correctly to allow iTunes music
sharing.
A. Make sure your firewall software is
configured to allow iTunes music
sharing. For a Mac: Open System
Preferences. Select the Sharing icon
and click on the firewall tab. Select
the option ″iTunes Music Sharing.″
For a PC: Refer to your
documentation for changing
firewall settings. If running
Windows XP service pack 2, open
″Security Center,″select ″Windows
Firewall,″click on the ″Exceptions″
tab, and check to see that iTunes is
enabled. If not, use ″Add
Programs″to enable it. After these
changes have been made, restart
the Media Module by
disconnecting and reconnecting the
AC power.
8. The Media Module can
not access Windows
Media Connect library.
A. Windows Media Connect is not
configured for sharing. A. Make sure that your computer
containing your music library is
powered ON and Windows Media
Connect is running (icon should be
visible in the task tray). With the
Media Module powered ON and
connected to your network, make
sure that the Media Module is an
authorized device. Launch
Windows Media Connect through
your Control Panel. On the wizard
screen, scroll down the list of
devices. If the Media Module is not
listed, click the ″Add″button at the
bottom of the list. Click on Media
Module, then click ″OK.″It should
show up on the list of authorized
devices. Click ″Done.″Reboot the
Media Module by disconnecting
the AC power from the wall outlet.
1069763-5-F 10 Kohler Co.

Troubleshooting (cont.)
Music Troubleshooting Table
Symptoms Probable Cause Recommended Action
9. The Media Module can
not access the iTunes
library.
A. iTunes is not running. A. Make sure the computer containing
your iTunes library is turn on and
iTunes is running.
B. iTunes is not configured for
sharing. B. In iTunes, be sure to turn on the ″music sharing″option. Go to the
iTunes>Preferences menu or Edit>
Preferences for PC users. In the
dialog box that appears, click the
″Sharing″icon, then check the
option ″Share my music″to enable
sharing on your local network.
C. iTunes is not responding to
commands from the Media
Module.
C. Close and restart iTunes on your
computer.
10. I can see my iTunes
library in the list of
libraries, but when I try to
connect, the connection
fails.
A. iTunes is not configured for
sharing. A. In iTunes, be sure to turn on the ″music sharing″option. Go to the
iTunes>Preferences menu or Edit>
Preferences for PC users. In the
dialog box that appears, click the
″Sharing″icon, then check the
option ″Share my music″to enable
sharing on your local network.
B. No IP address assigned to the
Media Module. B. The Media Module was not assigned an IP address via DHCP,
but the PC was. In this situation,
the Media Module is able to see the
library via Rendezvous, but is not
able to connect to the library. Here
is how to check your Media
Module’s address: Enter the
settings menu, select ″System,″
select ″Music,″select ″Roku IP
Address.″If your IP address is of
the form 169.254.xxx.xxx, the Media
Module did not get a
DHCP-assigned address. Check the
configuration of your router to
ensure it is set up to assign DHCP
addresses. Reboot the Media
Module by disconnecting the AC
power from the wall outlet.
11. The Media Module can
not access the Musicmatch
library.
A. Musicmatch is not running. A. Make sure the computer containing
your music library is powered ON.
B. Musicmatch is not configured
for sharing. B. Make sure music sharing is enabled in Musicmatch. From the main
Musicmatch menu, click on
Options/Settings. Click on the tab
″CD Lookup/Connectivity.″Click
the buttons next to ″Enable music
server″as well as ″Universal Plug
and Play.″Musicmatch does not
need to be running while using the
Media Module; once enabled, the
UPnP server runs in the
background. Reboot the Media
Module by disconnecting the AC
power from the wall outlet.
Kohler Co. 11 1069763-5-F

Troubleshooting (cont.)
Music Troubleshooting Table
Symptoms Probable Cause Recommended Action
12. The Media Module is
connected to my network
via wired ethernet, but is
unable to play Internet
radio and may sometimes
fail to locate, connect to,
or play music from my
music servers.
A. No IP address assigned to the
Media Module. A. Determine the Media Module’s address by entering the settings
menu, select ″System,″select
″Music,″select ″Roku IP Address.″
If your IP address is of the form
169.254.xxx.xxx, the Media Module
did not get a DHCP-assigned
address. Check the configuration of
your router to ensure it is set up to
assign DHCP addresses. Reboot the
Media Module by disconnecting
the AC power from the wall outlet.
B. Ethernet cable is damaged. B. Replace the ethernet cable.
13. No sound plays through
the speakers. A. The song is paused. A. Make sure a song is playing. If the song is paused, press the OK
button to continue playback.
B. The volume is to low. B. Make sure the volume is turned up
high enough for proper enjoyment.
14. Some of my music files
do not display while
browsing.
A. Missing ID3 tag info. A. ID3 data tags may be missing.
Information about your music,
including Song Name, Artist,
Composer, Album, and Genre is
usually created automatically by
the software you used to save your
audio CD files on your computer’s
hard drive. This process creates
data called ″ID3 tags″to describe
each track. If this data is missing
from your music files, they will not
appear when you browse by that
data category. You can edit this
information in music jukebox
software such as iTunes.
15. A music file will not play. A. Unsupported file format. A. Make sure your file is a supported
format: iTunes Music Server: MP3,
AAC, ALAC, AIFF and WAV
Windows Media Player 11 /
Windows Media Connect: MP3,
WMA (including DRM WMA) and
WAV.
16. Songs purchased through
the iTunes music store
will not play.
A. Song is not supported because
of DRM. A. This is normal. DRM AAC files (i.e., files purchased on Apple’s
music store) are not supported.
Those files will be detected but will
be skipped during playback.
17. I cannot find playlists that
I saved on my computer. A. Some playlists may not be supported. A. iTunes users: Make sure your playlist was created in iTunes and
is visible in your iTunes
application. Windows Media
Connect users: Make sure your
playlists are saved in the My
Documents\My Music\My
Playlists or other shared folder.
Musicmatch users: Musicmatch
exports playlists in a manner that is
not supported. Slimserver users:
Make sure your playlist is a
Slimserver-supported playlist
format.
1069763-5-F 12 Kohler Co.

Troubleshooting (cont.)
Lights Troubleshooting Table
Symptoms Probable Cause Recommended Action
1. The shower lights do not
turn on. A. The light bulbs are burned out. A. Change the light bulbs.
B. A fuse is blown inside the
wiring compartment. B. Unplug the unit from the wall outlet. Open the AC wiring
compartment. Replace the fuse
with a proper replacement.
Reinstall the cover. Plug the power
cord back into the wall outlet and
retest.
2. Shower lights come on,
but do not dim. A. Wrong style of light bulbs being used. A. Incandescent bulbs should be installed in the fixture, do not use
compact florescent bulbs.
3. Internal lighting fuse
keeps blowing. A. Maximum wattage rating is being exceeded. A. Make sure the total wattage of light bulbs does not exceed 250 Watts.
4. No ″Lighting″listed in
menu. A. Lighting is disabled in the settings menu. A. In the settings menu, enable lighting.
Media Module Troubleshooting Table
Symptoms Probable Cause Recommended Action
1. System stops working and
the status LED is a solid
red.
A. System failure. A. Reboot the Media Module by
disconnecting the AC power from
the wall outlet. If the status LED
remains a solid red after reboot,
replace the Media Module.
2. System stops working and
the Status LED is a OFF. A. Power supply failure. A. Reboot the Media Module by disconnecting the AC power from
the wall outlet. If there is no
change after reboot, replace the
Media Module.
B. Incorrect wiring of the AC
power supply. B. Verify that the Media Module was installed per the installation
manual. Make sure AC power is
present at the outlet the Media
Module is plugged into.
3. Music stops playing and I
get a music error. A. Thermal shutdown. A. Shut down the system for 1 hour to allow the unit to cool. Make sure
the area where the unit is installed
does not exceed 104°F (40°C).
B. Incorrect speaker load. B. Verify the speaker load is 4 to 8
ohms.
4. Devices (lighted rain
panel, steam generator,
etc.) are sometimes not on
the menu, even though I
have them connected to
the Media Module.
A. Damaged cables or incorrect
cable installation. A. Check all wiring connections.
B. Power fluctuation. B. Verify that the devices are
connected to a stable power supply.
C. The device is not installed
correctly. C. See peripheral device owners manual.
5. No display on the user
interface. A. The interface cable is damaged. A. Replace the interface cable.
B. The interface cable is not
plugged in. B. Verify the interface cable is properly plugged into the interface
at all locations.
Kohler Co. 13 1069763-5-F

Troubleshooting (cont.)
Media Module Troubleshooting Table
Symptoms Probable Cause Recommended Action
C. The interface or Media Module
requires servicing. C. Contact your Kohler Co. Authorized Service Representative.
1069763-5-F 14 Kohler Co.

Service Parts
**Finish/color code must be specified when ordering.
1081232
Screw
1074847
1070876
Seal
1068929
Grommet
1074848
Power Cover Kit
1074558
Fuse
1066496
Gasket
1068928
Wall Mounting Bracket
1068962
Nut
1068928
Wall Mounting Bracket
1068243
Cable
1081232
Screw
1066497
Gasket
1065703
Grommet
1074849
Enclosure
Assembly
Accessory
Cover Kit
1078031
Grommet
1070876
Seal
1088983
Grommet
Kohler Co. 15 1069763-5-F

Guide du propriétaire
Module média
NOTICE IMPORTANTE
AVERTISSEMENT : Lors de l’utilisation des produits électriques, des précautions de base
doivent toujours être observées, incluant ce qui suit :
AVERTISSEMENT : Risque d’électrocution. Tout le câblage électrique devrait être réalisé par un
électricien qualifié.
AVERTISSEMENT : Risque d’électrocution. Débrancher l’alimentation avant de procéder à
l’entretien.
AVIS : Respecter tous les codes de plomberie, d’électricité et de bâtiment.
IMPORTANT ! Le serveur musique sur l’ordinateur doit être proprement configuré pour utiliser les
fichiers musique dans la baignoire. Se référer au guide d’utilisateur emballé avec l’interface digitale pour
l’information de configuration du serveur de musique.
Conformité FCC et IC
Le terme « IC : » avant le numéro de certification/enregistrement signifie que les spécifications techniques
canadiennes ont été satisfaites.
Contenu :
Kohler Company
N° de modèle : 1070734
IC : 4554A-KOHLER004
FCC ID: N82-KOHLER004
Cet appareil est conforme aux exigences de la section 15 du règlement de FCC. L’appareil est soumis aux
deux conditions d’exploitation suivantes :
1. Cet appareil ne devrait pas causer d’interférences dangereuses, et
2. Cet appareil doit recevoir les toutes interférences reçues, ainsi que celles qui pourraient causer des
opérations non désirées.
REMARQUE :
Tous changements et/ou modifications non expressément approuvés par la partie responsable garantissant la
conformité, pourrait annuler le droit à l’utilisateur d’opérer l’équipement.
Déclaration FCC et IC d’exposition aux rayonnements pour les appareils mobiles
Cet équipement est conforme aux limites FCC et IC d’exposition aux rayonnements stipulées pour un
environnement non contrôlé. Il doit être installé et utilisé en laissant une distance minimale de 7-7/8″(20 cm)
entre le radiateur et votre corps. L’émetteur ne doit pas être placé au même emplacement que celui d’une
autre antenne ou d’un autre émetteur, et ne doit pas fonctionner en même temps que de tels dispositifs.
Kohler Co. Français-1 1069763-5-F

Spécifications
Température ambiante Max 104°F (40°C)
Humidité relative maximum 95% non-condensé
Service électrique 100-240 VAC, 50-60 Hz, 4,4-1,83 A
Éclairage 100-240 VAC, 50-60 Hz, 2,4-1,0 A
Module média 100-240 VAC, 50-60 Hz, 2.0-0,83 A
Longueur de câble de valve (fourni) 30 pieds (9,14 m)
Longueur de câble de haut-parleur 25 pieds (7,62 m)
Longueur de câble de ligne d’entrée 5,6 pieds (1,71 m)
Longueur de câble ethernet 30 pieds (9,14 m)
Merci d’avoir choisi la compagnie Kohler
Merci d’avoir choisi Kohler Co. Vos produits Kohler Co. sont l’expression d’une vraie passion pour la
conception, le travail soigné, le caractère artistique et l’innovation représentés par Kohler Co. Nous sommes
confiants que sa fiabilité et beauté surpasseront vos exigences les plus élevées, vous satisfaisant pendant les
années à venir.
Toute information contenue dans ce guide est basée sur l’information la plus récente du produit disponible
au moment de la publication. Chez Kohler Co, nous aspirons à remplir notre mission d’améliorer le niveau
d’un mode de vie agréable pour chaque personne affectée par nos produits et services. Nous nous réservons
le droit d’apporter des modifications aux caractéristiques, aux emballages et à la disponibilité des produits à
tout moment, et ce sans préavis.
Veuillez prendre s’il vous plaît quelques minutes pour étudier ce guide. Prêter une attention toute
particulière aux instructions d’entretien et de nettoyage.
Garantie
Robinets électroniques, valves et contrôles KOHLER
®
GARANTIE LIMITÉE DE CINQ ANS
Kohler Co. garantit que les robinets électroniques, valves et contrôles sont exempts de tout défaut de matériel
et de fabrication pour une durée de cinq ans en cours d’usage normal domestique à partir de la date
d’installation du produit. Cette garantie s’applique uniquement aux robinets électroniques, valves et contrôles
installés aux États-Unis d’Amérique, au Canada et au Mexique (« Amérique du Nord »).
Kohler Co. décidera, à son propre gré, de réparer, de fournir une pièce ou un produit de rechange ou
d’effectuer les réglages appropriés si de telles défaillances sont décelées au cours d’une utilisation
domestique normale. Un endommagement causé par un accident, mauvais usage ou mauvais traitement n’est
pas couvert par cette garantie. Un entretien et un nettoyage non-appropriés annuleront la garantie*. Une
preuve d’achat (ticket de caisse original) doit être présentée à Kohler Co. avec tous les recours en garantie.
Kohler Co. n’est pas responsable des coûts de main-d’œuvre, d’installation ou d’autres frais accessoires ou
indirects autres que ceux cités ci-dessus. La responsabilité de Kohler Co. n’excédera en aucun cas le prix
d’achat du robinet, de la valve ou du contrôle.
Si les robinets électroniques, les valves ou les contrôles sont utilisés dans un commerce ou bien installés hors
d’Amérique du Nord, Kohler Co. garantit le robinet, la valve ou le contrôle contre tout défaut matériel et de
fabrication pour un (1) et ceci à partir de la date d’installation, avec tous les autres termes de cette garantie
en vigueur excepté la durée.
Pour vous prévaloir d’une indemnisation en vertu de cette garantie, contacter votre concessionnaire ou
entrepreneur plombier, centre de rénovation ou revendeur par internet. Veuillez fournir tous les
renseignements pertinents à votre demande, y compris une description complète du problème, le produit,
numéro du modèle, la date et le lieu d’achat, ainsi que la date d’installation. Joindre également l’original de
la facture. Pour plus de renseignements ou pour demander les coordonnées du centre de réparation le plus
proche, écrire à Kohler Co., à l’attention de: Customer Care Center, Kohler, Wisconsin 53044 USA, ou en
appelant le 1-800-4-KOHLER (1-800-456-4537) à partir des États-Unis et du Canada, et le 001-800-456-4537 à
partir du Mexique, ou rendez-vous à l’adresse www.kohler.com aux États-Unis, à l’adresse
www.ca.kohler.com au Canada, ou à l’adresse www.mx.kohler.com au Mexique.
Kohler Co. Français-2 1069763-5-F

Garantie (cont.)
LES GARANTIES DONNÉES CI-DESSUS REMPLACENT TOUTES AUTRES GARANTIES, EXPRESSES
OU TACITES, Y COMPRIS, MAIS SANS S’Y LIMITER, CELLES DE QUALITÉ MARCHANDE ET
D’APTITUDE À UN EMPLOI PARTICULIER.
KOHLER CO. ET/OU LE REVENDEUR DÉCLINENT TOUTE RESPONSABILITÉ CONTRE LES
DOMMAGES PARTICULIERS, IMPRÉVUS OU DE CIRCONSTANCE. Certains états/provinces ne
permettent pas de limitations de durée d’une garantie implicite ni l’exclusion ou la limitation de tels
dommages; ces limitations et exclusions pourraient par conséquent ne pas s’appliquer dans votre cas. La
présente garantie accorde au consommateur des droits légaux spécifiques. Vous pouvez également avoir
d’autres droits qui varient d’un état/province à l’autre. Cette garantie est accordée uniquement à
l’acquéreur initial et exclut tous dommages dus à une installation erronée, un usage abusif ou une
mauvaise utilisation du produit, qu’ils soient effectués par un entrepreneur, une société de services ou le
consommateur.
Ceci constitue la garantie écrite exclusive de Kohler Co.
*Ne jamais utiliser de nettoyants contenant des agents abrasifs, de l’ammoniaque, de l’eau de Javel, des
acides, des cires, de l’alcool, des dissolvants ou autres produits non-recommandés pour le chrome. Ceci
annulera la garantie.
1069763-5-F Français-3 Kohler Co.

Clé de connexion
Ethernet
Couvercle d'accès
à faible voltage
Entrée audio
Kohler Co. Français-4 1069763-5-F

Connecter les composants
ATTENTION : Risque de choc électrique ou d’endommagement du produit. S’assurer que le
cordon d’alimentation est débranché avant de retirer les couvercles d’accès.
REMARQUE : Si le cordon d’alimentation est endommagé, il doit être remplacé par le fabricant, son
représentant ou autre personnel similaire qualifié pour éviter tout danger.
Remarque: Pour des applications sans fil une connexion ethernet n’est pas nécessaire.
Retirer le couvercle d’accès de faible voltage.
Retirer les œillets aux emplacements d’installation du (des) câble(s). Se référer à « Clé de connexion
».
Presser gentiment chaque connexion jusqu’à ce qu’elles s’engagent ensemble.
Glisser l’œillet du câble dans la rainure avec l’extrémité mâle vers le haut. Vérifier que l’œillet est
assis correctement.
Réinstaller les couvercles d’accès. Ne pas trop serrer.
Brancher l’alimentation électrique dans la prise. Vérifier que la lumière indicatrice s’allume et
clignote.
Tester chaque composant pour en assurer le bon fonctionnement. Se référer aux guides d’installation
et du propriétaire emballés avec chaque composant pour une information additionnelle.
S'assurer que le cordon
d'alimentation est
débranché avant d'ouvrir
les couvercles d'accès.
Oeillet
Glisser un oeillet dans la
rainure avec l'extrémité
mâle vers le haut.
Couvercle d'accès
à haut voltage
Couvercle d'accès
à faible voltage
Installer des
oeillets à
égalité avec le
boîtier média.
Extrémité mâle
Indicateur
lumineux
1069763-5-F Français-5 Kohler Co.
