Kohler K-3323 Assembly instructions

Homeowners Guide
Toilets
1042175-X5-B
X product numbers are for Thailand (i.e. K-12345X)


K-3323, K-3466, K-3494,
K-11458, K-11460, K-11462,
K-11468, K-11472, K-11474

1042175-X5-B 2 Kohler Co.
Thank You For Choosing Kohler Company
Your Kohler Toilet Featuring the IngeniumTM Flushing
System
Thank you for choosing the Bold Look of Kohler with your toilet purchase.
Kohler crasmanship oers you a rare combination of proven performance
and graceful sophistication that will satisfy you for years to come. The
dependability and beauty of your new Kohler toilet will surpass your
highest expectations. We’re very proud of our products here at Kohler and
we know you will be too.
Please take a few minutes to study this Homeowners Guide. Pay special
aention to the Care and Cleaning instructions.
All information in this manual is based upon the latest product informa-
tion available at the time of publication. At Kohler, we constantly strive to
improve the quality of our products. We therefore reserve the right to
make changes in product characteristics, packaging or availability at any
time without notice.
Just because you want a plug-resistant toilet doesn’t mean you have to
sacrice style or cleanliness. Aer all, complete performance requires
aention to each and every detail of the ush. The Ingenium ushing
system by Kohler is precision engineered for complete performance.
Of course you get an exceptional ush, but with the Ingenium system you
get so much more...
• Ingenium ushing system - 1.6 gallons per ush (6 liters per ush)
performance comparable to our previous 3.5 gpf (13Lpf) models.
• Two-inch fully-glazed trapway - provides sleek, streamlined passage.
Optimizes ecient waste elimination.
• Automatic ow-control ll valve - provides consistent water usage
over a wide range of water pressures.
• Sustained swirling water - rinses the bowl with each ush.
• Precisely-placed siphon jet - helps propel waste through the fully-
glazed trapway and provides exceptional resistance against plugging.
• 11” x8-3/4” (27.9 cm x 22.2 cm) minimum water surface - helps keep
the bowl clean and reduces odor.

Kohler Co. 3 1042175-X5-B
Care and Cleaning
Clean the outside surfaces of your vitreous china xture with mild soap
and warm water. Wipe the entire surface completely dry with a clean, so
cloth. Many cleaners contain harsh chemicals, such as ammonia, which
can damage the nish. Do not use those cleaners.
If the surface of your vitreous china xture becomes excessively dirty, you
use a general purpose cleaner.
If you live in a hard water area, make certain all the xture rim holes are
kept clean to ensure proper operation.
Use a toilet bowl cleaner at least once a week. Use a long-handled brush
to clean the xture rim holes. Also use the long-handled brush to clean
as far into the trap of your toilet as possible to prevent mineral deposits
from forming.
Most toilet bowl cleaners are not harmful to the surface of your vitreous
china xture. Please follow the bowl cleaner manufacturer’s instructions
carefully.
Do not use abrasive cleansers or solvents on vitreous china.
Kohler Co. and Kohler Ltd. shall not be responsible or liable for any tank
ing damage caused by the use of cleaners containing chlorine (calcium
hypochlorite).
WARNING: Risk of property or product damage. Do not use
in-tank cleaners in your toilet. Products containing chlorine
(calcium hypochlorite) can seriously damage ings in the tank. This
damage can cause leakage and property damage.

1042175-X5-B 4 Kohler Co.
Troubleshooting
This troubleshooting guide is for general aid only.
See the label on the inside of the toilet lid for service parts. Refer to the
illustration on the last page for parts identication.
• Adjust tank water level to match waterline.
• Fully open water supply shut-o valve.
• Clear obstruction in trapway, jet, or bowl rim holes.
• Clear obstruction in soil pipe or vent pipe.
• Reconnect ush ball chain to trip lever or ush valve.
• Adjust ush ball chain assembly to remove excessive slack.
• Adjust ush ball chain for proper slack so ush ball isn’t held
o ush valve seat.
• Clean or replace ush ball if ush ball is worn, dirty, or
misaligned with flush valve seat or flush valve seat is
damaged Replace ush valve seal or ush valve.
• Remove tank and tighten ush valve nut if ush valve
gasket is leaking. Do not overtighten. If leakage continues,
replace gasket.
• Clean ll valve seat / seat washer of debris, or replace piston/
seat washer assembly.
• Replace ll valve if valve oat sinks.
• Adjust tank water level if too high.
• Fully open water supply shut-o valve.
• Clean ll valve inlet, valve head, or supply line. Flush lines.
• Partially close water supply shut-o valve if water pressure
to toilet is too high. Check toilet performance following any
such adjustment.
• Remove dirt or obstruction in valve head. Flush lines.
• Adjust ush ball chain assembly to remove excessive slack.
• Adjust trip arm bracket and ange so they are parallel with
tank top.
Poor ush.
No ush.
Fill valve turns
on / o by itself
without toilet
being ushed,
or runs allow-
ing water to
enter tank.
Long tank ll
cycle.
Noisy tank ll
cycle.
Trip arm strikes
tank lid under-
side.
Symptoms Corrective action

Kohler Co. 5 1042175-X5-B
One Piece
Two Piece
Flush Valve
Waterline
Chain
Trip Arm
Trip Handle
Fill Valve
Valve Float
Flush Valve Seal
Flush Valve Seat
Flush Ball
Flush
Valve
Waterline
Chain
Trip Lever
Trip
Handle
Fill
Valve
Valve Float
Flush Valve Seal Flush Valve Seat
Flush Ball
Adjustable

1042175-X5-B 6 Kohler Co.
Service Parts
Model Toilet Seat
K-3323X-** K-4653T-**
K-3323X-C-** K-4713X-**
1057941
1096016
1110315
Locknut
Cap
Fill Valve Kit
French Curve Elongated Toilet Seat
K-4653T-**
1056509
Hardware
Kit
GP1078440
87998
83996
88497**
GP1013092**
1059897-CP
(2 ea.)
Flapper Kit
Flush Valve Kit
Trip Lever Kit
Gasket
Tank Cover
Bolt Caps
French Curve Quiet Close
Elongated Toilet Seat
K-4713X-**
1066744
Hardware
Kit
**Finish/color code must be specified when ordering.
1121259**
Hinge Kit
135809**
Hinge Mount
1060198 use 1096016
Fill Valve Kit
83143
Seal
1110314
Seal
85307
Washer

Kohler Co. 7 1042175-X5-B
Model Toilet Seat
K-3466X-** K-4653X-**
K-3466X-C-** K-4713X-**
84676
GP84995
1013944
10132579**
1057941
GP1013092**
1010658**
1096016
(2 ea.)
1054649
Hardware
Kit
Flapper Kit
Locknut
Fill Valve Kit
Flush Valve Kit
Trip Lever Kit
Tank Cover
Bolt Caps
Gasket
**Finish/color code must be specified when ordering.
French Curve Elongated Toilet Seat
K-4653T-**
French Curve Quiet Close
Elongated Toilet Seat
K-4713X-**
1066744
Hardware
Kit
1121259**
Hinge Kit
135809**
Hinge Mount
1110315
Cap
1110314
Seal
85307
Washer
1060126 use 1096016
Fill Valve Kit
84999
Anchor Kit (2 ea.)

1042175-X5-B 8 Kohler Co.
Model Toilet Seat
K-3494X-C-** K-4636X-**
K-3494X-S-** K-4713X-**
Cachet Quiet Close Quick Release
Toilet Seat
K-4636X-A-**
1066744
Hardware
Kit
1096016
1110315
Cap
Fill Valve Kit
1057941
Locknut
GP1013092**
(2 ea.)
Bolt Caps
1033114
78423-CP
81804**
GP84995
84676
84700
Flush Valve Kit
Trip Lever Assy.
Tank Cover
Gasket
Anchor
(2 ea.)
Flapper Kit
**Finish/color code must be specified when ordering.
French Curve Quiet Close
Elongated Toilet Seat
K-4713X-**
1066744
Hardware
Kit
1121259**
Hinge Kit
135809**
Hinge Mount
1110314
Seal
85307
Washer
1033116 Use 1096016
Fill Valve Kit
83143
Seal
84929
Washer
84897
Locknut

Kohler Co. 9 1042175-X5-B
Model Toilet Bowl Tank Seat
K-11458X-** K-4276X-** K-4609X-** K-4653X-**
K-11458X-C-** K-4276X-** K-4609X-** K-4713X-**
1057941
1096016
1110315
1110314
Locknut
Seal
Cap
Fill Valve Kit
83143
1060196 Use
1096016
Fill Valve Kit
Seal
30419
51624 32572 51533
Tank Acc. Pack
Consists of 3 each
32572
51624
51533
Tank Gasket
Tank Cover
Trip Lever Kit
Flush Valve Kit
Flapper
Valve Kit
1015137**
1015139
51487
50752
50751
GP1079948
GP1013092**
Bolt Caps (2 ea.)
French Curve Elongated Toilet Seat
K-4653X-**
1054649
Hardware
Kit
GP85085-CP
**Finish/color code must be specified when ordering.
85307
Washer
French Curve Quiet Close
Elongated Toilet Seat
K-4713X-**
1066744
Hardware
Kit
1121259**
Hinge Kit
135809**
Hinge Mount

1042175-X5-B 10 Kohler Co.
Model Toilet Bowl Tank Seat
K-11460X-** K-4254X-** K-4464X-** K-4664X-**
K-11460X-S-** K-4254X-** K-4464X-** K-4636X-**
1057941
1096016
1110315
1110314
Locknut
Seal
Cap
Fill Valve Kit
83143
1060196 Use 1096016
Fill Valve Kit
Seal
Tank Gasket
Tank Cover
Flush Valve Kit
Flapper
Valve Kit
1060141
51487
50752
50751
GP1079948
GP1013092**
Bolt Caps (2 ea.)
84407**
Trip Lever Kit
GP85086-CP
30419
51624 32572 51533
Tank Acc. Pack
Consists of 3 each
32572
51624
51533
Cachet Quiet Close Quick Release
Toilet Seat
K-4636X-**
1066744
Hardware
Kit
Brevia Elongated Toilet Seat
K-4664X-**
1054649
Hardware
Kit
**Finish/color code must be specified when ordering.
85307
Washer

Kohler Co. 11 1042175-X5-B
Model Toilet Bowl Tank Seat
K-11462X-** K-4276X-** K-4608X-** K-4653T-**
K-11462X-C-** K-4276X-** K-4608X-** K-4713X-**
GP83725-CP
83845**
83846**
GP1013092**
Bolt Caps (2 ea.)
Trip Lever Kit
Trip Lever
Handle Assy
Trip Lever
Flange Assy
30419
51624 32572 51533
Tank Acc. Pack
Consists of 3 each
32572
51624
51533
1057941
1096016
Locknut
Fill Valve Kit
Tank
Gasket
Tank Cover
Tank Cover Kit
Flush Valve Kit
Flapper
Valve Kit
1004808
51487
50752
50751
GP1079948
1032188**
1059565**
1014339
1060160
1060135 Use 1004808
Flush Valve Kit
Flapper Kit
1056509
Hardware
Kit
French Curve Seat
K-4653T-**
**Finish/color code must be specified when ordering.
French Curve Quiet Close
Elongated Toilet Seat
K-4713X-**
1066744
Hardware
Kit
1121259**
Hinge Kit
135809**
Hinge Mount
85307
Washer
1110314
Seal
1110315
Cap
83143
Seal
1060194 Use
1096016
Fill Valve Kit

1042175-X5-B 12 Kohler Co.
Model Toilet Bowl Tank Seat
K-11468X-** K-4276X-** K-4605X-** K-4653X-**
K-11468X-C-** K-4276X-** K-4605X-** K-4713X-**
30419
51624 32572 51533
Tank Acc. Pack
Consists of 3 each
32572
51533
51624
1057941
1096016
Locknut
Fill Valve Kit
GP30440**
Tank Gasket
Tank Cover
Trip Lever Kit
Flush Valve Kit
Flapper
Valve Kit
85314**
1060138
51487
50752
50751
GP1079948
GP1013092**
Bolt Caps (2 ea.)
French Curve Elongated Toilet Seat
K-4653X-**
1054649
Hardware
Kit
**Finish/color code must be specified when ordering.
French Curve Quiet Close
Elongated Toilet Seat
K-4713X-**
1066744
Hardware
Kit
1121259**
Hinge Kit
135809**
Hinge Mount
83143
Seal
1060196 Use 1096016
Fill Valve Kit
85307
Washer
1110314
Seal
1110315
Cap

Kohler Co. 13 1042175-X5-B
Model Toilet Bowl Tank Seat
K-11472X-** K-4276X-** K-4447X-** K-4653X-**
K-11472X-C-** K-4276X-** K-4447X-** K-4713X-**
Trip Lever Kit
GP85085-CP
30419
51624 32572 51533
Tank Acc. Pack
Consists of 3 each
32572
51533
51624
1057941
1096016
Locknut
Fill Valve Kit
Tank Gasket
Tank Cover
Flush Valve Kit
Flapper
Valve Kit
84274**
1060139
51487
50752
50751
GP1079948
GP1013092**
Bolt Caps (2 ea.)
French Curve Elongated Toilet Seat
K-4653X-**
1054649
Hardware
Kit
**Finish/color code must be specified when ordering.
83143
Seal
84481 Use 1096016
Fill Valve Kit
French Curve Quiet Close
Elongated Toilet Seat
K-4713X-**
1066744
Hardware
Kit
1121259**
Hinge Kit
135809**
Hinge Mount
85307
Washer
1110314
Seal
1110315
Cap

1042175-X5-B 14 Kohler Co.
Model Toilet Bowl Tank Seat
K-11474X-** K-4269X-** K-4619X-** K-4664X-**
K-11474X-S-** K-4269X-** K-4619X-** K-4636X-**
Trip Lever Kit
GP85086-CP
30419
51624 32572 51533
Tank Acc. Pack
Consists of 3 each
32572
51533
51624
1060160
1060140 Use 84665
Flush Valve Kit
Flapper Kit
1057941
1096016
Locknut
Fill Valve Kit
GP1013092**
Bolt Caps (2 ea.)
Tank Gasket
Tank Cover
Flush Valve Kit
Flapper
Valve Kit
84652**
84665
51487
50752
50751
GP1079948
Cachet Quiet Close Quick Release
K-4636X-**
1066744
Hardware
Kit
Brevia Elongated Toilet Seat
K-4664X-**
1054649
Hardware
Kit
**Finish/color code must be specified when ordering.
83143
Seal
1060194 Use
1096016
Fill Valve Kit
85307
Washer
1110315
Cap
1110314
Seal
Toilet Seat

1042175-X5-A


K-3323, K-3466, K-3494,
K-11458, K-11460, K-11462,
K-11468, K-11472, K-11474

1042175-X5-B 16 Kohler Co.


 



 
 


 

l

l

l
l
l
l


Kohler Co. 17 1042175-X5-B
คำ�เตือน 



 


 
 

 

 


  
 


1042175-X5-B 18 Kohler Co.

  
 
 
 
 
   
 
 
 
 

 

 
 
 
 
 
 

 
 
 

 



















Kohler Co. 19 1042175-X5-B



1042175-X5-B 20 Kohler Co.

