Kohler Intelligent Toilet Assembly instructions

Homeowners Guide
Intelligent Toilet
Français, page “Français-1”
Español, página “Español-1”
1295780-5-A
PROOF

IMPORTANT SAFEGUARDS
READ ALL INSTRUCTIONS BEFORE USING
When using electrical products, especially when children are present, basic safety precautions should
always be followed, including the following:
DANGER: Risk of electric shock. Connect only to a circuit protected by a Ground-Fault
Circuit-Interrupter (GFCI)*.
WARNING: Risk of personal injury. UV light emitted from this light can cause injury to skin or
eyes. Avoid exposure to unshielded lamp.
WARNING: Risk of personal injury. Replacement of the UV lamp must only be performed by
qualified service personnel.
CAUTION: Risk of personal injury. Do not remove the UV lamp protective cover. Eye damage
may result from viewing the UV light directly.
For Service Personnel:
WARNING: Risk of electric shock. Disconnect power before servicing.
WARNING: Risk of personal injury. The UV lamp cover has an interlock designed to reduce the
risk of excessive ultraviolet radiation. Do not bypass the interlock. Reinstall the interlock after
servicing.
*Outside North America, this device may be known as a Residual Current Device (RCD).
WARNING: To reduce the risk of burns, electrocution, fire, or injury to persons:
Close supervision is necessary when this product is used by or near children, the elderly, or
invalids. Adjust the temperature of the seat for the elderly, those who are incapacitated, or persons
with sensitive skin.
Use this product only for its intended use as described in this manual. Do not use attachments not
recommended by Kohler Co.
Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has
been dropped, damaged, or dropped into water. Return the product for examination and repair.
Keep the cord away from heated surfaces.
Never block the air openings of the product. Keep the air openings free of lint, hair, and the like.
Never use while sleeping or drowsy.
Never drop or insert any object into any opening or hose.
Do not use outdoors or operate where aerosol spray products are being used or where oxygen is
being administered.
Connect this product to a properly grounded outlet only. See the ″Grounding instructions″section.
This product conforms to applicable provisions of US 21 CFR, Chapter 1, Subchapter J, Radiological
Health.
SAVE THESE INSTRUCTIONS
Grounding Instructions
1295780-5-A 2 Kohler Co.
PROOF

IMPORTANT SAFEGUARDS (cont.)
This product should be grounded. In the event of an electrical short circuit, grounding reduces the
risk of electric shock by providing an escape wire for the electric current. This product is equipped
with a cord having a grounding wire with a grounding plug. The plug must be plugged into an
outlet that is properly installed and grounded.
DANGER: Risk of electric shock. Improper use of the grounding plug can result in a risk of
electric shock.
If repair or replacement of the cord or plug is necessary, do not connect the grounding wire to either
flat blade terminal. The wire with insulation having an outer surface that is green with or without
yellow stripes is the grounding wire.
Check with a qualified electrician or service personnel if the grounding instructions are not
completely understood, or if in doubt whether the product is properly grounded.
Do not use an extension cord with this product.
Kohler Co. 3 1295780-5-A
PROOF

Manual Operation
NOTE: When the cleansing wash features are activated from the control panel, they will default to the
middle temperature, pressure, and wand position settings.
Front Wash - Press the icon to activate front wash. Washing will stop automatically after 5 minutes
or can be stopped by pressing the Stop icon.
Rear Wash - Press the icon to activate rear wash. Washing will stop automatically after 5 minutes or
can be stopped by pressing the Stop icon.
Stop - Press the icon to stop front wash, rear wash, dryer and deodorizer features.
Flush - Press the icon to manually flush the toilet. When the power to the toilet is off, press and
hold the icon for 2 seconds to flush. To flush during a power outage, pour a 2-gallon bucket of
water into the bowl.
Low Light Sensor - Senses low light levels and turns the nightlight on when the automatic feature
is enabled. To enable or disable the nightlight, refer to the ″Enable/Disable Automatic Features″
section.
Standby Mode - To conserve energy, press and hold the Stop icon until a beep is heard. The
automatic cover open/close feature, remote control functionality, and heated seat options are
deactivated. Press any icon on the control panel to reactivate the features.
Front
Wash Rear
Wash
Seat
Sensor
Area
Spray
Wand
Control
Panel
Flush
Low Light
Sensor
Stop
1295780-5-A 4 Kohler Co.
PROOF

Remote Control - Setup
NOTE: The remote control must be charged to operate. The ″stop″icon will blink when the remote needs
to be charged.
Charging the Remote
Verify that the docking station has batteries installed. Refer to the ″Replacing the Batteries″section.
Place the remote control on docking station.
The remote is adequately charged when the ″stop″icon stops blinking.
Pairing to the Toilet
IMPORTANT! The remote control cannot be paired to the toilet while the toilet is occupied.
NOTE: The icons on the bottom row of the remote control will flash when the remote is not paired or is
out of range of the toilet.
Press the power button to turn on the remote control.
Move the remote control within close proximity to the toilet. The bottom row of icons should be
flashing.
Press and hold the ″dryer″icon on the remote control.
While holding the ″dryer″icon on the remote control, press and hold the Front Wash and Rear
Wash icons simultaneously on the toilet control panel. Release after a short beep is heard.
When pairing is successful, the bottom icons will stop flashing.
Power Button
Docking Station
Control Panel
Front
Wash Rear
Wash
Kohler Co. 5 1295780-5-A
PROOF

Remote Control - General Features
IMPORTANT! To activate features using the remote control, the remote must be paired with the toilet.
Refer to the ″Remote Control - Setup″section.
Press the power button to turn the remote control on or off.
Stop - Press the ″stop″icon to stop an activated cleansing wash feature. Press and hold to turn off
the remote control.
Eco Flush - Press the ″eco flush″icon to flush the toilet with 0.8 gpf (3.0 lpf).
Full Flush - Press the ″full flush″icon to flush the toilet with 1.0 gpf (3.8 lpf).
Seat Cover - With the seat unoccupied, press this ″cover″icon to open or close the cover.
Seat - With the seat unoccupied, press the ″seat″icon to open or close the seat.
Dryer - While seated, press the ″dryer″icon to activate air flow. This feature will stop automatically
after 4 minutes or can be stopped by pressing the ″stop″icon.
UV Disinfection - With the seat unoccupied, press the ″sanitize″icon to initiate wand disinfection.
Heated Seat Temperature - While seated, press the ″seat temp″icon, then press the ″+″or ″–″icon
to increase or decrease the temperature. The dots to the left of the icon indicate the temperature
setting. There are five settings.
Power Button
Docking Station
1295780-5-A 6 Kohler Co.
PROOF

Remote Control - Cleansing Features
IMPORTANT! To activate features using the remote control, the remote must be paired with the toilet.
Refer to the ″Remote Control - Setup″section.
NOTE: Water temperature, water pressure, wand position, and massage action are adjustable while the
front or rear wash is in use. The dots to the left of the icons indicate the current setting.
Front Wash - Press the ″front″icon to activate water spray from the front of the wand. Washing will
stop automatically after 5 minutes or can be stopped by pressing the ″stop″icon.
Rear Wash - Press the ″rear″icon to activate water spray from the back of the wand. Washing will
stop automatically after 5 minutes or can be stopped by pressing the ″stop″icon.
Massage - Press the ″massage″icon to activate oscillating action. Press again to switch to pulsating
action. Press a third time for simultaneous oscillating and pulsating actions. Press a fourth time to
stop the action.
Spiral - Press the ″spiral″icon to activate spiral action. This feature is only available while the rear
wash is in use. Press the icon again to stop the action.
Water Temperature - Press the ″water temp″icon, then press the ″+″or ″–″icon to increase or
decrease the temperature through five settings.
Water Pressure - Press the ″pressure″icon, then press the ″+″or ″–″icon to increase or decrease
water pressure through five settings.
Wand Position - Press the ″position″icon, then press the ″+″or ″–″icon to adjust the wand position
through five settings.
Kohler Co. 7 1295780-5-A
PROOF

Enable/Disable Automatic Features
NOTE: Automatic features come enabled from the factory.
Deodorizer
When enabled, the deodorizer automatically activates while the toilet is in use.
Press and hold the Flush icon on the control panel until the nightlight blinks three times.
Press the ″rear″icon on the remote control. The nightlight will blink.
A short beep indicates that the feature is enabled. A long beep indicates that the feature is disabled.
Automatic Flush
When enabled, the toilet will automatically flush 60 seconds after the user stands up, lowers the
seat, or leaves the area.
Press and hold the Flush icon on the control panel until the nightlight blinks three times.
Press the ″full flush″icon on the remote control. The nightlight will blink.
A short beep indicates that the feature is enabled. A long beep indicates that the feature is disabled.
Cover Open/Close
When enabled, the seat cover automatically opens when the toilet is approached. The cover will
automatically close 2 minutes after the toilet has been used.
Press and hold the Flush icon on the control panel until the nightlight blinks three times.
Press the ″cover″icon on the remote control. The nightlight blinks once when the sensor is set to
short distance, twice for middistance, and three times for long distance.
A short beep indicates that the feature is enabled. A long beep indicates that the feature is disabled.
Prolonged Seating Indicator
When enabled, the toilet will buzz if the user has been on the seat for a prolonged period of time.
Press and hold the Flush icon on the control panel until the nightlight blinks three times.
Control Panel
Flush
1295780-5-A 8 Kohler Co.
PROOF

Enable/Disable Automatic Features (cont.)
Press the ″seat″icon on the remote control. The nightlight blinks once when the sensor is set to
short distance, twice for middistance, and three times for long distance.
A short beep indicates that the feature is enabled. A long beep indicates that the feature is disabled.
Nightlight
When enabled, the nightlight automatically turns on in low lighting conditions.
Press and hold the Flush icon on the control panel until the nightlight blinks three times.
Press the ″spiral″icon on the remote control. The nightlight will blink.
A short beep indicates that the feature is enabled. A long beep indicates that the feature is disabled.
UV Disinfection
When enabled, ultra violet rays and water sterilize the spray wand daily. This feature only operates
when the seat is closed.
Press and hold the Flush icon on the control panel until the nightlight blinks three times.
Press the ″sanitize″icon on the remote control. The nightlight will blink.
A short beep indicates that the feature is enabled. A long beep indicates that the feature is disabled.
Energy Save Mode
When enabled, the toilet conserves energy by reducing the heated seat temperature when the toilet
is not in use.
Press and hold the Flush icon on the control panel until the nightlight blinks three times.
Press the ″seat temp″icon on the remote control. The nightlight will blink.
A short beep indicates that the feature is enabled. A long beep indicates that the feature is disabled.
Care and Cleaning
WARNING: Risk of property or product damage. Do not use in-tank cleaners in your toilet.
Products containing chlorine (calcium hypochlorite) can seriously damage fittings in the tank. This
damage can cause leakage and property damage.
Kohler Co. shall not be responsible or liable for any tank fitting damage caused by the use of cleaners
containing chlorine (calcium hypochlorite).
For best results, keep the following in mind when caring for your KOHLER product:
•Always test your cleaning solution on an inconspicuous area before applying to the entire surface.
•Wipe surfaces clean and rinse completely with water immediately after applying cleaner. Rinse and
dry any overspray that lands on nearby surfaces.
•Do not allow cleaners to soak on surfaces.
•Use a soft, dampened sponge or cloth. Never use an abrasive material such as a brush or scouring
pad to clean surfaces.
•For Artist Edition Toilets: Treat your decorative product just as you would treat your fine china.
DO NOT use bristle brushes or abrasive-backed sponges. They will scratch decorative surfaces. Use
only warm water to clean. Dry with a cotton cloth or soft sponge.
For detailed cleaning information and products to consider, visit kohler.com/clean. To order Care & Cleaning
information, call 1-800-456-4537.
Kohler Co. 9 1295780-5-A
PROOF

Cleaning the Spray Wand
On the remote control, press and hold the ″position″icon to extend the wand forward.
Or on the control panel (while unseated), press and hold the Front Wash or Rear Wash button to
extend the wand forward.
Remove and immerse the wand tip in an appropriate cleaning solution.
Clean the spray wand with a soft-bristled brush and an appropriate cleaning solution.
Install the wand tip back onto the spray wand.
The wand will automatically retract after 2 minutes. Press the one of the icons mentioned above to
retract if needed.
Control Panel
1295780-5-A 10 Kohler Co.
PROOF

Cleaning or Replacing the Filters
Disconnect the power to the toilet.
Turn off the water by closing the water supply stop.
Remove the right side panel.
Turn off the power to the toilet by flipping the internal switch.
Remove the filters and inspect them for damage.
If the filters are damaged, replace them.
If the filters are clogged, remove all debris.
Install the filters.
Turn on the power to the toilet by flipping the internal switch.
Reattach the right side panel.
Open the supply stop.
Reconnect the power to the toilet.
Filter
Power
Switch
Kohler Co. 11 1295780-5-A
PROOF

Draining the Tank
NOTICE: Drain the water from the internal water line if the seat will not be used for long periods of
time, or there is the possibility of freezing temperatures.
Turn off the water supply and unplug the unit.
Flush the toilet to relieve any pressure from the water supply hose.
Remove the right side panel.
Turn off the power to the toilet by flipping the internal switch.
Press the drain button until all water is drained from the internal water line.
Drain Button
1295780-5-A 12 Kohler Co.
PROOF

Replacing the Batteries
NOTE: The red light on the docking station will blink when the batteries are low. The ″stop″icon on the
remote control will blink when it has a low charge and should be returned to the docking station.
If the remote control is secured to the docking station, remove it and set aside.
Remove the docking station from the wall by carefully lifting up and out.
Open the back compartment on the docking station by pushing both tabs outward at the same time.
Install four AA batteries, oriented as shown in the battery compartment.
Reinstall the cover.
Reinstall the docking station on the wall.
Troubleshooting
NOTE: For service parts information, visit the product page at kohler.com/serviceparts.
Small Children
The automatic flush and cleansing features are activated by a sensor located under the seat. Small
children may not be tall enough to be detected by the sensor.
General
Symptoms Probable Causes Recommended Action
1. The toilet beeps while
occupied. A. The seat has been occupied for an extended period of time. A. No action required. This is simply an indicator beep.
2. The toilet has no power. A. The power cord is not
connected. A. Connect the power cord.
B. The GFCI or RCD is tripped. B. Reset the GFCI or RCD.
C. The toilet is in standby mode. C. Press any icon on the side control
panel to reactivate the toilet.
D. The internal switch is turned off. D. Remove the right side panel and
turn the internal switch on.
3. The toilet has power but
does not flush. A. No water being supplied to the toilet. A. Fully open the water supply stop.
Back of Docking Station
Kohler Co. 13 1295780-5-A
PROOF

Troubleshooting (cont.)
General
Symptoms Probable Causes Recommended Action
4. The toilet has power but
does not respond. A. As the toilet is powering off, before the prompt sound has
stopped, the power was turned
on again.
A. After turning the power off, wait
until the prompt sound has ended
before turning the power back on.
5. No water sprays from the
wand or it has a weak
stream when activated.
A. The water supply stop is closed
or only partially open. A. Fully open the water supply stop.
B. The inlet hose from the water
supply stop to the toilet is
kinked or looped too tight.
B. Remove the kink in the hose or
make the loop wider.
C. The sensor does not detect the
user. C. Small children may not be detected. Adjust the sitting position. The
sensor may have difficulty with
fabric or other objects. The sensor
is designed to sense skin.
D. The filter is blocked or
damaged. D. Service the filter. Refer to the ″Cleaning and Replacing the
Filters″section.
6. The heated seat is not
working. A. The heated seat is not enabled. A. Activate the heated seat. Refer to the ″Enable/Disable Automatic
Features″section.
B. The temperature setting is too
low. B. Adjust the heated seat temperature using the remote control.
7. Water stops flowing from
the spray wand before
cleansing is complete.
A. Washing automatically stops 5
minutes after pressing a spray
icon.
A. Press the ″front″or ″rear″icon to
restart cleansing.
8. The deodorizer is not
working. A. The deodorizer is not activated. A. Activate the deodorizer using the remote control.
9. The toilet does not flush
automatically. A. The automatic flush feature is not enabled. A. Activate automatic flush. Refer to the ″Enable/Disable Automatic
Features″section.
B. The sensor does not detect the
user. B. If this issue occurs repeatedly, call
the Customer Care Center using
the information on the back of this
manual.
10. The nightlight does not
turn on in low lighting
conditions.
A. The nightlight is not enabled. A. Enable the nightlight. Refer to the
″Enable/Disable Automatic
Features″section.
B. The low light sensor is not
working. B1. Clean the light sensor on the side control panel.
B2. Call the Customer Care Center
using the information on the back
of this manual.
Remote Control
Symptoms Probable Causes Recommended Action
1. The remote control is not
turning on. A. The batteries are not properly installed. A. Reinstall the batteries. Refer to the ″Replacing the Batteries″section.
B. The batteries are drained. B. Replace the batteries. Refer to the
″Replacing the Batteries″section.
2. The remote control is not
connecting with the toilet.
The bottom row of icons
is blinking.
A. The remote is too far from the
toilet to receive a signal. A. Move the remote closer to the toilet to regain a connection.
B. The remote is not paired with
the toilet. B. Pair the remote to the toilet. Refer to the ″Remote Control – Setup″
section.
1295780-5-A 14 Kohler Co.
PROOF

Troubleshooting (cont.)
Compliance
FCC ID: N82-KOHLER032, N82-KOHLER034, N82-KOHLER035, N82-KOHLER036
IFT: Certification Number RCPKO1215-2233 and RCPKO1215-2234.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired
operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
RF Exposure Warning
This transmitter with its antenna complies with FCC’s RF exposure limits for general
population/uncontrolled exposure.
This device must not be co-located or operated in conjunction with any other antenna or transmitter.
This device should be operated with a minimum distance of at least 20 cm between the antenna and a
person’s body.
CANADA IC: 4554A-KOHLER032, 4554A-KOHLER034, 4554A-KOHLER035
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the
following two conditions:
1. This device may not cause interference, and
2. This device must accept any interference, including interference that may cause undesired operation of the
device.
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio
interference to other users, the antenna type and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than that necessary for successful communication.
This device complies with Industry Canada’s RSS-310. Operation is subject to the condition that this device
must not cause harmful interference and must accept any interference, including interference that may cause
undesired operation of the device.
Kohler Co. 15 1295780-5-A
PROOF

Guide du propriétaire
Toilette intelligente
MESURES DE SÉCURITÉ IMPORTANTES
LIRE TOUTES LES INSTRUCTIONS AVANT UTILISATION
Lors de l’utilisation de produits électriques, et en particulier en présence d’enfants, toujours observer les
mesures de sécurité fondamentales, notamment :
DANGER: Risque de choc électrique. Raccorder uniquement à un circuit protégé par un
disjoncteur de fuite de terre (GFCI)*.
AVERTISSEMENT: Risque de blessures. La lumière ultraviolette émise par cette lampe peut créer
des lésions oculaires ou de la peau. Éviter toute exposition à une lampe non blindée.
AVERTISSEMENT: Risque de blessures. Le remplacement de la lampe UV peut seulement être
effectué par un personnel d’entretien qualifié.
ATTENTION: Risque de blessures. Ne pas retirer le couvercle de protection de la lampe UV. Les
yeux pourraient subir des lésions lorsque l’on regarde directement dans la lumière UV.
Pour le personnel préposé à l’entretien :
AVERTISSEMENT: Risque de choc électrique. Déconnecter l’alimentation électrique avant
d’effectuer un entretien.
AVERTISSEMENT: Risque de blessures. Ce couvercle de lampe UV est doté d’un système de
verrouillage conçu pour réduire le risque d’un rayonnement ultraviolet excessif. Ne pas annuler le
verrouillage. Réinstaller le verrouillage après l’entretien.
*Hors de l’Amérique du Nord, ce dispositif peut être connu sous le nom de dispositif à courant résiduel
(RCD).
AVERTISSEMENT: Pour réduire le risque de brûlures, d’électrocution, d’incendie ou de
blessures personnelles :
Il est nécessaire de superviser de près lorsque ce produit est utilisé par des enfants, des personnes
âgées ou invalides, ou lorsqu’il se trouve dans leur proximité. Ajuster la température du siège pour
les personnes âgées, les personnes frappées d’incapacité, ou les personnes dont la peau est sensible.
Utiliser ce produit uniquement pour l’usage auquel il est destiné, tel que décrit dans ce manuel. Ne
pas utiliser de dispositifs d’attache non recommandés par Kohler Co.
Ne jamais faire fonctionner ce produit si son cordon ou sa prise sont endommagés, s’il ne fonctionne
pas correctement, s’il est tombé, s’il est endommagé, ou s’il est tombé dans de l’eau. Retourner le
produit pour le faire examiner et réparer.
Tenir le cordon à distance de surfaces chauffées.
Ne jamais bloquer les ouvertures d’air du produit. S’assurer de l’absence de peluches, de cheveux
ou d’autres éléments similaires sur les ouvertures d’air.
Ne jamais utiliser ce dispositif lorsque l’on dort ou si l’on se sent somnolent.
Ne jamais faire tomber ou insérer un objet quelconque dans une ouverture ou un tuyau.
Kohler Co. Français-1 1295780-5-A
PROOF

MESURES DE SÉCURITÉ IMPORTANTES (cont.)
Ne pas utiliser ce dispositif à l’extérieur et ne pas le faire fonctionner en présence de produits
aérosols ou si l’on administre de l’oxygène.
Connecter ce produit à une prise mise à la terre de manière adéquate uniquement. Voir la section
« Instructions de mise à la terre ».
Ce produit est conforme aux conditions applicables de l’US 21 CFR, Chapitre 1, Sous-chapitre J,
Hygiène radiologique.
CONSERVER CES INSTRUCTIONS
Instructions de mise à la terre
Ce produit doit être mis à la terre. En cas de court-circuit électrique, la mise à la terre réduit le
risque de choc électrique en fournissant un câble d’échappement pour le courant électrique. Ce
produit est équipé d’un cordon muni d’un câble de mise à la terre avec une fiche de mise à la terre.
Cette fiche doit être branchée dans une prise installée et mise à la terre de manière adéquate.
DANGER: Risque de choc électrique. L’utilisation incorrecte de la fiche de mise à la terre peut
résulter en risque de choc électrique.
S’il est nécessaire de remplacer le cordon ou la fiche, ne pas brancher le câble de mise à la terre à
l’une des bornes à lame plate. Le câble avec isolation dont l’extérieur est vert avec ou sans rayures
jaunes est le câble de mise à la terre.
Vérifier auprès d’un électricien qualifié ou d’un dépanneur si les instructions de mise à la terre ne
sont pas bien comprises ou en cas de doute sur la mise à la terre adéquate du produit.
Ne pas utiliser de cordon de rallonge avec ce produit.
Kohler Co. Français-2 1295780-5-A
PROOF

Fonctionnement manuel
REMARQUE: Lorsque les fonctions de lavage et nettoyage sont activées à partir du panneau de
commande, elles se mettent par défaut aux réglages moyens de température, de pression et de position de
la baguette.
Lavage avant - Appuyer sur l’icône pour activer le lavage avant. Le lavage s’arrête
automatiquement au bout de 5 minutes, ou il peut être arrêté en appuyant sur l’icône Stop (Arrêt).
Lavage arrière - Appuyer sur l’icône pour activer le lavage arrière. Le lavage s’arrête
automatiquement au bout de 5 minutes, ou il peut être arrêté en appuyant sur l’icône Arrêt.
Arrêt - Appuyer sur l’icône pour arrêter les fonctions de lavage avant, de lavage arrière, de séchoir
ou de désodorisant.
Chasse - Appuyer sur l’icône pour rincer la toilette manuellement. Lorsque la toilette n’est pas sous
alimentation, appuyer sur l’icône pendant 2 secondes pour passer la chasse. Pour passer la chasse
pendant une panne de courant, verser un seau de 2 gallons d’eau dans la cuvette.
Capteur d’éclairage faible - Détecte les niveaux d’éclairage faible et allume la veilleuse lorsque la
fonction automatique est activée. Pour activer ou désactiver la veilleuse, se référer à la section
« Activer/Désactiver les fonctions automatiques ».
Mode d’attente - Pour conserver de l’énergie, appuyer et continuer à appuyer sur l’icône Arrêt
jusqu’à ce qu’un bip soit entendu. La fonction d’ouverture/de fermeture automatique du couvercle,
la fonctionnalité de télécommande et les options de siège chauffé sont désactivées. Appuyer sur
n’importe quelle icône du panneau de commande pour réactiver les fonctions.
Lavage
avant Lavage
arrière
Zone de
capteur
de siège
Baguette de
vaporisation
Panneau de
commande
Chasse
Capteur
d'éclairage
faible
Arrêt
1295780-5-A Français-3 Kohler Co.
PROOF

Télécommande - Configuration
REMARQUE: La télécommande doit être chargée pour fonctionner. L’icône « stop » (arrêt)» clignotera
lorsque la télécommande doit être chargée.
Chargement de la télécommande
Vérifier que des piles ont été installées dans la station d’accueil. Se référer à la section « Remplacer
les piles ».
Placer la télécommande sur la station d’accueil.
La télécommande est suffisamment chargée lorsque l’icône «stop » (arrêt) s’arrête de clignoter.
Appariement de la toilette
IMPORTANT! La télécommande ne peut pas être appariée à la toilette lorsque celle-ci est occupée.
REMARQUE: Les icônes qui se trouvent dans la rangée du bas de la télécommande clignoteront lorsque
la télécommande n’est pas appariée ou si elle est hors de portée de la toilette.
Appuyer sur le bouton Marche/Arrêt pour activer la télécommande.
Rapprocher la télécommande dans un rayon proche de la toilette. La rangée d’icônes inférieure
devrait clignoter.
Appuyer et continuer à appuyer sur l’icône « dryer » (séchoir) sur la télécommande.
Tout en maintenant l’icône « dryer » (séchoir) enfoncée sur la télécommande, appuyer
simultanément et continuer à appuyer sur les icônes Lavage avant et Lavage arrière sur le panneau
de commande de la toilette. Relâcher après avoir entendu un bip bref.
Lorsque l’appariement est réussi, les icônes du bas s’arrêtent de clignoter.
Bouton
Marche/Arrêt
Station d'accueil
Panneau de commande
Lavage
avant Lavage
arrière
Kohler Co. Français-4 1295780-5-A
PROOF

Télécommande - Fonctions générales
IMPORTANT! La télécommande doit être appariée avec la toilette pour que les fonctions puissent être
activées à l’aide de la télécommande. Se référer à la section « Télécommande Configuration ».
Appuyer sur le bouton Marche/Arrêt pour mettre la télécommande en marche ou pour l’arrêter.
Arrêt - Appuyer sur l’icône « stop » (arrêt) pour activer une fonction de lavage et nettoyage activée.
Appuyer et continuer à appuyer pour éteindre la télécommande.
Chasse Éco - Appuyer sur l’icône « eco flush » (chasse éco) pour rincer la toilette avec 0,8 gpf
(3,0 lpf).
Chasse complète - Appuyer sur l’icône « flush-full » (chasse complète) pour rincer la toilette avec
1,0 gpf (3,8 lpf).
Couvercle de siège - Avec le siège non occupé, Appuyer sur l’icône « cover » (couvercle) pour
ouvrir ou fermer le couvercle.
Siège - Avec le siège non occupé, appuyer sur l’icône « seat » (siège) pour ouvrir ou fermer le siège.
Séchoir - Tout en étant assis, appuyer sur l’icône « dryer » (séchoir) pour activer le débit d’air. Cette
fonction s’arrête automatiquement au bout de 4 minutes, ou elle peut être arrêtée en appuyant sur
l’icône « stop » (arrêt).
Désinfection par UV - Avec le siège non occupé, appuyer sur l’icône « sanitize » (désinfecter) pour
lancer la désinfection de la baguette.
Température de siège chauffé - Tout en étant assis, appuyer sur l’icône « seat temp » (temp siège),
puis appuyer sur le«+»ousurl’icône«–»pour augmenter ou diminuer la température. Les
points situés à gauche de l’icône indiquent le réglage de la température. Cinq réglages sont
possibles.
Bouton Marche/Arrêt
Station d'accueil
1295780-5-A Français-5 Kohler Co.
PROOF
