KOLEDA SOLUS+ User manual

1
KOLEDA SOLUS+ USER MANUALKOLEDA KOLEDA.CO
SOLUS+
SOLUS+
USER MANUAL

2
KOLEDA SOLUS+ USER MANUAL
Dear user, please note that the FOVI app is available to
download. We do not recommend the use of the SOLUS+ heater
without the accompanying app.
SOLUS+ SPECIFICATIONS
MODEL M1
Weight: 4.5kg
Dimensions: 750 x 321 x 10mm
Advised Heating Area: 10m2
Rated Input: 400W
WiFi Operational Range: up to 50m outdoors/30m indoors
MODEL M2
Weight: 10kg
Dimensions: 1050 x 445 x 10mm
Advised Heating Area: 20m2
Rated Input: 700W
Wi-Fi Operational Range: up to 50m outdoors/30m indoors
Wi-fi Requirments: Works with standard 2.4Ghz Bandwidth!*
*You will need a standard 2.4 ghz Wi-Fi bandwth . If your router has
band steering, we advise that you uncouple the 2.4 ghz and 5.0 ghz
networks. This can easily be done by logging into your Wi-Fi router IP
address!
INTENDED USE
• Before utilizing the product, the user should determine the
suitability of the product for its intended use. The product is
intended for use as a heating device for residential use as
outlined in this document. Use outside of this scope is NOT
covered by the warranty.
• SOLUS+ heaters are intended for use with a specific voltage
which is region based. The voltage that is needed is based on
the delivery address. If the heater is used in a different region
than the delivery address - there are risks of overheating and
damage.
• Region specific voltages:
USA: 110V/120V
Canada: 110V/120V
UK: 240V
Ireland: 230V
Europe: 230V
Australia: 230V/240V
New Zealand: 230V/240V
South Africa: 230V
Switzerland: 230V
Japan: 100V
DOWNLOAD THE
FOVI iOS APP
Open your camera app and point the camera at the QR code
above to download the FOVI IOS control app.
http://b.link/FOVI-IOS-APP
DOWNLOAD THE
FOVI ANDROID APP
Open your camera app and point the camera at the QR code
above to download the FOVI Android control app.
http://b.link/FOVI-Android-APP
VIDEO SET UP
INSTRUCTION
Open your camera app and point the camera at the QR code
above to watch the FOVI quick start video instructions
http://b.link/FOVI-Video

3
KOLEDA SOLUS+ USER MANUAL
• In no case shall SIA Green Warm Technology (KOLEDA)
be liable under any legal theory, including but not limited
to contract or strict liability, for any direct, indirect special,
incidental or consequential damages resulting from incorrect
product use.
SAFETY ADVICE
• CAUTION! Danger of electrocution. The mounting/
installation is recommended to be done by a qualified
professional.
• CAUTION! At no point should the product be disassembled.
Opening the product control box will violate the warranty
and may lead to malfunction and danger to life.
• CAUTION! There is always risk of injury from touching
any form of electric heater and SOLUS+ panels are no
different. However, a key benefit of SOLUS+ panels, unlike
conventional heaters, is that they can be mounted higher up
on walls - reducing the likelihood of accidentally touching
them or falling against them. We always advise this, especially
in areas where young children or the elderly are present.
• CAUTION! Connect and install the device only in the way
shown in these instructions. Any other method could cause
damage, injury and/or risk to life.
WHERE TO PLACE THE HEATER
• This is an infrared panel heater. It heats objects by transferring
energy directly from the heater into the object. Therefore,
consider placing the heater where it will not be immediately
obstructed by objects like furniture or where it cannot
effectively radiate out, such as at the edge or in the corners of
a room.
• Heater placement should be guided by the most actively used
areas in a room. You want to ensure the maximum comfort for
people within a room.
• Objects placed in front of the heater will heat up and can
prevent effective heat dispersion into the room. Avoid placing
the device opposite windows or open doorways.
• The mounting location should be chosen in such a way that the
glass cannot be accidentally broken and people will not be in
danger from a possible break in the glass.
• The minimum distance from the back side of the panel must be
40mm to the mounting surface. This will always be the case if
the mounting hardware provided is used.
• Objects in front of the panel must be at least 400mm away
from the sides. Failure to do so will cause excess heat to build
up behind the heater and will void the warranty. The distance
between the sides of the heater and the sides of any adjacent
heater must be a minimum of 800mm. Failure to do so could
cause excess heat to build up behind the heaters and will void
the warranty.
SHELLY THERMOSTAT
PLEASE NOTE THAT THE SHELLY THERMOSTAT
DOES NOT WORK WITHOUT THE FOVI APP
To enable the Shelly Thermostat follow the in-app instruction.
Battery Type: 3V DC - CR123A
Battery Life: Up to 18 months
Electrical consumption: Static ≤70uA/Awake ≤250mA
Humidity measurement range: 0~100% (±5%)
Temperature measurement range: -40°C ÷ 60 °C (± 1°C)
Working temperature: -40°C ÷ 60 °C
Dimensions (HxWxL): 35x45x45 mm
Radio protocol: WiFi 802.11 b/g/n
Frequency: 2400 – 2500 MHz;
Operational range: up to 50m outdoors/30m indoors
• CAUTION! Use the device only with batteries which comply
with all applicable regulations. Inappropriate batteries may
cause a short circuit in the device, which may damage it.
• CAUTION! Do not allow children to play with the device,
especially with the Power Button. Keep the devices for remote
control of SOLUS+ (mobile phones, tablets, PCs) away from
children.
• Device Wake Up: To open the device, twist the top and
bottom part of the case counter clockwise. Press the Button.
The LED should flash slowly. This means that Shelly Thermostat
is in AP mode. Press the Button again and the LED will turn off
and Shelly Thermostat will be in sleep mode.
LED States:
• LED flashing quickly - AP Mode
• LED flashing slowly - STA Mode (No Cloud)
• LED still - STA Mode (Connected to Cloud)
• LED flashing quickly - FW Update (STA mode
connected Cloud)
Factory Reset: You can return your SOLUS temperature sensor to its
Factory Settings by pressing and holding the button for 10 seconds.
Upon successful factory reset the LED will flash slowly.
Wi-fi Requirments: Works with standard 2.4Ghz Bandwidth!*

4
KOLEDA SOLUS+ USER MANUAL
*You will need a standard 2.4 ghz Wi-Fi bandwth . If your router has
band steering, we advise that you uncouple the 2.4 ghz and 5.0 ghz
networks. This can easily be done by logging into your Wi-Fi router IP
address!
INSTALLING YOUR SOLUS+
HEATER ON THE WALL:
• Attach the template to the wall in the position that you intend
to hang the heater ensuring the template itself is level.
• Drill the 4 holes as indicated on the template using an
appropriate sized drill bit.
• Remove the template from the wall.
• Insert raw plugs and screw in supplied mounting screws,
leaving the screw head and 4- 5mm of screw shaft exposed
(to mount the brackets on).
• The heater can now be affixed to the wall using the installed
screws by aligning the screw head with the holes on the
heater wall mount.
INSTALLATION SAFETY
• This appliance must be disconnected from its power source
during installation or service activities and when replacing.
• In order to avoid overheating and potential fire hazard,
DO NOT cover the heater with insulating material or similar
material under any circumstances. DO NOT locate the
heater within 0.3m of any flammable materials (eg. Furniture,
curtains).
• The recommended minimum distance of the panel to the floor
should be 1.2m, especially if there are children at home.
• The space between the rear of the panel and the wall must be
unobstructed at all times to allow sufficient air flow.
• NEVER mount the heater where there is a risk it could fall into
any kind of water container.
• DO NOT install in rooms where direct contact with water is
possible.
• If your electric supply exceeds 250 Volts, DO NOT USE the
heater under any circumstances.
• Under ALL circumstances, the electrical circuit to power the
heater must be capable of disconnection and de-activation
by a switch, fuse, RCD or GFCI.
• DO NOT operate the heater if the cord or plug is damaged
or after the heater malfunctions, or if it has been dropped or
damaged in any manner. Check each heater for damage
before installation. Make sure that the heater itself, the plug
and the cable are free of any visible signs of damage. If the
cord is damaged the appliance must be sent for repair to the
manufacturer (SIA Green Warm Technology).
• Handle carefully and avoid stressing the glass mechanically.
Do not use the heater if the glass panels are damaged.
Disconnect the heater and do not put it into operation again.
Dismount the heater immediately to reduce the danger of
direct impact from falling pieces and dispose of the unit
in accordance with the local Waste Electrical Equipment
regulations.
• This heater must only be used for the heating of people or
buildings. The heater is not to be used by children or persons
with reduced physical, sensory or mental capabilities, or lack
of experience or knowledge. Children should be kept away
and should not be left unsupervised around the unit.
• All operators should only switch on/off the appliance
provided that it has been placed or installed in its intended
operating position in accordance with these instructions.
Children must not plug in, switch on or regulate the appliance
or perform user maintenance including cleaning.
• DO NOT touch the heater when in use. The product has a
surface temperature of around 115°C and prolonged contact
with the heater will cause burns and injury.
• IMPORTANT: The heater must be mounted on a non-
flammable surface that is capable of bearing the weight of
the heater.
CLEANING
• Before attempting to clean the panel, unplug the heater,
isolate the unit from the electrical supply and allow it to
completely cool down. DO NOT immerse the SOLUS+ in
water or splash water onto it. Clean the glass surface with a
damp cloth and glass cleaner. Never use a wet cloth. When
clean, dry the surfaces with a dry cloth.
• DO NOT apply abrasive materials, solvents or solvent wipes
to the surface as this can cause irreparable damage. Wait
until the unit is completely dry before use.
MAINTENANCE & REPAIR
• DO NOT attempt to repair or adjust any electrical or
mechanical functions on this unit. Doing so will void your
warranty. Repairs must only be carried out by an authorised
KOLEDA service partner or the manufacturer (SIA Green
Warm Technology).

5
KOLEDA SOLUS+ USER MANUAL
DISPOSAL
• The devices should not be disposed of with other household
waste at the end of it’s working life. Household users should
contact either the retailer where they purchased this product
for proper disposal or recycle them through the local return
system. For further information contact your municipal waste
management.
WARRANTY
• Within the warranty period, repair or replacement due to
defects in material and workmanship is completely free
of charge; the costs are covered by the manufacturer on
presentation of your invoice or delivery slip.
• A prerequisite for validity of the warranty is use of the device
as intended with observance of the specified conditions of
use. Any further warranty or claims are excluded. The warranty
covers the repair or replacement of the defective product only.
Any further claims or liability for consequential loss
are excluded.
• WARRANTY RESTRICTION: The warranty will be void if
the heater has been tampered with or opened in any way.
Green Warm Technology SIA will assume no responsibility
for scratches on surface or frames after first use. SIA Green
Warm Technology cannot accept responsibility for damage,
loss or injury caused by ingress of water or moisture,
accidental damage, mishandling, external impact, adjustment
by unauthorised personnel or failure to follow the correct
maintenance and safety precautions as stated in the manual.
• If a fault or defect covered by the warranty occurs, the heating
panel has to be sent to an authorised service partner or the
manufacturer together with the invoice or original delivery
note. If sending by carrier the heating panel should be
properly packaged and proof of purchase must be produced.
PRODUCT CERTIFICATION
• CE- European Safety Standards Low Voltage Directive
2014/35/EC
• EMC Directive 2014/30/EC
• RoHS 2011/65/EC Ecodesign requirements for local space
heaters 2009/125/EC.
• IP44 rated
LEGAL
Manufacturer: SIA Green Warm Technology
Trading Name: KOLEDA
Address: MEZA street 1 k-1, Riga, Latvia, LV-1048
E-mail: h[email protected]
Website: https://koleda.co
Changes in the contact data are published by the manufacturer at
the official website of the device: https://koleda.co
The user is obliged to stay informed for any amendments of
these warranty terms before exercising his/her rights against the
manufacturer.
