Calibration Procedure
Signature
The contact image sensor (CIS) of the unit is calibrated properly from the factory. With regular, basic use, the
sensor’s sensitivity decreases which can lead to IMAGE errors. To resolve this issue, the unit can be
re-calibrated using the white calibration paper that came with the unit.
3. Then turn the machine backside front. Proceed to pull the top-back cover from the machine upwards.
4. Put the provided laminated calibration card inside the top back door opening until it fits securely against the
hopper rollers.
Please follow the steps below to calibrate the sensor:
1. Ensure the machine is turned ON.
2. On the front of the machine, press the “ADD” and “PRINT” button at
the same time. A calibration screen will display with a message
instructing you to “Open the Cover and put in the calibration paper”.

KB-052019 2019 Kolibri USA
Calibration Procedure
Signature
5. Carefully proceed to close the top back cover with the calibration card in place inside the machine.
6. Once the top back cover is closed, turn the machine face side to yourself to start the calibration process.
7. Press the buttons in the following order “BATCH,” “REPORT,” “BATCH”. Once the buttons are pressed in that
order, a calibration screen should appear on the display.
8. Next, press the “START/STOP” Button 7 times to initiate the calibration
process. Once the buttons are pressed 7 times, calibration will begin and
the calibration screen will display a message “CIS check wait.”
9. Once calibration is completed, a message of successful adjustment will
show “CIS check ok.” If a message of “CIS check fail” is shown, try
re-adjusting the calibration card in the machine for better placement
underneath the CIS sensor and repeat steps 4 to 8 again.
10. Once the successful message is shown, remove the calibration card from
inside the machine
11. Reset the machine by turning it off, then on.
12. The CIS calibration is done.
If, after calibrating the unit, this does not resolve the issue, please see the support section on the
Kolibri USA website at www.kolibriusa.com, or contact Kolibri Support at suppor[email protected]
for further troubleshooting.
