Kong RAIZER User manual

EN
ZZV0XXXX rev. 0
RAIZER
817.640

2 original version in Italian dated 09/10/2023
Laden Sie die Übersetzung in Ihrer Sprache herunter
- Download the translation in your language - Bájate
la traducción en tu idioma - Télécharger la traduction
dans vostre langue - Scarica la traduzione nella tua
lingua - 下载您语言版本的手册

817.640 RAIZERwww.kong.it 3 original version in Italian dated 09/10/2023
CONTENTS
1 - SYMBOLOGY AND ASSISTANCE 4
1.1 Symbology 4
1.2 Assistance 4
2 - GENERAL INFORMATION 5
3 - TECHNICAL CHARACTERISTICS 6
3.1 Terminology and materials of parts 6
3.2 Optional components 8
4 - SPECIFIC INFORMATION 9
4.1 Intended use 9
4.2 Positioning 9
4.3 Use of winch 10
5 - MAINTENANCE AND REPAIR 15
5.1 General 15
5.2 Maintenance 15
5.3 Repair 15
6 - STORAGE 16
7 - CHECKS, INSPECTIONS AND SERVICES 17
7.1 Checks 17
7.2 Inspections 17
7.3 Services 17
8 - DURATION AND WARRANTY 18
8.1 Duration 18
8.2 Disposal 18
8.3 Warranty 18
8.4 Legal obligations 18
9 - MARKING 19
9.1 Marking 19
10 - DOCUMENTS 20
10.1 Inspections and services log 20
10.2 Maintenance and repair log 21

4 original version in Italian dated 09/10/2023
CHAPTER
For the sake of comfort and clarity while reading this manual, below are the symbols used
for handling important warnings for a proper and safe use of the device.
1.1 SYMBOLS
REQUIREMENT FOR PROPER USE
It identifies the presence of information for proper use of the device.
INFORMATION REQUIREMENT
It identifies the presence of useful and general information which guides
the reader towards a conscious use of the device and/or performance of
actions.
1
SYMBOLS
AND SUPPORT
For information please contact Kong Customer Support Service by:
- telephone [phone]
- fax [phone]
- email: [email protected]
or write to KONG S.p.A. – Via XXV Aprile, 4 – 23804 Monte Marenzo LC - ITALY.
To facilitate support operations, please always communicate or state the serial number (SN)
indicated on the label fixed to the Device.
1.2 SUPPORT

817.640 RAIZERwww.kong.it 5 original version in Italian dated 09/10/2023
Warning: not suitable for
use in an ATEX environment
(Directive 94/9/CE)
The information provided by the
manufacturer (hereinafter information) must
be read and clearly understood by the user
prior to using the device. The information
regards the description of the features,
performance, assembly, disassembly,
maintenance, preservation, disinfection, etc.
of the device. Even though the information
offers tips on use, this information shall
not be considered as a user manual under
actual conditions of use.
WARNINGS AND
LIMITATIONS OF USE:
- this device is to be used only by persons who
are physically fit, trained (instructed and taught)
in its use, or under the direct supervision of
trainers/supervisors who ensure its safety,
- do not use the device until this user manual
has been read and understood in its entirety,
- strictly follow the manufacturer’s information,
improper use of the device is hazardous,
- modifying and/or repairing the device is strictly
forbidden,
- all checks described in chapter 7 must be
carried out prior to and after using the device.
In case of any doubt on the efficiency of the
device, the user must replace it immediately,
- improper use, deformations, falls, wear,
chemical contamination, exposure to
temperatures below -30°C or above +50°C
for textile/plastic components/ devices, and
+100°C for metallic components/devices, are
some examples of causes that can reduce,
limit and end the life of the device,
- the location of the anchor is critical to the
safety of fall arrest: carefully evaluate the
clear height present below the user, the the
height of a potential fall, the elongation of
2 GENERAL INFORMATION
the rope/ rope, the elongation of any energy
absorber/dissipator, the height of the user,
and the “pendulum” effect so as to avoid any
possible obstacles (e.g., the ground, rubbing,
abrasions, etc.),
- the minimum strength of anchor points, made
on both natural and artificial elements, must
be at least 12 kN. The evaluation of those
made on natural elements (rock, plants, etc.)
is only possible empirically, so it must be
carried out by an experienced and competent
person, while for those made on artificial
elements (metals, concrete, etc.) it is possible
scientifically, so it must be carried out by a
qualified person.
- Before any recovery operation ensure that the
weight does not exceed the range defined in
Section 3.3,
- To reduce the risks of exposure/transmission
of infectious diseases carry out cleaning
and disinfection of the device as defined in
Chapter 5,
- Always check the compatibility of the devices
used in combination through the relevant
manufacturer’s information,
- the use of spare parts or accessories other than
those listed in Section 3.4 can be dangerous,
- Avoid exposing the device to heat sources
and contact with chemicals. Reduce direct
exposure to the sun to the extent necessary.
At low temperatures and in humid conditions,
icing can reduce flexibility and increase
the risk of cuts and abrasion on textile and
synthetic devices.
All our devices are tested/ checked piece
by piece in compliance with the procedures
laid down by the Quality System certified
in accordance with the UNI EN ISO 9001
standard. Laboratory tests, testing, information
and standards do not always reproduce the
practical result. Thus, the results obtained
under the actual conditions of use of the device
in the natural environment may differ, even
considerably at times. The
best information lies in the continuous practical
use under the supervision of skilled/
expert/qualified people.
CHAPTER 2

6 original version in Italian dated 09/10/2023
TECHNICAL
SPECIFICATIONS
3.1 TERMINOLOGY AND MATERIALS OF PARTS
CHAPTER 3
A) Aluminium alloy rigging plate
B) Connecting eyelets
C) Connecting holes
D) Fixed clamp
E) Tube clamp
F) Tube clamp slots
G) Self-locking nuts
H) Butterfly nuts
I) Winch
I1) Drum
I2) Bushing
I3) Self tailing
J) Protective plate
K) Protective bushing
L) Cranks
3.1.1 Spare parts
E) Tube clamp
G) Self-locking nuts
H) Butterfly nuts
K) Protective bushing
L) Cranks

817.640 RAIZERwww.kong.it 7 original version in Italian dated 09/10/2023
H
x4
x4
I
I2
F
DCBA
K
L
G
E
I3
I1

8 original version in Italian dated 09/10/2023
817630000KK WINCH ADAPTER
Aluminium plate that allows the RAIZER to be assembled on the Ortles Stand and on the
Stelvio fishing pole
817640001KK LARGE TUBE CLAMP
Large tube clamp that allows positioning of the RAIZER on tubes with a diameter of 60 mm.
3.2 OPTIONAL COMPONENTS
x4
x4

817.640 RAIZERwww.kong.it 9 original version in Italian dated 09/10/2023
SPECIFIC
INFORMATION
4.1 INTENDED USE
The 817.640 RAIZER is a device that is:
- suitable for the simultaneous anchoring of 2 persons and for the connection of elements
of personal protection systems against falls from a height (EN 795:2012 and CEN/TS
16415:2013) (plate A),
- a multi-anchor for connections of up to 6 persons (RfU CNB/P/11.114) (plate A),
- used for lifting (max 240 kg) with additional hand-operated lowering function designed for
descents of up to 2 m (EN 1496/B:2017).
This device facilitates the handling of loads (inert or human but not for multi-purpose
use) in work at height and in technical rescue operations.
Do not use the device to lift persons after using it to lift materials.
For descents greater than 2 meters, connect a device to descent points
compliant with the EN 341 standard or, alternatively, to a EN 12841/B device
and an additional safety rope.
CHAPTER 4
4.2 POSITIONING
The 817.640 RAIZER can be positioned, according to the needs of users:
- floating, by means of ropes that connect to anchor points,
- on tubes, through the use of the tube clamp,
- attached to columns or sections, with the help of ratchet belts,
- on the ground, with the use of the Winch Adapter and the Ortles Stand.
The choice of the best positioning must be made by experienced and trained
personnel.
The anchor points must guarantee a minimum strength of 12 kN.

10 original version in Italian dated 09/10/2023
4.2.1 Floating positioning
Position the RAIZER in a “floating” manner using ropes/cables connected to the eyelets (B)
and/or to the connecting holes (C).
The RAIZER must be connected to AT LEAST 3 different anchor points.
MIN 12 kN
MIN 12 kN
MIN 12 kN
