Simrad C-All
Photo by Silas Baisch (Unsplash)
INSTALLATION
MANUAL

479237/A
March2022©KongsbergMaritimeAS
SimradC ‑ ‑
‑
All
Transducer
InstallationManual
Thepurposeofthismanualistoprovidetheinformation,procedures
andbasicdrawingsrequiredforthephysicalinstallationoftheSimrad
C‑Alltransducer.Themanualfurtherprovidesrelevantdescriptions
andillustrationstoexplainthebasicprinciplesforlocationandnoise
considerations.
Note
Theinstallationshipyardmustprovideallnecessaryinstallation
drawings.Ifrequired,alldocumentsprovidedbytheshipyardforthe
physicalinstallationoftheC
‑ Alltransducermustbeapprovedby
thevessel’ snationalregistryandcorrespondingmaritimeauthority
and/orclassicationsociety.Theshipownerandshipyarddoingthe
installationareresponsibleforobtainingandpayingforsuchapproval.
Additionalend-userdocumentsrelatedtotheC‑Alltransducercanbe
foundonourwebsite.Thisincludespublicationsthataretranslatedto
otherlanguages.SelectedpublicationsarealsoprovidedonIETM
(InteractiveElectronicTechnicalManual)formats.
•www.kongsberg.com/c-all

KongsbergMaritimeAS
www.kongsberg.com
Documentinformation
•Product:SimradC‑All
•Document:InstallationManual
•Documentpartnumber:479237
•Revision:A
•Dateofissue:25March2022
Copyright
TheinformationcontainedinthisdocumentremainsthesolepropertyofKongsbergMaritimeAS.No
partofthisdocumentmaybecopiedorreproducedinanyformorbyanymeans,andtheinformation
containedwithinitisnottobecommunicatedtoathirdparty,withoutthepriorwrittenconsentof
KongsbergMaritimeAS.
Warning
Theequipmenttowhichthismanualappliesmustonlybeusedforthepurposeforwhichitwas
designed.Improperuseormaintenancemaycausedamagetotheequipmentand/orinjurytopersonnel.
Youmustbefamiliarwiththecontentsoftheappropriatemanualsbeforeattemptingtooperate
orworkontheequipment.
KongsbergMaritimedisclaimsanyresponsibilityfordamageorinjurycausedbyimproperinstallation,
useormaintenanceoftheequipment.
Disclaimer
KongsbergMaritimeASendeavourstoensurethatallinformationinthisdocumentiscorrectandfairly
stated,butdoesnotacceptliabilityforanyerrorsoromissions.
Supportinformation
Ifyourequiremaintenanceorrepair,contactyourlocaldealer.Youcanalsocontactususingthe
followingaddress:[email protected].Ifyouneedinformationaboutourotherproducts,visit
https://www.kongsberg.com/simrad.Onthiswebsiteyouwillalsondalistofourdealersanddistributors.

479237/A3
Tableofcontents
ABOUTTHISMANUAL..............................................................5
INTRODUCTION.......................................................................7
SimradC‑All......................................................................................................................8
Physicalandenvironmentalspecications........................................................................9
Orderinformation............................................................................................................10
Supportinformation.........................................................................................................10
TRANSDUCERHANDLINGANDMAINTENANCE.......................13
Rulesfortransducerhandling..........................................................................................14
Inspectingandcleaningthetransducerface....................................................................15
Paintingthetransducerface.............................................................................................17
Approvedanti-foulingpaints...........................................................................................19
PREPARATIONS.....................................................................20
Installationsummary........................................................................................................21
Aboutinstallationdrawings.............................................................................................22
Tools,equipmentandconsumablesrequiredforinstallation...........................................22
Personnelqualications...................................................................................................23
Transducerinstallationprinciples....................................................................................24
Transducerinstallationinablister.........................................................................24
Transducerinstallationinaushmountedsteeltank............................................27
Transducerinstallationinkeelbox.........................................................................29
Transducerinstallationusingdropkeel..................................................................30
Smoothsurfaceisimportant...................................................................................32
Usingasuitableinclinationangle..........................................................................32
Wheretoinstallthetransducer........................................................................................33
Introductiontotransducerlocation.........................................................................33
Mountthetransducerdeep.....................................................................................33
Avoidprotrudingobjectsnearthetransducer.........................................................34
Mountthetransduceratforwardpartofhulltominimizetheeffectsfromthe
owboundarywaterlayer.................................................................................35
Keepthetransducerfarawayfromthepropellers.................................................36
Mountthetransduceratasafedistancefrombowthruster(s)...............................36
Summaryandgeneralrecommendations...............................................................37
Acousticnoise..................................................................................................................39
Contributingfactors................................................................................................39
Selfnoise................................................................................................................41
Ambientnoise.........................................................................................................43
Fishinggearnoise...................................................................................................44
InstallationManual

4479237/A
Electricalselfnoise................................................................................................44
Somemeanstoreduceacousticnoise....................................................................44
INSTALLINGTHETRANSDUCER.............................................47
Installationsummary........................................................................................................48
Usingasuitableinclinationangle..........................................................................50
Smoothsurfaceisimportant...................................................................................50
Usingself-lockingtaps...........................................................................................51
Designing,manufacturingandmountingtheinstallationhardware................................53
Installingthecablegland.................................................................................................55
Designing,manufacturingandmountingthesteelconduit.............................................56
Unpackingthetransducerfromitstransportcrate...........................................................58
Installingthetransducercable.........................................................................................59
Mountingthetransducer..................................................................................................61
Paintingthetransducerface.............................................................................................63
CABLELAYOUTANDINTERCONNECTIONS.............................66
Connectingthetransducercabletothetransceiver..........................................................67
Connectingtoa12-pinAmphenolsocket........................................................................68
12-pinAmphenolplug....................................................................................................70
Connectingthetransducertotheothertransceivers........................................................71
Splicingthetransducercable...........................................................................................72
Splicingthecableusingagroundedjunctionbox..................................................73
Splicingthecableusingajunctionboxisolatedfromvessel’sground..................74
SETTINGTOWORK................................................................75
Settingtoworksummary.................................................................................................76
Inspectingthetransducer.................................................................................................77
InstallingtheC‑Alltransducerintheechosounderuserinterface..................................78
Installingtransceiverchannels.........................................................................................80
Checkingand/oreditingthetransceiverparameters........................................................82
DRAWINGFILE......................................................................84
Aboutthedrawingsinthedrawingle............................................................................85
483897OutlinedimensionsC‑All...................................................................................86
436003MountingringC‑All...........................................................................................88
436004ClampingringC‑All...........................................................................................91
204678MountingarrangementC‑All..............................................................................94
SimradC‑All

479237/A5
Aboutthismanual
Thepurposeofthismanualistopresentthedescriptionsanddrawingsrequiredtoinstall
theC‑Alltransducer.
Targetaudience
Themanualisintendedfortechnicalpersonnel;suchasskilledshipyardworkers,
electricians,qualiedengineersandnavalarchitects.Itisassumedthatyouunderstand
thegeneralprinciplesofmaritimeelectronicequipment.Y oumustalsobefamiliarwith
theinstallationofelectronicandmechanicalproducts.Youareexpectedtohavebasic
mechanicalskillsandfamiliaritywithhandlingofsensitiveelectronicequipment.
Installationinstructions/Installationdrawings
Theinformationinthisdocumentmustberegardedasguidelinesandrecommendations.
Theinstallationshipyardmustdesignandmanufacturethenecessaryhardwaretoinstall
thetransducerunderthehull.
Note
Theinstallationshipyardmustprovideallnecessarydesignandinstallationdrawings,as
wellastherelevantworkstandardsandmountingprocedures.
Ifrequired,alldocumentsprovidedbytheshipyardforthephysicalinstallationofthe
C ‑ Alltransducermustbeapprovedbythevessel’ snationalregistryandcorresponding
maritimeauthorityand/orclassicationsociety.Suchapprovalmustbeobtainedbefore
theinstallationcanbegin.Theshipownerandshipyarddoingtheinstallationare
responsibleforobtainingandpayingforsuchapproval.
KongsbergMaritimeASwillacceptnoresponsibilityforanydamageorinjurytothe
product,vesselorpersonnelcausedbyequipmentthathasbeenincorrectlyinstalledor
maintained,orbydrawings,instructionsorproceduresthathavenotbeenpreparedby
us.TheoutlinedimensionsoftheC‑Alltransducerandtherelevantinstallationitems
canbefoundintheDrawinglechapterinthismanual.
Endusermanualsandsourcedrawings(normallyinAutoCadformat)canbedownloaded
fromourwebsite.
•www.kongsberg.com/c-all
Aboutthismanual

6479237/A
Registeredtrademarks
Observetheregisteredtrademarksthatapply.Windows®isaregisteredtrademarkof
MicrosoftCorporationintheUnitedStatesandothercountries.Simrad®,SIMRAD®
andtheSimrad®logoareeitherregisteredtrademarks,ortrademarksofKongsberg
MaritimeASinNorwayandothercountries.
Wewantyourfeedback
Wealwayswanttoimproveourproducts.Wealsowantourend-userdocumentationto
becomprehensiveandrelevant.Youcanhelp.Pleaseprovidecomments,suggestionsor
constructivecriticismtoanyofoursupportofces.
SimradC‑AllInstallationManual

479237/A7
Introduction
Topics
SimradC‑All,page8
Physicalandenvironmentalspecications,page9
Orderinformation,page10
Supportinformation,page10
Introduction

8479237/A
SimradC‑All
TheSimradC-Allisasinglebeamtransducerdesignedforshndingapplications.The
transducerbodyincludesfourdifferenttransducerelementsprovidingfouroperational
frequencies:38,70,120and200kHz.Thebeamwidthis18degreesateachnominal
operatingfrequency.
Itisawell-establishedfact
thattheechosounderoperating
frequencyisimportantforgood
results.Thisisbecausethe
echostrengthofdifferentsh
speciesvarieswithfrequency.
Someshspeciesareeasier
tondwithahighfrequency
thanalowone,andviceversa.
Thisisalsoimportantifyouare
goingtondsmallerspecies,
suchasshrimporkrill.
Atthesametime,lower
frequenciesgenerallyhavelongerrange.Alowfrequencyallowsyoutondbothsh
andthebottomwhenworkingindeepwater.
Forthesereasons,manyechosoundersystemsareequippedwithmorethanone
transducer.Somepeopleprefertwotransducerstoworkwithtwodifferentfrequencies,
otherswantmore.Thisincreasesthepriceoftheechosounder,andentailsincreased
installationcosts.
TheC‑Alltransducerisalong-awaitedsolutionformanyusers.Withfourdifferent
operatingfrequenciesinasingletransducerbody,yougetacompletefrequencyrange.
ThetransducerisalsospeciallyadaptedtoourWideBandTransceiver(WBT).This
meansthatyou–withonlyafewmainparts-canassembleaprofessionalsingle-beam
echosoundersuitableforalltypesofshing.
TheSimradC-Alloffersalargebandwidth.Thisprovidesanerangeresolution,which
isimportantforsingleshdetectionandtargetstrengthmeasurements.
Thetransducerisnormallymountedushwiththehullplating.Aclampingringisused
tosecurethetransducerbodytoamountingring.Themountingringisweldedtothe
bottomplate.Thetransducercablepenetratesthehullusingacablegland.Thecable
glandconsistsofabushing,rubbergasket,washersandapackingnipple.
Thetransducercanalsobeushmountedatthebottomofablisteroradropkeel.
Relatedtopics
Introduction,page7
Physicalandenvironmentalspecications,page9
Orderinformation,page10
Transducerhandlingandmaintenance,page13
SimradC‑AllInstallationManual

479237/A9
Physicalandenvironmentalspecications
Thesephysicalandenvironmentalspecicationsareimportantforhandling,storage
andinstallation.
Note
Wearecontinuouslyworkingtoimprovethequalityandperformanceofourproducts.
Thetechnicalspecicationsmaybechangedwithoutpriornotice.
Weightsandoutlinedimensions
•Physicaldimensions:
–Diameter:300mm
–Height:116mm(Body)
•Weight:
–Inair:9.1kg(Withoutcable)
–Inair:12.2kg(Withcable)
–Inwater:1.0kg(Withoutcable)
Cablespecications
•Cablelength:20m
•Bendingradius:
–Static:100mm(Theoretical)
–Dynamic:185mm(Theoretical)
Environmentalrequirements
•Storagetemperature:
–Maximum:+60°C
–Minimum:–20°C
•Operatingtemperature:
–Maximum:+40°C
–Minimum:–5°C
Relatedtopics
Introduction,page7
Drawingle,page84
Introduction

10479237/A
Orderinformation
ToordertheC‑Alltransducer,oranyoftheoptionalitemsprovidedwithit,contactyour
localdealer.Ifyoudonothavearegulardealer,alistofallourdistributorsanddealers
canbefoundonourwebsite.Yourdealerwillalsobeabletohelpyouwithadetailed
quotationincludingpriceanddeliveryinformation.
Relevantorderinformationisprovidedonourwebsite.
•www.kongsberg.com/c-all
Relatedtopics
Introduction,page7
Supportinformation
IfyouneedtechnicalsupportforyourC‑Alltransduceryoumustcontactyourlocal
dealer,oroneofoursupportofces.Alistofallourofcesanddealersisavailableon
ourwebsite.YoucanalsocontactourmainsupportofceinNorway.
Norway(mainofce)
•Companyname:KongsbergMaritimeAS/Simrad
•Address:Strandpromenaden50,N3190Horten,Norway
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
Spain
•Companyname:KongsbergMaritimeSpainS.L.U
•Address:PartidaAtalayes20,03570Villajoyosa,Spain
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
France
•Companyname:SimradFrance
•Address:5ruedeMenMeur,29730Guilvinec,France
•Telephone:[phone]
SimradC‑AllInstallationManual

479237/A11
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
USA
•Companyname:KongsbergUnderwaterTechnologyLLC(KUTL)/SimradFisheries
•Address:1921033rdAveW,SuiteA,Lynnwood,W A98036,USA
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
Canada
•Companyname:KongsbergMesotechLtd.
•Address:1598KebetWay,PortCoquitlam,BC,V3C5M5,Canada
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
Malaysia
•Companyname:KongsbergMaritimeMalaysiaSdn.Bhd
•Address:Unit27-5SignatureOfces,TheBoulevard,MidV alleyCity,
LingkaranSyedPutra,59200KualaLumpur,Malaysia
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
Korea
•Companyname:KongsbergMaritimeKoreaLtd
•Address:#1101HarborTower,113-1,Nampodong6-Ga,Jung-Gu,
Busan600-046,Korea
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
Introduction

12479237/A
China
•Companyname:KongsbergMaritimeChinaLtd
•Address:555ChuanqiaoRoad,China(Shanghai)PilotFreeTradeZone,201206,China
•Telephone:[phone]
•Telefax:[phone]
•Website:www.kongsberg.com/simrad
•Emailaddress:[email protected]
Relatedtopics
Introduction,page7
SimradC‑AllInstallationManual

479237/A13
Transducerhandlingand
maintenance
Topics
Rulesfortransducerhandling,page14
Inspectingandcleaningthetransducerface,page15
Paintingthetransducerface,page17
Approvedanti-foulingpaints,page19
Transducerhandlingandmaintenance

14479237/A
Rulesfortransducerhandling
Tosecurelonglifeandaccurateresults,thetransducermustbehandledcorrectly.
Atransducermustalwaysbehandledasadelicateinstrument.Incorrectactionsmay
damagethetransducerbeyondrepair.Observethesetransducerhandlingrules:
1Donotactivatethetransducerwhenitisoutofthewater.
2Donothandlethetransducerroughly.Avoidimpacts.
3Donotexposethetransducertodirectsunlightorexcessiveheat.
4Donotusehigh-pressurewater,sandblasting,metaltoolsorstrongsolventsto
cleanthetransducer.
5Donotdamagetheouterprotectiveskinofthetransducer.
6Donotdamagetheouterprotectiveskinofthetransducerface.
7Donotsteponthetransducercable.
8Donotdamagethetransducercable.Avoidexposuretosharpobjects.
Transportprotection
Sometransducersaredeliveredwithacoverplatetoprotectthefaceduringtransport
andinstallation.Letthisplatestayonaslongaspossible,butdonotforgettoremove
itbeforethevesselgoestosea.
Cleaningandpaintingthetransducerface
Duringnormaluse,thetransducerissubjectedtobiologicalfouling.Ifthismarine
growthisexcessive,itwillreducetheoverallperformanceofyoursystem.
Thetransducerhasnotbeendesignedwithanyprotectionagainstbiologicalfouling.
Wheneveropportunityarise,typicallywhenthevesselisdry-docked,thetransducerface
mustbecleanedforshellsandothermarinegrowth.
•Becareful
sothatyoudonotaccidentallymakecutsorinictotherphysicaldamage
tothetransducerface.
•Removebiologicalfoulingcarefullyusingaplasticbrush,asuitablesynthetic
detergentandfreshwater.Biologicalmaterialwhichisstronglyrootedinthesubstrate
canberemovedcarefullywithapieceofwoodorplastic.
•Donotusehigh-pressurewater,sandblasting,metaltoolsorstrongsolventstoclean
thetransducer.
Anti-foulingpaintmaybeappliedtothetransducerface.Tominimizethenegative
acousticaleffectsthelayerofanti-foulingpaintmustbeasthinaspossible.
SimradC‑AllInstallationManual

479237/A15
Note
Theanti-foulingpaintwillreducetheacousticalperformanceofthetransducer.The
surfaceroughnessofthetransducersubstrateandthethicknessofthepaintmayalso
inuencetheperformance.KongsbergMaritimecannotbeheldresponsibleforany
negativeconsequencesoftheanti-foulingpaint.
Approvedanti-foulingpaints
Becausesomepainttypesmaybeaggressivetothepolyurethaneinthetransducer,
consultourlistofapprovedpaints.Observetherelevantinstructionsandsafety
informationprovidedbythepaintmanufacturer.Approvedanti-foulingpaintsfor
transducersarefoundonourwebsite.
•https://www.kongsberg.com/anti-fouling-paints
Specialrulesforacousticwindows
Arctictankshaveacousticwindowsmadeofpolycarbonate.Thesemustneitherbe
paintednorcleanedwithchemicals.Acousticwindowsmustnotbeexposedtodirect
sunlight.
Relatedtopics
Transducerhandlingandmaintenance,page13
Inspectingandcleaningthetransducerface
Marinegrowth(biologicalfouling)onthetransducerfacereducestheperformance.For
thisreason,itisimportanttokeepthetransducerfaceclean.Everytimeyourvesselisin
drydock,youmustremovethemarinegrowth.Atthesametime,youmustinspectthe
transducercloselyforphysicaldamage.
Prerequisites
Thefollowingtoolsandconsumablesarerequired:
•Personalprotection
•Freshwater
•Plasticbrush
•Mildsyntheticdetergent
•Pieceofwoodorplasticwithoutsharpcorners
Context
Duringnormaluse,thetransducerissubjectedtobiologicalfouling.Ifthismarine
growthisexcessive,itwillreducetheoverallperformanceofyoursystem.Whenever
Transducerhandlingandmaintenance

16479237/A
opportunityarise,typicallywhenthevesselisdry-docked,thetransducerfacemustbe
cleanedforshellsandothermarinegrowth.
Itisimportanttocheckthetransducerforphysicaldamage.Anycracks,fracturesor
holesintheredprotectivecoatingmayresultinawaterleak,andaleakmaycause
irreparabledamagetothetransducer.
Atransducermustalwaysbehandledasadelicateinstrument.Incorrectactionsmay
damagethetransducerbeyondrepair.Observethesetransducerhandlingrules:
•Donotactivatethetransducerwhenitisoutofthewater.
•Donothandlethetransducerroughly.Avoidimpacts.
•Donotexposethetransducertodirectsunlightorexcessiveheat.
•Donotusehigh-pressurewater,sandblasting,metaltoolsorstrongsolventstoclean
thetransducer.
•Donotdamagetheouterprotectiveskinofthetransducer.
•Donotdamagetheouterprotectiveskinofthetransducerface.
•Donotsteponthetransducercable.
•Donotdamagethetransducercable.Avoidexposuretosharpobjects.
Procedure
1Allowforsufcientaccesstocleanandinspecttheentiresurfaceofthetransducer.
2Removebiologicalfoulingcarefullyusingaplasticbrush,asuitablesynthetic
detergentandfreshwater.
Biologicalmaterialwhichisstronglyrootedinthesubstratecanberemoved
carefullywithapieceofwoodorplastic.Ifrequired,youcanalsousecitricacid.
Apply,leaveitworkingforseveralhours,andrinsethoroughlywithfreshwater.
Note
Donotusehigh-pressurewater ,sandblasting,metaltoolsorstrongsolventstoclean
thetransducer .Donotdamagetheouterprotectiveskinofthetransducerface.
3Allowthetransducersurfacetodry.
4Doathoroughvisualinspectionofthetransducer.
Checkfordents,scratches,holesorotherdamagetothesurface.
Ifyoundsuspiciousdamage,takehighresolutionphotosthatshowthedamage.
ContactyourdealerortheSimradsupportorganizationforadvice.
SimradC‑AllInstallationManual

479237/A17
5Ifnecessary,applyanti-foulingpaintasdescribedinthededicatedprocedure.
Note
Becausesomepainttypesmaybeaggressivetothepolyurethaneinthetransducer ,
consultourlistofapprovedpaints.Thelistofapprovedanti-foulingpaintscanbe
foundonourwebsite.
•https://www.kongsberg.com/anti-fouling-paints
Relatedtopics
Transducerhandlingandmaintenance,page13
Approvedanti-foulingpaints,page19
Paintingthetransducerface
Marinegrowth(biologicalfouling)onthetransducerfacereducestheperformance.We
recommendthatyoupaintthetransducerfaceimmediatelyafterinstallation,andthen
againasoftenasrequiredtomaintaintheprotection.
Prerequisites
Thefollowingtoolsandconsumablesarerequired:
•Personalprotection
•Freshwater
•Plasticbrush
•Mildsyntheticdetergent
•Pieceofwoodorplasticwithoutsharpcorners
•Primer
•Anti‑foulingpaint
•Wetlmgauge
•Airlessspray
Becausesomepainttypesmaybeaggressivetothepolyurethaneinthetransducer,
consultourlistofapprovedpaints.Approvedanti-foulingpaintsfortransducersare
foundonourwebsite.
•https://www.kongsberg.com/anti-fouling-paints
Context
Thetransducerhasnotbeendesignedwithanyprotectionagainstbiologicalfouling.
Anti-foulingpaintmaythereforebeappliedtothetransducerface.Tominimizethe
negativeacousticaleffectsthelayerofanti-foulingpaintmustbeasthinaspossible.
Transducerhandlingandmaintenance

18479237/A
Note
Theanti-foulingpaintwillreducetheacousticalperformanceofthetransducer.The
surfaceroughnessofthetransducersubstrateandthethicknessofthepaintmayalso
inuencetheperformance.KongsbergMaritimecannotbeheldresponsibleforany
negativeconsequencesoftheanti-foulingpaint.
Observetherelevantinstructionsandsafetyinformationprovidedbythepaint
manufacturer.
Procedure
1Cleanthetransducerthoroughly.
Makesurethatyouremovealloilgreaseresidues,aswellassaltandother
contamination.
2Allowthetransducersurfacetodry.
3Abradethetransducersurfaceusingasandingpaperwith240inchgritsize.
Donotexceedasurfaceroughness(Rmax)of35micronsasthiscaninuencethe
transducerperformance.
4Removealldust.
5Applytheprimer,andletitdry.
6Applythepaint.
Observetheinstructionsprovidedbythepaintmanufacturer.Useairlessspray.
Applytheminimumspeciedlmthicknesspercoatandforthecompletelayer.
Itisnotpossibletomeasuredrylmthicknessontransducersurface.Youmust
thereforeuseawetlmgaugetofrequentlymeasurethepaintthickness.
Note
Westronglyrecommendthatyoudonot useapaintbrushand/oraroller.
7Allowthepainttodry.
Furtherrequirements
Thecontractororshipyardmustkeepadailypaintlogrecordingallrelevantinformation
fromthesurfacetreatment.
Relatedtopics
Transducerhandlingandmaintenance,page13
Approvedanti-foulingpaints,page19
Installingthetransducer,page47
Drawingle,page84
SimradC‑AllInstallationManual
