magicolor DLSeries
Firmware Updater
Guide
®
4138-7795-01A
1760673-001A

System Requirements 1
System Requirements
Computer:
PC with a Pentium 2, 400 MHz or faster processor
(A Pentium 3, 500 MHz or faster processor is recommended.)
Operating system:
–Microsoft Windows XP Home Edition/Professional, Windows Server
2003, Windows 2000, Windows Me, Windows 98SE
Available hard disk space:
–Approximately. 20 MB (printer driver and Status Display)
Memory:
128 MB or more
Interface:
–10Base-T/100Base-TX (IEEE 802.3) Ethernet interface port
–USB 2.0 or later interface port
Compatible printers:
magicolor 2430 DL, magicolor 5430 DL, magicolor 5440 DL
Printer driver:
Must be installed
–magicolor 2430 DL version 1.7.925.0 or later
–magicolor 5430 DL version 1.9.126.0 or later
–magicolor 5440 DL version 1.6.1130 or later

Starting magicolor DL Series Firmware Updater2
Starting magicolor DL Series Firmware
Updater
CAUTION
Before starting the firmware updater, make sure that the printer driver is
installed.
1Download the firmware updater from the Web site, and then decompress
it in any folder.
2Double-click magicolor DL Series Firmware Updater.exe.
3Select I accept, and then click the OK button.

Starting magicolor DL Series Firmware Updater 3
4Select the appropriate connection for the environment where the printer is
being used.
For a network connection
1When using Windows XP Service Pack 2 or later, the following message
will appear. Click the Unblock button.
For a network connection:
The firmware updater searches the print-
ers connected to the Local Area Network.
Select Network. →p. 3
For a local (IP) connection:
The firmware updater searches the print-
ers listed in the Printers folder on your
computer.
Select Local. →p. 8
For a local (USB) connection:
The firmware updater searches the print-
ers listed in the Printers folder on your
computer.
Select Local. →p. 13

Starting magicolor DL Series Firmware Updater4
2Select the appropriate printer model, and then click the OK button.
A list of printers on the network appears.
3Select the check box for the printer whose firmware is to be updated, and
then click Select/Deselect Firmware in the menu bar.

Starting magicolor DL Series Firmware Updater 5
4Select the updated firmware file for the printer, and then click the Open
button.
" If one of the following messages appears, an incorrect firmware
file was selected. Click the OK or No button, and then select the
correct firmware file.

Starting magicolor DL Series Firmware Updater6
5Click Update Printer Firmware in the menu bar.
As an example, the following dialog box shows file version 2.05 selected.
6Click the OK button.
7Click the OK button.
Updating of the firmware begins.
" Do not turn off the printer while its firmware is being updated.

Starting magicolor DL Series Firmware Updater 7
" If the following message appears, click the OK button.
8Reboot your printer.
9Click Exit in the menu bar
10 Click the OK button to exit the Updater.

Starting magicolor DL Series Firmware Updater8
For a local (IP) connection
1When using Windows XP Service Pack 2 or later, the following message
will appear. Click the Unblock button.
2From the Printer Selection list, select the printer whose firmware is to be
updated.
3Click the Browse button.

Starting magicolor DL Series Firmware Updater 9
4Select the updated firmware file for the printer, and then click the Open
button.
" If one of the following messages appears, an incorrect firmware
file was selected. Click the OK or No button, and then select the
correct firmware file.

Starting magicolor DL Series Firmware Updater10
5Click the Update Firmware button.
6Click the OK button.

Starting magicolor DL Series Firmware Updater 11
7Click the OK button.
Updating of the firmware begins.
" Do not turn off the printer while its firmware is being updated.
" If the following message appears, click the OK button.
8Reboot your printer.

Starting magicolor DL Series Firmware Updater12
9Click the Close button to exit the Updater.

Starting magicolor DL Series Firmware Updater 13
For a local (USB) connection
1From the Printer Selection list, select the printer whose firmware is to be
updated.
2Click the Browse button.
3Select the updated firmware file for the printer, and then click the Open
button.

Starting magicolor DL Series Firmware Updater14
" If any of the following messages appear, an incorrect firmware file
was selected. Click the OK or No button, and then select the cor-
rect firmware file.

Starting magicolor DL Series Firmware Updater 15
4Click the Update Firmware button.
5Click the OK button.

Starting magicolor DL Series Firmware Updater16
6Click the OK button.
Updating of the firmware begins.
" Do not turn off the printer while its firmware is being updated.
" If the following message appears, click the OK button.
7Reboot your printer.

Starting magicolor DL Series Firmware Updater 17
8Click the Close button to exit the Updater.
