Introducing High-Speed Color / Monochrome Continuous Feed Inkjet

Introducing the Screen Truepress Jet520 Series
Introducing the Screen Truepress Jet520 Series for full-color
or monochrome variable data printing offering extremely fast
high-volume printing, easy operation and a full lineup of models
to suit every business need. The Screen Truepress Jet520 Series
has printing speed ranging from 210 feet per minute to over 722
feet per minute depending upon the model selected and capable
of printing onto a wide range of paper from general purpose
paper, newsprint, recycled paper, coated and uncoated inkjet
media, and even peel-off postcards.
When high speed, variable data printing is required for
magazines, newspapers, small lot printing, textbooks and
transactional applications then look no further than one of the
world’s best selling high speed inkjet press, Screen Truepress
Jet520 Series. Whether you are looking for a monochrome or
color high speed inkjet, the Screen Truepress Jet520 Series will
deliver reliability, consistency and high-quality printing results.
Features
Quality – High-quality printing with variable
drop sizes
Easy Operation – Operator does not have to
be a pressman or technician
Flexibility – Full lineup of models to suit every
business need
Productivity – High-speed, up to 722 feet per
minute onto a range of media
Workflow – Flexible workflow can be adjusted to
suit production
Finishing – Finishing equipment from major
vendors means virtually any output form
Sample Applications
√Direct Mail
√Statements / Invoices / Promotional
√Publications / Books on Demand / Magazines
√Study Materials
√Product Manuals
√Newspapers
√Workbooks
√Novelty: Maps, Church Envelopes, Note Pads
√Variable Data for Transpromo

Screen Truepress Jet520
The Truepress Jet520 is the world’s most successful high-speed,
single-pass color inkjet printer. The Truepress Jet520 prints on
rolls of paper up to 20.4” wide. Its top printing speed of 420’ per
minute enables fast turnarounds and efficient production of high
print volumes.
Screen Truepress Jet520EX Monochrome
Screen Truepress Jet520EX Color
The Truepress Jet520EX allows lower-volume applications
to enjoy the benefits of color inkjet printing, and builds on
the performance and popularity of the Truepress Jet520, the
industry’s leading continuous-feed, color inkjet printing system.
Screen’s entry-level inkjet web press, available in monochrome
and color versions, features a more compact footprint than its
predecessor. Its smaller size allows it to fit in a wider range
of environments.
Screen Truepress Jet520ZZ
The Truepress Jet520ZZ is for high volume users. The
flagship of the Truepress Jet520 series of continuous-feed,
single-pass inkjet printing systems produces direct mail,
books, magazines and other high-volume work that traditionally
has been printed offset. When used for personalized catalogs,
color bank statements, technical manuals and newsletters,
the Truepress Jet520ZZ improves response rates of printed
materials, reduces costs and increases product demand.
Konica Minolta and Screen Partnership
Our strategic partnership with Screen USA allows Konica
Minolta to deliver an extended range of capabilities to our
production print customers and respond to the growing
expectations and high demands of the marketplace —
another reason why our customers can count on Konica
Minolta for all of their digital printing needs. Konica Minolta’s
strong resources further extend the reputation of the Screen
Truepress Jet520 Series as an impressive on-demand printer
capable of handling diverse applications.

Specifications
Screen Truepress
Jet520EX
Monochrome
Screen Truepress
Jet520EX Color
Screen Truepress
Jet520
Screen Truepress
Jet520ZZ
Printing Method Piezo single-pass printing, four tones per drop**
Print Head
Technology Epson drop-on-demand inkjet
Ink Water-based pigment inks,
water based dye inks Water-based dye inks
Water-based pigment inks,
water based dye inks,
four process colors (CMYK)
Water-based pigment inks,
water based dye inks,
four process colors (CMYK)
Resolution Maximum 720 x 360 dpi Maximum 360 x 720 dpi
360 x 360
720 x 360
720 x 720 dpi
Maximum 720 x 360 dpi
Printing Speed Maximum 128m (420’)
per minute
Maximum 64m (210’)
per minute
Maximum 128m (420’)
per minute
Maximum 220m (722’)
per minute**
Printing Width 150 to 506 mm
(5.90” to 19.9”)
150 to 506 mm
(5.90” to 19.9”)
150 to 507 mm
(5.90” to 19.96”)
150 to 502 mm
(5.90” to 19.7”)
Paper Width 165 to 520 mm
(6.50” to 20.47”)
165 to 520 mm
(6.50” to 20.47”)
165 to 520 mm
(6.50” to 20.47”)
165 to 520 mm
(6.50” to 20.47”)
Typical Monthly
Print Volumes ≥1.5 Million Pages ≥1.5 Million Pages ≥5 Million Pages ≥10 Million Pages
Product
Configurations
Simplex,
Dual Engine Duplex
Simplex,
Dual EngineDuplex,
Single Engine Duplex
Simplex,
Dual Engine Duplex
Length of
Print Engine* 86.1” (2,186 mm) 86.1” (2,186 mm) 116.54” (2,960 mm) 130.7” (3,319 mm)
Finishing Options Open system supporting multiple finishing partners
© 2011 All rights reserved. Reproduction in whole or in part without written permission is prohibited. Konica Minolta is a trademark of
KONICA MINOLTA HOLDINGS, INC. All other brands and product names are registered trademarks or trademarks of their respective owners.
Design & specifications are subject to change without notice. Not all features described are available on all models.
KONICA MINOLTA
BUSINESS SOLUTIONS U.S.A., INC.
100 Williams Drive
Ramsey, N.J. 07446
www.kmbs.konicaminolta.us
www.CountOnKonicaMinolta.com
3/11
*Based on a Simplex configuration
**High speed (220m) for Truepress Jet 520ZZ is optional. Printing Method is three tones per drop using this option.
