Kontron ECX-BYT User manual

 USER GUIDE
www.kontron.com // 1
ECX-BYT
Doc. User Guide, Rev. 1.0
Doc. ID: [To be Determined]

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 2
This page has been intentionally left blank

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 3
 ECX-BYT - USER GUIDE
Disclaimer
Kontron would like to point out that the information contained in this user guide may be subject to alteration,
particularly as a result of the constant upgrading of Kontron products. This document does not entail any guarantee
on the part of Kontron with respect to technical processes described in the user guide or any product characteristics
set out in the user guide. Kontron assumes no responsibility or liability for the use of the described product(s),
conveys no license or title under any patent, copyright or mask work rights to these products and makes no
representations or warranties that these products are free from patent, copyright or mask work right infringement
unless otherwise specified. Applications that are described in this user guide are for illustration purposes only.
Kontron makes no representation or warranty that such application will be suitable for the specified use without
further testing or modification. Kontron expressly informs the user that this user guide only contains a general
description of processes and instructions which may not be applicable in every individual case. In cases of doubt,
please contact Kontron.
This user guide is protected by copyright. All rights are reserved by Kontron. No part of this document may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer
language, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the
express written permission of Kontron. Kontron points out that the information contained in this user guide is
constantly being updated in line with the technical alterations and improvements made by Kontron to the products
and thus this user guide only reflects the technical status of the products by Kontron at the time of publishing.
Brand and product names are trademarks or registered trademarks of their respective owners.
©2017 by Kontron AG
Kontron AG
Lise-Meitner-Str. 3-5
86156 Augsburg
Germany
www.kontron.com

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 4
High Risk Applications Hazard Notice
THIS DEVICE AND ASSOCIATED SOFTWARE ARE NOT DESIGNED, MANUFACTURED OR INTENDED FOR USE
OR RESALE FOR THE OPERATION OF NUCLEAR FACILITIES, THE NAVIGATION, CONTROL OR
COMMUNICATION SYSTEMS FOR AIRCRAFT OR OTHER TRANSPORTATION, AIR TRAFFIC CONTROL, LIFE
SUPPORT OR LIFE SUSTAINING APPLICATIONS, WEAPONS SYSTEMS, OR ANY OTHER APPLICATION IN A
HAZARDOUS ENVIRONMENT, OR REQUIRING FAIL-SAFE PERFORMANCE, OR IN WHICH THE FAILURE OF
PRODUCTS COULD LEAD DIRECTLY TO DEATH, PERSONAL INJURY, OR SEVERE PHYSICAL OR
ENVIRONMENTAL DAMAGE (COLLECTIVELY, "HIGH RISK APPLICATIONS").
You understand and agree that your use of Kontron devices as a component in High Risk Applications is entirely at
your risk. To minimize the risks associated with your products and applications, you should provide adequate design
and operating safeguards. You are solely responsible for compliance with all legal, regulatory, safety, and security
related requirements concerning your products. You are responsible to ensure that your systems (and any Kontron
hardware or software components incorporated in your systems) meet all applicable requirements. Unless otherwise
stated in the product documentation, the Kontron device is not provided with error-tolerance capabilities and cannot
therefore be deemed as being engineered, manufactured or setup to be compliant for implementation or for resale as
device in High Risk Applications. All application and safety related information in this document (including application
descriptions, suggested safety measures, suggested Kontron products, and other materials) is provided for reference
only.

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 5
Revision History
Revision Brief Description of Changes Date of Issue
1.0 Initial Issue 2017-Dec-15
Terms and Conditions
Kontron warrants products in accordance with defined regional warranty periods. For more information about
warranty compliance and conformity, and the warranty period in your region, visit http://www.kontron.com/terms-
and-conditions.
Kontron sells products worldwide and declares regional General Terms & Conditions of Sale, and Purchase Order
Terms & Conditions. Visit http://www.kontron.com/terms-and-conditions.
For contact information, refer to the corporate offices contact information on the last page of this user guide or visit
our website CONTACT US.
Customer Support
Find Kontron contacts by visiting: http://www.kontron.com/support.
Customer Service
As a trusted technology innovator and global solutions provider, Kontron extends its embedded market strengths into
a services portfolio allowing companies to break the barriers of traditional product lifecycles. Proven product
expertise coupled with collaborative and highly-experienced support enables Kontron to provide exceptional peace of
mind to build and maintain successful products.
For more details on Kontron’s service offerings such as: enhanced repair services, extended warranty, Kontron
training academy, and more visit http://www.kontron.com/support-and-services/services.
Customer Comments
If you have any difficulties using this user guide, discover an error, or just want to provide some feedback, contact
Kontron support. Detail any errors you find. We will correct the errors or problems as soon as possible and post the
revised user guide on our website.

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 6
Symbols
The following symbols may be used in this user guide
DANGER indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
NOTICE indicates a property damage message.
CAUTION indicates a hazardous situation which, if not avoided,
may result in minor or moderate injury.
Electric Shock!
This symbol and title warn of hazards due to electrical shocks (> 60
V) when touching
products or parts of products
. Failure to observe the precautions indicated and/or
prescribed by the law may endanger your life/health and/or result in damage to your
material.
ESD Sensitive Device!
This symbol and title inform that the electronic boards and their components are sensitive
to static electricity. Care must therefore be taken during all handling operations and
inspections of this product in order to ensure product integrity at all times.
HOT Surface!
Do NOT touch! Allow to cool before servicing.
Laser!
This symbol inform of the risk of exposure to laser beam and light emitting devices (LEDs)
from an electrical device. Eye protection per manufacturer notice shall review before
servicing.
This symbol indicates general information about the product and the user guide.
This symbol also indicates detail information about the specific product configuration.
This symbol precedes helpful hints and tips for daily use.

ECX-BYT – User Guide, Rev. 1.0
www.kontron.com // 7
For Your Safety
Your new Kontron product was developed and tested carefully to provide all features necessary to ensure its
compliance with electrical safety requirements. It was also designed for a long fault-free life. However, the life
expectancy of your product can be drastically reduced by improper treatment during unpacking and installation.
Therefore, in the interest of your own safety and of the correct operation of your new Kontron product, you are
requested to conform with the following guidelines.
High Voltage Safety Instructions
As a precaution and in case of danger, the power connector must be easily accessible. The power connector is the
product’s main disconnect device.
Warning
All operations on this product must be carried out by sufficiently skilled personnel only.
Electric Shock!
Before installing a non hot-swappable Kontron product into a system always ensure that
your mains power is switched off. This also applies to the installation of piggybacks. Serious
electrical shock hazards can exist during all installation, repair, and maintenance operations
on this product. Therefore, always unplug the power cable and any other cables which
provide external voltages before performing any work on this product.
Earth ground connection to vehicle’s chassis or a central grounding point shall remain
connected. The earth ground cable shall be the last cable to be disconnected or the first
cable to be connected when performing installation or removal procedures on this product.
Special Handling and Unpacking Instruction
ESD Sensitive Device!
Electronic boards and their components are sensitive to static electricity. Therefore, care
must be taken during all handling operations and inspections of this product, in order to
ensure product integrity at all times.
Do not handle this product out of its protective enclosure while it is not used for operational purposes unless it is
otherwise protected.
Whenever possible, unpack or pack this product only at EOS/ESD safe work stations. Where a safe work station is not
guaranteed, it is important for the user to be electrically discharged before touching the product with his/her hands
or tools. This is most easily done by touching a metal part of your system housing.
It is particularly important to observe standard anti-static precautions when changing piggybacks, ROM devices,
jumper settings etc. If the product contains batteries for RTC or memory backup, ensure that the product is not placed
on conductive surfaces, including anti-static plastics or sponges. They can cause short circuits and damage the
batteries or conductive circuits on the product.

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 8
Lithium Battery Precautions
If your product is equipped with a lithium battery, take the following precautions when replacing the battery.
Danger of explosion if the battery is replaced incorrectly.
Replace only with same or equivalent battery type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
General Instructions on Usage
In order to maintain Kontron’s product warranty, this product must not be altered or modified in any way. Changes or
modifications to the product, that are not explicitly approved by Kontron and described in this user guide or received
from Kontron Support as a special handling instruction, will void your warranty.
This product should only be installed in or connected to systems that fulfill all necessary technical and specific
environmental requirements. This also applies to the operational temperature range of the specific board version
that must not be exceeded. If batteries are present, their temperature restrictions must be taken into account.
In performing all necessary installation and application operations, only follow the instructions supplied by the
present user guide.
Keep all the original packaging material for future storage or warranty shipments. If it is necessary to store or ship
the product then re-pack it in the same manner as it was delivered.
Special care is necessary when handling or unpacking the product. See Special Handling and Unpacking Instruction.
Quality and Environmental Management
Kontron aims to deliver reliable high-end products designed and built for quality, and aims to complying with
environmental laws, regulations, and other environmentally oriented requirements. For more information regarding
Kontron’s quality and environmental responsibilities, visit http://www.kontron.com/about-kontron/corporate-
responsibility/quality-management.
Disposal and Recycling
Kontron’s products are manufactured to satisfy environmental protection requirements where possible. Many of the
components used are capable of being recycled. Final disposal of this product after its service life must be
accomplished in accordance with applicable country, state, or local laws or regulations.
WEEE Compliance
The Waste Electrical and Electronic Equipment (WEEE) Directive aims to:
Reduce waste arising from electrical and electronic equipment (EEE)
Make producers of EEE responsible for the environmental impact of their products, especially when the product
become waste
Encourage separate collection and subsequent treatment, reuse, recovery, recycling and sound environmental
disposal of EEE
Improve the environmental performance of all those involved during the lifecycle of EEE
Environmental protection is a high priority with Kontron.
Kontron follows the WEEE directive
You are encouraged to return our products for proper disposal.

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 9
Table of Contents
Symbols.................................................................................................................................................................................................................6
For Your Safety ...................................................................................................................................................................................................7
High Voltage Safety Instructions ..................................................................................................................................................................7
Special Handling and Unpacking Instruction ............................................................................................................................................7
Lithium Battery Precautions.......................................................................................................................................................................... 8
General Instructions on Usage..................................................................................................................................................................... 8
Quality and Environmental Management................................................................................................................................................ 8
Disposal and Recycling.................................................................................................................................................................................... 8
WEEE Compliance.............................................................................................................................................................................................. 8
Table of Contents...............................................................................................................................................................................................9
List of Tables .....................................................................................................................................................................................................10
List of Figures.....................................................................................................................................................................................................11
1/ Introduction .........................................................................................................................................................................................13
2/ Installation Procedures ...................................................................................................................................................................14
2.1. Installing the Board ..................................................................................................................................................................................14
2.2. Chassis Safety Standards......................................................................................................................................................................15
2.3. Lithium Battery Replacement ..............................................................................................................................................................15
3/ System Specifications......................................................................................................................................................................17
3.1. System Block Diagram.............................................................................................................................................................................17
3.2. Component Main Data ............................................................................................................................................................................18
3.3. Environmental Conditions .....................................................................................................................................................................19
3.4. Standards and Certifications................................................................................................................................................................19
3.5. Processor Support...................................................................................................................................................................................20
3.6. System Memory Support......................................................................................................................................................................20
3.6.1. Memory Operating Frequencies ......................................................................................................................................................20
3.7. On-board Graphics Subsystem............................................................................................................................................................21
3.8. Power Supply.............................................................................................................................................................................................21
4/ Connector Locations ........................................................................................................................................................................22
4.1. Top Side.......................................................................................................................................................................................................22
4.2. Rear Side ....................................................................................................................................................................................................24
4.3. Connector Panel Side ............................................................................................................................................................................. 25
5/ Connector Definitions......................................................................................................................................................................26
6/ I/O-Area Connectors........................................................................................................................................................................ 27
6.1. HDMI Connector (HDMI1) ....................................................................................................................................................................... 27
6.2. VGA Connector (VGA1)............................................................................................................................................................................28
6.3. Ethernet Connectors (LAN1 & LAN2) ................................................................................................................................................ 29
6.4. USB Connectors (I/O Area)...................................................................................................................................................................30
7/ Internal Connectors .........................................................................................................................................................................32
7.1. Power Connector ......................................................................................................................................................................................32
7.1.1. Power Input Wafer (CN1)..................................................................................................................................................................... 32
7.1.2. CR2032 Battery Power Input Wafer (BAT1)..................................................................................................................................32
7.2. DC5V Fan Wafer (FAN1) .........................................................................................................................................................................33
7.3. SATA (Serial ATA) Disk Interfaces (SATA1)......................................................................................................................................34
7.4. HDD Power Output Wafer (CN3)......................................................................................................................................................... 35
7.5. USB Connectors (Internal) (CN15, CN16) .......................................................................................................................................... 36
7.6. Speaker Connector (CN11 & CN12)......................................................................................................................................................38

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 10
7.7. Audio Connector (CN9)...........................................................................................................................................................................38
7.8. Front Panel Pin Header (FP1 & FP2) .................................................................................................................................................. 39
7.9. Serial COM1 - COM6 Ports (COM1 - COM6).......................................................................................................................................41
7.10. LVDS Flat Panel Connector (LVDS1).................................................................................................................................................42
7.11. Backlight Power Output Wafer (CN14)............................................................................................................................................44
7.12. Digital Input / Output Wafer (CN13).................................................................................................................................................45
7.13. mPCIe Slot Connector (MPCIE1).........................................................................................................................................................46
7.14. SIM Interface Wafer for MPCIE1 (CN10)..........................................................................................................................................48
7.15. mSATA Socket (MSATA1) .....................................................................................................................................................................49
7.16. PS/2 Keyboard and Mouse Wafer (CN2).........................................................................................................................................51
7.17. Switches and Jumpers.......................................................................................................................................................................... 52
7.17.1. RTC Reset Selection (JP1) .................................................................................................................................................................. 52
7.17.2. MPCIE1 Activity LED Indication (JP2)............................................................................................................................................. 53
7.17.3. Backlight Enable Selection for LVDS1 (JP4)................................................................................................................................ 53
7.17.4. Panel & Backlight Power Selection for LVDS1 (JP5)................................................................................................................ 53
7.17.5. USB Power Selection (JP6)...............................................................................................................................................................54
7.17.6. AT / ATX Power Mode Selection (JP7) .........................................................................................................................................54
7.17.7. ME F/W Selection (JP8)..................................................................................................................................................................... 55
8/ On-Board Connectors & Mating Connector Types ............................................................................................................... 56
9/ BIOS.........................................................................................................................................................................................................57
9.1. Starting the uEFI BIOS..............................................................................................................................................................................57
9.2. Setup Menus .............................................................................................................................................................................................58
9.2.1. Main Setup Menu..................................................................................................................................................................................58
9.2.2. Advanced Setup Menu........................................................................................................................................................................60
9.2.3. Power Setup Menu ..............................................................................................................................................................................74
9.2.4. Boot Setup Menu.................................................................................................................................................................................. 76
9.2.5. Security Setup Menu............................................................................................................................................................................77
9.2.5.1. Remember the password ...............................................................................................................................................................78
9.2.6. Save & Exit Setup Menu..................................................................................................................................................................... 79
Appendix A: List of Acronyms.....................................................................................................................................................................80
About Kontron ...................................................................................................................................................................................................81
List of Tables
Table 1: Component Main Data ....................................................................................................................................................................18
Table 2: Environmental Conditions ............................................................................................................................................................19
Table 3: Standards and Certifications .......................................................................................................................................................19
Table 4: Processor Support..........................................................................................................................................................................20
Table 5: Memory Operating Frequencies ................................................................................................................................................20
Table 6: Two-displays Configurations ......................................................................................................................................................21
Table 7: Supply Voltages................................................................................................................................................................................21
Table 8: Jumper List........................................................................................................................................................................................22
Table 9: Top Side Internal Connector Pin Assignment........................................................................................................................22
Table 10: Rear Side Internal Connector Pin Assignment ....................................................................................................................24
Table 11: Connector Panel Side Connector List ...................................................................................................................................... 25
Table 12: Pin Assignment HDMI Connector HDMI1 ............................................................................................................................... 27
Table 13: Pin Assignment DP Connector VGA1 .......................................................................................................................................28
Table 14: Pin Assignment Ethernet Connectors CN11, CN12 ..............................................................................................................29
Table 15: Pin Assignment USB2.0 Connector CN6.................................................................................................................................30
Table 16: Pin Assignment USB3.0 Connector USB1...............................................................................................................................30
Table 17: Signal Description ..........................................................................................................................................................................31

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 11
Table 18: Pin Assignment CN2.....................................................................................................................................................................32
Table 19: Pin Assignment BAT1 ...................................................................................................................................................................32
Table 20: Pin Assignment FAN1 ..................................................................................................................................................................33
Table 21: Signal description .........................................................................................................................................................................33
Table 22: Pin Assignment SATA1 ................................................................................................................................................................34
Table 23: Signal Description ........................................................................................................................................................................34
Table 24: Pin Assignment CN3 .................................................................................................................................................................... 35
Table 25: Pin Assignment CN15...................................................................................................................................................................36
Table 26: Pin Assignment CN16................................................................................................................................................................... 36
Table 27: Signal Description.........................................................................................................................................................................36
Table 28: Pin Assignment CN11, CN12 .......................................................................................................................................................38
Table 29: Pin Assignment CN8 ....................................................................................................................................................................38
Table 30: Pin Assignment FP1......................................................................................................................................................................39
Table 31: Signal Description.........................................................................................................................................................................39
Table 32: Pin Assignment FP2.....................................................................................................................................................................40
Table 33: Signal Description ........................................................................................................................................................................40
Table 34: Pin Assignment COM1, COM2 ....................................................................................................................................................41
Table 35: Pin Assignment COM3 - COM6 ..................................................................................................................................................41
Table 36: Signal Description ........................................................................................................................................................................42
Table 37: Pin Assignment LVDS1.................................................................................................................................................................42
Table 38: Signal Description ........................................................................................................................................................................43
Table 39: Pin Assignment CN16...................................................................................................................................................................44
Table 40: Signal Description........................................................................................................................................................................44
Table 41: Pin Assignment FP2......................................................................................................................................................................45
Table 42: Pin Assignment MPCIE1..............................................................................................................................................................46
Table 43: Pin Assignment CN10 ..................................................................................................................................................................48
Table 44: Pin Assignment MSATA1 ............................................................................................................................................................49
Table 45: Pin Assignment CN2 .....................................................................................................................................................................51
Table 46: Signal Description.........................................................................................................................................................................51
Table 47: Pin Assignment JP1....................................................................................................................................................................... 52
Table 48: Pin Assignment JP2 ..................................................................................................................................................................... 53
Table 49: Pin Assignment JP4 ..................................................................................................................................................................... 53
Table 44: Pin Assignment JP5......................................................................................................................................................................54
Table 51: Pin Assignment JP6.......................................................................................................................................................................54
Table 52: Pin Assignment JP7 ......................................................................................................................................................................54
Table 53: Pin Assignment JP8...................................................................................................................................................................... 55
Table 54: On-Board Connectors & Mating Connector Types ........................................................................................................... 56
Table 55: Font Size Table ...............................................................................................................................................................................57
Table 56: Main Setup Menu Sub-Screens and Functions ..................................................................................................................58
Table 57: List of Acronyms ...........................................................................................................................................................................80
List of Figures
Figure 1: System Block Diagram ECX-BYT ................................................................................................................................................17
Figure 2: Top Side ............................................................................................................................................................................................22
Figure 3: Rear Side...........................................................................................................................................................................................24
Figure 4: Connector Panel Side................................................................................................................................................................... 25
Figure 5: HDMI Connector HDMI1................................................................................................................................................................ 27
Figure 6: VGA Connector VGA1.....................................................................................................................................................................28
Figure 7: Ethernet Connectors LAN1, LAN2 .............................................................................................................................................29
Figure 8: USB 2.0 Connector CN6 ...............................................................................................................................................................30
Figure 9: USB 3.0 Connector USB1..............................................................................................................................................................30
Figure 10: USB 2.0 High Speed Cable..........................................................................................................................................................31
Figure 11: USB 3.0 High Speed Cable...........................................................................................................................................................31
Figure 12: Power Input Wafer CN1..............................................................................................................................................................32
Figure 13: CR2032 Battery Power Input Wafer BAT1 ........................................................................................................................... 32

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 12
Figure 14: DC5V Fan Wafer FAN1 ................................................................................................................................................................33
Figure 15: SATA Connector SATA1...............................................................................................................................................................34
Figure 16: HDD Power Output Wafer CN3................................................................................................................................................ 35
Figure 17: USB 2.0 Port Wafer CN15...........................................................................................................................................................36
Figure 18: USB 2.0 Port 8, 9 Pin Header CN16 .........................................................................................................................................36
Figure 19: 3W Audio AMP Output Wafer CN11 (Right Channel), CN12 (Left Channel)................................................................38
Figure 20: Audio Input / Output Pin Header CN9...................................................................................................................................38
Figure 21: Front Panel Pin Header FP1 ......................................................................................................................................................39
Figure 22: Front Panel Pin Header FP2.....................................................................................................................................................39
Figure 23: Serial COM COM1 - COM6 ..........................................................................................................................................................41
Figure 24: LVDS Connector LVDS1..............................................................................................................................................................42
Figure 25: Backlight Power Output Wafer CN14....................................................................................................................................44
Figure 26: Digital Input / Output Wafer CN5...........................................................................................................................................45
Figure 27: mPCIe Slot Connector MPCIE1.................................................................................................................................................46
Figure 28: SIM Interface Wafer CN10........................................................................................................................................................48
Figure 29: Serial ATA Port-1 mSATA Socket MSATA1...........................................................................................................................49
Figure 30: PS/2 Keyboard / Mouse Wafer CN2......................................................................................................................................51
Figure 31: Jumper Connector........................................................................................................................................................................ 52
Figure 32: RTC Reset Selection (JP1).......................................................................................................................................................... 52
Figure 33: MPCIE1 Activity LED Indication JP2 ........................................................................................................................................ 53
Figure 34: Backlight Enable Selection JP4............................................................................................................................................... 53
Figure 35: Panel & Backlight Power Selection JP5 ............................................................................................................................... 53
Figure 36: USB Power Selection JP6..........................................................................................................................................................54
Figure 37: AT / ATX Power Mode Selection JP7.....................................................................................................................................54
Figure 38: ME F/W Selection JP8 ............................................................................................................................................................... 55
Figure 39: BIOS Main Menu Screen System Data and Time .............................................................................................................. 59
Figure 40: BIOS Advanced Menu .................................................................................................................................................................61
Figure 41: BIOS Advanced Menu - Display Configuration...................................................................................................................62
Figure 42: BIOS Advanced Menu - Super IO Configuration................................................................................................................64
Figure 43: BIOS Advanced Menu - Super IO Configuration - Serial Port 1 Configuration ........................................................64
Figure 44: BIOS Advanced Menu - Super IO Configuration - Serial Port 2 Configuration ....................................................... 65
Figure 45: BIOS Advanced Menu - Super IO Configuration - Serial Port 3 Configuration........................................................ 66
Figure 46: BIOS Advanced Menu - Super IO Configuration - Serial Port 4 Configuration ....................................................... 66
Figure 47: BIOS Advanced Menu - Super IO Configuration - Serial Port 5 Configuration........................................................ 67
Figure 48: BIOS Advanced Menu - Super IO Configuration - Serial Port 6 Configuration .......................................................68
Figure 49: BIOS Advanced Menu - CPU Chipset Configuration......................................................................................................... 69
Figure 50: BIOS Advanced Menu - SATA Configuration ...................................................................................................................... 70
Figure 51: BIOS Advanced Menu - USB Configuration...........................................................................................................................71
Figure 52: BIOS Advanced Menu - DIO Configuration.......................................................................................................................... 72
Figure 53: BIOS Advanced Menu - H/W Monitor................................................................................................................................... 73
Figure 54: BIOS Power Setup Menu...........................................................................................................................................................74
Figure 55: BIOS Power Setup Menu - WatchDog Timer Configuration...........................................................................................75
Figure 56: BIOS Boot Setup Menu............................................................................................................................................................... 76
Figure 57: BIOS Boot Setup Menu................................................................................................................................................................77
Figure 58: BIOS Boot Setup Menu .............................................................................................................................................................. 79

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 13
1/ Introduction
This user guide describe the ECX-BYT board made by Kontron. This board will also be denoted ECX-BYT within this
user guide.
Use of this user guide implies a basic knowledge of PC-AT hardware and software. This user guide focuses on
describing the ECX-BYT board's special features and is not intended to be a standard PC-AT textbook.
New users are recommended to study the short installation procedure stated in the following chapter before
switching on the power.
All configuration and setup of the CPU board is either carried out automatically or manually by the user via the BIOS
setup menus.
Latest revision of this user guide, datasheet, thermal simulations, BIOS, drivers, BSP's (Board Support Packages),
mechanical drawings (2D and 3D) can de download from Kontron's Web Page.

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 14
2/ Installation Procedures
2.1. Installing the Board
ESD Sensitive Device
Electrostatic discharge (ESD) can damage equipment and impair electrical circuitry.
Wear ESD-protective clothing and shoes
Wear an ESD-preventive wrist strap attached to a good earth ground
Check the resistance value of the wrist strap periodically (1 MΩ to 10 MΩ)
Transport and store the board in its antistatic bag
Handle the board at an approved ESD workstation
Handle the board only by the edges
To get the board running follow these steps. If the board shipped from KONTRON already has components like RAM
and CPU cooler mounted, then skip the relevant steps below.
1. Turn off the PSU (Power Supply Unit)
Turn off PSU (Power Supply Unit) completely (no mains power connected to the PSU) or
leave the Power Connectors unconnected while configuring the board. Otherwise,
components (RAM, LAN cards etc.) might get damaged. Make sure to use +12 V DC single
supply only. Alternatively, use a standard ATX PSU with suitable cable kit and PS-ON#
active.
2. Insert the DDR3L 1333 / 1067 module(s)
Be careful to push the memory module in the slot(s) before locking the tabs.
3. Connecting interfaces
Insert all external cables for hard disk, keyboard etc. A monitor must be connected in order to change BIOS
settings.
4. Connect and turn on PSU
Connect PSU to the board by the +12 V 3.0mm pitch 1x4-pin wafer connector.
5. BIOS setup
Enter the BIOS setup by pressing the <DEL> key during boot up.
Enter "Exit Menu" and Load Setup Defaults.
To clear all BIOS setting, including Password protection, activate "Clear CMOS Jumper"
for 10 sec (without power connected).
6. Mounting the board in chassis
When mounting the board to chassis etc. please note that the board contains
components on both sides of the PCB that can easily be damaged if board is handled
without reasonable care. A damaged component can result in malfunction or no
function at all.

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 15
When fixing the board on a chassis, it is recommended to use screws with an integrated washer and a diameter
of > 7 mm. Do not use washers with teeth, as they can damage the PCB and cause short circuits.
2.2. Chassis Safety Standards
Before installing the ECX-BYT in the chassis, users must evaluate the end product to ensure compliance with the
requirements of the IEC60950-1 safety standard:
The board must be installed in a suitable mechanical, electrical and fire enclosure.
The system, in its enclosure, must be evaluated for temperature and airflow considerations.
The board must be powered by a CSA or UL approved power supply that limits the maximum input current.
For interfaces having a power pin such as external power or fan, ensure that the connectors and wires are
suitably rated. All connections from and to the product shall be with SELV circuits only.
Wires have suitable rating to withstand the maximum available power.
The peripheral device enclosure fulfils the IEC60950-1 fire protecting requirements.
2.3. Lithium Battery Replacement
If replacing the lithium battery follow the replacement precautions stated in the notification below:
Danger of explosion if the lithium battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the manufacturer
Dispose of used batteries according to the manufacturer's instructions
VORSICHT! Explosionsgefahr bei unsachgemäßem Austausch der Batterie.
Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleichwertigen Typ
Entsorgung gebrauchter Batterien nach Angaben des Herstellers
ATTENTION! Risque d'explosion avec l'échange inadéquat de la batterie.

Remplacement seulement par le même ou un type équivalent recommandé par le
producteur
L'évacuation des batteries usagées conformément à des indications du fabricant
PRECAUCION! Peligro de explosión si la batería se sustituye incorrectamente.
Sustituya solamente por el mismo o tipo equivalente recomendado por el fabricante
Disponga las baterías usadas según las instrucciones del fabricante
ADVARSEL! Lithiumbatteri – Eksplosionsfare ved fejlagtig håndtering.
Udskiftning må kun ske med batteri af samme fabrikat og type
Levér det brugte batteri tilbage til leverandøren
ADVARSEL! Eksplosjonsfare ved feilaktig skifte av batteri.
Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten
Brukte batterier kasseres i henhold til fabrikantens instruksjoner
VARNING! Explosionsfara vid felaktigt batteribyte.

Använd samma batterityp eller en ekvivalent typ som rekommenderas av
apparattillverkaren
Kassera använt batteri enligt fabrikantens instruktion
VAROITUS! Paristo voi räjähtää, jos se on virheellisesti asennettu.
Vaihda paristo ainoastaan lalteval- mistajan suosittelemaan tyyppiln
Hävitä käytetty paristo valmistajan ohjeiden mukaisesti

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 16

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 17
3/ System Specifications
3.1. System Block Diagram
Figure 1: System Block Diagram ECX-BYT

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 18
3.2. Component Main Data
The table below summarizes the features of the ECX-BYT single board computer.
Table 1: Component Main Data
System
Processor Intel® Bay Trail SoC Processors
Memory 1x DDR3L SO-DIMM memory socket
Video
Display Interface 1x LVDS (24-bit, 2-ch)
1x HDMI (on rear, 1920 x 1080 @ 60 Hz)
1x VGA (on rear, 2560 x 1600 @ 60 Hz)
Multiple Display Dual
Audio
Audio Codec Realtek ALC662
Audio Interface 2x Speaker-out (3 W)
1x Line-in (by header)
1x Line-out (by header)
1x Mic-in (by header)
Network Connection
Ethernet 2x GbE LAN (RJ45 on rear, 1x Intel® I210-AT, 1x Realtek RTL8111G)
Peripheral Connection
USB 1x USB 3.0 (Type A on rear)
5x USB 2.0 (2x Type A on rear, 3x by header)
Serial Port 2x RS232/422/485 (by header)
4x RS232 (by header)
Other I/Os 1x PS/2 Keyboard / Mouse (by header)
1x 8-bit DIO (by header)
Storage & Expansion
Storage &
Expansion
1x SATA
1x mPCIe (full size)
1x mPCIe (full size)
1x SIM Card Cage (by wafer)
Power
Input Voltage DC 12 V
Connector 1x4-pin Lockable Wafer
Firmware
BIOS AMI uEFI BIOS w/ 64 Mb SPI Flash
Watchdog Programmable WDT to generate system reset event
H/W Monitor Voltages, Temperatures
Real Time Clock SoC integrated RTC
TPM Optional for models with Atom™ E3845 (Infineon SLB 9660 TPM 1.2)
System Control & Monitoring

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 19
FP Header 1x Header for Reset button, HDD LED & External Speaker
1x Header for Power button, Power LED & SM bus
1x Header for mPCIe activity LED
Cooling
FAN 1x Wafer for CPU Smart Fan
Software
OS Support Windows 7, Windows 8, Linux
Mechanical
Dimension (L x W) 3.5" ECX (146 x 105 mm / 5.75" x 4.13")
3.3. Environmental Conditions
The ECX-BYT is compliant with the following environmental conditions. It is the customer's responsibility to provide
sufficient airflow around each of the components to keep them within the allowed temperature range.
Table 2: Environmental Conditions
Operating Temperature 0 °C ~ 60 °C / 32 °F ~ 140 °F (Standard)
-20 °C ~ 70 °C / -4 °F ~ 158 °F (Extended)
Storage Temperature -20 °C ~ 80 °C / -4 °F ~ 176 °F (Standard)
-40 °C ~ 85 °C / -40 °F ~ 185 °F (Extended)
Humidity 0 % ~ 95 %
3.4. Standards and Certifications
The ECX-BYT meets the following standards and certification tests.
Table 3: Standards and Certifications
CE EN 55032: 2015 + AC: 2016, CISPR 32: 2015 + COR1: 2016
AS/NZS CISPR 32: 2015
EN 61000-3-2: 2014, IEC 61000-3-2: 2014
EN 61000-3-3: 2013, IEC 61000-3-3: 2013
EN 55024: 2010 + A1: 2015, CISPR 24: 2010 + A1: 2015
EN 61000-4-2: 2009, IEC 61000-4-2: 2008
EN 61000-4-3: 2006 + A1: 2008 + A2: 2010, IEC 61000-4-
3: 2006 + A1: 2007, + A2:
2010
EN 61000-4-4: 2012, IEC 61000-4-4: 2012
EN 61000-4-5: 2014, IEC 61000-4-5: 2014
EN 61000-4-6: 2014 + AC: 2015, IEC 61000-4-6: 2013
EN 61000-4-8: 2010, IEC 61000-4-8: 2009
EN 61000-4-11: 2004, IEC 61000-4-11: 2004
FCC FCC CFR Title 47 Part 15 Subpart B: 2016 - Section 15.107 and 15.109
ANSI C63.4-2014
ICES-003 Issue 6: 2016 Class A

ECX-BYT - User Guide, Rev. 1.0
www.kontron.com // 20
3.5. Processor Support
The ECX-BYT is designed to support Intel® Bay Trail SoC Processors. The BGA CPU is remounted from factory. Kontron
has defined the board versions as listed in the following table, so far all based on Embedded CPUs. Other versions are
expected at a later date.
Table 4: Processor Support
Name Core # Speed Turbo Embedded Cache Socket TDP Tj
Celeron® J1900 4 2.00 GHz 2.42 GHz Yes 2M FCBGA1170 10 W 105 °C
Atom™ E3845 4 1.91 GHz - Yes 2M FCBGA1170 10 W -40 °C ~ 110 °C
Atom™ E3825 2 1.33 GHz - Yes 1M FCBGA1170 6 W -40 °C ~ 110 °C
Celeron® N2807 2 1.58 GHz 2.16 GHz Yes 1M FCBGA1170 4.3 W 105 °C
Sufficient cooling must be applied to the CPU in order to remove the effect as listed as TDP (Thermal Design Power) in
above table. The sufficient cooling is also depending on the worst case maximum ambient operating temperature and
the actual worst case load of processor.
3.6. System Memory Support
The ECX-BYT has one DDR3L SO-DIMM socket. The sockets support the following memory features:
1x DDR3L SO-DIMM 204-pin
Up to 4GB (for model with Celeron® N2807)
Up to 8GB (for other models)
SPD timing supported
ECC not supported
The installed DDR3L SO-DIMM should support the Serial Presence Detect (SPD) data structure. This allows the BIOS to
read and configure the memory controller for optimal performance. If non-SPD memory is used, the BIOS will attempt
to configure the memory settings, but performance and reliability may be impacted, or the board may not be able to
boot totally.
3.6.1. Memory Operating Frequencies
In all modes, the frequency of system memory is the lowest frequency of all the memory modules placed in the
system. Each memory module's frequency can be determined through the SPD registers on the memory modules.
The table below lists the resulting operating memory frequencies based on the combination of SO-DIMMs and
processor.
Table 5: Memory Operating Frequencies
SO-DIMM Type Module Name Memory Data
Transfer (MT/s)
Processor System
Bus Frequency
(MHz)
Resulting
Memory Clock
Frequency (MHz)
Peak Transfer
Rate (MB/s)
DDR3L 1067 PC3-8500 1067 533 133 8533
DDR3L 1333 PC3-10600 1333 667 167 10667
