Kontron MOPSlcd6 User manual

p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 1of 42
MOPSlcd6
Technical Manual
Rev. 1.5
JUMPtec
Industrielle Computertechnik AG
Brunnwiesenstraße 16
94469 Deggendorf/ Germany Document part number:
Document name: < p588m114>

MOPSlcd6 Table of Contents
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 2of 42
1. TABLE OF CONTENTS
1. TABLE OF CONTENTS ........................................................................................................................................ 2
2. USER INFORMATION........................................................................................................................................... 4
2.1 Trademarks .............................................................................................................................................. 4
2.2 General..................................................................................................................................................... 4
2.3 Warranty................................................................................................................................................... 4
2.4 Support, problems and failure analysis.................................................................................................... 5
3. INTRODUCTION .................................................................................................................................................. 6
4. FEATURES......................................................................................................................................................... 7
5. I/O MAP............................................................................................................................................................ 8
6. BLOCK DIAGRAM............................................................................................................................................... 9
7. CONNECTOR ARRANGEMENT ........................................................................................................................... 10
8. BIOS-DESCRIPTION ........................................................................................................................................ 11
8.1 The Setup Guide..................................................................................................................................... 11
8.2 Boot Utilities............................................................................................................................................ 21
8.3 BIOS Update with Phoenix Phlash......................................................................................................... 22
8.4 Boot Block Support................................................................................................................................. 23
9. HARDWARE DESCRIPTION................................................................................................................................ 24
9.1 ALI-Chipset Features.............................................................................................................................. 24
9.2 Memory configuration............................................................................................................................. 24
9.3 Interrupts................................................................................................................................................. 24
9.4 DMA........................................................................................................................................................ 25
9.5 Onboard C&T VGA................................................................................................................................. 26
9.6 Watchdog Extension............................................................................................................................... 28
10. THE JIDA STANDARD...................................................................................................................................... 29
11. NETWORK OPERATION..................................................................................................................................... 32
11.1 Overview............................................................................................................................................. 32
11.2 Configuration 82559ER...................................................................................................................... 32
11.3 Software and driver setup................................................................................................................... 33
11.4 Ethernet Technical Support................................................................................................................ 33
12. SPECIFICATIONS.............................................................................................................................................. 34
12.1 Mechanical Specifications.................................................................................................................. 34
12.2 Electrical Specifications...................................................................................................................... 34
12.3 Environmental Specifications ............................................................................................................. 34
13. PERIPHERAL INTERFACE.................................................................................................................................. 35
13.1 Keyboard, Reset, Battery, Speaker.................................................................................................... 35
13.2 Serial Port COM A, B RS232C........................................................................................................... 36
13.3 Parallel Port LPT 1 ............................................................................................................................. 37
13.4 Floppy Connector ............................................................................................................................... 37
13.5 IDE Connector for 2,5" Hard Disk....................................................................................................... 38
13.6 Ethernet Connector ............................................................................................................................ 38
13.7 CRT Connector................................................................................................................................... 38
13.8 USB Connector................................................................................................................................... 39
13.9 Power Connector................................................................................................................................ 39
13.10 PC/104-Connector.............................................................................................................................. 40
14. LITERATURE, STANDARDS, LINKS.................................................................................................................... 41
14.1 PC/104-Bus ........................................................................................................................................ 41

MOPSlcd6 Table of Contents
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 3of 42
14.2 ISA-Bus, Standard PS/2 - Connectors............................................................................................... 41
14.3 RS232C.............................................................................................................................................. 41
14.4 ATA..................................................................................................................................................... 41
14.5 USB .................................................................................................................................................... 41
14.6 PCI...................................................................................................................................................... 41
15. DOCUMENT REVISION HISTORY........................................................................................................................ 42

MOPSlcd6 User Information
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 4of 42
2. USER INFORMATION
Copyright 1999 JUMPtec®Industrielle Computertechnik AG.
In this document JUMPtec®Industrielle Computertechnik AG will also be referred to by the short form
"JUMPtec®".
The information in this document has been carefully checked and is believed to be accurate and
reliable. However, no responsibility is assumed for inaccuracies. Furthermore, JUMPtec®reserves the
right to make changes to any portion of this manual to improve reliability, function or design.
JUMPtec®does not assume any liability for any product or circuit described herein.
2.1 Trademarks
AT and IBM are trademarks of International Business Machines
XT, AT, PS/2 and Personal System/2 are trademarks of International Business Machines Corporation.
Microsoft is a registered trademark of Microsoft Corporation.
Intel is a registered trademark of Intel Corporation.
All other products and trademarks mentioned in this manual are trademarks of their respective owners.
The reproduction, transmission or use of this document or its contents is not permitted without
expressed written authority.
Offenders will be liable for damages. All rights created by patent grant or registration of a utility model
or design, are reserved.
(C) JUMPtec®AG 1999
2.2 General
For the circuits, descriptions and tables indicated no responsibility is assumed as far as patents or
other rights of third parties are concerned.
The information in the Technical Descriptions describes the type of the boards and shall not be
considered as assured characteristics.
The reproduction, transmission or use of this document or its contents is not permitted without express
written authority. Offenders will be liable for damages. All rights, including rights created by patent
grant or registration of a utility model or design, are reserved.
(C) JUMPtec®AG 1999
2.3 Warranty
Each board is tested carefully and thoroughly before being shipped. If, however, problems should
occur during the operation, please check your user specific settings of all boards included in your
system. This is often the source of the fault. If a board is defective, it can be sent to your supplier for
repair. Please take care of the following steps:
1. The board returned should have the factory default settings since a test is only possible
with these settings.
2. In order to repair your board as fast as possible we require some additional information
from you. Please fill out the attached Repair Form and include it with the defective board.
3. If possible the board will be upgraded to the latest version without additional cost.
4. Upon receipt of the board please be aware that your user specific settings were changed
during the test.
Within the warranty period the repair is free of charge as long as the warranty conditions are
observed. Because of the high test expenditure you will be charged with the test cost if no fault is
found. Repair after the warranty period will be charged.

MOPSlcd6 User Information
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 5of 42
This JUMPtec®product is warranted against defects in material and workmanship for the warranty
period from the date of shipment. During the warranty period JUMPtec®will at its option either repair
or replace defective products.
For warranty service or repair the product must be returned to a service facility designated by
JUMPtec®.
The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance
or handling by buyer, unauthorized modification or misuse, operation outside of the product´s
environmental specifications or improper installation or maintenance.
JUMPtec®will not be responsible for any defects or damages to other products not supplied by
JUMPtec®that are caused by a faulty JUMPtec®product.
2.4 Support, problems and failure analysis
It is not in the responsibility of JUMPtecto supply you with informations about standard PC
technology. Please find a selection of different information sources for your convenience in
chapter „Literature“
Before contacting JUMPtecplease check first our web page for available information (newest
manuals, application notes etc.). If you can't solve the problem on your own with this documents, do
not hesitate to contact us by email or phone. Please prepare yourself to answer a few questions like
•which JUMPtecmodule(s) is(are) concerned?
•what serial numbers (xx???????)?
•what BIOS versions?
•since when is this problem known
•is this problem already reported (to whom?)
•and so on...
Note: You can save time and increase the problems solving process by using the FAReq.DOT form
from our web page www.jumptec.de for problem reports.

MOPSlcd6 Introduction
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 6of 42
3. INTRODUCTION
The MOPSlcd6 integrates the complete functionality of a pentium motherboard with CPU, System-
BIOS, up to 64 MByte SDRAM, keyboard-controller, real time clock, onboard high-performance PCI-
SVGA with LCD interface and additional peripheral functions like COM1, COM2, LPT1, Floppy-
interface, EIDE-harddisk-interface, watchdog and Ethernet access. The system runs with CPU clock
speed 166MHz and 266 MHz.

MOPSlcd6 Features
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 7of 42
4. FEATURES
•Processor
Intel Pentium®with 166 MHz internal Clock and 32 kByte write-back-Cache or
Intel Pentium®with 266 MHz internal Clock and 32 kByte write-back-Cache
•Chipset
ALI M1543C/M1531 PCI Chipset; extended temperature
•Power Supply
5V only supply
•Memory
32/64MB SDRAM-SODIMM-Module
•Ethernet 100BaseT (Twisted Pair)
•Two serial ports, (COM1 and COM2)
standard RS232C serial ports with FIFO, 16550 compatible
•Parallel port, LPT1
With ECP/EPP-support
•Floppy-interface
•EIDE-PCI-hard disk-interface
PCI Bus Master IDE port (up to 2 IDE Devices)
supports PIO Mode 3,4 IDE & ATAPI CD-ROM
supports JUMPtec CHIPdisk
•Watchdog
•128 KByte FLASH-BIOS (Phoenix)
•Real Time Clock
With external Battery-support
•Keyboard Controller
•Onboard C&T-VGA
•C&T 69000 LCD-VGA-Controller with PCI-Bus interface incl. Burst Mode support
•VGA-CRT and LCD Controller with integral 2 MByte Video RAM
•Resolution up to 1280x1024 on panel and CRT
•Color depths up to 16 millions of colors
•Simultaneous display on CRT and panel
•True 64-Bit Graphics engine and accelerator
•Powerful drivers for Win3.11, Win95, NT3.51, NT4.0, OS/2....
•plug and play panel interfacing on the upper SO-DIMM-Connector supports almost
any type of LCD

MOPSlcd6 I/O Map
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 8of 42
5. I/O MAP
The I/O-port addresses of the processor module MOPSlcd6 are functionally identical with a standard
PC/AT.
I/O Addresses MOPSlcd6 - onboard Function
0000 - 001F XDMA-Controller 1
0020 - 003F XInterrupt-Controller 1
0040 - 0043 XTimer
0050 - 005F Onboard Control Registers
0060 - 0064 XKeyboard-controller
0061 XPort B Register
0070 XNMI Enable Register
0070 - 0071 XReal Time Clock
0080 - 008F XDMA Page Register 74LS612
0092 XPort A Register (Fast A20 Gate)
00A0 - 00BF XInterrupt-Controller 2
00C0 - 00DF XDMA-Controller 2
00F0 - 00FF XMath-Coprocessor
0100 – 10F XOnboard Control Registers
01F0 - 01F8 XFixed Disk
0200 – 0207 Game I/O
020C-020D Reserved
021F Reserved
0274 Control Register 1 External SSD (Board 0 - 3)
0275 Control Register 1 External SSD (Board 4 - 7)
0278 – 027F Parallel Port 2
02B0 - 02DF Alternate Enhanced Graphics Adapter
02E1 GPIB (adapter 0)
02E2 - 02E3 Data acquisition (Adapter 0)
02E8 - 02EF Serial Port 4
02F8 - 02FF XSerial Port 2
0300 – 030F XOnboard Network (default configuration)
0310 – 031F Prototype Card
0360 – 0363 PC Network (low Address)
0364 – 0367 Reserved
0368 – 036B PC Network (high Address)
036C – 036F Reserved
0370 – 0377 Config. Space for second SMC Controller
0378 – 037F XParallel Port 1
0380 – 038F SDLC, Bisynchronous 2
0390 – 0393 Cluster
03A0 - 03AF Bisynchronous 1
03B0 - 03BF XMonochrom Disp. and Printer Adap.
03C0 - 03CF XEnhanced Graphic Adapter
03D0 - 03DF XColor/Graphic Monitor Adapter
03E8 - 03EF Serial Port 3
03F0 - 03F7 XDiskette Controller
03F8 - 03FF XSerial Port 1

MOPSlcd6 Block Diagram
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 9of 42
6. BLOCK DIAGRAM
CPU
SDRAM
ALI
Chipset
RTC
C&T PCI
VGA
EIDE
BIOS
IO-Con-
troller
Ethernet-
Con-
troller
COM1
COM2
LPT1
100/10baseT
PC/104plus
-Con.

MOPSlcd6 Connector Arrangement
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 10 of 42
7. CONNECTOR ARRANGEMENT

MOPSlcd6 BIOS-Description
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 11 of 42
8. BIOS-DESCRIPTION
The MOPS/lcd6 is equipped with a Phoenix BIOS which is located in a Flash EPROM onboard. This
device has 8bit wide access. Faster access (16bit) is provided by the shadow RAM feature (default).
8.1 The Setup Guide
With the PhoenixBIOS Setup programm, you can modify BIOS settings and control the special
features of the computer. The setup programm uses a number of menus for making changes and
turning the special features on or off.
General Information
To start the PhoenixBIOS setup utility press <F2> when the string Press <F2> to enter Setup is
displayed during bootup. The Main Menu will be displayed.
The Menu Bar
The Menu Bar at the top of the window lists all the different menus. Use the left/right arrows to make a
selection.
The Legend Bar
Use the keys listed in the legend bar on the bottom to make your selection or exit the current menu.
The table below describes the legend keys and their alternates:
Key Function
<F1> or <Alt-H> General help window
<Esc> Exit this menu
←or →Arrow key Select a different menu
↑or ↓Arrow key Move cursor up and down
<Tap> or <Shift-Tap> Cycle cursor up and down
<Home> or <End> Move cursor to top or bottom of current window
<PgUp> or <PgDn> Move cursor to next or previous page
<F5> or <-> Select the previous value for the current field
<F6> or <+> or <Space> Select the next value for the current field
<F9> Load default configuration values for this menu
<F10> Save and Exit
<Enter> Execute command or select submenu
<Alt-R> Refresh screen
To select an item, simply use the arrow key to move the cursor to the field you want. Then use the
plus and minus keys to select a value for that field. The Save Value commands in the Exit Menu save
the values currently displayed in all the menus.
To display a sup menu, use the arrow keys to move the cursor to the sub menu you want. Then
press <Enter>. A pointer (4) marks all sub menus.
The Field Help Window
The help window on the right side of each menu displays the help text for the currntly selected field. It
updates as you move the cursor to each field.
The General Help Window
Pressing <F1> or <Alt-F1> on any menu brings up the General Help Window that describes the
legend keys and their alternates. Press <Esc> to exit the General Help Window.

MOPSlcd6 BIOS-Description
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 12 of 42
The Main Menu
You can make the following selections on the Main Menu itself. Use the sub menus for other
selections.
Feature Option Description
System Time HH:MM:SS Set the system time. Use <Enter to move to
MM or SS.
System Date MM/DD/YYYY Set the system date. . Use <Enter to move to
DD or YYYY.
Legacy Diskette A 360 kB, 5 ¼ “
1.2 MB, 5 ¼ “
720 kB, 3 ½ “
1.44/1.25 MB, 3 ½ “
2.88 MB, 3 ½ “
Not Installed
Disabled
Select the type of floppy disk drive installed in
the system.
Legacy Diskette B See above
Disabled See above
8Primary Master autodetected drive Displays result of PM autotyping.
8Primary Slave autodetected drive Displays result of PS autotyping.
8Memory Shadow sub menu Opens Memory Shadow Menu
8Memory Cache sub menu Opens Memory Cache Menu
System Memory N/A Displays amount of conventional memory
detected during bootup.
Extended Memory N/A Displays amount of extendedmemory detected
during bootup.

MOPSlcd6 BIOS-Description
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 13 of 42
Selecting one of the Master or Slave sub menus displays a menu like this:
Feature Option Description
Type None
User
Auto
CD-ROM
None = Autotyping is not able to supply the
drive type or end user has selected None,
disabling any drive that may be installed.
User = End user supplies the hdd information.
Auto = Autotyping, the drive itself supplies the
information.
CD-RO = CD-ROM drive.
Cylinders 1 to 65,536 Number of cylinders.
Heads 1 to 256 Number of read/write heads.
Sectors 1 to 63 Number of sectors per track.
Maximum Capacity N/A Displays the calculated size of the drive
Multi-Sector Transfer Disabled
Standard
2 sectors
4 sectors
8 sectors
16 sectors
Any selection except Disabled determines the
number of sectors transferred per block.
Standard is 1 sector per block.
LBA Mode Control Disabled
Enabled Enabling LBA causes Logical Block
Addressing to be used in place of CHS.
32-Bit I/O Disabled
Enabled Enables 32-bit communication between CPU and IDE card. Requires PCI or Local Bus.
Transfer Mode Standard
Fast PIO 1
Fast PIO 2
Fast PIO 3
Fast PIO 4
Selects the method for transferring the data
between the hard disk and system memory.
SMART Device Monitoring Disabled
Enabled Enables SMART warnings of imminent failure of drive.
Memory Shadow sub menu:
Feature Option Description
C800 - CBFF Disabled
Enabled Accesses to this upper memory region go to the ISA bus if Disabled or to local memory if
Enabled.
NOTE: This option is not displayed if VGA
BIOS exceeds 32kB! In that case this region is
shadowed automatically.
CC00 - CFFF Disabled
Enabled Accesses to this upper memory region go to the ISA bus if Disabled or to local memory if
Enabled.
D000 – D3FF Disabled
Enabled see above.
D400 – D7FF Disabled
Enabled see above.
D800 - DBFF Disabled
Enabled see above.
DC00 - DFFF Disabled
Enabled see above.

MOPSlcd6 BIOS-Description
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 14 of 42
Memory Cache sub menu:
Feature Option Description
System BIOS Disabled
Enabled Caches the system BIOS to improve
performance.
Video BIOS Disabled
Enabled Caches the video BIOS to improve
performance.
C800 - CBFF Disabled
Enabled Controls caching of accesses to this upper memory region.
NOTE: this option is not displayed if VGA
BIOS exceeds 32k! In that case this region is
handled by the option video BIOS.
CC00 - CFFF Disabled
Enabled Controls caching of accesses to this upper memory region.
D000 – D3FF Disabled
Enabled see above.
D400 – D7FF Disabled
Enabled see above.
D800 - DBFF Disabled
Enabled see above.
DC00 - DFFF Disabled
Enabled see above.
The Advanced Menu
Selecting „Advanced“ from the menu bar displays this menu:
Feature Option Description
8Advanced Chipset Control sub menu Opens Advanced Chipset Control sub menu.
Plug & Play OS Yes
No If your system has a PNP OS (e.g. Win95) select Yes to let the OS configure PNP devices
not required for boot. No makes the BIOS
configure them.
Secured Setup Configuration** Yes
No Yes prevents a Plug and Play OS from
changing system settings.
Reset Configuration Data No
Yes Yes erases all configuration data in ESCD, which stores the configuration settings for
plug-in devices. Select Yes when required to
restore the manufacturer’s defaults.
8PCI Configuration sub menu Opens PCI Advanced sub menu.
8Keyboard Features sub menu Opens Keyboard Features sub menu.
8I/O Device Configuration sub menu Opens I/O Device Configuration sub menu.
Large Disk Access Mode DOS
Other Select DOS if you have DOS. Select Other if you have another OS such as UNIX.
A large disk is one that has more than 1024
cylinders, more than 16 heads or more than 63
sectors per track.
Halt On Errors* Yes
No Determines if post errors cause the system to halt.
*) P588R113 upwards, **) P588R116 upwards

MOPSlcd6 BIOS-Description
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 15 of 42
Advanced Chipset Control sub menu:
Feature Option Description
AT bus clock frequency 7.16 MHZ
PCICLK/4
PCICLK/3
Allows to select ISA bus clock frequency.
NOTE: Some ISA devices might not work at
PCICLK/3 (11 MHz)!
Passive Release Disabled
Enabled Enables more efficient ISA Bus master cycles
to PCI.
Delayed Transaction Disabled
Enabled Latches PCI-to-ISA cycles into buffer to free the PCI bus.
ISA Master Line Buffer Disabled
Enabled Enables ISA master line buffer to enhance
performance.
DMA Line Buffer Disabled
Enabled Enables DMA line buffer to enhance
performance.
PCI to ISA Posted Write Buffer Disabled
Enabled Enables PCI to ISA posted write buffer.
Enable Memory Gap ** Disabled
Conventional
Extended
Turns system RAM of and frees address space
(512kB-640kB or 15MB-16MB) for use with an
option card.
CAS Latency 2
3Select CAS Latency time.
SDRAM Timing * 3-6-9
3-5-8
3-4-7
2-5-7
Controls RAS pre-charge timing in HCLKIN’s.
tRP – tRAS – tRC
Pipe Function Disabled
Enabled Enables the asserting of NA (Next Address)
when the cycle is a L2 or DRAM access cycle.
Primary Frame Buffer Disable, 1 MB, 2 MB, 4 MB,
8 MB, 16 MB Select the size of the primary frame buffer and enables Host to PCI write buffer
VGA Frame Buffer Disabled
Enabled Enables burst PCI cycles for VGA fixed frame buffer at A0000h – BFFFFh.
Data Merge Disabled
Enabled If enabled, only the words which address are consecutive linear can be merged into one
line.
Byte Merge Disabled
Enabled Enables the byte-merge feature for frame buffer cycles
Fast Back to Back Disabled
Enabled Enables PCI fast back to back capability.
PCI Write Burst Disabled
Enabled Enables PCI write burst capability.
*) default changed for P588R115 (was 3-4-7), **) P588R116 upwards

MOPSlcd6 BIOS-Description
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 16 of 42
PCI Configuration sub menu:
Feature Option Description
8PCI Device, Slot #1 sub menu Opens sub menu to configure slot 1 PCI
device
8PCI Device, Slot #2 sub menu Opens sub menu to configure slot 2 PCI
device
8PCI Device, Slot #3 sub menu Opens sub menu to configure slot 3 PCI
device
8PCI Device, Slot #4 sub menu Opens sub menu to configure slot 4 PCI
device
PCI IRQ line 1 Disabled
Auto
IRQ3, 4, 5, 7, 9, 10, 11, 12,
14,15
Select IRQ for PIC interrupt INTA. Select Auto
to let the BIOS assign the IRQ.
PCI IRQ line 2 see above Select IRQ for PIC interrupt INTB. Select Auto
to let the BIOS assign the IRQ.
PCI IRQ line 3 see above Select IRQ for PIC interrupt INTC. Select Auto
to let the BIOS assign the IRQ.
PCI IRQ line 4 see above Select IRQ for PIC interrupt INTD. Select Auto
to let the BIOS assign the IRQ.
USB IRQ line* see above Select IRQ for embedded USB device. Select
Auto to let the BIOS assign the IRQ.
8PCI/PNP ISA UMB Region
Exclusion sub menu Opens UMB Region Exclusion sub menu.
8PCI/PNP ISA IRQ Resource
Exclusion sub menu Opens IRQ Exclusion sub menu.
ISA graphics device installed No
Yes PCI devices may need to know if an ISA graphics device is installed in the system in
order to enable that card to function correctly
Assign IRQ to PCI VGA Yes
No Actually the onboard vga does not need an IRQ assigned, but Win98 2nd Edition doesn‘t
work correctly if no IRQ is assigned
*) P588R113 upwards
NOTE: Use IRQ Miniport driver for ALI M1543C south bridge (download from www.ali.com.tw) on Sytems running Win95!

MOPSlcd6 BIOS-Description
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 17 of 42
PCI Device, Slot #X sub menu:
Feature Option Description
Option ROM Scan Disabled
Enabled Initialize device expansion ROM
Enable Master Disabled
Enabled Enables device in slot as a PCI bus master.
Not every device can function as a master.
Check your device documentation.
Latency Timer 20h, 40h, 60h, 80h, A0h, C0h,
E0h Minimum guaranteed time slice allocated for bus master in units of PCI bus clocks.
A high-priority, high-throughput device may
benefit from a greater value.
PCI/PNP ISA UMB Region Exclusion sub menu:
Feature Option Description
C800 - CBFF Available
Reserved Reserves the specified block of upper memory for use by legacy ISA devices.
CC00 - CFFF see above see above
D000 – D3FF see above see above
D400 – D7FF see above see above
D800 - DBFF see above see above
DC00 - DFFF see above see above
PCI/PNP ISA IRQ Exclusion sub menu:
Feature Option Description
IRQ3 Available
Reserved Reserves the specified IRQ for use by legacy ISA devices.
IRQ4 see above see above
IRQ5 see above see above
IRQ7 see above see above
IRQ9 see above see above
IRQ10 see above see above
IRQ11 see above see above
IRQ12 * see above see above
IRQ14 * (only visible if IDE disabled) see above see above
IRQ15 see above see above
*) P588R116 upwards
Keyboard Features sub menu:
Feature Option Description
Numlock Auto
On
Off
On or Off turns NumLock on or off at bootup.
Auto turns NumLock on if it finds a numeric
key pad.
Key Click Disabled
Enabled Turns audible key click on.
Keyboard auto-repeat rate 30/sec, 26.7/sec, 21.8/sec,
13.3/sec, 10/sec, 6/sec, 2/sec Sets the number of times to repeat a keystroke per second if you hold the key down.
Keyboard auto-repeat delay ¼ sec, ½ sec, ¾ sec, 1 sec Sets the delay time after the key is held down
before it begins to repeat the keystroke.

MOPSlcd6 BIOS-Description
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 18 of 42
I/O Device Configuration sub menu:
Feature Option Description
Local Bus IDE adapter Disabled
Enabled Enables onboard PCI IDE device.
Floppy disk controller Disabled
Enabled Enables onboard FDC controller.
Base I/O address Primary
Secondary Selects base address of onboard FDC conroller. (Primary = 3F0h, Secondary = 370)
Serial port A
Serial port B Disabled Enabled
Auto
OS Controlled
Disabled turns off the port.
Enabled requires end user to enter the base
I/O address and the IRQ.
Auto makes the BIOS configure the port.
OS Controlled lets the PNP OS configure the
port after bootup.
Base I/O address 3F8h, 2F8h, 3E8h, 2E8h Select I/O base of port.
IRQ (port A and B) IRQ 3, IRQ 4 Select IRQ of port A and B
Parallel Port Disabled
Enabled
Auto
OS Controlled
Disabled turns off the port.
Enabled requires end user to enter the base
I/O address and the IRQ.
Auto makes the BIOS configure the port.
OS Controlled lets the PNP OS configure the
port after bootup.
Mode Output only
Bi-directional
ECP
EPP
Set the mode for the parallel port.
Base I/O address 378h, 278h, 3BCh Select I/O base of port.
IRQ IRQ 5, IRQ 7 Select IRQ of parallel port.
DMA DMA0, 1, 2, 3 Select DMA channel of port if in ECP mode.
USB Host Controller Disabled
Enabled Enable or Disable onboard USB controller.
USB BIOS Legacy Support* Disabled
Enabled Enable or Disable support for USB keyboard and mice. Enable for use with non-USB aware
OSes such as UNIX and DOS.
8Watchdog Settings sub menu Opens Watchdog Settings sub menu
*) NOTE: If USB legacy support is enabled, IRQ12 is used by the usb ohci controller. If you run
a system with win9x and without a mouse attached, set irq12 to reserved in the PCI/PNP ISA
IRQ Exclusion sub menu to prevent win9x from allocating irq12 for pci devices!
Watchdog Settings sub menu:
Feature Option Description
Mode Disabled
Reset
NMI
Select watchdog operation mode.
Delay 1s, 5s, 10s, 30s, 1min, 5min,
10min, 30min The time until the watchdog counter starts counting. Useful to handle longer boot times.
Timeout 0.4s, 1s, 5s, 10s, 30s, 1min,
5min, 10min Max. trigger periode.

MOPSlcd6 BIOS-Description
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 19 of 42
The Security Menu
Selecting „Security“ from the menu bar displays this menu:
Feature Option Description
Set User Password Up to seven alphanumeric
characters Pressing <Enter> displays the dialog box for entering the user password. In related
systems, this password gives restricted access
to setup.
Set Supervisor Passord Up to seven alphanumeric
characters Pressing <Enter> displays the dialog box for entering the user password. In related
systems, this password gives full access to
setup.
Password on boot Disabled
Enabled Enabled requires a password on boot. Requires prior setting of the supervisor
password.
If supervisor password is set and this option is
disabed, BIOS assumes user is booting.
Diskette access User
Supervisor Enabled requires supervisor password to
access floppy disk.
Fixed disk boot sector Normal
Write protected Write protect the boot sector on the hard disk for virus protection. Requires a password to
format or Fdisk the hard disk.
Virus check reminder
System backup reminder Disabled Daily
Weekly
Monthly
Displays a message during bootup asking
(Y/N) if you backed up the system or scanned
for viruses.
Message returns on each boot until you
respond with „Y“.
Daily displays the message on the first boot of
the day, Weekly on the first boot after Sunday,
and Monthly on the first boot of the month.
Enabling „Supervisor Password“ requires a password for entering Setup.
The passwords are not case sensitive!
Note: User and Supervisor passwords are related! You cannot have a User password without first
creating a Supervisor password.
The Power Menu
A power managment system reduces the amount of energy used after specified periods of inactivity.
The setup menu supports a Full On state, a Standby state with partial power reduction, and a
Suspend state with full power reduction.
Use the Advanced Options sub menu to specify whether or not an activity can terminate a Standby or
Suspend state and restore Full On.
Selecting „Power“ from the menu bar displays this menu:
Feature Option Description
Power Savings Disabled
Customized
Maximum Power Saving
Maximum Performance
Maximum options select predifined values.
Select Customized to make your own
selections from the following fields. Disabled
turns off all power managment.
Standby Timeout Off, 1min, 2min, 4min, 6min,
8min, 12min, 16min Inactivity period required to put system in Standby mode (partial power shutdown).
Auto Suspend Timeout Off, 5min, 10min, 15min,
20min, 30min, 40min, 60min Inactivity period required after Standby to Suspend mode (maximum power shutdown).
Hard Disk Timeout Disabled, 10 sec – 15 min Inactivity period of hard disk required before
standby (motor off).
8Advanced Options sub menu Opens advanced options sub menu

MOPSlcd6 BIOS-Description
p588m115.doc JUMPtecIndustrielle Computertechnik AG Page: 20 of 42
LCD Backlight Off Timer Disabled, 28 sec – 14 min If enabled, backlight is switched off after the
selected period of time without video activity
Advanced Options sub menu:
Feature Option Description
Video IO Yes
No Wakes up system on video event
Primary HDD Yes
No Wakes up system on primary HDD event.
Floppy Disk Drive Yes
No Wakes up system on FDD event.
Serial I/O Yes
No Wakes up system on serial I/O event.
Parallel I/O Yes
No Wakes up system on parallel I/O event.
Keyboard Yes
No Wakes up system on keyboard event.
RTC Yes
No Wakes up system on RTC alarm.
monitored events:
Video IO 3B0h – 3DF I/O and A/B segment memory
Primary HDD 1F0h – 1F7h and 3F6h I/O access, primary IDE channel DMA request
Secondary HDD 170h – 177h and 376h I/O access, secondary IDE channel DMA request
FDD 3F0h – 3F7h I/O access
Serial I/O 3F8h – 3FFh, 2F8h – 2FFh, 3E8h – 3EFh, 2E8h – 2EFh, 338h – 33Fh, 238h – 23Fh
Parallel I/O 378h – 37Fh, 278h – 27Fh, 3BCh – 3BEh
Keyboard 60h and 64h I/O access
Besides the events explained above the following events will wake the system from suspend state:
•IRQ[1-7], IRQ[9-15], NMI, SMI, INIT
•RTC IRQ 8
The Boot Menu
See chapter „Boot Utilities“ below
The Exit Menu
The following sections describe the five possible options of the Exit Menu. Note that <Esc> does not
exit this menu. You must select one of the items from the menu to exit.
Exit Saving Changes
Saves all the selections and exits setup. The next time you boots, the BIOS configures the system
according to the Setup selection stored in CMOS.
Exit Discarding Changes
Use this option to exit Setup without storing in CMOS any new selections you may have made. The
selections previously in effect remain in effect.
Load Setup Defaults
Select to display the default values for all the Setup menus.
Discard Changes
If, during a Setup session, you changeyour mind about changes you have made and have not yet
saved the values to CMOS, you can restore the values you previously saved to CMOS.
