Korenix JetCon 3401G V2 User manual

JetCon 3401G V2
Quick Installation Guide v1.0
This is warranty is voided if defects, malfuncons or failures ohe
warranted Product are caused by damage resulng from force measure
(such as floods, fire, etc.), other external forces such as power
disturbances, over spec power input, or incorrect cabling; or the
warranted producs misused, a bused, or operated, altered and
repaired in an unauthorized or improper way.
Aenon! Toavoid system damage caused by sparks, please DO NOT
pluginpower connector when power ison.
The producs in compliance with Direcve2002/95/EC and 2011/65/EU
ohe European Parliament and ohe Council of 27 January 2003 on the
restricon ohe use of certain hazardous substances in electrical and
electronics equipment (RoHS Direcves & RoHS 2.0)
KorenixCustomer Service
KoreCARE is Korenix Technology's global service center, where our
professional staffare ready to solveyourproblems at anymeKorenix
global service center's e -mail is [email protected].
For more informaon and documents download please visit our website:
hp://www.korenix.com/downloads.htm
5 Years Warranty
Each of Korenix’s product line is designed, produced, and tested with
high industrial standard. Korenix warrants thahe Product(s) shall be
free from defects in materials and workmanship for a period offive (5)
years from the date of delivery provided thahe Product was properly
installed and used.
Support
DIP Switch Setting
Note:
Aer adjusng the DIP-switch, please reboot the unit to acvate the
new sengs.
Dipswitch Funconality
Switch 1 On: Enable power event alarm
Off: Disable.
Switch #2 On: SFP speed at 100Mbps
Off: SFP speed at 1000Mbps
Switch #3 On: Enable LLF funcon
Off: Disable.
Wiring the Relay Output
The relay output contacts are in the middle of the terminal block connector
as shown below. By inserng the wires and sengs the DIP switch of the
respecve alarm funcon to “ON”, relay output alarm will detect port or
power fault, and form a short circuit. The alarm relay output is “Normal
Open”. For more informaon, please refer Manual chapter for more detail.
Note:
The relay contact only support 1A current, DC 24V. It does not recommend
apply higher voltage and current that over this specificaon.
Wiring the Power Inputs
1. Insert the posive and negave wires into the V+ and V- contact on the
terminal block connector.
2. Tighten the wire-clamp screws to prevent the power wires loosened.
Connecng toNetwork
1. Connecng the Ethernet Port: Connect one end of an Ethernet cable
into the UTP port of JetCon 3401G V2, while the other end is
connected to the aached networking device. UTP port support auto
MDI/MDIX funcon. The LNK / ACT LED will turn on and flash to
indicate RJ-45 port link and the packets received and transmied
from RJ-45.
2. Install Gigabit SFP transceiver and make the connecon: Connect
the fiber port on your JetCon 3401G to another Gigabit Fiber
Ethernet device, by following the figures below. Wrong connecon
will cause the fiber port not working properly.
The SFP Fiber port supports 2 LEDs for link/acvity and full duplex/
collision, once the gigabit fiber port is in up, the link LED will be
trigger to”ON”
JetCon 3401G V2 industrial Gigabit Ethernet converter, conforming
IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, and IEEE 802.3ab 1000Base-T
supports RJ-45 copper to Gigabit fiber conversion using store and forward
technology. The JetCon 3401G V2 adopts rugged metal case design to
operate in harsh environment (-40~75°C). It also IP-31 standard protecon.
It features link loss forwarding raise an alarm when a remote fault occurs
and also adopts one relay output to alarm users if a port link or power fails.
Alarm can be enable/disable by dip switch. The fiber port supports SFP
sockets forseveral of SFP transceiver to achieve different link distance.
JetCon 3401G recommend working voltage is DC 48V. (Input range: DC10~
60 V)
Package Check List
JetCon 3401G V2 Industrial Media Converter
Quick Installaon Guide
Copyright
Copyright © 2014 all rights reserved. No part of this publicaon may be
reproduced, adapted, stored in a retrieval system, translated into any
language, or transmied in any form or by any means without the wrien
permission of the supplier.
About the Quick Installaon Guide
This Quick Installaon Guide is intended to guide professional installer to
install and configure the JetCon 3401G V2. It covers procedures to assist
you in avoiding unforeseen problems.
Introduction
Mount the unit
Din-Rail mount: Mount the din-rail clip on the rear of JetCon 3401G V2 on
the DIN rail. For informaon about the DIN Rail installaon, please refer
to user’s manual.
Grounding JetCon 3401G V2
There is one grounding screw on the
boom side of JetCon 3401G V2. Connect the
frame grounding of JetCon 3401G V2 to the
grounding surface to ensure safety and
prevent noise for communicaon interference.
Installaon
Aenon:
This is a Class 1 Laser/LED product.
Don’t stare into the Laser/LED
Beam.

注意:
1. 这是1类激光/ LED产品。 不要盯着激光/ LED 光束。
DIP拨码开关设定
Dipswitch 描述
Switch 1 On: 启动电源报警
Off: 关闭电源报警
Switch #2 On: SFP 速度设定为 100Mbps
Off: SFP 速度设定为 1000Mbps
Switch #3 On: 启动 Link Loose Forwarding 功能
LLF
Off: 关闭 Link Loose Forwarding 功能
Korenix Technology Co.,Ltd.
(A Beijer Electronics Group Company)
Tel:[phone]
Fax:[phone]
Business service:[email protected]
Customer service: [email protected]
www.korenix.com
CPQ000V3401004
Patent No. (Taiwan):
Granted Invenon: I 313547
Granted Invenon: I 321415
Granted Invenon: I 344766
Granted Invenon: I 346480
Granted Invenon: I 356616
Granted Invenon: I 364684
Granted Invenon: I 376118
Granted Invenon: I 393317
Granted Invenon: I 398066
Granted Invenon: I 398125
Granted Invenon: I 459757
Ulity Model: M 339841
Ulity Model: M 339840
客户服务
5年质保
所有Korenix产品的设计、制造及测试都是采用较高的工业标准。
Korenix保证自产品出货日起提供最高5年之免费保修服务，保修
期间如因零件损坏或制程不良而导致产品故障，我们提供免费维
修服务。自然外力 （火、水、雷灾）所造成的产品故障，或其它
外部因素如电源干扰、不当电源输入、不当接线等造成的损坏，
不列入产品保固范围；此外，产品被误用、未经授权的修理及修
改等行为将造成保固条款失效。
注意! 请勿于电源开启时插拔接线端子，避免产生火花造成系统
损坏。
此产品保证完全符合欧盟2003年1月27日电气和电子设备危害物
质限制委员会限用指令2002/95/EC (RoHS)及2011/65/EU(RoHS
2.0)。
Korenix售后服务
KoreCARE是Korenix科技全球服务中心，我们专业的技术人员随
时准备解答您的疑问。
Korenix全球服务中心 EMAIL: [email protected]
业务服务: [email protected]
官网:www.korenix.com.cn
版权
版权所有©2014保留所有权利。 未经供应商书面许可，不得将
本出版物的任何部分复制，改编，存储在检索系统中，翻译成任
何语言，或以任何形式或方式传播。
关于快速安装指南
本“快速安装指南”旨在指导专业安装人员安装和配置JetCon
3401G V2。 它涵盖了帮助您避免意外问题的程序。
常规
警告:此符号表示您必须遵守的警告
注意:此符号表示您必须注意的重要注意事项。
介绍
JetCon 3401G V2是单端口快速以太网到光纤介质转换器。
JetCon 3401G V2具有冗余电源输入，具有宽范围DC10〜60V。
JetCon 3401G V2的光纤端口也支持单模或多模，最高高达
30KM的延长距离传输。
打開包裝，檢查下列配件
•JetCon 3401G V2工业媒体转换器*1
•快速安装指南*1
安装
Din-Rail支架：
将JetCon 3401G V2背面的Din-rail夹子安装在DIN导轨。有关
DIN导轨安装的信息请参考用户手册。
JetCon 3401 V2 接地:
JetCon 3401G V2底部有一个接地螺
丝。将JetCon 3401G V2连接框架接地
以保证安全，防止噪音用于通信干扰。
输入电源接线:
1.将正极和负极线插入端子块连接器上的V +和V-触点。(如下图)
2.拧紧电线夹螺钉，防止电源线松动。
连接到网络
1. 连接以太网端口：将以太网电缆的一端连接到JetCon 3401G
V2 的UTP端口，另一端连接到所连接的网络设备。 UTP端口
支持自动MDI/ MDIX功能。 LNK/ACT LED将亮起并闪烁，表
示RJ-45端口链路和从RJ-45接收和发送的数据包。
2.连接光纤端口：将JetCon 3401G V2
上的光纤端口连接到另一个光纤
太网设备，如图所示。 连接错误
或光缆类型会导致光纤端口工
作不正常。
注意:
推荐的输入电压为DC 24V。(可输入范围：DC10〜60V)
接线输出
继电器输出触点位于连接器端子中间，如下所示。 透过将警报功能
的DIP开关插入到“ON”，继电器输出报警将检测端口或电源故障，
并形成短路。 有关更多信息，请参阅手册章节了解更多详细信息。
注意:
继电器触点仅支持
1A电流，DC 24V
。 不建议使用超过
本规范的更高的电
压和电流。
