Korenix JetNet 6059G User manual

JetNet 6059G Series
Industrial 9-port Gigabit Managed
Ethernet Switch
Quick Installation Guide
www.korenix.com
V1.0

Introduction
JetNet 6059G series is an Industrial Gigabit Managed Ethernet Switch with 9 full gigabit
ports and 32G switching backplane to ensure high quality data transmission in industrial
applications requiring high-bandwidth connectivity. In addition to 4 Giga RJ-45 ports, the
switch is equipped with 5 Giga RJ-45/SFP combo ports to deliver maximum throughput and
flexibility for high-density connection while providing Giga uplink or Giga Ring connection.
With the Korenix patented MSR technology, users can aggregate up to 4 Multi Gigabit Rings
into a single switch and ensure network reliability in applications with increased bandwidth
and expended system. Furthermore, JetNet 6059G supports advanced management and
security features, such as LLDP and JetViewPro, 4 Priority queues per port, 256 VLANs,
IGMP Snooping, DHCP, LACP to ensure high performance network communication. JetNet
6059G is compliant with NEMA -TS2 /Maritime, Railway standards and has dual redundant
10.5~60VDC power inputs and -40~75OC wide operating temperature range to work reliably
under vibrating and shock environments in Maritime, Railway or rolling stock applications.
Package Checklist
Unpack the box, you will find
4JetNet 6059G with DIN Rail kit x1
4Quick Installation Guide
4CD User Manual
4Console Cable (RJ-45 /DB9)
4Wall Mount kits
Mounting the Unit
Din-Rail mount: Mount the din-rail clip on the rear of
JetNet 6059G on the DIN rail.
For information about the DIN Rail installation, please
refer to user’s manual.
JetNet 6059G Series
Industrial 9-portGigabit Managed
Ethernet Switch
Quick Installation Guide
www.korenix.com
V1.0

Grounding JetNet 6059G
There is one grounding screw on the bottom side
of JetNet 6059G. Connect the frame grounding
of JetNet 6059G to the grounding surface to
ensure safety and prevent noise to interfere
communication.
Wiring the Power Inputs
1. Insert the positive and negative wires into the V+ and V- contact on the terminal block
connector.
Wiring the Relay Output (DO)
The relay output contacts are in the bottom side as shown on Figure-3. The relay output (DO)
is controlled by the pre-defined operating rules. To activate relay output function, please refer to
the User’s Manual for the Relay Output information.
2. Tighten the wire-clamp screws to prevent the power wires from being loosened.
Notes: The recommended working voltage is DC 24V (Input range: DC10.5~ 60 V),
maximum power consumption is 20 Watts.
Note: The relay contact only
supports 1A current, DC 24V.
It is not recommended to apply
voltage and current higher than
the specifications.
Figure-3

Wiring the Digital Input (DI)
The Digital Input (D.I.) contacts are in the bottom side of the device as shown in Figure-4.
It accepts one external DC type signal input and can be configured to send alert message
through Ethernet when the signal is changed.
Note: the DI accepts DC type signal and supports isolated input circuit with Digital High
Level input DC 11V~30V and Digital Low Level input DC 0V~10V. Don’t apply higher
voltage than the specification; it may cause internal circuit damage or a wrong action of DI.
Connecting to Network
1. Connecting the Ethernet Port: Connect the Ethernet port of JetNet 6059G with the
other Ethernet device by Cat-5/Cat-6 UTP or STP cable, and then the LNK/ACT LED will
turn on and start flashing to indicate the communication is occurred between 2 devices.
2. Connecting the SFP Port: Plug in SFP fiber transceiver. We recommend using Korenix
certificated SFP mini GBIC transceiver. Cross-connect the transmit channel at each end to
the receive channel at the opposite end as illustrated in the Figure-5.
Figure-5
Ȋ
This is a Class 1 Laser/LED product.
Don’t stare at the Laser/LED Beam.
TX
RX
AB
TX
RX
ATTENTION
Figure-4

Device Management
JetNet 6059G Industrial Managed Switch provides both in-band and out-band configuration
methods. You can configure the switch via the RS232 console with the attached console
cable. Or you can remotely manage the switch via network. You can choose Telnet/SSH,
Web/HTTPS management.
1. Preparation for console management: Attach the RS-232 DB9 connector to your PC’s
COM port. Connect the RJ-45 connector to the console port of the JetNet 6059G
Go to Start -> Program -> Accessories -> Communication -> Hyper Terminal
Give a name to the new console connection.
Choose the COM name and select the correct serial settings. The serial port settings of
JetNet 6059G are as below: 9600bps, No parity check, 8 Data bits, 1 stop bit
After connected, you will see the Switch login request. Type the username and password
then you can login. The default username is “admin”, password is “admin”.
Follow the manual to configure the software features.
2. Preparation for Web management: Before you attempt to use the embedded web
interface to manage switch operation, verify that JetNet 6059G is properly installed on your
network and that every PC on this network can access the switch via the web browser.
Launch the web browser (Internet Explorer or Mozilla Firefox) on the PC.
Type http://6059G_IP_Address (The default IP address is 192.168.10.1.) then press Enter.
The login screen will appear next.
Type in the user name and password and click
“OK” button. The welcome page of the Web-Based
management interface will appear then. The default
user name and password is admin/admin

Korenix Customer Service
KoreCARE is Korenix Technology’s global service center, where our professional staffs are
ready to answer your questions at any time.
Korenix global service center’s e-mail is [email protected]
At the left column of the web management interface
are the software features, where ring column will
list the available settings.
For more operating instructions, please refer to
the User’s manual of JetNet 6059G included in the
packing or downloadable from the Korenix Website
– www.korenix.com.

Tel:[phone]
Fax:[phone]
Business service:[email protected]
Customer service:[email protected]
CPQ000N6059000
