KORG M3-73
SERVICE MANUAL
Blockdiagram and Schematics are in another file.
TABLE OF CONTENTS
ASSEMBLY SKETCH (HOOKUP): 2
TEST MODE: 3-4
PARTS LIST: 5-8
Issued June.5, 2007
Ver.2 Changed P6-7

M3 Test mode
How to enter the test mode
-Tset mode to confirm that the keybed is not connected when to use as M3-M
Turn the power on pressing ENTER + 6
-Full inspection mode
Turn the power on pressing ENTER + 5
-Other test mode
ENTER + 0 :Initialize Backup Area
ENTER + 2 :Skip the internal check
ENTER + 7 :Check of connectors of M3-73/88’s Sub-OUT
ENTER + 8 :Ext Key Check
ENTER + 9 :Diplay of Version No.
MENU + 1 :Option memory simple check
MENU + 2 : writing check of GUID to Firewireboard
MENU + 3 :On Board + Option memory simple check
MENU + 4 :RADIAS Option Check
MENU + 5 :Test Mode
MENU + 6 :Firewire Option Check
MENU + 7 :Option memory Full Check
MENU + 8 :Load Preload/Demo Data
MENU + 9 :On Board + Option memory Full Check
LOCATE + 0 :USB Storage Mode
LOCATE + 1 :Keybed Update
Operation in the test mode
[ENTER] : Proceed to next check
[△] : Proceed to next item
[∇] : Go back to former item
[ FF ] : Proceed to next step
[ RW ] : Go back to former step

Notice
-Connect a USB flash memory (USB2.0) to the USB A connector.
-Connect a personal computer which is working on USB2.0 to the USB B connector.
-When internal check [ Please Connect Digital Cable] is displayed, connect the OPTICAL IN and OUT using
a OPTICAL cable (loop).
-Confirm that the numer of keys wich is connected is same as in the diplay.
When the different number of the keys is displayed, the PCB of the keyboard is different KLM-2860.
-In the operation check, the caliblation is needed for RIBBON, JOYSTICK, PAD, AFTERTOUCH..
-When to set the preload data of M3-88 to factory setting, connection of KEYBED is needed.

1/4
KORG M3-73 Parts List
Part No.
Category
Part Name
Note
QTY
500314001400
DIODE
RLS-73 TE-11
KLM-2810
2
500320012320
IC
MB87M4080PB-GE1
KLM-2810
1
500324026017
IC
MC9328MX1DVM20R2
KLM-2810
1
500320041011
IC
K4S511632D-UC75
KLM-2810
2
500324006012
SDRAM
V54C365164VEI7(TP)
KLM-2810
1
500324006014
SDRAM
V54C3256164VDI7PC(TP)
KLM-2810
4
500324007039
IC
BU2373FV-E2
KLM-2810
1
500324021113
Logic IC
SN74LV4040APWR
KLM-2810
1
500324021121
Logic IC
SN74LV541APWR
KLM-2810
3
500324021158
Logic IC
SN74LVC32APWR
KLM-2810
3
500324021166
Logic IC
SN74LVC1G02DCKR
KLM-2810
1
500324021168
Logic IC
SN74LVC1G04DCKR
KLM-2810
1
500324021215
Logic IC
SN74LVC1G86DCKR
KLM-2810
1
500324021230
Logic IC
SN74LVC2G08DCTR
KLM-2810
1
500324021235
Logic IC
SN74LVC2G157DCTR
KLM-2810
1
500324021246
Logic IC
SN74LVC2G74DCTR
KLM-2810
1
500324021280
Logic IC
SN74AHCU04PWR
KLM-2810
1
500324022000
Logic IC
SN74LV14APWR
KLM-2810
1
500324022100
Logic IC
SN74LVC245APWR
KLM-2810
2
500324026016
LDO IC
SPX2815AT-L/TR
KLM-2810
1
500324053005
RESET IC
MAX811SEUS+T
KLM-2810
2
500324053006
ASSP IC
DS2411R+T&R
KLM-2810
1
500334002100
INDUCTOR
NLC453232T-4R7K-PF
KLM-2810
2
500335400380
CRYSTAL
CX-49G-24.576MHZ
KLM-2810
1
500335400400
CRYSTAL
CM200S 32.768KHZ
KLM-2810
1
500404001100
INDUCTOR
BLM18BB121SN1D
KLM-2810
1
500404001280
BLM18BB470SN1D
KLM-2810
2
500404001150
FERRITE BEAD
MMZ1608Y102BT
KLM-2810
2
500404001160
FERRITE BEAD
MPZ2012S221AT
KLM-2810
5
500474044300
CONNECTOR
8903-060-177MS-B-F
KLM-2810
2
500474044500
CONNECTOR
DM04-144B2-F
KLM-2810
1
500474045200
CONNECTOR
STMM-110-02-G-D-SM-K-TR
KLM-2810
1
500474045400
CONNECTOR
MICS/SMD 10RP
KLM-2810
1
500474045500
CONNECTOR
MICS/SMD 26RP
KLM-2810
1
200060942810
PCB ASS'Y
KLM-2810-M3SERIES
(1)
500184080020
Chip FUSE R
RF732BTBK0R2J
KLM-2642-2700
1
500219401960
INDUCTOR
SLF12575T-220M4R0-PF
KLM-2642-2700
1
500219402050
EMI/EMC PART
RLF12560T-5R6N9R2
KLM-2642-2700
1
500304050490
FET
CPH6316-TL-E
KLM-2642-2700
1
500304050530
POWER MOS FET
SI4944DY-T1
KLM-2642-2700
1
500314001400
DIODE
RLS-73 TE-11
KLM-2642-2700
2
500314010580
DIODE
1N4148T-77
KLM-2642-2700
1
500314030700
SCHOTTKY DIODE
RB051L-40TE25
KLM-2642-2700
1
500314031100
SCHOTTKY DIODE
RB081L-20
KLM-2642-2700
1
500314032500
SCHOTTKY DIODE
RB751V-40TE17
KLM-2642-2700
2
500315000500
DOUBLE DIODES
MC2840-T112-1
KLM-2642-2700
2
500320012359
MEMORY
S29AL004D70TFI010 (X4210)
KLM-2642-2700
1
500320038008
IC
ISP1761BE,557
KLM-2642-2700
1
500324007038
EEPROM
BR24L04F-WE2
KLM-2642-2700
1
500324009054
REGULATOR IC
NJM78M05DL1A-TE1
KLM-2642-2700
1
500324009086
IC
NJM2374AE-TE1-#ZZZB
KLM-2642-2700
1
500324017026
IC
R2051S01-E2-F
KLM-2642-2700
1
500324018012
ANALOG IC
AK4112BVF-E2
KLM-2642-2700
1
500324021114
Logic IC
SN74LV05APWR
KLM-2642-2700
1
500324021149
IC
NE5532ADR
KLM-2642-2700
3
500324021190
Logic IC
SN74LVC1G19DCKR
KLM-2642-2700
1
500324021225
Logic IC
SN74LVC2G04DCKR
KLM-2642-2700
1
500324021232
Logic IC
SN74LVC2G126DCTR
KLM-2642-2700
1
500324021253
Logic IC
SN74LVC3G07DCTR
KLM-2642-2700
1
500324022101
DC-DC Converter
TPS40071PWPRG4
KLM-2642-2700
1
500324022102
ASSP IC
TPS2042BDRG4
KLM-2642-2700
1
500324022105
REGULATOR IC
LP2985-33DBVR
KLM-2642-2700
1
500324023007
IC
S-8520F50MC-B0JT2G
KLM-2642-2700
1
500324036013
ANALOG IC
PCM1793DBR
KLM-2642-2700
3
500324036015
ANALOG IC
PCM1802DBR
KLM-2642-2700
1
500324053004
USB/1394 IC
SC16C2550BIB48,128
KLM-2642-2700
1
500334001900
PHOTO COUPLER
PC410LKNIP0F
KLM-2642-2700
1
500335400350
CRYSTAL
CX-49G-12.000MHZ
KLM-2642-2700
1
500335400360
CRYSTAL
CX-49G-16.000MHZ
KLM-2642-2700
1
500335400370
CRYSTAL
CX-49G-20.000MHZ
KLM-2642-2700
1
500335400400
CRYSTAL
CM200S 32.768KHZ
KLM-2642-2700
1
500375014800
SW
SDKLA10200
KLM-2642-2700
1
500402004600
FERRITE BEAD
2943-666673
KLM-2642-2700
1
500402400700
COMMON MODE FILTER
ACM9070-701-2PL-TL
KLM-2642-2700
1
500402400800
COMMON MODE FILTER
ZJSR5101-223TA-01
KLM-2642-2700
9

2/4
Part No.
Category
Part Name
Note
QTY
500404000500
INDUCTOR
BLM21BD102SN1D
KLM-2642-2700
4
500404001150
FERRITE BEAD
MMZ1608Y102BT
KLM-2642-2700
30
500404001160
FERRITE BEAD
MPZ2012S221AT
KLM-2642-2700
4
500404001250
Chip INDUCTOR
CDRH127LD
KLM-2642-2700
1
500454012732
POWER PLUG/JACK
LGP6531-0800F
KLM-2642-2700
1
500474027400
CONNECTOR
A3E-50PA-2DSA(71)
KLM-2642-2700
1
500474039400
CONNECTOR
YKF45-0021N(USB RA B-TYPE)
KLM-2642-2700
1
500474042800
CARD CONNECTOR
AXA263021T
KLM-2642-2700
1
500474044400
CONNECTOR
8913-060-178S-C-F
KLM-2642-2700
2
500474044700
CONNECTOR
UAR64-8W5J00
KLM-2642-2700
1
500474045400
CONNECTOR
MICS/SMD 10RP
KLM-2642-2700
1
500480010560
PHONE JACK
YKF51-5073V
KLM-2642-2700
1
500515400100
FUSE HOLDER
CNT47-0003A
KLM-2642-2700
2
500641041609
GROUND TERMINAL
M1698A
KLM-2642-2700
1
500649007400
BATTERY HOLDER
HL32-A2
KLM-2642-2700
1
200060942642
PCB ASS'Y
KLM-2642/2700 M3-SERIES
(1)
500219401920
EMI/EMC PART
NFM21PC104R1E3D
KLM-2644-47-66
2
500304000110
TRANSISTOR
2SA812-T1B-A (M6)
KLM-2644-47-66
1
500304020230
TRANSISTOR
2SC3661-TB-E
KLM-2644-47-66
14
500314001400
DIODE
RLS-73 TE-11
KLM-2644-47-66
4
500314031600
ZENER DIODE
HZM9.1NB3TL-E
KLM-2644-47-66
1
500315000500
DOUBLE DIODES
MC2840-T112-1
KLM-2644-47-66
4
500315001200
DOUBLE DIODES
DAN217T146
KLM-2644-47-66
1
500320009108
IC
NJM4556AL (SIP)
KLM-2644-47-66
1
500324001015
OPAMP
UPC4570G2-E2-A
KLM-2644-47-66
1
500324021149
IC
NE5532ADR
KLM-2644-47-66
6
500330003400
OPTO TX/RX MODULE
TOTX142L(F)
KLM-2644-47-66
1
500330003500
OPTO TX/RX MODULE
TORX142L(F)
KLM-2644-47-66
1
500334002000
INDUCTOR
NLFC322522T-470K-PF
KLM-2644-47-66
1
500362009030
VR
RK09K12A0D0D
KLM-2644-47-66
1
500373009000
SW
SSSS928400
KLM-2644-47-66
1
500402400600
INDUCTOR
PK0810-331K-UL-T/F (TR)
KLM-2644-47-66
2
500402400800
COMMON MODE FILTER
ZJSR5101-223TA-01
KLM-2644-47-66
1
500404001150
FERRITE BEAD
MMZ1608Y102BT
KLM-2644-47-66
19
500450003100
PHONE JACK
LGR4609-7100F
KLM-2644-47-66
10
500454005600
PHONE JACK
YKB21-5006G
KLM-2644-47-66
2
500474039700
CONNECTOR
SLW4R-1C7
KLM-2644-47-66
1
500474044600
CONNECTOR
08-6210-020-340-800+
KLM-2644-47-66
1
500474045500
CONNECTOR
MICS/SMD 26RP
KLM-2644-47-66
1
500641041623
X-9100 JACK PLATE 2 C41068-2
KLM-2644-47-66
2
500641042045
X4210 JACK PLATE 1 C41446
KLM-2644-47-66
1
500641042046
X4210 JACK PLATE 2 C41447
KLM-2644-47-66
2
500219402070
INDUCTOR
NLCV32T-221K-PF
KLM-2644-47-66
2
200060942644
PCB ASS'Y
KLM-2644/47/66 M3-SERIES
KLM-2644-47-66
(1)
500304020150
TRANSISTOR
2SC1623-T1B-A (L7)
KLM-2645/46/48/49/2701
8
500304020370
TRANSISTOR
2SC2655-Y (TPE6 F)
KLM-2645/46/48/49/2701
2
500304020380
DIGITAL TR
FP1L2Q-T1B-A
KLM-2645/46/48/49/2701
18
500304050540
DIGITAL TR
DTD143EKT146
KLM-2645/46/48/49/2701
8
500314001400
DIODE
RLS-73 TE-11
KLM-2645/46/48/49/2701
1
500314010570
LED
KPBD-3224SURKSGC
KLM-2645/46/48/49/2701
2
500314028800
LED
SLZ-190B-09-T2
KLM-2645/46/48/49/2701
14
500315000500
DOUBLE DIODES
MC2840-T112-1
KLM-2645/46/48/49/2701
9
500315000600
DOUBLE DIODES
MC2838-T112-1
KLM-2645/46/48/49/2701
37
500320012335
IC
MB89935BPFV-G-291-BNDE1
KLM-2645/46/48/49/2701
1
500320020215
IC
CY8C24423A-24SXI
KLM-2645/46/48/49/2701
3
500324009019
ANALOG IC
NJM2115M-TE1
KLM-2645/46/48/49/2701
1
500324021108
Logic IC
SN74LV138APWR
KLM-2645/46/48/49/2701
4
500324021119
Logic IC
SN74LV4051APWR
KLM-2645/46/48/49/2701
2
500324052001
IC
HG-106C-FT
KLM-2645/46/48/49/2701
8
500335400138
CERAMIC RESONATOR
CSTCC10M0G53-R0
KLM-2645/46/48/49/2701
1
500360025600
VR
RK09K1130B56
KLM-2645/46/48/49/2701
1
500362009007
VR
RK11K1140A9L
KLM-2645/46/48/49/2701
1
500365011500
VR
EWA NA0C15B14
KLM-2645/46/48/49/2701
1
500365011400
VR
RS30111A602N
KLM-2645/46/48/49/2701
9
500370005000
SW
EC11B15204A5
KLM-2645/46/48/49/2701
1
500374001500
SW
SKRGAED010
KLM-2645/46/48/49/2701
74
500402009300
INDUCTOR
RCH895NP-181K
KLM-2645/46/48/49/2701
1
500402009400
INDUCTOR
EP208B
KLM-2645/46/48/49/2701
1
500404001150
FERRITE BEAD
MMZ1608Y102BT
KLM-2645/46/48/49/2701
15
500415004900
BUZZERS
PKM17EPP-2002-B0
KLM-2645/46/48/49/2701
1
500454012737
DIN PLUG/JACK
DIN JACK MD24-9PSC4EC-000-21
KLM-2645/46/48/49/2701
1
500471071001
CONNECTOR
B10B-PH-K-S(LF)(SN)
KLM-2645/46/48/49/2701
1
500472060401
CONNECTOR
S4B-EH(LF)(SN)
KLM-2645/46/48/49/2701
1
500472060601
CONNECTOR
S6B-EH(LF)(SN)
KLM-2645/46/48/49/2701
1
500472070301
CONNECTOR
S3B-PH-K-S(LF)(SN)
KLM-2645/46/48/49/2701
1
500472070501
CONNECTOR
S5B-PH-K-S(LF)(SN)
KLM-2645/46/48/49/2701
2

3/4
Part No.
Category
Part Name
Note
QTY
500472070801
CONNECTOR
S8B-PH-K-S(LF)(SN)
KLM-2645/46/48/49/2701
2
500641041609
GROUND TERMINAL
M1698A
KLM-2645/46/48/49/2701
2
500314010590
LED
KPTD-3216SURCK
KLM-2645/46/48/49/2701
49
500472084080
CONNECTOR
SM02(8.0)B-BHS-1-TB(LF)(SN)
KLM-2645/46/48/49/2701
1
200060942645
PCB ASS'Y
KLM-2645/6/8/9/2701
(1)
500304050220
DIGITAL TR
DTC114ESA TP
KLM-2650/2706
2
500314001300
DIODE
1SS-133 T-77
KLM-2650/2706
2
500314031000
LED
SLR-325VR-T31-K/L/M/N
KLM-2650/2706
2
500320009001
OPAMP
NJM4558D-V
KLM-2650/2706
1
500375016400
SW
SKRGAQD010
KLM-2650/2706
2
500474041000
CONNECTOR
5597-05APB7F
KLM-2650/2706
1
500312054000
LED
EW5809C-9B0
KLM-2650/2706
2
200062462650
PCB ASS'Y
KLM-2650/2706 M3-61/73/88
(1)
500472060301
CONNECTOR
S3B-EH(LF)(SN)
KLM-2704/2705
1
500472060401
CONNECTOR
S4B-EH(LF)(SN)
KLM-2704/2705
1
500362009052
VR
RK11K1140D1H
KLM-2704/2705
2
500314001400
DIODE
RLS-73 TE-11
KLM-2860/61(73)
1
500315000500
DOUBLE DIODES
MC2840-T112-1
KLM-2860/61(73)
3
500324007033
EEPROM
BR93L46RFV-WE2
KLM-2860/61(73)
1
500324021182
Logic IC
SN74LVC1G126DCKR
KLM-2860/61(73)
1
500335400151
CERAMIC RESONATOR
CSTCE20M0V51-R0
KLM-2860/61(73)
1
500404001150
FERRITE BEAD
MMZ1608Y102BT
KLM-2860/61(73)
47
500454012737
DIN PLUG/JACK
DIN JACK MD24-9PSC4EC-000-21
KLM-2860/61(73)
2
500641041609
GROUND TERMINAL
M1698A
KLM-2860/61(73)
2
500320004729
CPU
HD64F3687GFPV (X4100)
KLM-2860/61(73)
1
500310040900
SCHOTTKY DIODE
RB706D-40T146
KLM-2860/61(73)
1
200062472860
PCB ASS'Y
KLM-2860/61 M3-73 (ASS'Y)
(1/2)
500475003715
HARNESS
HNS-3715
1
500475003716
HARNESS
HNS-3716
1
500475003717
HARNESS
HNS-3717
1
500475003718
HARNESS
HNS-3718
1
500475003719
HARNESS
HNS-3719
1
500475003720
HARNESS
HNS-3720
1
500475003721
HARNESS
HNS-3721
1
500475003722
HARNESS
HNS-3722
1
500475003723
HARNESS
HNS-3723
1
500475003724
HARNESS
HNS-3724
1
500475003725
HARNESS
HNS-3725
1
500475003726
HARNESS
HNS-3726
1
500475003727
HARNESS
HNS-3727
1
500475003729
HARNESS
HNS-3729
1
500475003730
HARNESS
HNS-3730
1
500475003809
HARNESS
HNS-3809
1
500475003810
HARNESS
HNS-3810
1
500475003733
HARNESS
HNS-3733
1
500475003734
HARNESS
HNS-3734
1
500475003737
HARNESS
HNS-3737
1
500475003738
HARNESS
HNS-3738
1
500545020640
FFC
SML2CD-20X60BDX8(BL)-P0.5-S4+4
1
500600006514
AC CABLE
CORDSET SP0523-2-90 W/INLET
1
500313006700
LCD
KCG057QV1DH-G68
ASS'Y
1
500405015500
AC ADAPTER
KA300 (DSA-60W-12 1 12060A)
ASS'Y
1
500415004705
TOUCH PANEL
N010-0554-T017
ASS'Y
1
500415005001
PRESSURE SENSOR
KX-2100 SENCER WHITE
ASS'Y
1
500420007500
KEYBOARD UNIT
SK73
ASS'Y
1
500464071003
FUSE
FUSE 125V 4A 0233004.MXP
ASS'Y
1
500475103752
HARNESS
HNS-3752(WITH DIN/ANGLE DIN)
ASS'Y
1
500520001700
LITHIUM BATTERY
CR2032-3K///ZWW
ASS'Y
1
500525002000
FERITE MAGNET 7X7X2S WHITE
ASS'Y
8
500525001300
FERRITE CORE
NFT-25 (WITH CASE)
ASS'Y
1
500600006508
AC CABLE
LY100JPVCTFLY35LY37(JP)
(1)
500600005400
AC CABLE
EC-652-E03 (230V GE WG FR)
(1)
500600005700
AC CABLE
UC-953-J01 (120V US CN EX)
(1)
500600005800
AC CABLE
SC-111-J01 (AU)
(1)
500600006507
AC CABLE
LY230BSH05VVFBSLY13(UK)
(1)
500540028903
POWER PLUG/JACK
CONVERTER SOCKET YL-212 (JP)
(1)
500600006514
AC CABLE
CORDSET SP0523-2-90 W/INLET
(1)
500600006517
AC CABLE
CORDSET SP0523-2-90 W/INLET:UL
(1)
500641042048
X4210 MODULE PANEL ASSY H40252
1
500641042067
X4210 HOOK C41524
1
500641042055
X4210 MODULE BOTTOM COVER C30730
1
500646099989
X4210 MODULE SIDE PANEL E30453
2
500646099990
X4210 LCD PLATE 2 E40693
2
500646099991
X4210 PAD FRAME E30454
1
500646099993
4210 KEY BASE BLOCK L ASSY H30320
1
500646099994
4210 KEY BASE BLOCK R ASSY H30321
1

4/4
Part No.
Category
Part Name
Note
QTY
500646099992
X4210 SLIDER KNOB E40664
10
500620046910
X4210 ENCODER KNOB E40466-7
1
500646100060
X4210 1-KEY(V) H30323-1 WHITE
3
500646100061
X4210 2-KEYS(V) H30323-2 WHITE
2
500646100062
X4210 3-KEYS(V) H30323-3 WHITE
1
500646100063
X4210 5-KEYS(V) H30323-5 WHITE
1
500646100064
X4210 2-KEYS(H) H30322-2 WHITE
2
500646100065
X4210 3-KEYS(H) H30322-3 WHITE
9
500646100066
X4210 4-KEYS(H) H30322-4 WHITE
7
500641042058
X4210 PW CHASSIS C41501
1
500641042056
X4210 OP COVER C41483
1
500641042057
X4210 DIMM OP COVER C41484
1
500641042066
X4210 OP PLATE C41525
1
500641042049
X4210 LCD CHASSIS C20447
1
500641042051
X4210 AC CHASSIS C41500
1
500641042050
X4210 FIRE WIRE SUPPORT C41496
1
500641042052
X4210 USB SPRING C41521
1
500641042062
X4210 PU SUPPORT C30731
1
500646097600
X-2100 RUBBER KEYPAD E30375
1
500550020200
X-1450/60TOUCH PANEL TAPE L F41074
2
500550020300
X-1450/60 TOUCH PANEL TAPE S F41075
2
500620024600
X-952POW SW KNOB NO SILK E40304-2
1
500620044800
ROTARY VR KONB KOC-E48026-1
1
500620046920
P423-9FG
1
500646097501
X4210 PAD BTN M-WH PU E40623-2
8
500500036903
X4210 CASE LEG F41327
4
500500036902
X4210 AC SPONGE F41326
1
500540028905
METAL SPACER TS-1R
4
500630042524
X4210 SHIELD SHEET F41356
1
500540028913
EMI GASKET
E02S080070JST-25
2
500500037004
4100 KB Bar Tape F41371
2
500540028912
SPECIAL SCREW KOC-C41190
4
500645055212
4110 BottomBoard D30321
1
500642000001
4110 FrontBar C30755
1
500642000002
4110 KB Panel C30756
1
500642000003
4110 KB Cover C41540
1
500641042086
4110 SideChassis L-A C30764-1
1
500641042087
4110 SideChassis L-B C30764-2
1
500641042088
4110 SideChassis R C30765
1
500642000004
4110 SidePanel L C30757-1
1
500642000005
4110 SidePanel R C30757-2
1
500642000006
4110 RearCover C30758-1
2
500642000007
4110 RearPipe C41539-1
1
500646100085
4110/4120 PipeBracket E30497
2
500641042093
4110/4120 PipeAngle C41553
2
500646100086
4110/4120 CoverHook E30480
4
500500037007
RUBBER FOOT(K-24)
2
500500037008
RUBBER FOOT(K-36)
3
500540028915
EDGEING EO-24N(L=115mm)
4
500540028916
MINI BELT B(L=125mm)
2
500540028917
CABLE CLAMP HFCC6
2
500641042092
LiftUpAssy KOC-H30338
1
500649015007
Damper TD58L2-14K(G-L)
1
500644011004
TD58L2 SPRING
1
500646100087
TD58L2 SPACER
1
500500037004
X4100 KB BAR TAPE F41371
4
500645055208
4100 SIDE WOODPANEL R D30311-1
1
500645055209
4100 SIDE WOODPANEL L D30311-2
1
500646099987
X4100 JS PANEL E20281
1
500641042069
X4100 JS PANEL COVER C30733
1
500646099988
X4100 KEY BLOCK E30443
1
500641042070
X4100 KEY BLOCK COVER C41486
1
500641042060
X4100 KBF CHASSIS C30735
1
500641042047
X4100 KBR CHASSIS C41487
3
500641042053
X4100 FSR METAL 2 C41489
1
500620045500
X-8120 KNOB(x2) KOC-H40149-2
1
500646100067
X4100 JS COVER E40702
1
500646100068
X4100 JS WHEEL E40703
1
500646100070
X4100 JS WHEEL SUPPORT E30455
1
500646100071
X4100 JS FRAME E30456
1
500646100069
X4100 JS PLATE E40704
1
500644010500
X-0100 WHEEL SPRING KOC-C41222
2
500540026500
X-0100 JS WASHER KOC-F40979
2
500500037006
X4100 JS LED SPONGE F41372
1
500790092308
BOLT WITH HEXAGONAL HOLE BT NIC 3X8
5
