1. Introduction
Dear Customer,
Thank you for purchasing this product.
This product meets the requirements of current statutory, European
and national guidelines. To maintain this status and to ensure safe
operation, you as the user must observe these operating instructions!
In case of any technical questions, contact or consult:
Tel.: [phone]
E-mail: [e-mail]
Mon.-Sat.: 7:00 16:00
These operating instructions are part of this product. They
contain important information concerning operation and
handling. Please bear this in mind in case you pass on the
product to any third party. Therefore, retain these operating
instructions for reference!

USER MANUAL
www.kovan.ba
4
2. Intended use
The product measures the current room temperature via an internal
temperature sensor. Depending on an intended set temperature, the
integrated switching output is activated. The heating and cooling
devices can be controlled by it.
A contact-sensitive LC display is used to operate all functions.
The product is supplied with power by two AA/mignon type batteries.
Observe the safety notes and all other information in these
instructions.
This product complies with the applicable statutory, national and
European specifications. All company names and product names are
trademarks of their respective owners. All rights reserved.
3. Explanation of Symbols
This lightning symbol is used when your health is
at risk, e.g. from electric shock.
An exclamation mark in a triangle indicates
important instructions in this operating manual
which must be observed.

USER MANUAL
www.kovan.ba
5
4. Safety information
The device is not a toy. Devices operated using the mains
voltage must be kept out of the reach of children. Particular
care must therefore be exercised if children are around.
The product should only be used in closed, dry indoor areas, it
must not become damp or wet. There is the risk of a fatal
electric shock!
Do not leave packaging material unattended. It may become a
dangerous toy for children
Do not use the product inside of rooms or in bad ambient
conditions where flammable gases, vapours or explosive dust
may be or are present! There is a danger of explosion!

and advice on operation of the device.
In case of damage caused by non-compliance with
these safety instructions, the warranty/guarantee
will become void. We do not assume any
responsibility for consequential damage!
We do not assume any liability for damage to
property of personal injury caused by improper
use or the failure to observe the safety
instructions! In such cases the
warranty/guarantee is void.

USER MANUAL
www.kovan.ba
6
In commercial and industrial facilities, the regulations for the
prevention of accidents as laid down by the proffessional trade
association for electrical equipment and devices need to be
observed
5. Installation
1. Screw for casing closure
2. Screw for protective cover
3. Protective cover
4. Apertures for wall-mounting
Mount the room thermostat on stable surfaces
only. Use the screws or dowels appropriate for
the surface: The product must be operated
stationarily installed. The room thermostat must
be voltage-free during installation.
To ensure that the room thermostat works
properly, do not mount it close to radiators,
electrical devices or windows. Also avoid direct
sunlight.

USER MANUAL
www.kovan.ba
7
5. Opening for
connection cable
6. Screw terminal
(NC/COM/NO)
7. Battery compartment
8. Catches in the upper
part of the
casing
9.  button
For installation do the following steps:
Unscrew the screw (1) on the right side
Remove the upper casing
Insert two type AA/mignon batteries in the battery
compartment (7) with the correct polarity. IN CASE OF
DAMAGE CAUSED BY NON-COMPLIANCE WITH THESE SAFETY

USER MANUAL
www.kovan.ba
8
INSTRUCTIONS, THE WARRANTY/GUARANTEE WILL BECOME
VOID.
Remove the screw (2) only wire-thermostat
Remove the protective cover (3) only wire-thermostat
Connect the power supply to the screw terminals (6) only
wire-thermostat
oConnect contact No.19 of the boiler-electronics to
COM on the room-thermostat
oConnect contact No.18 of the boiler-electronics to NO
on the room-thermostat
Connecting the reciever of the wireless room-thermostat:
oConnect the brown wire to contact No.19 of the boiler-
electronics
oConnect the blue wire to contact No.21 of the boiler-
electronics
oConnect the green-yellow wire to contact No.18 of the
boiler-electronics
Replace the protective cover (3) again only wire-thermostat
Secure the protective cover with the screw (2) only wire-
thermostat
Use the fastening apertures (4) to srew the room thermostat to
the wall
Close the casing and retighten the screw (1) turned out in the
beginning.

USER MANUAL
www.kovan.ba
9
6. Factory settings
The room thermostat is set up with the following factory settings:
Monday - Sunday
Duration of daily regimen___________________________6:00 –23:00
Duration of night regimen___________________________23:00 –6:00
Daily temperature_______________________________________23⁰C
Night temperature_______________________________________18⁰C
7. Markings on the display

USER MANUAL
www.kovan.ba
10
8. Setting the time

Press the button. The year flashes.
Set it with the buttons and
Press the button. The month flashes.
Set the month with the and buttons
Press the button. The date flashes.
Set the date with the and buttons
Press the button. The hours of the current time flash.
Set the hours with the and buttons
Press the button. The minutes of the current time flash.
Set the minutes with the and buttons
Press to store the settings. The device leaves the setting
mode.
9. Selecting Heating and Cooling Modes
Press the button. The year flashes
Press repeatedly to switch between heating mode
d cooling mode (display 
Briefly press to confirm the settings. The device leaves
the setting mode.

USER MANUAL
www.kovan.ba
11
10. Programming setup
There are three different programs:
Daily program
In this program the regime is set up day by day:
Hold down the button for 5 seconds
A weekday or one of the day blocks starts flashing
1 = Monday, 2 = Tuesday, 3 = Wednesday, 4 =
Thursday, 5 = Friday, 6 = Saturday, 7 = Sunday
Select the desired weekday or day block with the and
buttons
Confirm the selection with
Now the time display 0:00 and the first point column in the bar
display for the temperature curve flash
Heating mode: The relay is activated if the
measured temperature falls below a set
temperature threshold. The display shows
Cooling mode: The relay is activated if the
measured temperature rises above a set
temperature threshold. The display shows

USER MANUAL
www.kovan.ba
12
Now set the desired period for the selected temperature value
with and (in steps of 30 minutes)
Normal temperature value
Temperature value for night reduction
Temperature value for economic operation
tipku
Example:
00:00 06:00 Night control temperature (18 C)
06:00 23:00 Daily control temperature (23 C)
23:00 00:00 Night control temperature (18 C)
Follow the next steps to program the room thermostat like shown
above:
1. Hold down the button for 5 seconds
For these settings use chapter 12.
Settin the control temperatures

USER MANUAL
www.kovan.ba
13
2. Set the day with the and buttons
3. Press the button
4. On the display flashes 0:00
5. Press the button
6. Press the button until 6:00 is displayed
7. Press the button
8. Press the button until 23:00 is displayed
9. Press the button
10. Press the button until 0:00 is displayed
11. Press the button
If you don't press anything for longer than 15 seconds, the device will
leave the programming mode.
Program 5/2
In this regime the program is set up in two blocks. The first block for
Monday Friday and the second for Saturday - Sunday
Hold down the button for 5 seconds
A weekday or one of the day blocks starts flashing
Select the dayblock (1-5 for Monday - Fridaj, 6-7 for Saturday -
Sunday) by pressing the and buttons
Press the button

USER MANUAL
www.kovan.ba
14
Now the time display 0:00 and the first point column in the bar
display for the temperature curve flash
Now set the desired period for the selected temperature value
with and (in steps of 30 minutes)
Normal temperature value
Temperature value for night reduction
Temperature value for economic operation
Example:
Monday - Friday
00:00 06:00 Night control temperature (18 C)
06:00 09:00 Daily control temperature (23 C)
09:00 17:00 Economic control temperature (15 C)
17:00 23:00 Daily control temperature (23 C)
23:00 00:00 Night control temperature (18 C)
For these settings use chapter 12.
Settin the control temperatures

USER MANUAL
www.kovan.ba
15
Follow the next steps to program the room thermostat like shown
above:
1. Press and hold the button for 5 seconds
2. Set the dayblock (1, 2, 3, 4, 5) with the and buttons
3. Press the button
4. On the display flashes 0:00
5. Press the button
6. Press the button until 6:00 is displayed
7. Press the button
8. Press the btuuon until 9:00 is displayed
9. Press the button
10. Press the button until 17:00 is displayed
11. Press the button
12. Press the button until 23:00 is displayed
13. Press the button
14. Press the button until 0:00 is displayed
15. Press the button
If you don't press anything for longer than 15 seconds, the device will
leave the programming mode.

USER MANUAL
www.kovan.ba
16
Weekly program
In this program one regime is set up for the whole weed.
11. Manual temperature setting
In manual mode is displayed.
If you want to set up a duration time, a is displayed.
Every confirmation is done by pressing the button. By pressing
the button again, the room thermostat returns to normal regime.
11.1. Manual temperature setting
Set the desired temperature manually with and
is displayed
Press the button once
To go back to normal regime, press the button again

USER MANUAL
www.kovan.ba
17
11.2. Retain manual temperature
To set up a retain manual temperature do the following steps:
Set up the desired temperatures with the and
buttons
Press the button once
oUse and to set the number of hours for
which the manual temperature setting is to apply (you
can set 1 24 hours)
oConfirm the setting with or
Press the button again to set the nuber of days
oUse and to set the number of days for
which the manual temperature setting is to apply (you
can set 1 99 days)
oConfirm the setting with the button or
Press the button to hold the manual temperature without
limitation
If you want to quit the manual mode, press the button
12.Temperature settings
Three control temperatures are available for temperature monitoring
of the room thermostat:
- Normal temperature value

USER MANUAL
www.kovan.ba
18
- Temperature value for energy saving
- Temperature value for night reduction
Proceed as follows to set the 3 temperatures:
Press the button and the symbol flashes
oTo set the normal temperature value use the
and buttons
Press the button and the symbol flashes
oTo set the temperature value for energy saving use the
and buttons
Press the button and the symbol flashes
oTo set the temperature value for night temperature
reduction use the and buttons
Briefly press the button to confirm the settings. The
device leaves the setting mode.
If you don't press anything for longer than 15 seconds, the device will
leave the programming mode.
13. Selecting mode of operation
Press repeatedly to either activate automatic operation or set the
room thermostat to maintain one of the temperature values.

USER MANUAL
www.kovan.ba
19
Symbol is displayed above the bar display normal temperature
value is active.
Symbol is displayed above the bar display temperature value for
economic operation is active.
Symbol is displayed above the bar display temperature value for
night temperature reduction is active.
The symbol is displayed above the bar display, as well as the
symbol for the current temperature value. The room thermostat now
controls the room temperature depending on the temperature curve
programmed by you.
The symbol appears to the right of the time/temperature display 
frost protection (this function is only available if the room thermostat is
in heating mode)
14.Alarm/Wake-up function
Keep the button pressed for 5 seconds
ALappears at the top of the display
Press the button
The pre-set alarm/wake-up time appears (e.g. 0:00) together
with the symbol

USER MANUAL
www.kovan.ba
20
Select the day block on which the wake-up sounds is to be
output with the buttons and
Press the button
The hours of the alarm/wake-up time flash
Set the hours with the and buttons
Press the button
The minutes of the alarm/wake-up time flash
Set the minutes with the and buttons
Confirm the setting with
If you don't press anything for longer than 15 seconds, the device will
leave the programming mode.
To deactivate the alarm/wake-up function do as follows:
Press and hold the button for 5 seconds
Press the button
Press the button
15.Key lock
To activate the key lock, keep the button pressed for approx. 5
seconds, until all button symbols disappear from the display.
