Kozy-World 20-6031 User manual

Kozy-World
Beforebeginnigassemblyof product, make sureall partsarepresent. Compare
partswith packagecontentslist and diagram under. If anypart ismissing or
damaged, donotattempt to assemble, install or operatetheproduct. Contact
customer service for replacementparts.
Estimated AssemblyTime: 30 minutes.
Tool List For Assembly(Not Included):
KEY NO DESCRIPTION QUANTITY
1 PHILLIPS SCREWDRIVER 1
2 WIRE CUTTING PLIERS 1
Part List
KEY NO PART NUMBER DESCRIPTION QUANTITY
1 XB001-01 Power Cord 1
2 XB002-01F Blower 1
3 XB003-01 TemperatureSensor 1
4 XB004-01F Connect Wire 1
5 PF06-0400-A Rocker Switch 1
6 M4.2 8 Screw 6
7 4.0 8 Screw 1
8 VL057-03 CableTie 6
IMPORTANT: Readall instructions andwarnings carefully beforestarting installation.
Failureto follow these instructions may result in apossible electric shock, fire hazard
and will void the warranty.
Questions about installation, operation, or troubleshooting? Before returning to your retailer, call
KOZY WORLD PHONE NUMBER [phone].
PACKAGE CONTENTS
BLOWER ACCESSORY
MODEL NO.20-6031

2
Safety Information
1.Readall instructions beforeusing this appliance.
2.If possiblealways unplugthis appliancewhennot inuse.
3.Donot operateany heaterwithadamagedcordor plugor after the appliance
malfunctions, hasbeendroppedor damaged inany manner.
4.Any repairs tothis applianceshouldbe carriedout byaqualifiedserviceperson.
5.Under nocircumstances shouldthis appliancebe modified. Parts havingtobe
removedfor servicing must be replaced prior tooperating this applianceagain.
6.Donot useoutdoors.
7.This heater is not intendedfor useinbathrooms, laundry areas and similar
indoor locations. Never locatethis appliancewhereit may fall intoabathtub or
other water container.
8.Donot runcordunder carpeting. Donot covercordwiththrow rugs, runners or
the like.Arrangecordaway from traffic areasand whereit will not be tripped over.
9.Todisconnect this appliance, turncontrols tothe off position, then removeplug
from outlet.
10.Connect toproperly grounded outlets only.
11.This appliance, when installed must be electrically grounded inaccordancewith
local codes, withthe current CSA C22.1CanadianElectrical codes or for USA
installations, followlocal codes andthe National Electric Code,ANSI/NFPA No. 70.
12.Donot insert or allow foreignobjectstoenter any ventilation or exhaust opening
as this may causean electric shock, fireor damage the appliance.
13.Toprevent possiblefire, do not blockair intakes or exhaust inany manner.
14.Usethis applianceonly asdescribedinthis manual. Any other usenotrecommended
by the manufacturer may causefire, electric shock or injury topersons.
15.Avoidthe useof anextension cordbecauseof the risk of overheating thecord
and therisk of fire. Extensioncords arefor temporary useonly.If an extension
cordmust be used, it must be UL/CSA certified, rated at 15A (1875W), 125V
maximum with14AWGminimumand constructed of twocurrent carrying conductors
withground. A heavy duty extensioncordwiththe shortest lengthpossible
forthe connection is recommended andmustnotbelongerthan 50 ft. (15.2m). Donot
coil or cover the extensioncord.

3
Exploded Drawing
78
6
3
1
2 5
4

4
AssemblyProcedurefor Item GFD2916& GFD2922& GFDC3030 Optional Parts:
NOTICE: Shut off gas heater during the following blower installation.
Figure1
Removeupper
firebox by unscrewingleft
/rightscrews onthe fire
box.
Figure2 Unscrew two
screws onheat insulation
boardcover anddraw it out.
.
Figure3
Fix temperature
sensor toheat insulation
boardcover as shownin
the figure.
Figure4 Insert wires into
the spacebetweenwire
protectingboardand shell;
Fix the wires tothetop
cover withwirefixture.
Wire Fixture
Figure5 Connect
temperaturesensor with
lead; Install the cover
accordingtoFigure2, then
fix the upper firebox
accordingtoFigure1.
Figure6 Insert blower
assemblyintothe bottom
spaceof burner pan
accordingtoFigure7. Pay
attentionnot totouchwires
inside.
Figure7 Set Blower plane
and fix it ontotwobrackets
of shell board. Pleaserefer
toFigure6. Makesure
Blower isinstalled intothe
slots.
Install Bower
into slots
Figure8 Fix Blower with
one screw, after manually
install it intoslots.
Figure9 Fix the wires,
whichis matchedwith
metal wafer, tothe shell
withthreescrews.
protecting
board

5
Figure10 Fix the grounding.
Figure11 Insert the blower. Figure12 Connect the port
and shell boardwithlinker
(maleport) intothethree
wires preset aside screws
(pleaserefer tolinker
(femaleport) preset (red,
yellow andblack) with
groundinglabel); add gasket
aside. switchseparately.
Codes betweenshell board
and on wires must
correspond groundingport
withthoseon the rocke
Figure13 Pushtherocker
switchintothe holeon the
panel.
Figure14 Insert the male
port, whichis on the black
power supply wire(marked
withP2), intothe
corresponding femaleport
(marked withP2).
Figure15 Insert the female
port, whichis on the white
power supply wire(marked
withP1), intothe
corresponding maleport.
(marked with P1).

6
Assembly Procedure forItem FBD3211R Optional Parts:
NOTICE: Shut off gas heater during the following blower installation.
Figure1
Removeupper
firebox by unscrewingleft
/rightscrews onthe fire
box.
Figure2 Unscrew two
screws onheat insulation
boardcover anddraw it out.
.
Figure3
Fix temperature
sensor toheat insulation
boardcover as shownin
the figure.
Figure4 Insert wires into
the spacebetweenwire
protectingboardand shell;
Fix the wires tothetop
cover withwirefixture.
Wire Fixture
Figure5 Connect
temperaturesensor with
lead; Install the cover
accordingtoFigure2, then
fix the upper firebox
accordingtoFigure1.
Figure8 Set Blower plane
and fix it ontotwobrackets
of shell board. Pleaserefer
toFigure7. Makesure
Blower isinstalled intothe
slots.
Install Bower
into slots
Figure9 Fix Blower with
one screw, after manually
install it intoslots.
protecting
board
Figure6 Unscrew and
removepanel on the left
side.
Figure7 Insert blower
assemblyintothe bottom
spaceof burner pan
accordingtoFigure8. Pay
attentionnot totouchwires
inside.

7
Figure10 Fix the wires,
whichis matchedwith
metal wafer, tothe shell
withthreescrews.
Figure11 Fix the grounding.
Figure12 Insert the blower.
Figure13 Connect the port
and shell boardwithlinker
(maleport) intothethree
wires preset aside screws
(pleaserefer tolinker
(femaleport) preset (red,
yellow andblack) with
groundinglabel); add gasket
aside. switchseparately.
Codes betweenshell board
and on wires must
correspond groundingport
withthoseon the rocker.
Figure14 Pushtherocker
switchintothe holeon the
panel.
Figure15 Insert the male
port, whichis on the black
power supply wire(marked
withP2), intothe
corresponding femaleport
(marked withP2).
Figure16 Insert the female
port, whichis on the white
power supply wire(marked
withP1), intothe
corresponding maleport.
(marked with P1).

8
Electrical Connection
A 15 amp, 120 Volt, 60 Hzcircuit withaproperly groundedoutlet is required.
Preferably, the fireplacewill be on adedicatedcircuit as otherappliances on the
samecircuit may causethecircuit breaker totripor the fusetoblow when theheater
is in operation.Plan the installation to avoid the use ofan extension cord.Extension cords
arefortemporary useonly. If an extensioncordmust beused,it must be UL/CSA certified,
rated at15A(1875W), 125Vmaximumwith14 AWGminimumand constructedoftwo
currentcarryingconductorswithground.Aheavy duty extension cordwiththe shortest
lengthpossibleforthe connectionisrecommended andmustnotbelongerthan 50 ft.
(15.2m). Donot coil or cover the extension cord.
Electrical outletwiringmust complywith local building codes and other
applicableregulationstoreduce therisk of fire, electrical shock and injury
to persons.
Do notuse thisfireplace if anypart of ithas been under water. Immediately
call aqualified service technician to inspect thefireplace and replace any
part of theelectrical system which has been underwater.
Grounding Instructions
This heater is for useon 120volts. The cordhas aplugas shownat A inFigure1.
Anadapter as shownat C is availablefor connectingthree-bladegrounding-type
plugs totwo-slot receptacles. The green groundinglugextending from the adapter
must be connectedtoapermanent groundsuchas aproperly groundedoutlet box.
The adapter shouldnot be used if athree-slot groundedreceptacleis available.

9
Operating Instructions
UsingRocker Switch, turnblower on and check for operation. Turnon Rocker Switchto
the desired position. Inthe MAN position it will remainconstantly on. AUTO position will
be controlledby theTemperatureSensor. Tostop the operation turnRocker Switchto
the OFF position.
Electrical Wiring Diagram
Any electrical repairs or rewiring of this unit shouldbe carried outby alicensed
electricianinaccordancewithnational andlocal codes.
If repairing or replacingany electrical component or wiring, the original wirerouting,
color coding and securing locations must be followed.
WARNING: Disconnect Power BeforeServicing.
Any electrical re-wiringof this appliancemust be doneby aqualified electrician. This
wiringmust be done inaccordancewithlocalcodes and/or inCanadawiththe current
CSA C22.1Canadian Electrical Code, and for US installations, theNational Electrical
CodeANSI/NFPA NO 70.
5
4
1.Power Cord
2.BushingStrain Relief
3.Fan
4.Temperaturelimiter
5.RockerSwitch
FAN
3
OFFAUTO MAN
t
1
~
120V
60Hz
2
GREEN
WHITE
BLACK
RED
BLACK

10
Maintenance ofMotors
Alwaysdisconnect theappliance from the main power supplyand allowit to
cool beforeanyservicing operation.
The motors used onthe fan heater andflameblower arepre-lubricated forextended
bearinglifeand requireno further lubrication. However,periodic cleaning/vacuuming
of the appliancearoundtheair intakeandexhaust, aswell as the fan heater is
recommended. For heavy or continuous use, periodic cleaning must be donemore
frequently. Ifthe heater blows alternating coldandwarm air, check the fan for free
movement and fordebris restricting air flow. If the fan doesnot movefreely, the unit
must be turnedoff and thefan replaced immediately inorder toprevent further damage
tothe unit.
WARNING: Makesurethepower is turned OFF beforeproceeding.
