Kozy-World GFNC3025 Quick start guide

1
WARNING: Ifthe informationinthismanual
isnotfollowedexactly, afireorexplosionmay
resultcausing propertydamage,personalinjury,
or lossof life.
*Aftermarket:Completionofsale,notforpurpose ofresale,
fromthemanufacturer.
Donotstoreoruse gasolineorotherflammable
vaporsand liquidsinthevicinityofthisor any
other appliance.
WHATTO DOIF YOUSMELL GAS
l Donottrytolight anyappliance.
l Donottouch anyelectricalswitch;do notuseany
phone inyourbuilding.
l Immediatelycallyour gassupplierfroma
neighbor sphone.Followthe gassupplier s
instructions.
l If youcannotreach yourgas supplier, call
thefiredepartment.
Installation and service must be performed bya
qualifiedinstaller,serviceagency, orthegas
supplier.
Thisappliancemay beinstalledinanaftermarket*,
permanentlylocated,manufactured(mobile)home,
wherenotprohibitedbylocalcodes.
Thisapplianceisonlyforusewiththe type of gas
indicated on theratingplate.Thisappliance isnot
convertibleforusewithothergases.
GFNC3025 GFPC3026
WARNING: Thisisanunvented gas-
fired heater. It usesair (oxygen)fromtheroom
inwhichitisinstalled.Provisionsfor ad-
equatecombustionandventilation air mustbe
provided.RefertoAirForCombustionand
Ventilation section onpage5ofthismanual.
Consumer:Pleaseretaintheseinstructionsforfuture
use.
InstaIIer:PleaseLeavetheseinstructionswiththecon-
sumer
FULLSIZEVENT-FREE
FIREPLACE
OWNER SOPERATIONAND
INSTALLATION MANUAL
WARNING: Improper installation,adjustment,
alteration,serviceor maintenance cancauseinjury
orpropertydamage.Refertothismanualforcorrect
installationandoperationalprocedures.Forassis-
tanceoradditionalinformation consultaqualified
installer, serviceagency,orgassupplier.
KW-FBL035-01HR/T-0608
World-MarketingofAmerican,Inc.
P.O.Box192,Rt.22West
MillCreek,PA17060
KOZY-WORLDPHONENUMBER:[phone]
http://www.worldmkting.com
Kozy-World R

2
IMPORTANT: Readthisowner s
manual carefullyand completely
beforetrying toassemble,operate,
orservice thisheater.Improper
useofthisheatercancause seri-
ous injuryordeathfromburns,
fire,explosion,electricalshock,
andcarbonmonoxide poisoning.
IMPORTIANTSAFETY
INFORMATION
DANGER: Carbonmonoxide
poisoning mayleadtodeath!
Carbon Monoxide Poisoning:
Earlysigns ofcarbonmonoxidepoi-
soningresemblethefluwith
headaches,dizziness,ornausea.
If youhavethesesigns,theheater
maynotbeworkingproperly. Get
fresh airimmediately! Haveheater
serviced.Somepeoplearemoreaf-
fectedbycarbon monoxidethan
others.Theseincludepregnant
women,peoplewithheart, orlung
disease,anemia,thoseunderthein-
fluenceofalcohol,andthoseathigh
altitudes.
WARNING:Anychange tothisfire-
placeoritscontrolscan be
dangerous.
WARNING: Donotallowfansto
blowdirectlyintotheheater.Avoidany
draftsthat alter burnerflamepatterns.
Ceilingfans cancreatedraftsthat al-
terburnerflamepatterns.Altered
burnerpatternscancausesooting.
Donotplaceclothingorother flam-
mablematerialonornearthe
appliance.Neverplaceanyobjects
inthe fireplace.
Duetohigh temperatures,theappli-
anceshouldbelocatedout oftraffic
andaway fromfurnitureand
draperies.
WARNING:Donotuse ablower
insert,heatexchangerinsert, or other
accessorynotapprovedfor usewith
thisheater.
Heaterbecomesveryhotwhen
running fireplace. Keepchildrenand
adultsawayfromhotsurfacesto
avoidburnsorclothing ignition.
Fireplacewill remainhot foratime
after shutdown.Allowsurfaces tocool
beforetouching.
Carefullysupervise young children
whentheyareinthe roomwith
fireplace.
Youmustoperatethisheaterwith
theheaterscreen inplace.Make
sureheaterscreenisinplace
beforerunningheater.
Keepthe applianceareaclearand
free fromcombustiblematerials,
gasoline,andotherflammable
vaporsand liquids.
1. Thisapplianceisonlyfor usewith
thetype of gas indicatedontherat
ing plate.Thisapplianceisnot con
vertibleforusewithothergases.
2. Donot placePropane/LPsupply
tank(s) inside anystructure.
LocatePropane/LPsupplytank(s)
outdoors.
3. If you smellgas
lShutoff gassupply.
lDonottrytolight anyappliance.
lDonot touch anyelectricalswitch:
donot useanyphoneinyour
building.
lImmediatelycall your gas supplier
fromaneighbor sphone. Follow
thegas supplier sinstructions.
lIfyou cannotreachyour gas
supplier, callthe firedepartment.
and toreplace anypartofthecon-
trolsystem,andanygascontrol,
whichhasbeenunderwater.
Important SafetyInformation ..............2
Air forCombustion and Ventilation.....5
AssemblyInstalltion.... ........................7
Installation.............................................9
Operating Heater,TAModels...........13
Cleaning&Maintenance.....................14
Troubleshooting..................................15
Specifications.....................................16
Replacement......................................16
PartsList..............................................17
WARNING
ModelGFNC3025 isequippedfor
Naturalgas.Fieldconversionisnot
permitted.
ModelGFPC3026 isequippedfor Pro-
panegas.Fieldconversionisnot
permitted.
Natual and Propane/LP Gas: Natural
andPropane/LPgasisodorless. An
odor-making agentisaddedtothegas.
The odorhelpsyoudetect agasleak.
However, theodoraddedtothegascan
fade.Gasmaybepresenteven though
noodorexists.
Makecertainyoureadandunderstand
all warnings.Keepthismanualfor
reference. It isyour guidetosafe
andproper operation ofthisheater.
TableofContents
4.Thisheatershallnotbeinstalled
inabedroomorbathroom.
5. Donotusethisheaterasa
wood-burningheater. Useonly
thelogsprovided withthe heater.
6. Donotadd extralogsorornaments
suchas pinecones,vermiculite,or
rockwool.Usingtheseaddeditems
cancausesooting.Donotadd lava
rockaroundbase. Rockand debris
couldfallintothe control area of
heater.Afterservicing, always
replace screenbeforeoperating
heater.
7. You mustoperatethisheater with
theheater screeninplace.Make
sureheater screenisinplace
beforerunning heater.

3
8.Thisheater isdesignedtobe
smokeless. If logsever appear to
smoke,turnoffheater andcalla
qualifiedserviceperson.
Note: Duringinitialoperation, slight
smokingcouldoccurdue tolog
curingand heaterburningmanufac
turingresidues.
9.Topreventthe creationofsoot,
followtheinstructionsin Cleaning
andMaintenance(page 12).
10.Beforeusingfurniturepolish,wax,
carpetcleaner,orsimilarproducts,
turnheateroff. If heated, the vapors
fromtheseproductsmay createa
whitepowderresiduewithinburner
boxoronadjacentwallsor furniture.
11.Thisheaterneedsfresh air ventila-
tiontorunproperly.Thisheaterhas
anOxygenDepletionSensing
(ODS) safetyshutoff system.
TheODSshutsdownthe heaterif not
enoughfreshairisavailable. See Airfor
CombustionandVentilation, pages5
through6.If heaterkeeps shutting off,
see Troubleshooting,pages16
through 17.
12.Donotrun heater:
l Whereflammableliquidsor
vaporsareusedor stored.
l Underdustyconditions.
13.Donotusethisheatertocook
foodorburnpaperorother objects.
14.Donot usethisheater if anypart
hasbeenunder water. lmmedia-
telycallaqualified service techni-
ciantoinspect the roomheater.
SAFETYINFORMATION
Continued
QUALIFIEDINSTALLINGAGENCY
Installation andreplacementofgas
piping,gas utilizationequipmentorac-
cessories and repairandservicing of
equipment shallbe performed onlyby
aqualified agency.Theterm “qualified
agency”meansanyindividual,firm,
corporation,orcompanythateither in
person orthrough arepresentative is
engagedinand isresponsiblefor(a)
the installation,testing,orreplacement
ofgaspipingor(b)theconnection,
installation,testing,repair,orservicing
ofequipment;thatisexperiencedin
suchwork; that isfamiliar withallpre-
cautionsrequired,and thathascom-
plied withallthe requirementofthe
authortyhavingjurisdiction.
15.Turnoffand unplugheater and
letcoolbeforeservicing.Onlya
qualifiedserviceperson should
serviceand repairheater.
16.Operatingheaterabove
elevations.
18.Topreventperformance
problems,donot usepropane/
LPfueltankof lessthan100lbs.
capacity.
PRODUCTFEATURES
SAFETYPILOT
Thisheaterhasapilot withan
OxygenDepletionSensing (ODS)
safetyshutoffsystem.TheODS/pilot
isarequiredfeatureforvent-free
roomheaters. TheODS/pilotshuts
offtheheaterif thereisnotenough
fresh air.
StateofMassachusetts: Theinstal-
lation mustbemadebyalicensed
plumberorgas fitterintheCommon-
wealthofMassachusetts.
Sellersofunventedpropane ornatu-
ralgas-firedsupplementalroomheat-
ersshall providetoeach purchasera
copyof 527 CMR30uponsaleofthe
unit.
InthestateofMassachusetts,
unventedpropaneor naturalgas-fired
spaceheatersshallbe prohibitedin
bedroomsand bathrooms.
Inthe StateofMassachusettsthe
gas cock mustbe a “T”handletype.
TheStateofMassachusettsre-
quiresthataflexibleappliancecon-
nectorcannotexceedthreefeetin
length.
17.Donotoperateheater if anylog
isbroken.Donotoperateheater
if anylogischipped(dime-sized
or larger).of4,500feet could
causepilotoutage.

4
UNPACKING
1. Remove topinnerpack.
2.Tiltcartonso thatfireplaceisupright.
3. Remove protectivesidepackaging.
4. Slide fireplace outofcarton.
5.Removeprotectiveplasticwrap.
6. Inastallfireplaceaccording toinstal
lationinstructiona forcorner.
7.Holdthescreen lift andpulling
forward.
8.Removelogsetbycuttingplastic
ties.
9. Carefullyunwrap log.
10. Checkforanyshippingdamage. If
stoveorlog isdamaged,promptly
informdealerwhereyoubought
stove.
PRODUCTIDENTIFICATION
Figure1- Vent Free LP/NG Gas Fireplace
WATERVAPOR:ABY-PRODUCTOFUNVENTEDROOMHEATERS
Watervaporisaby-productofgascombustion.Anunventedroomheater producesapproximatelyone(1)ounce
(30ml) of water forevery1,000BTU s(.3KW s)ofgas inputper hour.
Unventedroomheatersarerecommendedas supplementalheater(aroom). Rather thanaprimaryheatsource
(an entirehouse). Inmostsupplementalheatapplications,the watervapordoes notcreataproblem.Inmost
applications,thewater vaporenhances thelowhumidityatmosphereexperiencedduringcoldweather.Thefollowing
stepswill helpinsurethatwatervapordoesnotbecomeaproblem.
1.Besurethe heaterisasizedproperlyfor the application,including amplecombustionairandcirculationair.
2.If highhumidityisexperienced,dehumidifiermaybeusedtohelplowerthewatervapor content of the air.
3.Donot use an unventedroomheater astheprimaryheatsource.
lnstalland use heaterwithcare.
Followalllocalcodes.Inthe
absence oflocalcodes,usethe
latesteditionof The NationalFuel
Gas Code,ANSZ 223.1, alsoknown
as NFPA 54*.
*Availablefrom:
AmericanNationalStandards
lnstitute,lnc.
1430 Broadway
NewYork,NY10018
NationalFireProtection
Association,lnc.
BatterymarchPark
Quincy.MA02269
Thisheaterisdesignedforvent-
free operation.Stateand local codes
insomeareasprohibittheuseof
vent-freeheaters.
LOCALCODES

5
AIRFORCOMBUSTIONANDVENTILATION
WARNING:Thisheater
shall not be installedinaconfined
spaceorunusuallytightconstruc-
tionunlessprovisionsareprovided
foradequatecombustion and ven-
tilation air.Readthe following in-
structionstoinsureproperfresh
airforthisandotherfuel-burning
appliances inyourhome.
PROVIDING ADEQUATE
VENTILATION
Thefollowing areexcerptsfrom
NationalFuelGasCode, NFPA54/
ANSIZ223.1,Section5.3, Airfor
Combustionand Ventilation.
Allspacesinhomesfall intooneof
thethreefollowingventilation
classifications:
1.UnusuallyTightConstruction
2. Unconfined Space
3. Confined Space
Theinformationon pages5through6
willhelpyou classifyyour spaceand
provideadequateventilation.
Confined andUnconfined Space
TheNationalFuelGasCode,ANS
Z223.1 defines aconfinedspaceasa
spacewhosevolumeislessthan 50
cubicfeet per1,000 Btuperhour (4.8
m3perkw)ofthe aggregateinput
ratingof allappliancesinstalledinthat
spaceand anunconfining spaceasa
spacewhosevolumeisnotless
than50cubicfeet per1,000 Btuper
hour (4.8m3perkw) oftheaggregate
inputrating ofall appliances installed
inthat space. Roomscommunicat-
ingdirectlywiththe spaceinwhich
theappliancesareinstalled*,through
openingsnot furnished withdoors,
areconsidered apartofthe
unconfinedspace.
Thisheatershall notbeinstalledin
aconfinedspaceorunusuallytight
constructionunlessprovisionsare
providedforadequatecombustion
andventilationair.
* Adjoiningroomsarecommunicat-
ing onlyiftherearedoorlesspas-
sagewaysorventilation grillsbe-
tweenthem.
UnusuallyTightConstruction
DETERMINING FRESH-AIRFLOWFORHEATERLOCATION
DeterminingifYouHave aConfined orUnconfinedSpace
Usethisworksheettodetermineif you have aconfinedor unconfinedspace.
Space: Includesthe roominwhichyouwillinstallheaterplus anyadjoiningroomswithdoorlesspassageways
orventilationgrillsbetweentherooms.
1. Determine thevolumeof thespace(length×width×height).
Length×Width×Height= cu.ft.(volumeofspace)
Example: Spacesize 20ft.(length)×16ft.(width)×8ft. (ceilingheight)=2560cu. ft.(volumeofspace)
If additionalventilationtoadjoiningroomissupplied withgrillsor openings,addthevolumeofthese
roomstothetotalvolumeof thespace.
2.Dividethespacevolumeby50 cubicfeettodeterminethemaximumBtu/Hrthespacecansupport.
(volumeofspace) 50 cu.ft.=(MaximumBtu/Hr the spacecansupport)
Example: 2560 cu.ft. (volumeofspace) 50cu.ft.=51.2or 51,200(maximumBtu/Hrthe spacecansupport)
Theair that leaks arounddoorsand
windowsmay provideenoughfresh
airforcombustionandventilation.
However,inbuildings ofunusually
tightconstruction,youmustprovide
additionalfreshair.
Unusuallytightconstruction is
definedasconstructionwhere:
a) wallsand ceilingsexposedtothe
outsideatmospherehavea
continuouswatervaporretarder
witharating of oneperm(6×10-11 kg
perpa-sec-m2)orless with
openingsgasketedorsealed and
b)weatherstrippinghas been added
onwindowsthatcanbe opened
anddoors and
c) caulkingorsealantsareapplied
toareas such as jointsaround
windowanddoorframes, between
soleplates and floors,between
wall-ceiling joints,between wall
panels,atpenetrationsfor
plumbing,electrical,and gas
lines, andatother openings.
If yourhomemeetsall ofthe three
criteriaabove,you mustprovide
additionalfreshair.See VentilationAir
FromOutdoors(page6).
Ifyourhomedoes notmeetall ofthe
three criteriaabove,proceedto
DeterminingFresh-AirFlowFor
HeaterLocation(below).

6
WARNING:Reworkworksheet, adding
thespaceoftheadjoiningunconfined
space. Thecombinedspacesmusthave
enoughfreshair tosupplyallappliances in
bothspaces.
If the actualBtu/Hrusedislessthanthe maximumBtu/Hrthespace can support,the spaceisan
unconfinedspace.Youwillneednoadditionalfreshair ventilation.
3.AddtheBtu/Hrofallfuelburningappliancesinthespace.
Vent-free heaterBtu/Hr
Gas water heater* Btu/Hr
Gas furnaceBtu/Hr
Ventedgas heaterBtu/Hr
Gas heater logsBtu/Hr
Other gas appliances*+Btu/Hr
Total=Btu/Hr
*Donotincludedirect-ventgas appliances.Direct-ventdrawscombustion airfromtheoutdoorsand
ventstotheoutdoors.
4. Comparethe maximumBtu/Hrthespacecan supportwiththeactualamountofBtu/Hr used.
Btu/Hr (maximumthespacecan support)
Btu/Hr(actualamountof Btu/Hrused)
Example : 51,200Btu/Hr(maximumthespace cansupport)
56,000 Btu/Hr(actualamount of Btu/Hr used)
Thespaceintheaboveexampleisaconfinedspacebecause theactualBtu/Hrused ismorethan the
maximumBtu/Hrthe spacecansupport.
Youmustprovide additionalfresh air. Youroptions areasfollows:
A. Reworkworksheet, addingthespace ofan adjoiningroom.If theextraspaceprovidesanunconfined
space,removedoortoadjoining roomoradd ventilation grillsbetweenrooms. See Ventilation AirFrom
InsideBuilding (below).
B.Vent roomdirectlytothe outdoors.See VentilationAir FromOutdoors (below).
C. InstallalowerBtu/Hrheater,iflowerBtu/Hr size makesroomunconfined.
Figure2-VentilationAirfromInside Building
Example:
Gas waterheater30,000 Btu/Hr
Vent-free heater + 26,000 Btu/Hr
Total=56,000Btu/Hr
WARNING:If thearea inwhich theheatermaybeoperated issmallerthanthatdefinedas anunconfined
spaceorif the buildingisofunusuallytightconstruction,provideadequatecombustionandventilationairbyone
of themethodsdescribed intheNationalFuel GasCode,ANSI Z223.1,Section5.3 orapplicablelocalcodes.
Thisfreshairwouldcomefromanadjoining uncon-
finedspace.Whenventilatingtoanadjoininguncon-
fined space,you must providetwopermanentopenings:
one within12"oftheceiling andonewithin12"of the
flooron the wallconnecting the twospaces(see
options1and2,Figure2). Youcanalsoremovedoor
intoadjoiningroom(see option 3, Figure2). Followthe
National Fuel Gas Code.NFPA54/ANSI Z223.1, Sec-
tion 5.3,AirforCombustionand Ventilation forre-
quiredsize of ventilation grillsorducts.
VentilationAirFromlnsideBuilding
Ventilation AirFromOutdoors
Provide extrafreshair byusingventilationgrillsor ducts.
You mustprovidetwopermanentopenings:onewithin
12"of theceiling and onewithin12"of thefloor. Connect
these itemsdirectlytotheoutdoorsorspacesopento
theoutdoors.Thesespacesinclude attics andcrawl
spaces.Followthe NationalFuel Gas Code, NFPA54/
ANSI Z223.1, Section5.3,Air for Combustionand Ven-
tilation for required size ofventilation grillsorducts.
IMPORTANT: Donotprovide openingsforinlet oroutlet
airintoatticif attichas athermostat-controlledpower
vent.Heatedairenteringtheatticwillactivatethe power
vent.
Figure3-Ventilation AirfromOutdoors

7
INSTALLATION:
1.Surround mustbe installedflushwithwall.Baseboards
willpreventproperinstallationofsurround.
Baseboardscan bealteredtofit surroundbycutting
thatpartwithin34 1/2”distancefromthewallcorner.
2.Surround mustbe attached toeitherawall stud orwall
anchor.Useatapemeasuretodeterminecorrect
heightfromfloortolocation of mountingstrips.(See
Figure1). Makesurepointofthe miterededgeof
mountingstriptouchesthe corner.Usealeveltoen-
suremountingstripsareevenlybalanced.
IMPORTANT:Failuretobalance mountingstrips
withalevelcouldresultinunevensurfaceson
fullyassembledsurround.
3.Fastenmountingstriptowall byinserting2" screws
providedalong thepredrilled holesofmountingstrip.
If predrilled holesofmounting stripdonotline up with
wall studs,drill newholeswherewallstudsareorat-
tachtowallwithwall anchors.(SeeStep4below.)
4.Tousewall anchors,drillholesatmarkedlocation
using 5/16”drill bit. Foldwall anchor(see Figure2)
and insert(wingsfirst)intohole.Tap anchorflushinto
wall.Forthinwalls,insertred keyintowall anchorand
pushto “pop”openanchorwings(seeFigure3).
5.Repeatstepsabovetoattachothermounting strips
towall.Makesuremiterededgesfit togethertoform
acleanjointinthecornerofthewall.
ForCORNERSURROUND ANDHEARTH
READINSTRUCTIONSBEFOREBEGINNINGINSTALLATION.Checktoseethatyouhave
thefollowing.Ifanypartorpartsaremissing,contactthedealerwhereyouboughtthesur-
round andhearth.
TOOLSREQUIRED:
MeasuringTape,Pencil,Level,#2PhillipsScrewDriver,Hammer,ElectricDrill,5/6"DrillBit,
HandorElectricSaw
Figure1
Figure3
Figure2
AssemblyInstructions
191/2”191/2”

8
6.Placethe assembledfireplaceonthemiddlewhereitis30”fromthecornerandforma
45degree angletoeachsidewall.Movethe assembled surroundtothe corner,with
sidepanelsclosetosidewalls.Movethefireplacetowhereitcanproperlyattachthe
surround.
7.Movethe surround away, markfloororwall behind fireplaceforgasline entrance.
Connectinletgaspipe.
IMPORTANT:Makesuretherearenoelectrical lines wheregas pipingwill go
throughfloororwall.
8.Turnup the back ofmanteltop, the specialspring will lock the rearmanteltopin
position,thenusescrewstosecurebracketasshowinFigure5makesurethe front
andrearmanteltopareinthesamelevel.
9.Movethesurroundback.Setsurroundtopontopofmountingstripsandmantelfront.
Afterproperlyinstalling thetop,attachsurroundtop tomountingstripusingfinishing
nails.
10.Pushthe basetothebottomofsurround,closetotherightandleftsides.
11.InstallfireplaceperHomeowner sInstallation Manual.
Figure4 Figure5
Figure6

9
NOTICE: Thisheateris
intended foruse as supplemen-
talheat.Use thisheateralong with
yourprimaryheating system.Do
notinstallthisheateras your
primaryheatsource.If you have
acentral heating system,you
mayrunsystem'scirculating
blowerwhileusingheater. This
will helpcirculatethe heat
throughoutthe house.
INSTALLATION
WARNING: Aqualifiedtechni-
cianpersonmustinstallheater. Fol-
lowalllocalcodes.
WARNING: Neverinstallthe
heater
l inabedroomorbathroom
l inarecreationalvehicle
l wherecurtains,furniture,clothing,
orotherflammableobjectsare
less than42 inches fromthe
front, top,orsidesof theheater
l inhightrafficareas
l inwindyor draftyareas
WARNING: Maintainthemini-
mumclearances.If youcan, pro-
vide greater clearancesfromfloor,
ceiling,and adjoining sideand
back walls.
warmaircurrents.Thesecurrents
moveheat towallsurfacesnextto
heater.Installingheaternext tovinyl
orclothwallcoveringsoroperating
heaterwhereimpurities (such as
tobaccosmoke,aromaticcandles,
cleaning fluids,oilorkerosene
lamps,etc.)intheairexist,may
discolorwalls.
IMPORTANT: Vent-freeheatersadd
moisturetothe air. Although thisis
beneficial,installingheaterinrooms
withoutenoughventilationairmay
cause mildewtoformfromtoomuch
moisture.See AirforCombustion and
Ventilation,pages5through6.
CHECK GAS TYPE
Use onlythetypeofgas indicatedon
theplate.If yourgassupplycan not
meetthatrequirement,donotinstall
heater.Callthe dealerwhereyou pur-
chasedheater, forthe propertype of
heater.
Figure4-MinimumClearance toWall and Ceiling
CLEARANCESTOCOMBUSTIBLES
Carefullyfollowtheinstructionsbelow.
Thisfireplaceisafreestandingunit
designedtoset directlyonthefloor.
IMPORTANT:You mustmaintain
minimumwallandceilingclearances
duringinstallation.The minimum
clearances areshowninFigure4.
Measurefromoutermostpoint of stove
top.
MinimumWallandCeilingClearances
(seeFigure4)
A. Clearances fromoutermost point
offireplacetoptoanycombustible
sidewall shouldnotbelessthan
0inches.
B.Clearancesfromthefireplacetop
tothe ceilingshouldnotbe less
than 48inches.
CAUTION: Thisheater creates
48”
Minimum

10
CONNECTINGTO GAS
SUPPLY
WARNING: Aqualifiedtechni-
cianmust connect heater togas
supply. Followall localcodes.
CAUTION: Never connectheater
directlytothegas supply. Thisheater
requires an externalregulator(not
supplied). lnstall theexternalregu-
latorbetweentheheaterand gas
supply.
INSTALLATION ITEMSNEEDED
Beforeinstalling heater,makesure
youhavethe itemslisted below.
l piping(checklocalcodes)
lsealant(resistanttopropane/LP
gas)
lequipmentshutoffvalve*
ltestgauge connection**
lsedimenttrap
ltee joint
lpipewrench
lFlexibleGas hose(check localcode)
*ACSAdesign-certified equipment
shutoffvalvewith1/8" NPT tapisan
acceptablealternativetotestgauge
connection.Purchase the optional
CSA design-certifiedequipment
shutoffvalvefromyour dealer.
Figure5-Gas RegulatorLocation
and Gas Line Access IntoFire-
place Cabinet
Figure6-External RegulatorWith
VentPointing Down
Figure7-Gas Connection
Theinstallermustsupplyanexternal
regulator.Theexternalregulatorwill
reduceincoming gas pressure.You
must reduce incominggaspressure
tobetween11and 14 inches of water.
Ifyou do notreduceincoming gas
pressure,heaterregulatordamage
couldoccur. lnstallexternalregulator
withthe vent pointingdownasshown
inFigure6.Pointing theventdown
protectsitfromfreezing rainor sleet.
*Purchasethe optionalCSAdesign-certified equipmentshutoffvalve
fromyourdealer.
**Minimuminletpressureforpurposeof input adjustment.
NGModels:
5”to10.5”W.C.
Gassupplierprovideexternal
regulatorfornaturalgas
INSTALLATION
Continued
WARNING: Neverconnect
heatertoprivate(non-utility)gas
wells.Thisgasiscommonlyknown
as wellheadgas.
FrontView
CAUTION: Onlyuseanewblack
iron orsteelpipe.Internally-tinned
coppertubing maybeusedin
certainareas.Check you local
codes. Usepipeof1/2"diameteror
greater toallowproper volumegas
toheater. If pipeistoo small, undue
loss ofpressurewilloccur.
Installationmustinclude anequip-
mentshutoff valve,union,and
plugged 1/8"NPTtap. LocateNPT
tap withinreach for testgauge hook
up.NPTtap mustbe upstream
fromheater(seeFigure7).
IMPORTANT:Install equipment
shutoff valveinan accessiblelocation.
The equipmentshutoff valve isfor
turning on or shutting off thegasto
theappliance.Applypipejointsealant
lightlytomalethreads.Thiswillpre-
ventexcess sealantfromgoing into
pipe.Excesssealantinpipecould
result incloggedheatervalves.
CAUTION: Usepipejointseal-
antthatisresistanttogas
(PROPANE or NG).
Werecommendthatyouinstalla
sedimenttrapinasupplylineas
showninFigure7.Locatesediment
trapwhereitiswithinreachforcleaning.
Install inthepiping systembetween
fuelsupplyandheater.Locatesedi-
menttrapwheretrappedmatter isnot
likelytofreeze. Asediment traptraps
moistureand contaminants.This
keepsthemfromgoing intoheater
controls.Ifsedimenttrapisnotin-
stalledorisinstalledincorrectly,
heatermay notrun properly.
CAUTION: Avoiddamageto
regulator. Holdgas regulatorwith
wrench when connectingintogas
pipingand/orfittings.
Propane/LP
SupplyTank

11
WARNING: Neveruseanopen
flametocheckforaleak.Applya
mixtureofliquidsoap andwater to
alljoints.Bubblesformingshowa
leak.Correctall leaksimmediately.
CAUTION: Makesureexternal
regulatorhasbeeninstalledbe-
tweengassupplyand heater. See
guidelines under Connecting toGas
Supply (page8).
Figure8-Equipment Shutoff Valve
PressureTestingGas
SupplyPipingSystem
Test Pressures InExcessOf 1/2
PSIG(3.5kPa)
1.Disconnectheaterwithits
appliancemaingas valve (control
valve) andequipmentshutoff valve
fromgas supplypiping system.
Pressures inexcess of1/2psig
will damageheaterregulator.
2. Capoff openend of gas pipe
whereequipmentshutoffvalve
was connected.
3.Pressurizesupplypipingsystem
byeitherusingcompressed airor
openinggas supplytankvalve.
4.Check all jointsofgas supply
pipingsystem.Applymixtureof
liquidsoapand watertogas
joints.Bubblesforming showa
leak.
5. Correct all leaksimmediately.
6.Reconnectheaterand equipment
shutoff valvetogassupply.Check
reconnectedfittingsforleaks.
PressureTesting Heater
Gas Connections
1.Openequipmentshutoffvalve
(seeFigure8).
Figure9-Checking Gas Joints
CHECKING GASCON-
NECTIONS
WARNING: Test all gas piping
and connectionsforleaksafter
installingorservicing.Correctall
leaksimmediately.
INSTALLATION
Continued
2. Opengassupplytankvalve.
3. Makesurecontrolknobofheateris
intheOFFposition.
4.Checkall jointsfromequipment
shutoff valvetocontrolvalve
(Figure9). Applymixtureofliquid
soap andwatertogasjoints.
Bubbles formingshowaleak.
5.Correct all leaksimmediately.
6. Lightheater(see Operating
Heater, page11).Checkallother
internaljointsforleaks.
7.Turnoff heater(see Operation of
Turn-Off , page11).
TestPressuresEqualToor
Less Than 1/2PSIG(3.5kPa)
1.Closeequipmentshutoffvalve
(seeFigure8).
2.Pressurize supplypipingsystem
byeitherusing compressedair
oropeninggassupplytankvalve.
3.Check all jointsfromgas meterto
equipmentshutoffvalve(see
Figure9).Applymixtureofliquid
soapandwatertogasjoints.
Bubblesformingshowaleak.
4.Correct allleaksimmediately.

12
INSTALLATION
Continued
WARNING: Failuretoposition
thepartsinaccordance withthese
diagramsorfailuretouse onlyparts
mayresultinpropertydamageor
personalinjury.
CAUTION: After installationand
periodicallythereafter, checktoen-
surethatnoflamecomes in
contactwithanylog. Withtheheater
settoHigh,checktoseeifflames
contact anylog.If so, reposition logs
according totheloginstallation
instructionsinthismanual. Flames
contacting logs willcreatesoot.
INSTALLINGLOGS
It isveryimportant. Toinstallthelogsexactlyasinstructed. Donot modify
logs.Onlyuse logssuppliedwall heater.
IMPORTANT:Make surelog doesnot coveranyburnerports(see
Figure10).
Figure10-InstallingLog Set
FIG(1) FIG(2)
STEP 1:Install log1ontothetwo
slotsintherearplateas shown.
STEP2:Installlog2ontothe twoslotsin
therear plateas shown.
STEP3:Installlog3ontothe twoslotsin
the frontplateasshown.
FIG(3) FIG(4)
STEP4: Inserttherecessholeonthe
bottomoflog4ontothepinonlog 1,with
theouterendof log4placed onlog3as
shown.
STEP5: Insert the recessedholeonthe
bottomoflog5ontothepinonlog 2,with
theouterendof log5placed onlog3as
shown.
FIG(5) FIG(6)
1. All logs.

13

14
Figure12 -CorrectPilot FlamePattern
PILOTFLAMEPATTERN
Figure12showsacorrectpilot
flamepattern.Figure16showsan
incorrectpilotflamepattern.The
incorrectpilotflameisnot touching
thethermocouple.Thiswill cause the
thermocoupletocool.Whenthe
thermocouplecools,theheater
will shutdown.If pilotflamepattern
isincorrect, as showninFigure13
lTurnheateroff (seeTOTURNOFF
GAS TOAPPLIANCE, page10)
lseetroubleshooting, page15.
Figure13-Incorrect Pilot Flame
Pattern
Figure14showsacorrectburner
flamepattern.Figure15 showsan
incorrectburnerflamepattern.If
burnerflameisincorrect:
lTurnheater off(see TOTURNOFF
GAS TOAPPLIANCE, page10)
lseetroubleshooting, page15.
BURNERFLAMEPATTERN
Figure14 -CorrectFlamePattern
withControlKnobSet toHighFlame
Figure15-IncorrectFlamePattern
withControlKnobSet toHighFlame
WARNING: Disconnectpower be-
foreattempting anymaintenance or
cleaning toreducethe risk offire, elec-
tricshook orpersonalinjury.Turnoff
heaterandletcoolbeforecleaning.
CLEANINGAND MAINTENANCE
CAUTION: You mustkeepcontrol
areas, burner, andcirculatingairpas-
sagewaysofheaterclean.Inspect
these areasofheaterbeforeeach
use. Haveheaterinspectedyearlyby
aqualifiedserviceperson.Heater
mayneedmorefrequent cleaningdue
toexcessive lintfromcarpeting,
beddingmaterial,pethair,etc.
CLEANING ODS/IGNITOR AND
BURNER
Cleanwithavacuumcleaner.
CLEANINGBURNER
INJECTOR HOLDERAND
PILOTAIRINLETHOLE
Werecommend thatyou cleantheunit
everythree monthsor after2500 hours
of operation.Wealsorecommendthat
youkeepthe burnertubeandpilot as-
semblyclean andfree ofdustand
dirt. Toclean these partswerecom-
mend usingcompressed airnogreater
than30 PSI. You can use avacuum
cleanerinthe blowposition.Ifusing
compressedairinacan,pleasefol-
lowthedirections onthecan.Ifyou don't
followdirectionson thecan,youcould
damagethepilotassembly.
WARNING: Failuretokeep
primaryairopeningsofburnersclean
may resultinsooting andproperty
damage.
1.Shutoff theunit, includingthe
pilot. Allowthe unit tocoolforat
leastthirtyminutes.
2.Inspect burner, pilot andprimaryair
inletholes oninjectorholderfor
dustanddirt (see figure21).
Figure16-InjectorHolderOnOutlet
BurnerTube
Cleanthepilot assemblyalso.A
yellowtipon thepilot flame
indicates dustanddirtinthepilot
assembly.Thereisasmall pilotair
Figure17 -Pilot AirInlet Hole
CABINET
AirPassageways
l Useavacuumcleaner or
pressurizedairtoclean.
inlet holeabouttwoinchesfrom
wherethepilotflamecomes out of
thepilotassembly(see Figure17).
Withtheunit off, lightlyblowair
throughtheairinlet hole.Youmay
blowthrough adrinkingstrawif
compressedairisnotvailable.
3.Blowairthroughtheports/slots
andholesinthe burner.
4.Checktheinjectorholderlocated
attheendofthe burnertube
Exterior
l Useasoftclothdampened witha
mildsoapand watermixture. Wipe
the cabinet toremove dust.
LOGS
l If youremovelogsfor cleaning,
referto InstallingLogs (page10)
toproperlyreplace logs.
l Replacelogs if broken or chipped
(dime-sizedorlarger).
MAINBURNER
Periodicallyinspectall burnerflame
holes withtheheaterrunning.All
slottedburnerflameholes should
be openwithyellowflamepresent.All
roundburnerflameholesshouldbe
open withasmallblueflame
present.Someburnerflameholes
may becomeblockedbydebrisor
rust,withnoflamepresent. Ifso,
turnoffheaterandletcool.Either
removeblockageorreplaceburner.
Blockedburnerflameholes will
createsoot.
again.Removeanylargeparticles
of dust,dirt, lint, orpet hair witha
softclothorvacuumcleaner
nozzle.
5.Blowairintothe primaryairholes
ontheinjectorholder.
6.Incase anylargeclumpsofdust
have nowbeenpushed intothe
burner,repeatsteps 3and4.

15
OBSERVEDPROBLEM POSSIBLECAUSE REMEDY
TROUBLESHOOTING
WARNING:Makesurethat power
isturnoffbeforeproceeding....
WARNING: Turnoffandletcool
beforeservicing.Onlyaqualified
servicepersonshouldservice and
repairfireplace.
CAUTION:Neveruseawire,
needle,orsimilarobject toclean
ODS/pilot. Thiscan damage ODS/
pilotunit.
WARNING:Ifyou smell gas
l Shutoff gassupply.
l Donottryto lightanyappliance.
l Donottouchanyelectricalswitch;do notuse anyphonein your
building.
l Immediatelycallyourgassupplierfromaneighbor sphone.
Follow thegassupplier sinstructions.
l Ifyou cannotreachyourgassupplier,call thefire department.
Delayed ignition burner 1. Manifoldpressureistoolow
2. Burnerorifice clogged
1. Contactlocalgascompany
2.Cleanburner(see Cleaning and
Maintenance, page13)
Burnerbackfiringduringcombustion 1.Damaged burner
2. Gasregulatordefective
1. Cleanburnerorifice(see
CleaningandMaintenance, page
13)
2.Replace gasregulator
Slight smokeor odorduring initial
operation
1.Residues frommanufacturing
processes
2. Not enoughair
3. Gasregulator defective
1.Problemwill stopafterafew
hoursofoperation
2. Check burner for dirt and debris.
If found, cleanburner(seeCleaning
andMaintenance,page 13)
3.Replace gasregulator
Darkresidueonlogsorinsideof
fireplace
1.Improperlogplacement
2. Air holesatburner inlet blocked
3.Burnerflameholesblocked
1. Properlylocatelogs(see installing
logs,page10)
2.Cleanoutairholesat burner inlet.
Periodicallyrepeatasneeded.
3. Remove blockageor replaceburner
Heaterproducesaclicking/ticking
noisejustafter burnerislit or
shut off
1.Metalexpandingwhileheating
orcontractingwhilecooling
1. Thisiscommon withmost
heaters.Ifnoiseisexcessive,
contact qualified technician.
Burnerdoesnotlight after ODS/pilot
islit
1.Burner orifice clogged
2.Inletgaspressureistoolow
3. Burner orifice diameteristoo
small
4.Thermocoupleleadsdiscon-
nectedorimproperlyconnected
5. Burnerswillnotcomein
remoteposition
1.Clean burner (seeCleaning
and Maintenance,page13)or
replaceburner orifice.
2.Contactlocalpropane/LP
gascompany
3. Replace burnerorifice
4.Reconnect leads(seewiring
diagram)
5. Replacebatteryintransmitter
andreceiver

16
l Yourname
l Your address
l Modelandserialnumbers
of yourheater
l Howheater wasmalfunctioning
l Typeof gasused(propane/LPor
NG)
l Purchasedate
REPLACEMENTPARTS
l Warrantycard
Usually,wewill askyou
toreturnthe defective parttothe
factory.
REPLACEMENTPARTS
NOTE: Useonlyoriginalreplace-
ment parts.Thiswillprotectyour
warrantycoverageforpartsre-
placedunderwarranty.
PARTS UNDERWARRANTY
Contactauthorizeddealersofthis
product.If theycan'tsupplyoriginal
replacementpart(s), callKOZY-
WORLD sTechnicalServiceDepart-
mentat(814)643-1775forreferral
information.
PARTS NOTUNDER
WARRANTY
Contactauthorizeddealersofthis
product.If theycan t supplyoriginal re-
placementpart(s)call KOZY-WORLD s
PartsDepartmentat(814)643-1775for
referralinformation.
Whencalling KOZY-WORLD, have ready
l Modelnumber of yourheater
l The replacementpart number
SPECIFICATIONS
Btu(Variable)28000 28000
GasType LPGasNaturalGas
Ignition Piezo/AutomaticPiezo/Automatic
ManifoldPressure8"W.C. 3"W.C.
InletGasPressure
(In.ofwater)*
Maximum14"10.5"
Minimum11"5"
Dimensions,Inches(H×W×D)
Heater36 1/4”×53 13/16”×29 1/2”36 1/4”×53 13/16”×29 1/2”
Carton 40 5/8”×54 3/4”×18 1/8”40 5/8”×54 3/4”×18 1/8”
Weight, lbs
Fireplace130130
Shipping157 157
Voltage 120 120
Watt2727
*Forpurposesofinputadjustment
GFPC3026 GFNC3025

17
PARTSLIST
GFNC3025 GFPC3026
LPNG
SIT545-218T-STATVALVE1
SIT545-200T-STATVALVE1
NRV81F1-3REGULATOR1
NRV81F1-8REGULATOR1
BL023-01INJECTOR1
BL024-01INJECTOR1
NBY28-025B3BURNERASSEMBLY1
NBY28-160B3BURNERASSEMBLY1
ND1703X400X4ODS1
ND1908X400X4ODS1
1
2
3
4
5
QUALITY
KEYNOPARTNUMBERDESCRIPTION
Thislistcontains replaceablepartsusedinyourheater. When ordering
parts,followthe instructions listedunderReplacementParts onpage17
ofthismanual.

18
PARTSLIST
GFNC3025 GFPC3026
Thislistcontains replaceablepartsusedinyourheater. When ordering
parts,followthe instructions listedunderReplacementParts onpage17
ofthismanual.
LPNG
1BB26000LOGS11
2FB280AC6-01 TOPPANEL11
3FB280AC6-03 SIDE PANEL11
4FB280AC6-04 SIDE PANEL11
5FB280AC6-05 BASE11
6FB280AC6-02 UPPERPANEL11
7FBL001-01BODYTOP COVER11
8FBL008-01BBAFFLE11
9FBL006-01BSIDE REFLECTOR22
10 FBL007-01AFIREBOXFLOOR11
11 FBL002-01LOUVER88
12 FBL001-03RHBODYBOTTOMCOVER11
13 FBL001-02SBODY BOARDING11
14 FBL010-01BUPPERPANEL11
15 FBB102SCREEN11
16 ML083-02IGNITOR11
17 FBL015-01T-STAVALVE BRACKET11
18 QL016-03RBLOWERMOUNTPANEL11
19 PF06-YJLF-FFAN11
QUALITY
KEYNOPARTNUMBERDESCRIPTION
