Kozy-World®
EF5540R
Freestanding
Electric Fireplace
Installation Instructions and Homeowner's Manual
ANSI/UL 1278. MOVABLE AND WALL-OR CEILING HUNG ELECTRIC ROOM HEATERS
INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HOME OWNER
CUSTOMER: PLEASE RETAIN THIS MANUAL FOR FUTURE USE
WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.
Comfort Home Products, Inc.
12256 William Penn Hwy, Ste A
Huntingdon, PA 16652
FOR YOUR SAFETY
DO NOT STORE
OR USE GASOLINE OR
OTHER FLAMMABLE VAPORS
OR LIQUIDS
IN THE VICINITY OF THIS OR
ANY OTHER APPLIANCE
KOZY WORLD PHONE NUMBER: [phone]
http://www.worldmkting.com

TABLE OF CONTENTS
PLEASE READ THE INSTALLATION & OPERATIONS INSTRUCTIONS
BEFORE USING THIS APPLIANCE
IMPORTANT: Read all instructions and warnings carefully before starting installation.
Failure to follow these instructions may result in a possible electric shock, fire hazard
and will void the warranty.
Installation instructions……………………………………….………………..............…...2
General………………………………………………………………………….…..…...2
Locating Your Electric Fireplace………………………………...……………...….….2
Clearance To Combustibles…………………….…………………………...………...3
Electrical Connections……………………………………………..………...………...3
Electrical Specifications………………………………..…………………...………….3
Operating Instructions……………………….................................…………………….....4
Heater Controls..……………………………………….……………………....…....….4
Thermostat Control..…..……………………………….……………………....……….4
Remote Control......................................................................................................4
Instructions for power………….…………………………………..……………………6
Service Instructions………………………………………………………………………......5
Replacing Light Bulbs……………………………………………………………….….5
Glass Information………………………………………...………………………….….5
Maintenance of Motors……………………………………...…………………...….…5
Cleaning Instructions.......…………………………………………..……………....….5
Heater Specifications………...…………....……………………………………………6
1

1.Read all instructions before using this
appliance.
2.This appliance is hot when in use. To avoid
burns, do not let bare skin touch hot surfaces.
Keep combustible materials, such as furniture,
pillows, bedding, papers, clothes, and curtains at
least 3 feet from the front of this appliance.
3.CAUTION: Extreme caution is necessary
when any heater is used by or near children
or invalids and whenever the heater is left
operating and unattended.
4.Always unplug heater when not in use.
5.Do no operate any heater with a damaged
cord or plug or after the heater malfunctions,
has been dropped or damaged in any manner.
6.Any repairs to this appliance should be carried
out by a qualified service person.
7.Under no circumstances should this electric
fireplace be modified. Parts having to be
removed for servicing must be replaced prior to
operating this electric fireplace again.
8.Do not use outdoors.
9.This heater is not intended for use in bath-
rooms, laundry areas or similar indoor locations.
Never use this appliance near a bathtub or
vicinity of water.
10.Do not run cord under carpeting. Do not cover
cord with throw rugs, runners or the like. Arrange
cord away from traffic areas and where it will not
be tripped over.
11.To disconnect this appliance, turn controls to
the off position and remove plug from outlet.
12.Connect to properly grounded outlets only.
13.When this appliance is installed, it must be
electrically grounded in accordance with local
codes with the current CSA C22.1 Canadian local
codes for USA installations. Follow local codes
and National Electrical Code, ANSI/NFPA NO.70
and Canadian Code, CZ 22.2 No. 0.
14.Do not insert or allow foreign objects to enter
any ventilation or exhaust opening as this may
cause electric shock, fire or damage to the
appliance.
15.To prevent fire, do not block air intakes or
exhaust in any manner. Do not use on soft
surfaces, such as a bed, where openings may
become blocked.
16.CAUTION: This appliance gets hot and it
contains internal parts that could arc or spark.
Do not use it in areas where gasoline, paint, or
flammable liquids are used or stored. This
electric fireplace should not be used as a drying
rack for clothing. Also, do not have Christmas
stockings or decorations hung on or near it.
17.Use this appliance only as described in this
manual. All other uses not recommended by the
manufacturer may cause fire, electric shock or
injury.
18.Avoid the use of an extension cord because it
may overheat and cause a fire hazard. However
if you must use an extension cord, the cord shall
be 16 AWG, 1875 Watts. The extension cord
must be a three wire cord with grounding type
plug and cord connector.
19. Do not burn wood or other materials in this
fireplace.
20.SAVE THESE INSTRUCTIONS.
LOCATING YOUR ELECTRIC FIREPLACE
Your new freestanding electric fireplace may
be installed virtually anywhere in your home.
However, when choosing a location for your
new electric fireplace, ensure that the general
instructions are followed. For best results,
install the electric fireplace out of direct
sunlight.
2
IMPORTANT SAFETY INSTRUCTIONS
GENERAL

CLEARANCE TO COMBUSTIBLES
ELECTRICAL CONNECTION
A15 AMP, 120 Volt, 60Hz circuit with a properly
grounded outlet is required. Preferably, the
heater will be on a dedicated circuit. Other
appliances on the same circuit may cause the
circuit breaker to trip or the fuse to blow when the
heater is in operation. The unit comes standard
with a 6' (1828mm) long three wire cord exiting
from the rear of the fireplace. Plan the installation
to avoid the use of an extension cord. If an
extension cord must be used, it must be a mini-
mum 16 AWG three wire with grounding type plug
connector and rated no less than 1875 Watts.
ELECTRICAL SPECIFICATIONS
3
Back………….…0"/0mm
Sides……………0"/0mm
Floor…….………0"/0mm
Top…….........….24"/610mm
Front...................36”/915mm
WARNING: Electrical
outlet wiring must comply with
local building codes and all
other applicable
regulations to reduce the risk
of fire, electrical shock and
injury.
WARNING: Do not use this
fireplace if any part of it has
been under water. Immediately
call a qualified service
technician to inspect the
fireplace and replace any part
of the electrical system if
necessary.
Voltage................120 VAC/60Hz
Total Amps...........11.3 Amps
Total Watts...........1500 Watts
Heater Ratings.....1400 Watts (+5%,-10%)
WARNING: This is a 1500 watt heater and parts
become hot when in use. Be sure to maintain a
personal distance and keep any combustible material
at least three (3) feet away from the heater.
CAUTION:
KEEP CHILDREN AND PETS AWAY FROM THE HEATER AND CONTROLS.

LIft front grill to access the switches.
ON/OFF: Main power and flame effect. The
red indicator light will turn on when heater is
on.
FLAME/LOG: Press this button once for
flame effect. The unit will beep and the indi-
cator light will turn on. The bulbs for flame
effect & logset will be on. Pressing button
again will turn off the light function.
750W:For low heat function - Press this but-
ton while the ON/OFF switch is in the ON
position. The indicator light will turn on.
Pressing button again will turn off the low
heat function.
OPERATION USING REMOTE CONTROL:
ON/OFF: Press this button to turn on the
main power.
FLAME/LOG:
To change the brightness of the
flame effect, press and hold the flame/log button.
The brightness will adjust. Let go of the button
when desired brightness is acquired.
750W: Press this button and the fireplace will
work at 750W. Pressing again will turn it off.
1500W: Press this button and the fireplace
will work at 1500W. Pressing again will turn it
off.
1500W: For high heat function - Press this
button while the ON/OFF button and 750W
button are in the ON position. The indicator
light will turn on. Pressing button again will
turn off the high heat function.
TEMPERATURE CONTROL: To adjust the
temperature, turn the temperature control dial
to the right (clockwise) to increase to the
desired temperature and to the left for lower
temperature. This temperature control dial
can only be used while the ON/OFF button
and 750W & 1500W buttons are in the ON
position. When the heater reaches the
desired temperature, the heater and
750W/1500W indicator light will turn off and
the fan will stop working for air flow.
4
OPERATING INSTRUCTIONS
Controls and switches are located behind the grill below front glass and can be
accessed by pulling the grill up from the top, forward and down.
Note: When the ON/OFF button is turned OFF, all other functions will stop even though the
buttons may be in the ON position.

REPLACING LIGHT BULBS
CAUTION: The bulb in your unit can become
extremely hot. Allow at least 15 minutes between
turning off the unit and removing the light bulbs to
avoid hot bulbs coming in contact with the skin.
There is one (1) 40W Type B-10 bulb for the
flame generation.
1. Unplug the unit.
2. Remove four (4) screws on the back of
fireplace and remove the rear cover of the unit.
3. You will find one 40W Type B-10 bulb under
logset bed.
4. Loosen and remove burnt out bulb and
replace with new bulb.
5. Close the rear cover and secure the four (4)
screws.
6. Plug in the unit.
MAINTENANCE OF MOTORS
The motors used on both blower fan and
flame simulator assembly are prelubricated
for the extended warranty of the motor, no
further lubrication is required. However,
periodic cleaning/vacuuming of the fan/heater
unit is recommended.
GLASS INFORMATION
1. Under no circumstances should this
product be operated with missing or broken
glass.
2. Do not strike or slam the glass.
3. Do not use abrasive cleaners to clean the
glass.
4. Replacement glass is available from the
manufacturer and replacement should be
carried out by a qualified service person.
CLEANING
To clean the unit, first turn off controls on unit
and unplug unit from power source.
To clean the glass door: remove dust with
clean dry cloth or to remove finger prints and
other marks clean glass with clean damp
cloth. Do not use abrasive cleaners or spray
liquids on glass door surfaces.
Metal and metal painted parts should be
cleaned with clean damp cloth only. Do not
use abrasive cleaners or spray liquids on this
surface.
5
WARNING: Make sure
that the power is turned
off before proceeding.
WARNING: Wait until the
unit has completely
cooled before attempting
any cleaning.
SERVICE INSTRUCTIONS
WARNING: Disconnect power
before attempting any
maintenance or cleaning to
reduce the risk of fire, electrical
shock or personal injury.
WARNING: Do not exceed
40 Watts for light bulb.
Use of a higher rated bulb
may result in a fire
causing property damage
and personal injury.

INSTRUCTIONS FOR POWER
This heater is for use on 120 volts only. The cord has a plug as shown in the following figure.
WARNING: Before servicing this heater be sure to unplug heater from wall outlet. Do
not only turn off heater from the main “ON/OFF” switch, be sure to unplug this heater.
SPECIFICATIONS:
Model: EF5540R
Voltage: 120V/60Hz
Total Amps: 11.3A
Total Watts: 1500W
Heating Ratings: 1400W (+5%, -10%)
Dimensions, Inches (H x W x D):
Fireplace: 38.98X38X9.45
Carton: 42.52X41.73X12.80
6
