Kramer TOOLS VM-2C User manual

KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
VM-2C
1:2 Component Video DA
P/N: 2900-000112 Rev 2

VM-2C – Contents
i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 3
2.3 Recycling Kramer Products 3
3Overview 4
3.1 Defining the VM-2C 1:2 Component Video DA 4
4Connecting the VM-2C 5
5Technical Specifications 6
Figures
Figure 1: VM-2C 1:2 Component Video DA 4
Figure 2: Connecting the VM-2C 1:2 Component Video DA 5

VM-2C - Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Products.
Congratulations on purchasing your Kramer VM-2C 1:2 Component Video DA,
which is ideal for the following typical applications:
Component video signal distribution
Video duplication studios, delivering undiminished quality duplicates

2
VM-2C - Getting Started
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer VM-2C away from moisture, excessive sunlight and
dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
!

VM-2C - Getting Started
3
2.2 Safety Instructions
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the Kramer Electronics input power wall
adapter that is provided with the unit
Warning:
Disconnect the power and unplug the unit from the wall
before installing
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility.
!

4
VM-2C - Overview
3 Overview
The Kramer TOOLS VM−2C is a high−performance distribution amplifier for
component video (Y, Pb/Cb, Pr/Cr) signals. It takes one input, provides correct
buffering and isolation and distributes the signal to two identical outputs on RCA
connectors.
In particular, the VM-2C features:
HDTV compatibility
A bandwidth of 500MHz
A 12V DC power supply
3.1 Defining the VM-2C 1:2 Component Video DA
This section defines the VM-2C.
Figure 1: VM-2C 1:2 Component Video DA
#
Feature
Function
1
INPUTS Y, PB/CB, PR/CRRCA Connectors
Connect to a component source
2
ON LED
Illuminates when receiving power
3
OUTPUT 1 Y, PB/CB, PR/CRRCA Connectors
Connect to component acceptor 1
4
OUTPUT 2 Y, PB/CB, PR/CRRCA Connectors
Connect to component acceptor 2
5
12V DC
+12V DC connector for powering unit

VM-2C - Connecting the VM-2C
5
4 Connecting the VM-2C
Always switch off the power to each device before connecting it to your
VM-2C. After connecting your VM-2C, connect its power and then
switch on the power to each device.
To connect the VM-2C as illustrated in the example in Figure 2:
1. Connect a component video source (for example, a DVD player) to the Y,
PB/CB,and PR/CRINPUT RCA connectors.
2. Connect the OUTPUT RCA connectors (Y, PB/CB,andPR/CR)to up to two
component video acceptors (for example, a display and a projector).
3. Connect the 12V DC power supply to the 12V DC socket and then connect
the power supply to the mains electricity (not shown in Figure 2).
Figure 2: Connecting the VM-2C 1:2 Component Video DA
i

6
VM-2C - Technical Specifications
5 Technical Specifications
INPUTS:
1 component video (Y, Pb/Cb, Pr/Cr, or Y, U, V) on RCA
connectors, 1Vpp/75
OUTPUTS:
2 component video (Y, Pb/Cb, Pr/Cr, or Y, U, V) on RCA
connectors, 1Vpp/75
MAX. OUTPUT LEVEL:
2.4Vpp
BANDWIDTH (-3dB):
510MHz
DIFF. GAIN:
0.03%
DIFF. PHASE:
0.03%
K-FACTOR:
<0.05%
S/N RATIO:
73dB weighted
CROSSTALK (all hostile):
–58dB @ 5MHz
COUPLING:
DC
POWER CONSUMPTION:
12 VDC, 71mA
OPERATING TEMPERATURE:
0° to +40°C (32° to 104°F)
STORAGE TEMPERATURE:
-40° to +70°C (-40° to 158°F)
HUMIDITY:
10% to 90%, RHL non-condensing
DIMENSIONS:
12cm x 7.5cm x 2.5cm (4.7" x 0.98" x 2.95"), W, D, H
WEIGHT:
0.3kg. (0.66lbs.)
ACCESSORIES:
Power supply, mounting bracket
OPTIONS:
RK-3T 19” rack adapter

For the latest information on our products and a list of Kramer distributors,
visit our Web site where updates to this user manual may be found.
P/N:
2900-000112
Rev:
2
!
SAFETY WARNING
Disconnect the unit from the power
supply before opening and servicing
