Kramer VS-44HDCP User manual

KRAMER ELECTRONICS LTD.
USER MANUAL
MODEL:
VS-44HDCP
4x4 DVI Matrix Switcher
P/N: 2900-300210 Rev 3

VS-44HDCP –Contents
i
Contents
1Introduction 1
2Getting Started 2
2.1 Achieving the Best Performance 2
2.2 Safety Instructions 2
2.3 Recycling Kramer Products 3
3Overview 4
3.1 About Fast Switching 5
3.2 Defining the VS-44HDCP 4x4 DVI Matrix Switcher 5
4Installing in a Rack 8
5Connecting the VS-44HDCP 9
6Operating the VS-44HDCP 4x4 DVI Matrix Switcher 11
6.1Routing Inputs to Outputs 11
6.2 Disconnecting the Outputs 11
6.3 Storing and Recalling a Setup 12
6.4 Changing the Port Switching Speed 13
6.5 Setting HDCP to On/Off 13
6.6 Switching Between Protocol 2000 and Protocol 3000 14
6.7 Locking and Unlocking the Front Panel 15
6.8 Acquiring the EDID 15
6.9 Resetting the Ethernet Configuration to Default Values 17
7Controlling the VS-44HDCP 18
7.1 Connecting to the VS-44HDCP via RS-232 18
7.2 Connecting via Ethernet 18
7.3 Using the IR Transmitter 19
7.4 Firmware Upgrade 19
8Technical Specifications 20
9Default Communication Parameters 21
10 Default EDID 22
11 Protocol 3000 24
11.1 Kramer Protocol 3000 Syntax 24
11.2 Kramer Protocol 3000 Commands 27
11.3 Kramer Protocol 3000 –Detailed Commands 28
12 Kramer Protocol 2000 42
Figures
Figure 1: VS-44HDCP 4x4 DVI Matrix Switcher Front Panel 6
Figure 2: VS-44HDCP 4x4 DVI Matrix Switcher Rear Panel 7
Figure 3: Connecting to the VS-44HDCP Rear Panel 10
Figure 4: SELECTOR Buttons 12

VS-44HDCP - Introduction
1
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast range of
problems that confront video, audio, presentation, and broadcasting professionals
on a daily basis. In recent years, we have redesigned and upgraded most of our
line, making the best even better!
Our 1,000-plus different models now appear in 11 groups that are clearly defined
by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;
GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:
Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:
Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:
Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:
Sierra Video Products.
Congratulations on purchasing your Kramer VS-44HDCP 4x4 DVI Matrix Switcher,
which is ideal for conference room presentations and advertising applications as
well as for rental and staging.

2
VS-44HDCP - Getting Started
2 Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging
materials for possible future shipment
Review the contents of this user manual
Go to http://www.kramerelectronics.com/support/product_downloads.asp
to check for up-to-date user manuals, application programs, and to check if
firmware upgrades are available (where appropriate).
2.1 Achieving the Best Performance
To achieve the best performance:
Use only good quality connection cables (we recommend Kramer high-
performance, high-resolution cables) to avoid interference, deterioration in
signal quality due to poor matching, and elevated noise levels (often
associated with low quality cables)
Do not secure the cables in tight bundles or roll the slack into tight coils
Avoid interference from neighboring electrical appliances that may adversely
influence signal quality
Position your Kramer VS-44HDCP away from moisture, excessive sunlight
and dust
This equipment is to be used only inside a building. It may only be
connected to other equipment that is installed inside a building.
2.2 Safety Instructions
Caution:
There are no operator serviceable parts inside the unit
Warning:
Use only the power cord that is supplied with the unit
Warning:
Do not open the unit. High voltages can cause
electrical shock! Servicing by qualified personnel only
Warning:
Disconnect the power and unplug the unit from the wall
before installing
i
!
!

VS-44HDCP - Getting Started
3
3
2.3 Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
aims to reduce the amount of WEEE sent for disposal to landfill or incineration by
requiring it to be collected and recycled. To comply with the WEEE Directive,
Kramer Electronics has made arrangements with the European Advanced
Recycling Network (EARN) and will cover any costs of treatment, recycling and
recovery of waste Kramer Electronics branded equipment on arrival at the EARN
facility. For details of Kramer’s recycling arrangements in your particular country
go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

4
VS-44HDCP - Overview
3 Overview
The VS-44HDCP is a high quality 4x4 DVI matrix switcher. It reclocks and
equalizes the signals and can route any input to any or all outputs simultaneously.
It accepts up to four DVI/HDMI (over DVI-D connector) inputs and routes the
selected DVI input signal to any or all of four DVI/HDMI outputs.
DVI-D (Digital). Note that only the digital signal (DVI D) is available on the DVI connector.
In particular, the VS-44HDCP features:
Up to 6.75Gbps data rate (2.25Gbps per graphics channel)
Suitable for resolutions up to UXGA and 1080p at 60Hz
Support for HDCP (High Definition Digital Content Protection)
HDMI Support - HDMI support for Deep Color, x.v.Color™, Dolby® TrueHD,
Dolby Digital Plus, DTS−HD®, and linear PCM 7.1 surround sound
3D pass-through
Support for up to 7.1 multi-channel audio
Kramer reKlocking™ and Equalization Technology that rebuilds the digital
signal to travel longer distances
A LOCK button to prevent unwanted tampering with the buttons on the front
panel
Eight reset memory locations for quick access to common configurations
Support for Kramer Protocol 2000 and Protocol 3000
You can control the VS-44HDCP using the front panel buttons or remotely via:
RS-232 serial commands transmitted by a touch screen system, PC or other
serial controller
The Ethernet port
The Kramer infrared remote control transmitter
The infrared remote extension cable transmitter (optional), see Section 7.3

VS-44HDCP - Overview
5
5
3.1 About Fast Switching
Older display devices required a longer time between the loss of one digital signal
and the introduction of another, as well as a physical disconnection of the
interconnecting cable in order to be able to detect and adjust to the new video
attributes and parameters. Normal switching, therefore, introduced a 5V signal
disconnection along with a delay in switching. Many newer display devices,
however, are now capable of “on-the-fly” switching.
Depending on the display device in use, the VS-44HDCP allows for fast switching
(minor reset and the connection kept alive) and extra fast switching (no reset and
the connection kept alive). Using the fast and extra fast switching modes allows for
fraction-of-a-second switching times when using high performance display devices
or when using a scaler on the video output.
3.2 Defining the VS-44HDCP 4x4 DVI Matrix Switcher
This section defines the VS-44HDCP.

Figure 1: VS-44HDCP 4x4 DVI Matrix Switcher Front Panel
#
Feature
Function
1
IR Receiver and LED
IR remote control sensor. LED lights yellow when receiving an IR signal
2
ALL Button
Press to select all inputs or all outputs (see Section 6.1)
3
OFF Button
Press to disconnect one or all outputs (see Section 6.2)
4
IN Buttons
Press to select an input (from 1 to 4)
5
OUT Buttons
Press to select an output (from 1 to 4)
6
STO Button
Press to store a switching configuration
7
RCL Button
Press to recall a switching configuration
8
LOCK Button
Press and hold to lock the front panel buttons and to acquire the EDID (see Section 6.5). Press and hold
a second time to unlock the front panel buttons
9
EDID Button
Press to acquire the EDID
10
OUTPUT 1 to 4
Indicates the output channels and their respective input selections on the 7-segment display
11
INPUT 7-segment Display
Number shown on the display indicates the input channel routed to the corresponding output channel
6
VS-44HDCP –Overview

VS-44HDCP –Overview
7
Figure 2: VS-44HDCP 4x4 DVI Matrix Switcher Rear Panel
#
Feature
Function
12
IN DVI Connectors
Connect to the DVI/HDMI (over DVI-D connector) sources (from 1 to 4)
13
OUT DVI Connectors
Connect to the DVI/HDMI acceptors (from 1 to 4)
14
RS-232 9-pin D-sub (F) Connector
Connect to a PC or the serial remote controller (see Section 9)
15
ETHERNET RJ-45 Connector
Connect to a PC or other Ethernet controller via a LAN (see Section 9)
16
RESET Button
Press and hold while powering on the device to reset to factory default IP settings (see
Section 6.9 and see Section 9)
17
REMOTE IR 3.5mm Mini Jack
Connect to an external IR receiver unit for controlling the machine via an IR remote controller
(instead of using the front panel IR receiver), see Section 7.3
18
Power Connector with Fuse
AC connector, enabling power supply to the unit
19
POWERSwitch
Switch for turning the unit ON or OFF

8
VS-44HDCP - Installing in a Rack
4 Installing in a Rack
This section provides instructions for rack mounting the unit.

VS-44HDCP - Connecting the VS-44HDCP
9
9
5 Connecting the VS-44HDCP
Always switch off the power to each device before connecting it to your
VS-44HDCP. After connecting your VS-44HDCP, connect its power
and then switch on the power to each device.
To connect the VS-44HDCP as illustrated in the example in Figure 3:
1. Connect up to four DVI sources (for example, DVD players and/or Blu-ray
disc players) to the IN DVI connectors.
2. Connect the OUT DVI connectors to up to four DVI acceptors (for example,
DVI and/or LCD displays).
3. If required, connect a PC and/or controller to the RS-232 port (see
Section 7.1) and/or the Ethernet port (see Section 7.2).
4. Connect the power cord (not shown in Figure 3).
5. Power the device.
6. If required, acquire the EDID (see Section 6.8).
i

10
VS-44HDCP - Connecting the VS-44HDCP
Figure 3: Connecting to the VS-44HDCP Rear Panel

VS-44HDCP - Operating the VS-44HDCP 4x4 DVI Matrix Switcher
11
11
6 Operating the VS-44HDCP 4x4 DVI Matrix
Switcher
This section describes how to:
Route inputs to outputs (see Section 6.1)
Disconnect outputs (see Section 6.2)
Store and recall a setup (see Section 6.3)
Changing the port switching speed (see Section 6.4)
Set HDCP on or off (see Section 6.5)
Switching between Protocol 2000 and Protocol 3000 (see Section 6.6)
Lock and unlock the front panel (see Section 6.7)
Acquire the EDID (see Section 6.8)
Reset the Ethernet configuration to default values (see Section 6.9)
6.1 Routing Inputs to Outputs
To route an input to an output:
Press an OUT key, followed by an IN key to route this input to that output
To route one input to all outputs:
Press ALL followed by an IN button. The input is routed to all outputs
6.2 Disconnecting the Outputs
To disconnect one output:
Press the OUT button of the output to disconnect and press OFF
To disconnect all outputs at once:
Press the ALL button and then press OFF. This disconnects all the outputs

12
VS-44HDCP - Operating the VS-44HDCP 4x4 DVI Matrix Switcher
6.3 Storing and Recalling a Setup
You can use the STO and RCL buttons to store up to eight setups and then recall
them as illustrated in Figure 4.
IN 1 is used for setup number 5 and OUT 1 is used for setup number 1.
Figure 4: SELECTOR Buttons
The numbers (1 to 8) in Figure 4 that illustrate the corresponding
store/recall configuration numbers are for the purpose of illustration
only and do not actually appear on the buttons.
To store a setup:
1. Set the device to the desired setup.
For example, press the OUT 3 button and IN 4 button.
You can set any of the IN-OUT buttons
2. Press the STO button.
The STO button flashes.
3. Select an OUT or IN SELECT button to store the machine setup (for
example, IN 2 for preset 6).
4. Press the LOCK button to store the current setup.
In this example, the IN 2 button stores the setup.
Press the LOCK button within 10 seconds as the store operation times out
automatically after this period.
To recall a setup:
1. Press the RCL button.
The RCL button flashes.
2. Press the relevant OUT or IN button that stored the setup.
In this example, press IN 2.
3. Press the LOCK button to recall the stored setup.
i

VS-44HDCP - Operating the VS-44HDCP 4x4 DVI Matrix Switcher
13
13
6.4 Changing the Port Switching Speed
The switching speed can be set per port to any of the following:
3—Normal (default)
2—Fast
1—Extra fast
To change the port switching speed:
1. Ensure that the device is in normal switching mode, (that is, not Store,
Recall or EDID mode).
2. Press the RCL and EDID buttons at the same time.
The RCL and EDID buttons flash, and the display indicates the switching
speed mode of each port.
IN 1, IN 2 and IN 3 are illuminated (red).
3. Press one or more (or ALL) of the OUT buttons to select the port to change.
The selected port setting on the LED display flashes.
4. Press one of the IN 1/IN 2/IN 3 button to toggle the switching speed, (to Extra
fast/Fast/Normal, respectively).
The switching speed displayed changes for the selected ports.
5. Press the LOCK button to confirm the change.
The switching speed for the selected port is changed and the device reverts
to the normal switching mode.
Note: If the LOCK button is not pressed within about 12 seconds, the device exits
the port speed switching mode automatically and all changes are lost.
6.5 Setting HDCP to On/Off
HDCP support can be enabled (On) or disabled (Off) for each of the HDMI inputs,
allowing the source to transmit a non-HDCP signal if required (for example, when
working with a Mac computer)
To set the HDCP:

14
VS-44HDCP - Operating the VS-44HDCP 4x4 DVI Matrix Switcher
1. Turn the power off on the machine.
2. Press and hold the IN 1, IN 2 and LOCK buttons simultaneously and turn the
power on while pressing these buttons (you will need more than one person
to perform this step).
The machine is set to the HDCP enable/disable mode.
The input front panel buttons’ status indicates the HDCP state of each input:
HDCP enabled (ON) on an input –that input button is illuminated
HDCP disabled (OFF) on an input –that button is not illuminated
3. Press an input button to change its status.
You can press one or more inputs.
4. Once you have changed the status of HDCP on the inputs as desired, press
the EDID to save the changes and exit the HDCP enable/disable mode to
return to normal operation.
Note: If the EDID button is not pressed within about 12 seconds, the device exits
the port speed switching mode automatically and all changes are lost.
6.6 Switching Between Protocol 2000 and Protocol 3000
To switch from Protocol 2000 to Protocol 3000 and vice-versa using the front
panel buttons:
Press Output buttons 1 and 3 at the same time.
Protocol 3000 is active.
Press Output buttons 1 and 2 at the same time.
Protocol 2000 is active.
Note that when sending consecutive protocol commands make sure to
maintain at least a 200ms delay between commands.
After performing EDID get/store commands, a 1 sec delay is required
before sending another protocol command.
i

VS-44HDCP - Operating the VS-44HDCP 4x4 DVI Matrix Switcher
15
15
6.7 Locking and Unlocking the Front Panel
To prevent unintended tampering with the unit via the front panel buttons, lock
your VS-44HDCP.
To lock/unlock the VS-44HDCP:
Press and hold the PANEL LOCK button on the front panel to toggle the
locking/release of the front panel buttons
6.8 Acquiring the EDID
You can acquire the EDID from:
A single connected output to one or more of the four inputs (see
Section 6.8.1)
Several sets of inputs and outputs (see Section 6.8.2)
The default EDID (see Section 6.8.3)
6.8.1 Acquiring an EDID from a Single Connected Output
To acquire or change the EDID of a new output display:
1. Connect the required acceptor to the output from which you want to acquire
the EDID.
2. Press the EDID and STO buttons simultaneously and hold them for 3
seconds.
Both buttons flash.
3. Press the IN SELECT button to which the EDID is to be copied.
The selected input number flashes on the display.
4. Select the OUT SELECT button from which the EDID is to be acquired.
5. Press the EDID button.
The EDID is stored when the display returns to normal and the EDID and
STO buttons stop flashing.

16
VS-44HDCP - Operating the VS-44HDCP 4x4 DVI Matrix Switcher
6.8.2 Acquiring an EDID from Several Sets of Inputs and Outputs
To acquire the EDID from several sets of inputs and outputs (for example,
OUT 1 to IN 1 and OUT 4 to IN 3):
1. Connect the required acceptors to the outputs from which you want to
acquire the EDID.
2. Press the EDID and STO buttons simultaneously and hold them for 3
seconds.
Both buttons flash.
3. Press the SELECT IN button to which the first EDID is to be copied (for
example, IN 1).
The selected input number flashes on the display.
4. Press the SELECT OUT button from which the first EDID is to be acquired
(for example, OUT 1).
5. Press the SELECT IN 1 button again.
The IN 1 button stops flashing.
6. Press another SELECT IN to which the next EDID is to be copied (for
example, IN 3).
The selected input number flashes on the display.
7. Press the SELECT OUT button from which the next EDID is to be acquired
(for example, OUT 4).
8. Press the SELECT IN 3 button again.
The IN 3 button stops flashing.
9. Press the SELECT IN buttons to which you want to copy the EDID (for
example, IN 1 and IN 3).
10. Make sure that the relevant input numbers flash on the display.
11. Press the EDID button.
The process is complete when the display returns to normal.

VS-44HDCP - Operating the VS-44HDCP 4x4 DVI Matrix Switcher
17
17
6.8.3 Acquiring the Default EDID
To store the default EDID on a selected input (for example, IN 2):
1. Press the EDID and STO buttons simultaneously and hold them for 3
seconds.
Both buttons flash.
2. Press the SELECT IN button to which the EDID will be copied (for example,
IN 2).
The selected input number flashes on the display.
3. Press the OFF button until a "0" (zero) appears on the display.
4. Press the EDID button.
The default EDID is stored on the selected input when the display returns to
normal.
6.9 Resetting the Ethernet Configuration to Default Values
This procedure resets only the IP related parameters. All switching and
preset values remain unchanged.
To reset the IP parameters to their default values (see Section 9):
Press and hold the ETH Reset button on the rear panel while powering up
the device
i
